Page 2 With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler LLC shall be deemed to be deleted and the features and equipment that are either standard or op- name Chrysler Canada Inc. used in substitution there- tional on this vehicle.
Page 3: Introduction
TABLE OF CONTENTS SECTION PAGE ............. 3 INTRODUCTION .
Page 5: Table Of Contents
INTRODUCTION CONTENTS Introduction ......4 Vehicle Identification Number ....6 How To Use This Manual .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION HOW TO USE THIS MANUAL This Owner’s Manual has been prepared with the assis- Consult the Table of Contents to determine which section tance of service and engineering specialists to acquaint contains the information you desire. you with the operation and maintenance of your vehicle. The detailed Index at the back of this Owner’s Manual It is supplemented by a Warranty Information Booklet contains a complete listing of all subjects.
Page 7 INTRODUCTION 5...
Page 8: Vehicle Identification Number
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in an accident or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 11: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Vehicle Security Alarm System — If Equipped . . 19 Ignition Key Removal .
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Using The Express Down Windows Feature Power Windows ......36 —...
Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 Rear Seat Belts ..... . . 50 Airbag Deployment Sensors And Controls ..61 Seat Belt Pretensioners .
Page 14: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The authorized dealer that sold you your vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your authorized dealer.
Page 15: Ignition Key Removal
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Ignition Key Removal Automatic Transaxle Place the shift lever in PARK. Turn the ignition switch to the ACC position, push the key and cylinder inward, rotate the key to the LOCK position, and remove the key. Ignition Switch Positions 1 —...
Page 16 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: switches, radio, hands–free system (if equipped), and If you try to remove the key before you place the shift power outlets will remain active for up to 10 minutes lever in PARK, the key may become trapped tempo- after the ignition switch is turned to the LOCK posi- rarily in the ignition switch lock cylinder.
Page 17: Key-In-Ignition Reminder
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 You can insert the key with either side up. To lock the CAUTION! door, turn the key rearward. To unlock the door, turn the key forward. For door lock lubrication, see “Body Lubri- An unlocked car is an invitation to thieves.
Page 18 16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: A key which has not been programmed is also CAUTION! considered an invalid key even if it is cut to fit the ignition switch lock cylinder for that vehicle. Always remove the Sentry Key from the vehicle and lock all doors when leaving the vehicle unattended.
Page 19: Replacement Keys
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 All of the keys provided with your vehicle have been NOTE: When having the Sentry Key Immobilizer programmed to the vehicle electronics. System serviced, bring all vehicle keys with you to the authorized dealer.
Page 20: General Information
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE addition, the Vehicle Security Light will begin to flash. NOTE: If a programmed key is lost, see your authorized Turn the ignition switch to the LOCK position and dealer to have all remaining keys erased from the sys- remove the second key.
Page 21: Vehicle Security Alarm System - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 VEHICLE SECURITY ALARM SYSTEM — IF To Arm The System: EQUIPPED 1. Remove the keys from the ignition switch and get out The Vehicle Security Alarm system monitors the doors of the vehicle. and trunk for unauthorized entry and ignition switch for unauthorized operation.
Page 22: To Disarm The System
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The system remains armed during trunk entry. Press- During the 16 second arming period, if a door is ing the trunk button will not disarm the system. If opened or the ignition switch is turned ON, the system someone enters the vehicle through the trunk and will automatically disarm.
Page 23: Illuminated Entry System - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 Tamper Alert NOTE: If the alarm was triggered, but the warning signals have The front courtesy overhead console and door cour- timed out, the park and taillights flash three times tesy lights do not turn on if the dimmer control is in (instead of the normal twice), and the horn will chirp the interior lights ON position (extreme top position).
Page 24: To Unlock The Doors
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: To Unlock the Doors The line of transmission must not be blocked with Press and release the UNLOCK button on the RKE metal objects. transmitter once to unlock the driver’s door, or twice to unlock all doors.
Page 25 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 For vehicles not equipped with the EVIC, perform the system activated will cause the alarm to sound. Press the following procedure: UNLOCK button to deactivate the Vehicle Security Alarm system. 1. Press and hold the LOCK button on a programmed RKE transmitter for at least four seconds, but not longer Flash Lights With Lock than 10 seconds.
Page 26: To Lock The Doors
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE For vehicles not equipped with the EVIC, perform the activated will cause the alarm to sound. Press the UN- following procedure: LOCK button to deactivate the Vehicle Security Alarm system. 1. Press and hold the UNLOCK button on a programmed RKE transmitter for at least four seconds, but not longer Illuminated Approach —...
Page 27: To Unlatch The Trunk
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 Sound Horn with Lock 2. Release both buttons at the same time. This feature will cause the horn to chirp when the doors 3. Test the feature while outside of the vehicle, by are locked with the RKE transmitter.
