video cassette
recorder
user's guide
VR568

Advertisement

Table of Contents
loading

Related Manuals for RCA VR568

Summary of Contents for RCA VR568

  • Page 1 video cassette recorder user's guide VR568...
  • Page 2 WARNING To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. To reduce the risk of fire or Refer servicing to qualified service personnel. shock hazard, do not expose this product to rain or moisture. his symbol indicates his symbol indicates "dangerous...

  • Page 3: Table Of Contents

    First Things First .............. Setting up the VCR ............Using the QuickSet Guide ..............Using the Menu to Set Up features ..........8 Language ..................Cable Box Setup ................VCR Channels List ............... To Auto Channel Search ............10 To Change the Signal Type ........... 11 To Add or Remove Channels ..........
  • Page 4 Programming the Remote ..........About Programming the Remote ........... 34 Programming the Remote to Control a TV ......34 Operate the TV ................TV Codes ..................... Other Features .............. COMMERCIALI_I_ADVANCE ............38 MOVIE,I_ADVANCE ............... Picture Search Options ..............Forward and Reverse Search ............ 43 Slow Motion ..................

  • Page 5: First Things First

    HI, MY NAME IS LIZ... FIRST THINGS FIRST and I wrote this User's Guide. It's myjob to see that you have a rewarding user manual experience. You'll find that I've arranged this manual to clearly explain all of your VCR's features.
  • Page 6 STEP 1: UNPACK WHAT'S IN THE BOX The following items come packed in the box: • • Remote control • RF coaxial cable STEP 2: INSTALL BATTERIES IN THE REMOTE CONTROL Follow these steps whenever you need to install or change the batteries in your VCR remote.
  • Page 7 STEP 4: PLUG IN THE VCR Match the wide blade of the plug with the wide slot in the outlet. Be sure to insert the plug completely. STEP 5: TUNE THE TV Tune the TV to the VCR viewing channel. The VCR viewing channel is channel 3 or 4 or the TV's video input.
  • Page 8 Press MENU to display the VCR MAIN MENU. MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time Channels 5 Setup Preferences 7 Language Exit Press 6 to display the PREFERENCESmenu. PREFERENCES Remote Control: VCR1 2 Auto Play: 3 Auto TV/VCR: EnergySaver: 2:00...

  • Page 9: Setting Up The Vcr

    ON-SCREEN GUIDE ADDITIONAL SET-UP FEATURES Below is a list of set-up features that you may want to set up before you begin using yourVCR for the SETTI NG UP THE VCR first time. • Using QuickSet Guide • Select a Language •...

  • Page 10: Using The Quickset Guide

    USING THE QUICKSET GUIDE The QuickSet Guide is an automated procedure that helps you set up your VCR. The first time you turn on your VCR, the first screen of the Guide appears. Select language. Seleccione idioma. Choisissez langue. English Espanol Fran_ais Just follow the step-by-step...

  • Page 11: Cable Box Setup

    Press MENU to display the VCR MAIN MENU. MAIN MENU Plus+ Timer Recordings Time Channels Setup Preferences Language Exit Press 7 to select the LANGUAGE menu. LANGUAGE Select language. 1>English Espanol FranFais Press MENU continue Select English, Espahol (Spanish), or Fran(;ais (French). CABLE BOX SETUP This setup applies only when all channels are received through cable box.

  • Page 12: Vcr Channels List

    Press 5 to display CABLE BOX SETUP.Then select one of the three choices. CABLE SETUP cable your receive channels only SOME channels? channels Only SOME channels Cancel setup If you selected ALL channels, enter the output channel of your cable box, usually 03, 04, or video line input and press MENU.

  • Page 13: To Change The Signal Type

    Press 4 to display the CHANNELS menu. CHANNELS 1 Auto Channel Search 2 Add/Remove Channels Signal Type: CABLE 4 VCR Plus+ Channel List Cable Setup Exit Press 1 to display the AUTO CHANNEL SEARCH menu. AUTO CHANNEL SEARCH What type signal using? Cable...

  • Page 14: To Add Or Remove Channels

    To Add or Remove Channels You may want to add or remove channels after you Auto Channel Search, especially if some of the channels have weak signals or you don't want to watch them. Press MENU to display the VCR MAIN MENU. Press 4 to display the CHANNELS menu.

