Installation and Operation, cont'd

ASA 101 Features and Cabling

2
Input plugs — Plug the white RCA connector into the left
1
output of the stereo source device. Plug the red RCA connector
into the right output of the stereo source device.
Output connector — Strip the wires from the mono destination
2
device, insert them into this 3-pole captive screw connector, and
secure them by turning the screws (see the illustration below).
Tip
See Caution
Sleeve
Unbalanced Output
Connect the sleeve to ground (Gnd). Connecting
CAUTION
the sleeve to a negative (-) terminal will damage the
audio output circuits.

ASA 204/ASA 304 Front Panel Features

1
Power LED — Lights to indicate that the ASA is on.
1
ASA Series • Installation and Operation
2-6
1
Tip
Ring
Sleeve
Balanced Output
ASA 204/ASA 304 Rear Panel Features and
Cabling
1
QUAD AUDIO
STEREO INPUTS
SUMMING
L
L
AMPLIFIERS
POWER
12V
.2A MAX
R
R
1 2 3
4
ASA 204
1
QUAD AUDIO
STEREO INPUTS
SUMMING
AMPLIFIERS
POWER
12V L 1 R L
.2A MAX
2
L R L
4
ASA 304
ASA 204 input connectors —
1
Plug up to four stereo audio sources
into these female RCA connectors.
If you do not have pre-terminated
audio cable, wire the male RCA
connectors for unbalanced input as
shown at right.
ASA 304 input connectors — Plug up to four stereo audio
sources into these 5-pole captive screw connectors. Connectors
are included with each ASA, but you must supply the audio
cable. Wire the connectors for the appropriate input type and
impedance level as shown below. High impedance is generally
over 800 ohms.
Tip Tip
Sleeve Ring
Sleeve (s)
Tip
Tip
Sleeve Ring
Unbalanced Input Balanced Input
(high impedance) (high impedance)
ASA Series • Installation and Operation
2
MONO OUTPUTS
ASA
2 0 4
L
1 3
SPARE
UNBAL
2 4
R ON
3
4
BAL
2
MONO OUTPUTS
ASA
3 0 4
1 3
3
R
SPARE
UNBAL
4 2 4
R
ON
3
BAL
Tip (+)
Sleeve ( )
600 ohms
Tip
Ring
Sleeve (s)
Tip
Ring
600 ohms
Balanced Input
(600 ohms)
2-7