Page 28: Using The Express Down Windows Feature - If Equipped
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Using the Express Down Windows Feature — If The Panic Alarm will stay on for three minutes unless you turn it off by pressing the PANIC button a second Equipped This feature allows you to remotely lower both front door time or if the vehicle speed is 5 mph (8 km/h) or greater.
Page 29: Battery Replacement
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 Battery Replacement The recommended replacement battery is CR2032. NOTE: Perchlorate Material — special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate. 1. With the RKE transmitter buttons facing down, use a flat blade to pry the two halves of the RKE transmitter apart.
Page 30: General Information
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information If your RKE transmitter fails to operate from a normal This device complies with part 15 of FCC rules and with distance, check for these two conditions. RS-210 of Industry Canada. Operation is subject to the 1.
Page 31: Remote Start System - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 REMOTE START SYSTEM — IF EQUIPPED Remote start conveniently starts the engine from outside the vehicle by using the Remote Keyless Entry (RKE) transmitter while maintaining security. The system has a targeted range of up to 328 ft (100 m). The vehicle must be locked, the deck lid and hood closed and the shift lever in PARK in order to start the engine using the Remote Start button on the RKE transmitter.
Page 32: How To Use Remote Start
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How to Use Remote Start To Enter Remote Start Mode All of the following conditions must be met before the Press and release the REMOTE START button engine will remote start: on the RKE transmitter twice. The engine will start and the vehicle will remain in the Remote Shift lever in PARK Start mode for a 15 minute cycle.
Page 33 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 To Exit Remote Start Mode Without Driving the NOTE: The ignition switch must be in the ON position Vehicle in order to drive the vehicle. Allow the engine to run for the entire 15 minute cycle. To Turn Off the Engine While in Remote Start To Exit Remote Start Mode and Drive the Vehicle Mode...
Page 34: Door Locks
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOOR LOCKS WARNING! Manual Door Locks For personal security and safety in the event of an To lock each door, push the door lock plunger on each accident, lock the vehicle doors as you drive as door trim panel downward.
Page 35: Power Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 CAUTION! An unlocked vehicle is an invitation to thieves. Always remove the key from the ignition and lock all of the doors when leaving the vehicle unattended. Power Door Locks A door lock switch is located on the driver and passenger door panel.
Page 36 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Unlock Doors On Exit Automatic Unlock Doors On Exit Programming The doors will unlock automatically on vehicles with The Automatic Unlock Doors on Exit feature can be power door locks if: enabled or disabled as follows: 1.
Page 37: Child Protection Door Lock System (Rear Doors)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 3. Depress the power door unlock switch to unlock the doors. 4. A single chime will indicate the completion of the programming. 5. Repeat these steps if you want to return this feature to its previous setting.
Page 38: Power Windows
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the child protection locks are engaged. NOTE: For emergency exit with the system engaged, move the lock plunger up (UNLOCKED position), roll down the window, and open the door with the outside door handle.
Page 39: Auto Window Down - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 To cancel the Auto Down movement, operate the switch WARNING! either in the up or down direction and release the switch. Never leave children in a vehicle, with the keys in For vehicles not equipped with the Electronic Vehicle the ignition switch.
Page 40: Auto Window Up - If Equipped
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Auto Window Up — If Equipped WARNING! Lift the window switch to the second detent, release, and the window will go up automatically. When the window is almost closed, there is no anti-pinch protection.
Page 41: Wind Buffeting
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 open or partially open positions. This is a normal occur- rence and can be minimized. If the buffeting occurs with the rear windows open, then open the front and rear windows together to minimize the buffeting. If the buffeting occurs with the sunroof open, then adjust the sunroof opening to minimize the buffeting.
Page 42: Trunk Safety Warning
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To unlatch the trunk lid from outside the vehicle, press TRUNK SAFETY WARNING and release the TRUNK button on the RKE transmitter WARNING! two times. With the ignition ON, the word “deck” will display in Do not allow children to have access to the trunk, place of the odometer display indicating that the trunk is either by climbing into the trunk from outside, or...
Page 43: Trunk Internal Emergency Release
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Trunk Internal Emergency Release As a security measure, a Trunk Internal Emergency Release lever is built into the trunk latching mechanism. In the event of an individual being locked inside the trunk, the trunk can be simply opened by pulling on the glow-in-the-dark handle attached to the trunk latching mechanism.
Page 44: Occupant Restraints
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE OCCUPANT RESTRAINTS Supplemental Side Airbag Inflatable Curtains (SABIC) Some of the most important safety features in your that span the front and second rows for sedans (if vehicle are the restraint systems. The following safety equipped) features are standard on all vehicles: Supplemental front seat-mounted thorax side airbags...
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 more information on LATCH, see Lower Anchors and Buckle up even though you are an excellent driver, even Tether for CHildren (LATCH) in this section. on short trips. Someone on the road may be a poor driver and cause a collision that includes you.
