Summary of Contents for RCA VR525
- Page 1 VR525...
-
Page 2: Important Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. The numbers are located on the back of the product. Model No. VR525 Serial No. Purchase Date: Dealer/Address/Phone: This symbol indicates important instructions accompanying the product. -
Page 3: Table Of Contents
Recording ... 21 Recording Features ... 22 Express Recording (XPR) ... 22 Timer Recording ... 23 Timer Recording with VCR Plus+ ... 24 Setting Up the Channel List... 24 Using VCR Plus+... 24 Stopping a Timer Recording ... 26 Reviewing and Clearing Programs ... 26 Using Two VCRs for Copying and Editing Tapes ... - Page 4 Jacks and Cables ... 36 Choosing a VCR Connection ... 37 Advantages of Audio/Video Cable Connections ... 37 Don’t Forget about the AUTO TV/VCR Feature... 37 TV with RF jack only ... 38 TV with Audio/Video Jacks ... 39 TV with audio/Video Jacks and Cable Box to Unscramble Pay Channels Only ...
-
Page 5: First Things First
Read the First Three sections The first three sections of the manual introduce you to your VCR, and show you how to set the VCR up and use the on-screen menus. Reading these sections gives you the basic information you need to use your VCR. - Page 6 STEP 3: Connect your vcr If you connect your VCR to your home antenna or cable system and then to your TV, use the VCR’s ANT. IN and RF OUT jacks for a good signal as shown. If you have a TV with AUDIO/VIDEO jacks, use the jacks for a better connection.
- Page 7 Match the wide blade of the plug with the wide slot in the outlet. Be sure to insert the plug completely. STEP 5: TUNe THE TV Tune the TV to the VCR viewing channel. The VCR viewing channel is channel 3 or 4 or the TV’s video input. •...
- Page 8 0 Exit See Additional Set-Up Features for detailed information about the Auto Play feature. STEP 8: SET UP THE VCR Once you understand how to move around through the menus, go to the next section to set up your VCR.
-
Page 9: Setting Up The Vcr
Setting Up the VCR on-screen guide and Additional Set-up features Below is a list of set-up features that you may want to set up before you begin using your VCR for the first time. • Select a Language • Set up VCR Channel List (Auto Channel Search) •... -
Page 10: Using The Menu To Set Up Features
VCR CHANNELS LIST If you use a cable box for all channels, this step is not necessary. Your VCR may come with a channel list preset at the factory. Even though your VCR may come with a list, it’s possible that you may want to add or eliminate some channels depending on whether they are active. -
Page 11: To Auto Channel Search
Setting Up the VCR To Auto Channel Search 1. Press MENU to display the VCR MAIN MENU. VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Preferences 6 Language 0 Exit 2. Press 4 to display the CHANNELS menu. -
Page 12: To Change The Signal Type
Setting Up the VCR To Change the Signal Type 1. Press MENU to display the VCR MAIN MENU. 2. Press 4 to display the CHANNELS menu. 3. Press 3 to change the Signal Type between CABLE and ANTENNA. To Add or Remove Channels... -
Page 13: Set The Time And Date
Select ON if you want the VCR’s clock to automatically adjust for daylight-saving time. • Select OFF if you do not want the VCR’s clock to adjust for daylight-saving time. Set the Time and Date 1. Press MENU to display the VCR MAIN MENU. -
Page 14: Vcr Plus+ Channels
2 Add/Remove Channels 3 Signal Type: CABLE 4 VCR Plus+ Channel List 0 Exit 3. Press 4 to display the VCR Plus+ Channel List screen. VCR+ Channel My Channel 3 -> -> -> -- Use CH+/- to select Press 0-9 to change Press MENU to save 4. - Page 15 Number** Name ESPN *Check your local or cable listing for the channel number you receive this station on. **Check your local listing for broadcast or VCR Plus+ channel number assigned. Channel Number You Receive the Two-Digit VCR Plus+ Channel Station On*...