  • Page 15: Set The Time And Date

    Press 2 to turn Auto DST: ON or OFF. Select ON if you want the VCR's clock to automatically adjust for daylight-saving time. Select OFF if you do not want the VCR's clock to adjust for daylight-saving time. Set the Time and Date PressMENU to display the VCR MAIN MENU.

  • Page 16: Vcr Plus+ Channels

    VCR PLUS+ CHANNELS Using VCR Plus+ can make programming timer recordings Two-DigitVCR Plus+ Channel Numbers for CableTV cable or off-air antenna easier, but you have to put in a little time (USA List) right now to set up a channel list.
  • Page 17 VCR PLUS+ WORKSHEET Broadcast VCR Plus+ Channel Channel Number Cable-TV Station Number* You Receive Two-DigitVCR Plus+ Channel Name Station Numbers for CableTV (Canadian List) ESPN Allarcom PayTelevision/ Superchannel Arts & Entertainment Cable News Network-Headline News Cable News Network Canadian Home Shopping Network Canal FamUle...

  • Page 18: Additional Set-Up Features In The Preferences Menu

    REMOTE VCRI/VCR2 OPTION If you own a compatible RCA, GE, or ProScan remote that has a VCR2, VCR2,LD, or VCR2,DVD button, this feature allows you to set this VCR to respond to that button. Press 1 to select the Remote Control item. Then press the VCR2, VCR2,LD, or VCR2,DVD button to change.

  • Page 19: Auto Play

    The VCR will only respond to the compatible remote's VCR2, VCR2oLD, or VCR2oDVD button. If you change the remote setting to VCR2, the remote that came with your VCR will no longer control Use the compatible remote to change the remote setting back to VCRI.

  • Page 20: Energysaver

    ENERGYSAVER By default, this VCR automatically turns off after two hours of inactivity. Press 4 to change the time delay, or to disable the feature. • OFF: The VCR will remain turned on until you shut it off. • 1:00, 2:00, or 3:00: The VCR turns off after one, two, or three hours of inactivity.

  • Page 21: Vcr Basics

    LEARN THE BASICS TO GET YOU STARTED These basics should be enough for you to begin enjoying yourVCR. Learning remote control functions, playing a recorded tape, and recording a program should do just that. However, there are other features that enhance the enjoyment of your VCR,...

  • Page 22: Remote Buttons

    REMOTE BUTTONS The remote control is capable of controlling your VCR and many brands of televisions. If you have an RCA, ProScan, or GE TV, you may be able to control it without having to program the remote. REVERSE PLAY...

  • Page 23: Tv Function Buttons

    TV Buttons INFO Shows the TV's status displays on the TV screen. The TV buttons may not control all MUTE Reduces volume to minimum level. features of all models of RCA, ProScan and GE TVs. continued on next page...

  • Page 24: Playing A Tape

    Numbers (0 through 9) Select a channel up to 99 by pressing two numbers. Select a cable channel over 99 by pressing and holding 1 until 1 - - appears on the screen. Then press the other two numbers. OFF Turns a compatible TV off and on.

  • Page 25: Automatic Rewind

    AUTOMATIC REWI ND The VCR automatically rewinds the tape if it reaches the end of the tape during playback. While rewinding, you can press POWER and the VCR will turn off after rewinding. TAPE EJECT Press STOP.EJECT on the VCR (STOP on remote) when it is stopped to eject the tape.

  • Page 27: Recording

    SEVERAL RECORDI NG OPTIONS that you've gone through the necessary steps to operate yourVCR, I'll explain different recording features that are available to suit your needs. Recording Features: • Recording (explained in VCR Basics section) • Express Recording • Timer Recording •...

  • Page 28: Recording Features

    RECORDI NG FEATURES There are four ways to record programs: • Recording lets you press one button to start recording program. (See VCR Basics section.) • Express Recording lets you start recording a program are watching, and then set the VCR to automatically stop recording after...

  • Page 29: Timer Recording

    TIMER RECORDING You can set up as many as eight timer recording programs. Press MENU to display the VCR MAIN MENU. MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences Language Exit Press 2 to display the TIMER RECORDINGS menu. TIMER RECORDINGS Create...

  • Page 30: Timer Recording Withvcr Plus

    Review the information to make sure it is correct, and then press MENU to save. Program (One time) Program been saved Channel Cable Remember insert Start Time 12:00 recordable tape Time 01:30 turn before Start Date 11/18/98 program start time. Tape Speed Remember...
  • Page 31 Enter the VCR PlusCode shown in your local television programming guide. PLUS+ Enter PlusCode Number (from listing) 128768 Press CLEAR correct Press MENU when done Press MENU to enter the VCR PlusCode number. often should this program record? time Daily (every day) Weekdays...