Page 46: Lap/Shoulder Belts
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belts WARNING! (Continued) All seating positions in your vehicle are equipped with Wearing a seat belt incorrectly is dangerous. Seat lap/shoulder belts. belts are designed to go around the large bones of The belt webbing retractor will lock only during very your body.
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is above the back of the front seat, next to your arm. Grasp the latch plate and pull out the belt.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you.
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 4. Position the lap belt across your thighs, below your WARNING! abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, A belt that is worn under your arm is very danger- tilt the latch plate and pull on the lap belt.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. WARNING! The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to A lap belt worn too high can increase the risk of allow the belt to retract fully.
Page 51: Lap/Shoulder Belt Untwisting Procedure
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 Lap/Shoulder Belt Untwisting Procedure Adjustable Upper Shoulder Belt Anchorage Use the following procedure to untwist a twisted lap/ In the front seat, the shoulder belt can be adjusted shoulder belt. upward or downward to position the belt away from your neck.
Page 52: Rear Seat Belts
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE As a guide, if you are shorter than average, you will In addition, the front passenger seat belt includes a prefer a lower position, and if you are taller than average, two-stage load-limiting feature to enhance occupant pro- you’ll prefer a higher position.
Page 53: Beltalert Programming
ON or single chime will sound to signify that you have success- START position. fully completed the programming. Chrysler LLC does not recommend deactivating BeltAlert can be reactivated by repeating this procedure. BeltAlert . NOTE: Although BeltAlert has been deactivated, the 1.
Page 54: Automatic Locking Mode
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Locking Mode How to Disengage the Automatic Locking Mode In this mode, the shoulder belt is automatically pre- Unbuckle the combination lap/shoulder belt and allow it locked. However, the belt will still retract to remove any to retract completely to disengage the Automatic Locking slack in the shoulder belt.
Page 55: Supplemental Restraint System (Srs) - Airbags
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 dealer can provide you with a seat belt extender. This is mounted in the instrument panel, above the glove extender should be used only if the existing belt is not compartment. The words SRS AIRBAG are embossed on long enough.
Page 56: Srs Components
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The front airbags are certified to the Federal Driver Airbag regulations that allow less forceful deployment. Front Passenger Airbag The front airbags have a multistage inflator design. This Supplemental Side Airbag Inflatable Curtains (SABIC) may allow the airbag to have different rates of inflation (if equipped) that are based on collision severity and occupant size.
Page 57: Front Seat Airbag Features
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 Front Seat Airbag Features Driver Airbag Special Features The front airbag system has dual-stage driver and front Driver airbag deployment and force level is controlled by passenger airbags. This system provides output appro- the driver’s seat position as well as impact severity.
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Front Seat-Mounted Thorax Side Airbags Front seat-mounted thorax side airbags provide en- hanced protection and work together with supplemental Side Airbag Inflatable Curtains (SABIC) to help protect an occupant during a side impact. The seat-mounted side airbag is marked with an airbag label sewn into the outboard side of the seat.
Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 Supplemental Side Airbag Inflatable Curtain (SABIC) — If Equipped Supplemental Side Airbag Inflatable Curtain (SABIC) Airbags offer side-impact protection to front and rear seat outboard occupants in addition to that provided by the body structure.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) If your vehicle is equipped with left and right Do not put anything on or around the airbag window bags, do not stack luggage or other cargo covers or attempt to open them manually. You may up high enough to block the location of the Side damage the airbags and you could be injured Airbag Inflatable Curtains (SABIC).
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 The seat belts are designed to protect you in many types WARNING! of collisions. The front airbags deploy in moderate to severe frontal collisions. If your vehicle is equipped, the Infants in rear facing child restraints should NEVER side airbag on the crash side of the vehicle is triggered in ride in the front seat of a vehicle with a passenger moderate to severe side collisions.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE You should read the instructions provided with your WARNING! child restraint to make sure that you are using it properly. Relying on the airbags alone could lead to more 2. All occupants should wear their lap and shoulder severe injuries in a collision.
Page 63: Airbag Deployment Sensors And Controls
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 Airbag Deployment Sensors and Controls OFF position, in the ACC position, or not in the ignition, the airbags are not on and will not inflate. Occupant Restraint Controller (ORC) The Occupant Restraint Controller System (ORC) is The ORC contains a backup power supply system that part of a Federally regulated safety system required for will deploy the airbags even if the battery loses power or...
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Side Inflatable Curtain and Front Seat-Mounted WARNING! Airbags — If Equipped The Occupant Restraint Controller System (ORC) de- Ignoring the Airbag Warning Light in your instru- ploys the side inflatable curtain and seat-mounted thorax ment panel could mean you won’t have the airbags to side airbags during collision with other vehicles and protect you in a collision.