-
Page 16: Additional Set-Up Features In The Preferences Menu
Now you are ready to select an item from the menu to set up. REMOTE VCR1/VCR2 Option If you own a compatible RCA, GE, or ProScan remote that has a VCR2, VCR2•LD, or VCR2•DVD button, this feature allows you to set this VCR to respond to that button. -
Page 17: Auto Play
VCR is turned on or a cassette is inserted. This only applies if you connect the ANT. IN and RF OUT jacks of your VCR and TV and watch your VCR on channel 3 or 4 of your •... -
Page 18: Energysaver
OFF: The VCR will remain turned on until you shut it off. • 1:00, 2:00, or 3:00: The VCR turns off after one, two, or three hours of inactivity. Thirty seconds before shutting off, the VCR will warn you with a screen reading, “The VCR will turn off in 30 seconds. -
Page 19: Vcr Basics
VCR BAsICS learn the basics To get you started These VCR basics should be enough for you to begin enjoying your VCR. Learning the remote control functions, playing a recorded tape, and recording a program should do just that. However, there are other features that enhance the enjoyment of your VCR, but they aren’t necessary to get you started. -
Page 20: Remote Buttons
INFO Shows the status displays on the TV screen. INPUT Selects between the line input and the VCR’s tuner. Line input refers to the signal coming from the component connected to the AUDIO/VIDEO IN jacks on the back of the VCR. -
Page 21: Playing A Tape
TV•VCR Switches the picture signal so that it either comes from the VCR or cable/antenna system. Playing a Tape 1. Tune the TV to your VCR viewing channel (3, 4, or TV’s video input). 2. Insert a tape in the VCR. -
Page 22: Automatic Rewind
Check the Safety Tab No matter which recording option you use, you need to make sure there is a tape in the VCR, and that the tape’s safety tab is in place. You cannot record on a tape with the safety tab removed. -
Page 23: Recording
RECORDING SEVERAL recording OPTIONS Now that you’ve gone through the necessary steps to operate your VCR, I’ll explain the different recording features that are available to suit your needs. Recording Features: • Recording (explained in VCR Basics section) • Express Recording •... -
Page 24: Recording Features
Each time you press the RECORD button, you increase the recording time (up to 4 hours). The VCR continues to record for the amount of time you indicate, and then automatically turns off. To stop an express recording, press and hold STOP for a few seconds. -
Page 25: Timer Recording
RECORDING Timer Recording You can set up as many as eight timer recording programs. 1. Press MENU to display the VCR MAIN MENU. VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Preferences 6 Language 0 Exit 2. -
Page 26: Timer Recording With Vcr Plus
TV and don’t receive all channels through a cable box or if you receive your TV signal off-air. Setting Up the Channel List If you did not set up the VCR Plus+ channel list, you can do it now. 1. Display the CHANNELS menu from the VCR MAIN MENU. -
Page 27: Recording 21
2. Press 1 to display the VCR PLUS+ menu. VCR PLUS+ Enter PlusCode Number (from TV listing) Press MENU to cancel 3. Enter the VCR PlusCode shown in your local television programming guide. VCR PLUS+ Enter PlusCode Number (from TV listing) -
Page 28: Stopping A Timer Recording
Press and hold the STOP button for a few seconds. REVIEWING AND CLEARING PROGRAMS To review programs that you have already set up: 1. Press 2 when the VCR MAIN MENU is displayed to display the TIMER RECORDINGS menu. TIMER RECORDINGS 1 Create a New Program 2 Review Existing Progs. -
Page 29: Using Two Vcrs For Copying And Editing Tapes
1. Connect the VCRs using the diagram below. 2. Turn on both VCRs and TV. 3. Tune the TV to the VCR viewing channel (either 3, 4, or TV’s video input). 4. If you are using coaxial cables for the connection, tune recording VCR to channel 3 or 4—the one selected on the... -
Page 31: Other Features
OTHER FEATURES features to enhance VCR operation • Picture Search Options • Pro-Tect Plus™ Locking • Tracking • Time Counter • On-Screen Displays First things first Setting Up the VCR VCR Basics recording OTHER FEATURES Connections... -
Page 32: Picture Search Options
3. Press FWD to increase or REV to decrease the speed of the search. 4. Use TRACK up or down to remove any streaks from the picture. 5. Press PLAY to return to normal playback. The VCR switches automatically from slow-motion playback to stop after a few minutes. -
Page 33: Frame Advance
During playback you can locate the program you want to play by the number of index marks or by scanning. The VCR will search forward or reverse from the location you are on the tape. To Search: 1. -
Page 34: Pro-Tect Plus Locking Feature
Pro-Tect Plus Locking Feature To disable the usage of the VCR, or to protect your timer recordings, you can lock the VCR so that the buttons on the VCR or remote won’t work. • To Lock: Press and hold either the remote’s POWER or OFF button. -
Page 35: Tracking
When you manually adjust the picture, automatic tracking is turned off. To turn automatic tracking back on, press both TRACK buttons on the front of the VCR at the same time, or eject the tape and re-insert it. Tracking has no effect during recording –... -