  • Page 32: Stoppinga Timer Recording

    STOPPING A TIMER RECORDING To stop or cancel a timer recording in progress (even an express recording): • Press and hold the STOP button for a few seconds. REVIEWING CLEARING PROGRAMS To review programs that you have already set up: Press 2 when the VCR MAIN MENU is displayed to display the TIMER RECORDINGS menu.
  • Page 33 USING VCRS FOR COPYING EDITING TAPES Use one VCR as the playback VCR and the other as the recording VCR. 1. Connect the VCRs using the diagram below. 2. Turn on both VCRs and TV. 3. Tune the TV to the VCR viewing channel (either 3, 4, or TV's video input).

  • Page 35: Programming The Remote

    CONTROL YOUR remote can be programmed to control television. It is programmed to control an RCA, GE, or ProScan TV. Other manufacturer's brands need to be programmed. PROGRAMMING REMOTE...

  • Page 36: About Programming The Remote

    ABOUT PROGRAMMING THE REMOTE The remote can be programmed to control other brands of © remote-controllable TVs. It is already programmed to operate most RCA, ProScan, and GE televisions. REVERSE PLAY RECORD STOP PAUSE PROGRAMMING THE REMOTE TO CONTROL A TV...

  • Page 37: Tv Codes

    ProScan ........01 Proton ........06 Daytron ........06 Quasar ........11 Electrohome ....06,12 Emerson ........06 Radio Shack ....01,05,13 RCA ....... 01,06,12 Envision ......05,06 Realistic ........05 Fisher ........05,08 GE ......00,01,06,11 Sampo ........06 Goldstar ......06,12 Samsung ...... 06,09,12 Hallmark ........06 Sanyo ........

  • Page 39: Other Features

    FEATURES TO ENHANCE VCR OPERATION • COMMERCIALly,ADVANCE • MOVIEI_I_ADVANCE • Picture Search Options • Tracking • Auto Repeat • Pro-Tect Plus Locking • Time Counter • On-Screen Displays • LowVoltage Detection ¥ OTHER FEATURES...

  • Page 40: Commerciali_I_Advance

    COMMERCIALI_ I_ADVANCE COMMERCIA LI_I_ADVANCE is a patented technology that detects and marks most commercials on your tape for any recording that is more than 15 minutes long. After recording, the VCR rewinds the tape to the beginning of the recording and determines where the commercials are located.
  • Page 41 PREFERENCES Remote Control: VCR1 Auto Play: Auto TV/VCR: EnergySaver: 2:00 Front Panel: AUTO Tape Speed: Auto Repeat Commercial Advance Exit ADVANCE men u. Press 8 to display the COMMERCIAL COMMERCIAL ADVANCE Marking: Playback: AUTO Display: BLUE Exit Now, you can select one ofthe COMMERCIA L,,ADVANCE features.
  • Page 42 COMMERCIALI_ I_ADVANCE Playback Press 2 to switch between Playback: AUTO and MANUAL. • Select AUTO to have the VCR automatically advance through the blocks of marked commercials. It works with most 30, 45, and 60-second commercials. A commercial group starting within the first two minutes or last two minutes of a recording will not be...

  • Page 43: Moviei_Advance

    MOVIEI_ADVANCE MOVI E••ADVANCE helps you locate certain parts of prerecorded movies (rented or purchased). This feature works two ways: 1) you can go to the beginning of the movie or 2) you can skip from one preview to the next. MOVI E••ADVANCE works only on cassettes recorded in the SP speed with the safety tab removed.
  • Page 44 Press 1 to Go to movie. The following screen appears with a blue background. MOVIE ADVANCE Searching start movie... Press STOP cancel When the movie is found, the following screen is displayed. MOVIE ADVANCE movie ready. Press PLAY start, Press STOP cancel This display will time out after a few minutes and the...

  • Page 45: Picture Search Options

    PICTURE SEARCH OPTIONS The most basic way to search during playback is using the FORWARD or REVERSEbuttons. This section contains several other options available for searching a tape. FORWARD REVERSE SEARCH You can search a tape during playback. Sound is turned off during picture search.