Page 65 Enhanced (SRS) component or SRS related component or fas- Accident Response System performs the following func- tener be modified or replaced with any part except tions: those which are approved by Chrysler LLC/Mopar . Cuts off fuel to the engine...
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Flashes hazard lights If you do have a collision, which deploys the airbags, any or all of the following may occur: Turns on the interior lights which remain on as long as the battery has power or until the ignition key is The nylon airbag material may sometimes cause abra- removed...
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 irritation, move to fresh air. If the irritation continues, Maintaining Your Airbag System see your doctor. If these particles settle on your WARNING! clothing, follow the garment manufacturer’s instruc- tions for cleaning. Modifications to any part of the airbag system It is not advisable to drive your vehicle after the could cause it to fail when you need it.
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Perchlorate Material — special handling may Airbag Warning Light apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate You will want to have the airbags ready to inflate for your protection in a collision. While WARNING! the airbag system is designed to be mainte- nance free, if any of the following occurs, have Do not attempt to modify any part of your advanced an authorized dealer service the system immediately.
Page 69: Event Data Recorder (Edr)
In the event of an accident, your vehicle is designed to used by Chrysler LLC and others to learn more about the record up to five seconds of specific vehicle data param-...
Page 70 Impact acceleration and angle provided confidentiality of personal data is thereafter preserved. Seat belt status 2. Used in defense of litigation involving a Chrysler LLC Brake status (service and parking brakes) product. Accelerator status (including vehicle speed) 3. Requested by police under a legal warrant.
Page 71: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 Transmission gear selection WARNING! Cruise control status In a collision, an unrestrained child, even a tiny baby, Traction/stability control status can become a missile inside the vehicle. The force required to hold even an infant on your lap could Tire Pressure Monitoring System status (if equipped) become so great that you could not hold the child, no Child Restraints...
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants and Small Children WARNING! Safety experts recommend that children ride Rearward-facing child seats must NEVER be used in rearward-facing in the vehicle until they are at least the front seat of a vehicle with a front passenger one year old and weigh at least 20 lbs (9 kg).
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 The belt-positioning booster seat is for children weighing WARNING! (Continued) more than 40 lbs (18 kg), but who are still too small to fit A rearward-facing child restraint should only be the vehicle’s seat belts properly. If the child cannot sit used in a rear seat.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Before buying any restraint system, make sure that it In the rear seat, you may have trouble tightening the has a label certifying that it meets all applicable Safety lap/shoulder belt on the child restraint because the Standards.
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 lower anchorages that are capable of accommodating CAUTION! LATCH-compatible child seats having flexible, webbing- mounted lower attachments. Child seats with fixed lower When your child restraint is not in use, secure it in attachments must be installed in the outboard positions the vehicle with the seat belt or remove it from the only.
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Rear Seat LATCH Anchors Child restraints systems having attachments designed to connect to the lower anchorages are now available. Child restraints having tether straps and hooks for connection to the top tether anchorage have been available for some time.
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 have tether straps, and you are urged to take advantage Installing the LATCH-Compatible Child Restraint of all of the available attachments provided with your System child restraint in any vehicle. We urge that you carefully follow the directions of the manufacturer when installing your child restraint.
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In addition, there are tether strap anchorages cover directly behind the seat where you are placing the behind each rear seating position located in the child restraint and attach the tether strap to the anchor- panel between the rear seatback and the rear age, being careful to route the tether strap to provide the window.
Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 reach. If the buckled seat belt interferes with the child Installing Child Restraint Tether Strap restraint installation, instead of tucking the seat belt 1. Rotate the cover over the anchor directly behind the behind the child restraint, route the seat belt through seat where you are placing the child restraint.
Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Route the tether strap to provide the most direct path Installing Child Restraints Using the Vehicle Seat for the strap between the anchor and the child seat. If Belts your vehicle is equipped with adjustable rear head The passenger seat belts are equipped with Automatic restraints, raise the head restraint, and where possible, Locking Retractors (ALRs), which are designed to keep...
Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 In the rear seat, you may have trouble tightening the Children Too Large for Booster Seats lap/shoulder belt on the child restraint because the Children who are large enough to wear the shoulder belt buckle or latch plate is too close to the belt path opening comfortably, and whose legs are long enough to bend on the restraint.
Page 82: Transporting Pets
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Transporting Pets The engine oil installed in the engine at the factory is a Airbags deploying in the front seat could harm your pet. high-quality energy conserving type lubricant. Oil An unrestrained pet will be thrown about and possibly changes should be consistent with anticipated climate injured, or injure a passenger during panic braking or in conditions under which vehicle operations will occur.
Page 83: Safety Tips
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 SAFETY TIPS WARNING! Exhaust Gas If you are required to drive with the deck lid open, make sure that all windows are closed, and the WARNING! climate control blower switch is set at high speed. Exhaust gases can injure or kill.
