Pfaff Expression 2034 Instruction Manual page 10

3Hfl
111t1t
vviilth
pattern length
(lunsity/balance controls)
i
,u
ig
handle
Hdndwheel
/ "M" button
8
Cursor buttons
9
Clear/pattern start button
10 Stitch selection wheel
11
Connection socket "lead cord"
12
Connection socket "foot control"
13
Master switch
14 m+ button
15 Direct selection button "Alphabet"
16 Direct selection button "Alphabet"
17 Direct selection button "Linen buttonhole"
18 Direct selection button "Elastic blind hem
stitch"
19 Direct selection button "Zigzag stitch"
20 Direct selection button "Stretch triple straight
stitch"
21 Direct selection button "Blind hem stitch"
22
Direct selection button "Bridging stitch"
23 Direct selection button "Button attaching
program"
24 Direct selection button "Straight stitch"
25 Direct selection button "Elastic stitch"
26 Direct selection button "Closed overlock
stitch"
27 Slide for lowering the feed dog
28 Base plate
29 Removable accessory tray
30 Presser foot holder with presser foot
31 Integrated dual feed/IDT
32 Integrated needle threader
33
'Reverse sewing" button
34 Threading slots
35 Needle thread tension
36 "Tie-off" button
37 "Needle up/down" button
38
"Slow sewing" button
39
"Pattern mirror" button/ "Lock" button
40 Take-up lever
41 Thread guide
42 Spool holder with spool cap
43 Hole for second spool holder
44 Lid with stitch program chart
45 Bobbin winder
46
Bobbin door
47 Free arm
48 Sewing bulb (max. 5 W)
49 Thread cutter
50 Thread take-up
51
Presser foot lifter
52 Needle holder with retaining (set) screw
53
Needle plate
54 Contrast control