  • Page 46: Frame Advance

    FRAME ADVANCE Frame advance lets you view one-stop action frame after another during playback. Frame advance works well for tapes recorded at the SPor SLPspeed. Press PAUSE or F .ADV to "freeze" the action. Pr ess F.ADV each time you want to view a frame of the scene. Press PAUSE or PLAY to return to normal playback.

  • Page 47: Go-To Search

    GO-TO SEARCH The Go-T o search feature enables theVCR to quickly locate a counter reading anywhere on the tape. When the VCR locates the counter GO-TO SEARCH reading, it will begin playback. Current tape counter 2:17:25 Pre_ STOP Press PressSEARCHon the remote until the GO-TO SEARCHmenu -:--:00 appears on the screen.

  • Page 48: Auto Repeat

    AUTO REPEAT The VCR will automatically repeat a segment of tape. Locate the beginning of the segment you want the VCR to repeat, and press ST OP. PresslNFOtwicetodispla y the time counter, and press CLEAR to reset it to 0:00:00. Press MENU to display the VCR MAIN MENU.

  • Page 49: Pro-Tect Plus Tm Locking Feature

    PRO-TECT PLUS" LOCKI NG FEATURE To disable the usage of theVCR, or to protect your timer recordings, you can lock the VCR so that the buttons on the VCR or remote won't work. To Lock: Press and hold theVCR button on the r emote for approximately six seconds.

  • Page 50: On-Screen Displays

    ON-SCREEN DISPLAYS Stop 0:30:00 The INFO button shows the status of theVCR (Stop ,Play, Rec, etc.), channel number (Videol or Video2 for the line input), time counter, date, time, and tape speed on the TV screen. The date and time must be set before they can be displayed.

  • Page 51: Connections

    TH I NGS TO KNOW BEFORE CONNECTI NG COMPONENTS ¥ Protect Your Components from Power Surges • Connect all components before plugging anj power cords into the wall outlet. • Always turn off theTV and other components before you connect or disconnect any cables. Position Cables Correctly to Avoid Audio Hum or Interference Insert all cable plugs firmly into their jacks.

  • Page 52: Connecting Yourvcr

    VCR is used to connect the VCR's RF OUT jack and your TV's antenna input. Audio/Video Jacks and Cables (RCA-type) The AUDIO/VIDEO jacks provide very good picture quality and sound, and can be used if your TV has audio/video input jacks.

  • Page 53: Choosinga Vcr Connection

    CHOOSING A VCR CONNECTION There are several different ways to connect your VCR, depending whether or not you have cable service, and if you have a cable box, and whether some of the channels are scrambled, and maybe you have cable (but no cable box), or no cable or...well, you get the picture.

  • Page 54: Tv With Rf Jack Only

    TV WITH RF JACK ONLY This connection assumes: • You are connecting antenna, cable, or cable box system. • Your television has only an RF input jack. This connection provides: • Mono sound playback from VCR. • Record one channel while watching another (except when using a cable box for all channels).

  • Page 55: Tv With Audio/Video Jacks

    TV WITH AUDIO/VIDEO JACKS This connection assumes: • You are connecting an antenna, cable, or cable box system. • Your television has audio/video jacks. This connection provides: • Mono sound playback from VCR. • Record one channel while watching another (except when using a cable box for all channels).

  • Page 56: Tv With Audio/Video Jacks And Cable Box To Unscramble Pay Channels Only

    TV WITH AUDIO/VIDEO JACKS AND CABLE BOX TO UNSCRAMBLE PAY CHANNELS ONLY This connection assumes: • You are using a cable box only to unscramble premium channels. • Your TV has audio/video input jacks. This connection provides: • Mono sound playback from VCR. •...

  • Page 57: Appendix: Reference

    This section gives you some additional information about the VCR, including a description of the unit's controls and display. also will find a Troubleshooting Tips section COMMERCIALI_!_ Questions and Answers about ADVANCE in this Appendix, which might help to resolve some of those simple...

  • Page 58: Front Panel

    FRONT PANEL Remote Sensor AUDIO IN and VIDEO IN Jacks Receives signals from another component, like a VCR or camcorder, when it is connected these jacks. Use INPUT on the remote to select "L2" to record from these jacks. CHANNEL.TRACKING Up or Down Selects next higher...