Page 84: Periodic Safety Checks You Should Make Outside The Vehicle
82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Warning Light Periodic Safety Checks You Should Make Outside The Airbag Warning Light should come on and remain the Vehicle on for six to eight seconds as a bulb check when the Tires ignition switch is first turned ON.
Page 85 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......87 Phone Call Features ....101 Inside Day/Night Mirror .
Page 86 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Training ..... . . 124 Lights ......135 Seats .
Page 87 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85 Windshield Wipers And Washers ... 141 To Accelerate For Passing ....148 Intermittent Wiper System .
Page 88 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunroof Maintenance ....157 Storage ......163 Ignition Off Operation .
Page 89: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical mirror adjustment. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).
Page 90: Automatic Dimming Mirror
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped CAUTION! This mirror will automatically adjust for headlight glare from vehicles behind you. Push in the button on the face To avoid damage to the mirror during cleaning, never of the mirror to activate the dimming feature.
Page 91: Power Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 Power Mirrors After selecting a mirror, move the knob in the same The power mirrors switch is located on the drivers door direction you want the mirror to move. When finished, trim panel. return the knob to the center Off position to guard against accidentally moving a mirror position.
Page 92: Adjusting Sideview Mirrors
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjusting Sideview Mirrors Illuminated Vanity Mirrors — If Equipped An illuminated vanity mirror is on each sun visor. To use Outside Mirror — Driver’s Side the mirror, lower the sun visor and rotate the mirror Adjust the outside mirror to center on the adjacent lane of cover upward.
Page 93: Hands-Free Communication (Uconnect ) - If Equipped
For UConnect customer support, visit the following websites: UConnect system operating instructions for these ra- dios. Radio sales code can be located on the lower right www.chrysler.com/uconnect corner of the Radio faceplate. www.dodge.com/uconnect UConnect is a voice-activated, hands-free, in-vehicle communications system. UConnect allows you to dial a www.jeep.com/uconnect...
Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The UConnect system is driven through your radio or the mirror has the two control buttons (PHONE Bluetooth “Hands-Free Profile” cellular phone. Button and VOICE RECOGNITION button) that will UConnect features Bluetooth technology - the global enable you to access the system.
Page 95: Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 The UConnect system is fully integrated with the vehi- For certain operations, compound commands can be cle’s audio system. The volume of the UConnect system used. For example, instead of saying Setup and then can be adjusted either from the radio volume control Phone Pairing, the following compound command knob or from the steering wheel radio control (right...
Page 96 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Help Command To complete the pairing process, you will need to refer- If you need assistance at any prompt, or if you want to ence your cellular phone Owner’s Manual. The know your options at any prompt, say Help following UConnect website may also provide detailed instruc- the beep.
Page 97 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 For identification purposes, you will be prompted to Dial by Saying a Number give the UConnect system a name for your cellular Press the PHONE button to begin. phone. Each cellular phone that is paired should be given a unique phone name.
Page 98 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The system will prompt you to say the name of the After the Ready prompt and the following beep, say person you want to call. Phonebook New Entry. After the Ready prompt and the following beep, say When prompted, say the name of the new entry.
Page 99 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 The UConnect system will allow you to enter up to 32 Automatic download and update, if supported, begins names in the phonebook with each name having up to as soon as the Bluetooth wireless phone connection is four associated phone numbers and designations.
Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE This downloaded phonebook cannot be edited or Some phones cannot send phonebook entries if they deleted on the UConnect . These can only be edited on are already connected to any system via Bluetooth , the mobile phone.
Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 Press the PHONE button to begin. mobile and a home number, but you can add ”John Doe’s” work number later using the Phonebook Edit After the Ready prompt and the following beep, say feature.
Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After you enter the name, the UConnect system will Note that only the phonebook in the current language ask you which designation you wish to delete: home, is deleted. work, mobile, pager, or all. Say the designation you Automatic downloaded phonebook entries cannot be wish to delete.
Page 103: Phone Call Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 The UConnect system will then prompt you as to the call. Press the PHONE button to accept the call. To reject number designation you wish to call. the call, press and hold the PHONE button until you hear a single beep, indicating that the incoming call was The selected number will be dialed.
Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Making a Second Call While Current Call is in indicating that the active and hold status of the two calls Progress have switched. Only one call can be placed on hold at a To make a second call while you are currently on a call, time.
Page 105 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 Call Termination Call Continuation To end a call in progress, momentarily press the PHONE Call continuation is the progression of a phone call on the button. Only the active call(s) will be terminated and if UConnect system after the vehicle ignition key has been there is a call on hold, it will become the new active call.
Page 106: Uconnect System Features
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE UConnect System Features Emergency Assistance If you are in an emergency and the mobile phone is Language Selection reachable: To change the language that the UConnect system is using: Pick up the phone and manually dial the emergency number for your area.