Page 36: On-Screen Displays
OTHER FEATURES ON-SCREEN DISPLAYS The INFO button shows the status of the VCR (STOP, PLAY, RECORD, etc.), channel number, time counter, date, time, and tape speed on the TV screen. The date and time must be set before they can be displayed. -
Page 37: Connections
• Place an amplifier or satellite receiver on the top shelf of the stand so heated air rising from it will not flow around other components. First things first Setting Up the VCR VCR Basics recording PROGRAMMING THE REMOTE Connections... -
Page 38: Connecting Your Vcr
RF Jack These jacks are required for antenna or cable-TV connections. The RF jacks on the VCR are labeled ANT. IN and RF OUT. The coaxial cable supplied with your VCR is used to connect the VCR’s RF OUT jack and your TV’s antenna input. -
Page 39: Choosing A Vcr Connection
VCR or the TV. You can change the setting manually by using the TV•VCR button on the remote or you can set the Auto TV/VCR feature to ON when using only the ANT. IN and RF OUT jacks and OFF when using the AUDIO/VIDEO output jacks –... -
Page 40: Tv With Rf Jack Only
2. Return to First Things First, then follow the steps. Using This Connection Tune your TV to channel 3 or 4, whichever one you selected with the 3 CH. 4 switch on the back of the VCR. Auto TV/VCR Setting: •... -
Page 41: Tv With Audio/Video Jacks
To connect: 1. Connect cables as shown. 2. Return to First Things First, then follow the steps. Using This Connection Tune your TV to its video input channel. Use of TV•VCR button is not required. Auto TV/VCR Setting: • Set the Auto TV/VCR feature to OFF. -
Page 42: Tv With Audio/Video Jacks And Cable Box To Unscramble Pay Channels Only
To connect: 1. Connect cables as shown. 2. Return to First Things First, then follow the steps. Using This Connection Tune your TV to its video input channel. Use of TV•VCR button is not required. Auto TV/VCR Setting: • Set the Auto TV/VCR feature to OFF. -
Page 43: Appendix: Reference
This section gives you some additional information about the VCR, including a description of the unit’s controls and display. You also will find a Troubleshooting Tips section in this Appendix, which might help to resolve some of those simple problems. -
Page 44: Front Panel
VCR’s channel memory. Adjusts tracking when a tape is playing. Press both together to recenter tracking. FWD Forwards the tape when the VCR is stopped. Searches the picture forward during playback. Starts slow-motion during play- pause and increases slow-motion speed. -
Page 45: Indicator Panel
Back Panel 3 CH. 4 Switch Selects the channel to which you will tune the TV to see the VCR picture if you connect the VCR using one of the basic hookups. AUDIO and VIDEO IN Jacks Receives signals from another component, like a VCR or camcorder, when it is connected to these jacks. -
Page 46: Troubleshooting Tips
• The batteries may need changing. • Make sure the Remote VCR1/VCR2 setting is set to VCR1 so the remote that came packed with your VCR can operate it. Poor or no picture for normal TV viewing • Check to make sure the VCR indicator is off. - Page 47 Check to make sure daylight-saving feature is set correctly. VCR makes noise when stopped • VCR is removing tape from heads. This is normal. The head cylinder inside the VCR will continue to rotate for a few minutes after you put the VCR in the stop mode.
- Page 48 TIMER indicator flashes • Clock is not set. • Check to make sure there is a cassette in the VCR when a timer recording is set. • TIMER and RECORD indicators flash when the ProTect Plus Time counter disappears during searching •...
-
Page 49: Specifications
Cleaning the VCR Use a soft cloth or dusting attachment of your vacuum cleaner to dust your VCR. Remove dust from the ventilation holes on the top, back, sides, and bottom of the cabinet. Plastic surfaces are easily scratched and can be marred by alcohol and various solvents. -
Page 50: Limited Warranty
Pay any Authorized RCA VCR Service Center the labor charges to repair your VCR. • Pay any Authorized RCA VCR Service Center for the new or, at our option, refurbished replacement parts required to repair your VCR. How you get service: •... -
Page 51: Index
Channel List 24 Channel, VCR viewing 5 CHANNEL/TRACKING buttons 42 Channels, add or remove 10 Channels list, VCR 8 Choosing a VCR connection 37 Cleaning the VCR 47 CLEAR button 18 Clearing programs 26 Commercial scan 30 Connecting your VCR 4, 36... - Page 52 PAUSE button 18 Picture search options 30 PLAY button 18 PLAY•PAUSE button 42 Playing a Tape 19 Plugging in the VCR 5 POWER button 20, 42 POWER indicator 43 Power surges 35 Pro-Tect Plus™ Locking Feature 32 Problem solving 44...
- Page 53 Index Index Set up the VCR 6 Signal type, changing 10 SLOW button 18 Slow-motion search 30 SLP 20 Solving problems 44 SP 20 Specifications 47 SPEED button 18 STOP button 19 STOP•EJECT button 42 Stopping a timer recording 26...
- Page 54 If your VCR needs service, please contact your dealer or the nearest Servicenter from the yellow pages. Please do not send any products to the Indianapolis address listed in this manual or on the carton. This will only add delays in service for your product.