  • Page 59: Display Panel

    D I SPLAY PAN EL TIMERII--I" ---'II--IA vc lU. 3UM Time, Channel Number, Line Input Indicator (L1 or L2),Tape Speed Indicator, or Status Indicator Channel Number or Line Input Indicator The channel number appears when the VCR is tuned to a channel. The line indicator or L2) appears when a line input is selected.

  • Page 60: Back Panel

    BACK PANEL ANT. IN VIDEO AUDIO RF OUT 3 CH. 4 Switch Selects the channel to which you will tune the TV to see the VCR picture if you connect the VCR using one of the basic hookups. AUDIO IN and VIDEO IN Jacks Receives signals from another component, like a VCR or camcorder, when it is...

  • Page 61: Troubleshooting Tips

    Press TV to set remote to control a compatible • Check to make sure the remote is programmed to control an RCA, ProScan, or GE TV. Remote no longer controls a compatible • Press TV to set remote to control the corresponding component.
  • Page 62 Streaks in picture during normal playback • Press one of the TRACKING buttons to move streaks up or down for the best picture. • Check to make sure the tape is of good quality and not worn out. Time counter not working or time counter not working...
  • Page 63 Clock shows incorrect time or date • Power interruption. • Check to make sure the clock is set accurately (check AM/PM and date). • Check Daylight-Saving setting. The clock may have adjusted for daylight-saving time. Time did not adjust for daylight-saving time •...
  • Page 64 Index, Go-To, and Blank Search features do not operate • Check to see if MOVIEI_I, ADVANCE feature is activated. Cannot access MOVIE ,,ADVANCE feature • Cassette must have safety tab removed and be recorded in SP speed. • Home Recording was selected for the tape type in the menu.

  • Page 65: Questions And Answers About

    QUESTIONS ANSWERS ABOUT COMMERCIAL ADVANCE÷ Will commercials be scanned through only on playback of recordings? Yes. The VCR does not rewind and mark commercial segments until after recording is finished. How fast does the COMMERCIAL, ,ADVANCE VCR scan through the commercial breaks? In SLP tape speed, a 3-minute commercial break is scanned through in approximately...

  • Page 66: Limited Warranty

    What we will do: • Pay any Authorized RCA VCR Service Center the labor charges to repair your VCR. • Pay any Authorized RCA VCR Service Center for the new or, at our option, refurbished replacement parts required repair your VCR.

  • Page 67: Specifications

    SPECIFICATIONS Format: Video: 4-head Record/Playback System: Audio: Mono record/playback system EIA standard: NTSC color Video Signal System: 75-ohm external VHF/UHF combined Antenna: antenna terminal Tuner: USA: 181 channels capability* (125 cable channels) Canada: 178 channels capability* (122 cable channels) Type: AutoProgramming frequency synthesis...

  • Page 68: Index

    3 CH 4 switch 5, 8, 52, 58 Channels, add or remove Channels list, VCR 10 CHANNELS menu 9, 11, 12, 14, 28 Choosing a VCR connection Cleaning the VCR 65 Accessing menus 5 CLEAR button 20, 21, 29, 44, 45, 46, 47 Add or remove channels Clearing programs ADD/REMOVE CHANNELS screen 12...
  • Page 69 MENU button F.ADV button 20, 44 First setup 5, 8, 9, 10, 11, 12, 14, 16, 20, 27, 28, 29, 38, 46 Forward and reverse search 43 MOVIE ADVANCE menu Moviel, l_advance FORWARD button 22, 43, 44, 45, 47 Frame advance MUTE button Front panel controls...
  • Page 70 frame advance go-to QuickSet Guide 5, 8 index 44 MOVIEI_,ADVANCE reverse 43 slow-motion SEARCH button 21, 41, 42, 44, 45 RECORD button 21, 23, 26, 31, 56 Set time and date manually Record-protect SET TIME AND DATE menu Recording Set up copying and editing tapes 30 cable box 9...
  • Page 71 STOP 57 STOP button 21, 22, 23, 26, 30, 44, 45, 47 STOP,EJECT button 22, 23, 41, 56 Unpack Stop-action pause23 Stoppinga timer recording30 VCR button 20, 47 VCR channel list 10 VCR cleaning Tab, safety 23, 31, 41 VCR function buttons Table of contents VCR MAIN MENU...
  • Page 72 If your VCR needs service, please contact your dealer or the nearest Servicenter from the yellow pages. Please do not send any products to the Indianapolis address listed in this manual or on the carton. This will only add delays in service for your product.
