Exmark Lazer Z Parts Manual page 10

Ref.
No.
Part No.
1 632518 Frame wldmt, front 52" ........... 1
632513 Frame wldmt, front 60"........... 1
642046 Frame wldmt, front 72"........... 1
2
811006 Zerk, 1/4-28 straight ................ 5
3
633556 Floorpan ................................. 1
4
633553 Pad, anti skid........................... 3
5
634312 Lever w/grip............................ 1
632324 Lever wldmt, lift ...................... 1
6
633295 Grip, lift lever ........................... 1
7
632219 Arm wldmt, deck lift ................. 1
8
633325 Spring, compression ............... 1
9
805259 Washer, 3/8 SAE flat............... 1
10
804257 Nut, nylock 3/8-16 ................... 5
11
808505 E-ring....................................... 5
12
633068 Arm, deck lift ........................... 2
13
806761 Cotter pin, 1/8 x 3/4 ................. 2
14
808284 Clevis pin, 3/8 x 1 .................... 2
15
633889 Plate, deck lift .......................... 1
16
632899 Plate wldmt, deck lift................ 1
17
633082 Bushing, lift lever ..................... 1
18
633080 Bushing, lift lever ..................... 1
19 800299 Screw, 3/8-16 x 2 3/4 .............. 1
20
633097 Hitch pin w/lanyard .................. 1
21
806005 Hairpin cotter (serv only) ......... 1
22
800295 Screw, 3/8-16 x 1 3/4............... 2
23
303327 Washer, 3/8 disc spring........... 12
24 809007 Nut, whizlock 3/8-16 ............... 19
25
800292 Screw, 3/8-16 x 1..................... 3
26
800293 Screw, 3/8-16X1 1/4 ................ 12
27
805271 Washer, 7/8 SAE flat.. ............. 4
28
633096 Rod, deck lift............................ 2
29
804522 Nut, 5/8-11 regular .................. 8
30
633441 Swivel, deck mount.................. 4
31
805268 Washer, 5/8 std flat ................. 4
Exmark red touch up spray paint - P/N 850337
FRONT FRAME GROUP
Qty.
Description Req'd.
Ref.
No. Part No.
32
633064 Spring, deck support (52" & 60") 2
643015 Spring, deck support (72") ...... 2
33
804755 Jam nut, 5/8-11 ....................... 4
34
543513 Cap, grease ............................ 2
35
543509 Bearing cone, tapered roller ... 4
543508 Bearing cup, tapered roller ..... 4
36
543511 Seal, grease............................ 2
37
632511 Caster wldmt (52" Koh)........... 2
642111 Caster wldmt
38
804266 Nut, 3/4-10 nylock................... 2
39
633508 Washer, spring disk...... .......... 6
40
800339 Screw, 1/2-13x7 ½ (52" Koh) .... 2
800335 Screw 1/2-13x9
,
41
811010 Plug ........................................ 2
42
634662 Caster wheel assy (52" Koh)... 2
644251 Caster wheel assy
(52" Kaw, 60" & 72")............. 2
43
804269 Nut, 1/2-13 nylock.(light thin)..
44
633579 Spacer, front caster (52" Koh)
633959 Spacer, front caster
(52" Kaw, 60" & 72")............. 2
45
633580 Seal, bearing.. ......................... 4
46
633585 Bearing cone........................... 4
47
633581 Spacer, bearing....................... 4
48
633582 Wheel & tire assy (52" Koh)... . 2
633002 Tire,13x5.0-6 4 ply (52" Koh)... 2
633583 Wheel (52" Koh)...................... 2
633971 Wheel & tire assy
(52" Kaw, 60" & 72") ............ 2
523009 Tire, 13x6.5-6 4 ply
(52" Kaw, 60" & 72"). ........... 2
633987 Wheel (52" Kaw, 60" & 72")..... 2
633584 Bearing cup............................. 4
49
633587 Handle..................................... 1
9
Qty.
Description Req'd.
2
(52" Kaw, 60" & 72")
2
(52" Kaw 60" & 72")
,
2
2
