Safety Instructions
& Operator's
Manual for
MID MOUNT Z-RIDER
ZERO TURNING
HYDRO DRIVE
SERIES 2
MODELS
NZMJ23522KH
NZMJ25612KH
MODEL
NUMBER
EXPLANATION
INI
;
MODEL DESIGNATION ._
DRIVE SYSTEM TYPE
MOWER ORIENTATION
ENGINE HP *
: I_JI _31_zl :! I KHI
I
ENGINE TYPE
SERIES DESIGNATION
MOWER DECK SIZE
POWER
UNIT
N - Model Designation
23 - Engine Horse Power
2 - Series Designation
KH - Kohler Engine
Z -Zero
Turning - Hydro Drive
25-
Engine Horse Power
M - Mid Mount Mower
52 - 52" Mower Width
J - Joystick Control
61 - 61" Mower Width
Thank you for buying a SNAPPER Product!
Before operating your machine, read this manual carefully and pay
particular attention to the "IMPORTANT
SAFETY INSTRUCTIONS"
on Pages 2 - 4.
Remember that all power
equipment
can be dangerous
if used improperly.
Also keep in mind that SAFETY requires careful use in
accordance with the operating instructions and common sense!
NOTE: Specifications
are correct
at time of printing and are subject
to change without
notice.
* Actual sustained
equipment
horsepower will likely be lower due to operating limitations and environmental
factors.
,dnm_
in
IIIIll=lllnh
SNAPPER
A DIVISION
OF SIMPLIC]TY
_']FG
INC
ALL RIGHTS
RESERVED
MANUAL No. 7-4417 (Rev. I - 9/3/04)
