Figure 2-7 — Simple external sync connection example
Figure 2-8 shows another configuration, in which the timing source passes through
three video cameras and a video scan converter before connecting to the switcher.
This type of video camera is capable of synchronizing with the external timing
source for video editing applications.
If no external sync timing source is connected to the switcher, switching occurs
immediately after a front panel, RS-232, IR, or contact closure switch command.
Sync Timing Source
(black burst generator)
Video Camera
Figure 2-8 — Multiple device external sync connection example
Power connection
AC power connector — Plug a standard IEC power cord into this connector
12
to connect the switcher to a 100 VAC to 240 VAC, 50 or 60 Hz power source.