Page 107 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 Canada and 060 for Mexico). The number dialed may Towing Assistance not be applicable with the available cellular service If you need towing assistance: and area. Press the PHONE button to begin. If supported, this number may be programmable on After the Ready prompt and the following beep, say some systems.
Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Paging When calling a number with your UConnect system To learn how to page, refer to Working with Automated that normally requires you to enter in a touch-tone Systems. Paging works properly except for pagers of sequence on your cellular phone keypad, you can press certain companies, which time out a little too soon to the VOICE RECOGNITION button and say the sequence...
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 send the corresponding phone number associated with Turning Confirmation Prompts ON/OFF the phonebook entry, as tones over the phone. Turning confirmation prompts off will stop the system from confirming your choices (e.g., the UConnect sys- NOTE: tem will not repeat a phone number before you dial it).
Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dialing Using the Cellular Phone Keypad Mute/Un-Mute (Mute OFF) You can dial a phone number with your cellular phone When you mute the UConnect system, you will still be keypad and still use the UConnect system (while dial- able to hear the conversation coming from the other ing via the cellular phone keypad, the user must exercise party, but the other party will not be able to hear you.
Page 111: Advanced Phone Connectivity
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 Advanced Phone Connectivity List Paired Cellular Phone Names Transfer Call to and from Cellular Phone Press the PHONE button to begin. The UConnect system allows ongoing calls to be trans- After the “Ready” prompt and the following beep, say ferred from your cellular phone to the UConnect system “Setup Phone Pairing.”...
Page 112: Things You Should Know About Your Uconnect System
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Select Another Cellular Phone Delete UConnect Paired Cellular Phones This feature allows you to select and start using another Press the PHONE button to begin. phone paired with the UConnect system. After the Ready prompt and the following beep, say Press the PHONE button to begin.
Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Voice Training This procedure may be repeated with a new user. The For users experiencing difficulty with the system recog- system will adapt to the last trained voice only. nizing their voice commands or numbers, the UConnect To restore the Voice Recognition system to factory default system Voice Training feature may be used.
Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Performance is maximized under: Storing names in the phonebook when the vehicle is not in motion is recommended. low-to-medium blower setting, It is not recommended to store similar sounding low-to-medium vehicle speed, names in the UConnect phonebook. low road noise, Phonebook (Downloaded and UConnect Local) name smooth road surface,...
Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Far End Audio Performance Echo at the far end can sometimes be reduced by lowering the in-vehicle audio volume. Audio quality is maximized under: In a convertible vehicle, system performance may be low-to-medium blower setting, compromised with the convertible top down.
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 117 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115...
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 119 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) zero call cancel confirmation prompts three continue four delete five dial download seven edit eight emergency nine English star (*) erase all plus (+) Espanol pound (#) Francais add location...
Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) language return to main menu return or main menu list names select phone select list phones send mobile set up phone settings or phone set up mute towing assistance mute off...
Page 121: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 General Information VOICE RECOGNITION SYSTEM (VR) — IF This device complies with Part 15 of the FCC rules and EQUIPPED RSS 210 of Industry Canada. Operation is subject to the Voice Recognition System (VR) Operation following conditions: This Voice Recognition system allows you to Changes or modifications not expressly approved by...
Page 122 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When you press the VR hard-key, you will hear a beep. These commands are universal and can be used from any The beep is your signal to give a command. menu. All other commands can be used depending upon the active application.
Page 123: Commands
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Commands Main Menu The Voice Recognition system understands two types of Start a dialogue by pressing the VR hard-key. You may commands. Universal commands are available at all say “Main Menu” to switch to the main menu. times.
Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Radio AM (or Radio Long Wave or Radio Medium “Radio Menu” (to switch to the radio menu) Wave — If Equipped) “Main Menu” (to switch to the main menu) To switch to the AM band say “AM” or “Radio AM”. In this mode, you may say the following commands: Satellite Radio To switch to satellite radio mode say “Sat”...
Page 125 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Disc − “Continue” (to continue recording) To switch to the disc mode say “Disc”. In this mode, you − “Delete” (to delete the recording) may say the following commands: “Play Memos” (to play previously recorded memos) “Track”...
Page 126: Voice Training
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE System Setup Voice Training To switch to system setup say “Setup”. In this mode, you For users experiencing difficulty with the system recog- may say the following commands: nizing their voice commands or numbers, the UConnect system Voice Training feature may be used.
Page 127: Seats
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 SEATS Manual Front Seat Adjustment The manual seat adjustment bar is at the front of the seat, near the floor. Pull the bar upward to move the seat forward or rearward. Release the bar once the seat is in the position desired.
Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked.
Page 129: Reclining Bucket Seats
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 Reclining Bucket Seats WARNING! The recliner control is on the side of the seat. To recline, lean forward slightly before lifting the lever, then lean Adjusting a seat while the vehicle is moving is back to the desired position and release the lever.
