Controls and Features
Stainless Steel Hood
Controls
.
.
3.
.
ON/OFF Button : Turns both fan and lights
on to default (or user programmed) settings.
Default settings are FAN medium, LIGHT level
2. See below for details on how to program
the control to your preferred settings. If the
hood is in active mode (fan on and/or lumps
on), when the user presses the ON/OFF
button, all functions will be turned off.
Fan -: Pressing the fan decrease (-) button
will step the blower down to the next lower
blower speed, looping in this order: BOOST
HIGH _ MEDIUM _ LOW _ OFF _ BOOST...
Fan +: Pressing the fun increase (+)button
will step the blower up to the next higher
blower speed, looping in this order: LOW
MEDIUM_ HIGH _ BOOST_ OFF _ LOW...
Light -: Pressing the light decrease (-) button
will step the lamp intensity down to the next
lower intensity, looping in this order: Level 4
Level 3 _ Level 2 _ Level $ _ OFF_ Level 4...
"Light -"
Light Intensity
Decrease
"Light+"
Light Intensity
Increase
"Fan -"
Speed
Decrease
"Fan +"
Speed
Increase
ON/OFF
Button
S.
Light +: Pressing the light increase (+)button
will step the lamp intensity up to the next higher
intensity, looping in this order: Level 1 _ Level 2
Level 3 _ Level 4 _ OFF _ Level 1...
Programming
settings
You have the option of changing the factory
default (or previously programmed) settings for the
ON/OFF button.
.
With all functions off, press and hold the ON/
OFF button for :3 seconds. The fan speed will
be on medium and the light intensity will be on
Level 2 (or previously programmed settings).
The hood lamps will blink :3 times. Release the
button.
.
The control is now in programming mode.
You can set the fan and light settings to your
preferred setting by pressing the Fan +, Fan -,
Light +, and Light - buttons.
NOTE:You do not have the option of setting
the fan or lights to OFF.
3.
When the desired fan and light settings have
been selected, press the ON/OFF button to
store these settings. You have :30 seconds to
complete this task.
NOTE:If the control is in programming mode and
:30seconds have passed with no button activity
detected, the control will revert to the last saved fan
and light setting (default or programmed).
Power interruptions will cause the controls to revert
to the factory settings.
Heat sensor
To protect the electronics, this hood is equipped
with an Auto On feature that will automatically
turn on the blower or increase the speed if
excessive heat is detected above the cooking
surface.
When the Auto On feature is activated, you may
increase the fan speed but you cannot lower the fan
speed or turn off the blower. The hood will remain in
Auto On mode until temperatures have dropped to
acceptable levels.The fan speed will change to the
original user setting when Auto On is deactivated.
The Auto On feature will always have priority over
the fan speed set by the user.
4
