Kenmore 229.960330 Owner's Manual page 21

1. STOP! Read thesafety information onpage16.
2. Setthethermostat to lowest s etting.
3. Turnoffallelectricpower t otheappliance.
4. Remove l ower frontpanel.
5. Rotategas controlknob slightlyand turn clockwise
to
GAS CONTROL KNOB
[-SHOWN IN "ON" POSITION
/
GAS
INLET
• O
RESET BUTTON
6. Wait five (5) minutes to clear out any gas. Then smell
for gas, including near the floor. If you smell gas, STOP!
Follow "B" in the safety information on page 16. If you
don't smell gas, go to next step.
7. Find pilot - follow metal tube from gas control. The pilot
is between two burner tubes as shown in Fig. 15.
8. Turn knob on gas control counterclockwise _ to
"PILOT"
9 Rotate the gas control knob counterclockwise _, to
"PILOT" Push down and hold the red reset button while
you light pilot burner with a match.
After about one minute, re[ease reset button. Pilot should
remain lit If it goes out, turn gas control knob clockwise
to OFE To relight, repeat steps 5-9.
• If button does not pop up when released, stop and
immediately call your service technician or gas supplier.
• If the pilot will not stay lit after several tries, turn the
gas control knob to "OFF" and call your service
technician or gas supplier.
10. After pilot remains lit when red reset button is released,
turn gas control knob counterclockwise _ to "ON."
1 !. Replace lower front panel.
12. Turn on all electric power to the appliance.
1 3 Set thermostat to desired setting.
TO TURN OFF GAS TO APPLIANCE
1. Set the thermostat to lowest setting.
2. Turn off all electric power to the appliance if service is
to be performed.
3. Push in gas control knob slightly and turn clockwise
_i to "OFE" Do not force.
MATCH HOLDER
P_ESSUR( R£GULATOR CONVENIENCE WIRING
ADJUSTMENT TERMINAl{2} TERMINAL3 (2)
{UNDERpRESSUREINLET CAPTApSCREW)_I_i_(OPTION_L} OAUpTLET PRESSURE
;,: LoToU*L'T
THERMOCOUP OT ADJUSTt'_E NT
CONNECTION . 'RREE N \GA S (UNDER CAP SCREW)
BUTTON CONTROL/VALVE
11,523A KNOll
PRESSUR_R{GULATOR
A_JUSTMENT
(UNDER CAP SCREW)
PRESSURETA_
INLET
WIRING
TERMINALS(3)
OUTLETPRESSUR£
TAP
GROUNO
TERMCNAL$(2)
.: , ;:LOTOUT
OTADJ_STM_NT
{UNOERCAPSCREW)
_GA$
CONTROL
KNOE