Page 130: Lumbar Support - If Equipped
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lumbar Support — If Equipped Power Seats — If Equipped This feature allows you to increase or decrease the The power seat switches are on the outboard side of the amount of lumbar support. The control lever is located seat near the floor.
Page 131: Adjustable Head Restraints
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 Adjustable Head Restraints CAUTION! Head restraints can reduce the risk of whiplash injury in the event of impact from the rear. Adjust the restraints so Do not place any article under a power seat as it may that the upper edge is as high as practical.
Page 132: Heated Seats - If Equipped
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Seats — If Equipped Press the switch once to choose High (two lights), press it This feature heats leather or cloth front driver and a second time to choose Low (one light), press it a third passenger seats.
Page 133: Fold Flat Passenger Seat Back
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 Fold Flat Passenger Seat Back The hard seatback features a work surface and a molded The recline handle on the front passenger seat also rim for retaining items stored on the seatback panel. releases the seatback to fold forward.
Page 134: Folding Rear Seat
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Folding Rear Seat WARNING! To provide additional storage area, the rear seatback can be folded forward. Pull on the loops shown in the picture The rear cargo area of the vehicle (with the rear to fold down either or both seatbacks.
Page 135: Folding Rear Seat Center Armrest
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 Folding Rear Seat Center Armrest TO OPEN AND CLOSE THE HOOD The rear seat is equipped with a folding armrest with To open the hood, two latches must be released. cupholders. 1. Pull the hood release lever located under the left side of the instrument panel.
Page 136 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Then lift the secondary latch located under the front edge of the hood, near the center and raise the hood. Hood Prop Rod Hole Location Before closing the hood, make sure to stow the prop rod in its proper location.
Page 137: Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 lighting also comes on when a door is opened or the WARNING! dimmer control is turned fully upward, past the second detent. If the hood is not fully latched it could fly up when the vehicle is moving and block your forward vision.
Page 138: Headlights, Parking Lights And Instrument Panel Lights
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition switch is moved to the LOCK position. This will occur if the interior lights were switched on manually or are on because a door is open.
Page 139: Automatic Headlight System
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 To change the brightness of the instrument panel lights, Automatic Headlight System — If Equipped rotate the center portion of the multifunction lever up or Turning the end of the multifunction lever to the third down.
Page 140: Flash-To-Pass
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Flash-To-Pass NOTE: On this vehicle, the DRL will automatically turn You can signal another vehicle with your headlights by off when the turn signal is in operation and automatically lightly pulling the multifunction lever toward you. This turn back on when the turn signal is not operating.
Page 141: Turn Signals
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 Turn Signals Move the multifunction lever up or down and the arrows on each side of the instrument cluster flash to show proper operation of the front and rear turn signal lights. You can signal a lane change by moving the lever partially up or down without moving beyond the detent.
Page 142: High Beam/Low Beam Select Switch
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If either light remains on and does not flash, or there is a High Beam/Low Beam Select Switch very fast flash rate, check for a defective outside light Push the multifunction lever away from you to switch bulb.
Page 143: Windshield Wipers And Washers
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 WINDSHIELD WIPERS AND WASHERS Rotate the end of the lever to the first detent past the The wipers and washers are operated by a switch intermittent settings for low speed wiper operation, or to on the control lever.
Page 144: Intermittent Wiper System
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For vehicles equipped with the Speed Sensitive Intermit- CAUTION! (Continued) tent Wiper System, the wiper delay times depend on Always remove any buildup of snow that prevents vehicle speed. If the vehicle is moving less than 10 mph the windshield wiper blades from returning to the (16 km/h), delay times will double.
Page 145: Mist Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 Mist Feature Headlights With Wipers Feature (Available With Push down on the wiper control lever to activate a single Auto Headlights Only) wipe to clear the windshield of road mist or spray from When this feature is active, the headlights will turn on a passing vehicle.
Page 146: Windshield Washers
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Windshield Washers To use the washer, pull the windshield wiper/washer control lever toward you and hold it for as long as washer spray is desired. If you activate the washer while the wiper control is in the delay range, the wipers will operate in low speed for two wipe cycles after releasing the lever and then resume the intermittent interval previously selected.
Page 147: Electronic Speed Control - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 WARNING! Do not adjust the steering wheel while driving. The telescoping adjustment must be locked while driv- ing. Adjusting the steering wheel while driving or driving without the telescoping adjustment locked could cause the driver to lose control of the vehicle. ELECTRONIC SPEED CONTROL —...
Page 148: To Activate
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Activate To Set At A Desired Speed Push and release the ON/OFF button located When the vehicle reaches the speed desired, press down on the end of the Electronic Speed Control on the lever and release SET DECEL. Release the accel- lever.
