Before You Assemble ....3 Product Specifications ....4 Product Features ......4 Parts List / Box Contents ..... 5 Exploded View ....... 6 Hardware and Tool List ....7 Assembly Guide ......8 Warranty Information ....24 Contacting Nautilus ...... 25...
BEFOrE YOu ASSEmBLE BaSic aSSeMBly PriNciPleS Here are a few basic tips that will aid in the assembly of the Nautilus® NS700X. By using these principles, you can simplify each process and save yourself extra time and effort. 1. To make the assembly process go faster, gather the pieces you need for each step and thoroughly read the assembly instructions for that step prior to starting assembly for the step.
PrOduCT SPECIFICATIONS NOTE: All instructions in the manual are given with the orientation of sitting on the machine ready to exercise. 300lbs / 136.1Kg user Weight Capacity: dimensions: 96”w x 76”l x 83”h / 244 cm x 193 cm x 211cm Shipping Weight: 672 lbs / 304.8 kg Net Weight:...
ExPLOdEd VIEW A. Compare the Bill of Materials to the box contents to insure that all parts are present before installation begins. B. Unpackage parts and place them near the final asssembled location to avoid moving the gym when fully assembled.
ASSEmBLY STEP 1 Step 1 Components: Procedure: a. Set the Rear Base Frame (1) in a position close to the gym’s final position. Component Rear Base Frame B. Attach Rear Support Upright A and B (3) (4) to Rear Base Frame (1) using the Rear Top Frame hardware shown.
Page 9
7 Hex Bolt - /” x ”L /” Flat Washer e. Attach Top Beam (6) to Front Upright (7) and Rear Top Frame (2) using Backing 7 /” Lock Nut Plate (10) and the hardware shown. Tighten all frame hardware securely.. Nautilus NS700X...
Page 10
ASSEmBLY STEP 3 Step 3 Components: Procedure: component a. Attach Pec Fly Pulley Bracket (37) to Leg Extension Frame (8) using the hardware shown. Pec Fly Mount Tighten hardware securely. Pec Fly Cam B. Attach Pec Fly Mount (17) to Main Base (9) using the hardware shown. Left Pec Fly Arm Tighten hardware securely.
Page 11
D. Attach three Accessory Hooks (59a) Using the self tapping screws (91a) shown. 3/8” x 3/4”L with thread lock Tighten the hardware securly. 59a Accessory Hook 91a Self Tapping Screw 5/8” L 114 3/8” Curved Washer 5/16” Set Screw 1/4”L Nautilus NS700X...
Page 12
ASSEmBLY STEP 5 Step 5 Components: Procedure: component a. Attach Seat Cross Tube (32) to Seat Adjuster (31) using hardware shown. Tighten hardware Seat Pad securely. Back Pad B. Attach Seat Pad (28) to Seat Cross Tube (32) and Seat Adjuster (31) using hardware shown. T handle Pop Pin Tighten hardware securely.
Page 13
Slide the Eccentric Roller (41) on the Locking Roller Bar Round End Cap (38). Press the Locking Roller End Cap (43) into the Locking Roller Bar (38). Repeat for the opposite side making sure that the Eccentric Rollers are aligned. Nautilus NS700X...
Page 14
ASSEmBLY STEP 7 Step 7 Components: Procedure: component A. Place Guide Tubes (47) side by side on the floor with the adjustment holes facing each other. Power Spring Assembly Slide the Hi/Low Pulley Adjuster (48) onto the Guide Tubes (47) making sure that the Guide Front Plate Tubes are even and the Hi/Low Pulley Adjuster is locked into the middle adjustment holes.
Page 15
Place Weight Selector Pin (107) in the bottom weight plate. f. Repeat Steps A-E for the second weight stack. G. Attach Pulley Bracket (36) to Rear Top Frame (2) using the hardware shown. Do not tighten hardware. Nautilus NS700X...
Page 16
ASSEmBLY STEP 9 Step 9 Components: Procedure: component a. Remove the Ball, Washer, and U-Bracket from one side of Cable #2 (70). 4 1/2” Pulley B. Route Cable #2 (70) through the Pulleys in the left Swivel Arm as shown. Continue to route Cable Retaining Bracket Cable around the two pulleys connected to the Rear Base Frame and then around the pulleys Cable #2 - High/Low Pulley Cable...
Page 17
K. Feed Cable #1 (69) through the Top Beam tube and out the front slot. Draw cable around a 4 1/2” Pulley (58) and attach the pulley in the front slot using the hardware shown in Detail C. Tighten hardware securely. l. Attach Snap Caps (68) in the Press Arm Support Assembly (22) as shown. Nautilus NS700X...
Page 19
If an attachment is installed, attach the looped end of the Cable #4 (72) to the coupling on the attachment cable. Please refer to attachment instructions for more details. Nautilus NS700X...
Page 20
ASSEmBLY STEP 12 Step 12 Components: Procedure: component a. Attach two 4 1/2” Pulleys (58) to the Pec Fly Pulley Bracket (37). Attach two 4 1/2” Pulleys (58) to 6” Pulley either side of the Leg Extension Frame (8) using the Low Pulley Cover (60) and the hardware 4 1/2”...
Page 21
Attach the Shroud (59) to the gym using the hardware shown. Shroud B. Adhere the Weight stack decals (112) to the Weight Plates in the position shown. Button Head Allen Screw 3/8” x 1/2”L with thread lock 3/8” Flat Washer 112 Weight Stack decals Nautilus NS700X...
Page 22
ASSEmBLY STEP 14 attach accessories A. Attach the Handles, Lat Bar, Ankle Cuff, Shoulder Straps, and Ab Strap to the cable ends using the Cable Clips. lubrication and final check A. Lubricate Guide Rods and Guide Tubes using a silicon based lubricant.
Page 23
Assembly to the Rear Stabilizer Assembly. Attach the Bench Connecting Plate (65) to Hex Bolt - 3/8” x 3 1/4”L the NS-50X Bench using the new hardware shown. Tighten hardware securely. Hex Bolt - 3/8” x 3”L 3/8” Flat Washer 3/8” Lock Nut Nautilus NS700X...
Nautilus Fitness Products warrants to the original purchaser Nautilus Fitness Products will repair any product that proves of this Nautilus Home Gym to be free from defects in to be a defect in materials or workmanship. In the event repair materials or workmanship, with the exceptions stated below.
ImPOrTANT CONTACT NumBErS If you need assistance, please have both the serial number of your machine and the date of purchase available when you contact the appropriate Nautilus office listed below. WOrLdWIdE CuSTOmEr SErVICE INTErNATIONAL CuSTOmEr SErVICE • NOrTH AmErICA OFFICE •...