Page 149: To Resume Speed
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 To Resume Speed To decrease speed while the Electronic Speed Control is If you deactivated the Electronic Speed Control without set, push down and hold the lever SET DECEL. Release erasing the set speed from memory and your vehicle the lever when the desired speed is reached, and the new speed is above 20 mph (32 km/h) you can resume the set speed will be established.
Page 150: To Accelerate For Passing
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Accelerate For Passing The HomeLink buttons that are located in the headliner Depress the accelerator as you would normally. When the or sun visor designate the three different HomeLink pedal is released, the vehicle will return to the set speed. channels.
Page 151: Programming Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 Programming Homelink WARNING! Before You Begin Your motorized door or gate will open and close If you have not trained any of the HomeLink buttons, while you are training the universal transceiver. erase all channels before you begin training. Do not train the transceiver if people or pets are in To do this, press and hold the two outside buttons for up the path of the door or gate.
Page 152 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Begin Programming NOTE: Some gate operators and garage door openers may 1. Turn the ignition switch to the ON/RUN position. require you to replace Step 3 with procedures noted in 2. Hold the battery side of the handheld transmitter the “Gate Operator/Canadian Programming”...
Page 153 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 If the indicator light blinks rapidly for two seconds and then turns to a constant light, proceed to Step 5 “Pro- gramming A Rolling Code System.” 5. Programming A Rolling Code System At the garage door opener motor (in the garage), locate the “Learn”...
Page 154 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 6. Firmly press and release the “Learn” or “Training” Using HomeLink button. The name and color of the button may vary by To operate, simply press and release the programmed manufacturer. HomeLink button. Activation will now occur for the trained device (i.e., garage door opener, gate operator, NOTE: There are 30 seconds in which to initiate the next security system, entry door lock, home/office lighting,...
Page 155: Gate Operator/Canadian Programming
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 Gate Operator/Canadian Programming If you unplugged the device for training, plug it back in Canadian radio frequency laws require transmitter sig- at this time. nals to time-out (or quit) after several seconds of trans- Then proceed with Step 4 under “Programming mission –...
Page 156: Troubleshooting Tips
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Troubleshooting Tips General Information If you are having trouble programming HomeLink , here This device complies with FCC rules Part 15 and Industry are some of the most common solutions: Canada RSS-210. Operation is subject to the following two conditions: Replace the battery in the original transmitter.
Page 157: Power Sunroof - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 POWER SUNROOF — IF EQUIPPED WARNING! The sunroof controls are mounted between the sun visors in the Dome/Reading Lamp. Never leave children in a vehicle, with the keys in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch.
Page 158: Sunroof Operation
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunroof Operation Venting Sunroof - Express Press and release the V button, and the sunroof will Opening Sunroof Manually open to the vent position. This is called Express Vent. Press the switch rearward and hold, and the sunroof will open automatically from any position.
Page 159: Sunshade Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 Sunshade Operation Sunroof Maintenance The sunshade can be opened manually. However, the Use only a nonabrasive cleaner and a soft cloth to clean sunshade will open automatically as the sunroof opens. the glass panel. NOTE: The sunshade cannot be closed if the sunroof is Ignition Off Operation open.
Page 160: Electrical Power Outlets
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRICAL POWER OUTLETS There are two 12-Volt electrical outlets on this vehicle. Both of the outlets are protected by a fuse. The instrument panel power outlet, located below the climate control knobs, has power available only when the ignition is ON.
Page 161 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 The center console power outlet is powered directly from WARNING! the battery (power available at all times). Items plugged into this outlet may discharge the battery and/or prevent To avoid serious injury or death: engine starting.
Page 162: Cigar Lighter And Ash Receiver - If Equipped
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CIGAR LIGHTER AND ASH RECEIVER — IF CAUTION! EQUIPPED An optional ash receiver is available from your autho- Many accessories that can be plugged in draw rized dealer and will fit in the center console front power from the vehicle’s battery, even when not in cupholder.
Page 163: Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 When the unit is on and the LED is Red, the cup holder CAUTION! is being heated. When the LED is Blue, the cup holder is being cooled. For vehicles equipped with the heated and cooled cupholder, locate the cup holder ash receiver in the forward cupholder.
Page 164: Rear Bottle Holders
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Make sure the beverage container can withstand the temperatures shown above, when using the Cooled or Heated Cupholder. Rear Bottle Holders There are built-in bottle holders located in both rear door trim panels. Rear Bottle Holder WARNING! If containers of hot liquid are placed in the bottle...
Page 165: Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 STORAGE Driver’s Side Sunglass Holder — If Equipped An integrated sunglass holder is located in the headliner above the sun visor. To access the sunglass holder, lower the sun visor. Small items such as toll tickets can be stored between the two straps, while sunglasses or other items can be stored above the two straps.
Page 166: Cargo Area
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Cargo Area WARNING! (Continued) The 60/40 split-folding rear seat provides cargo-carrying The cargo area in the rear of the vehicle (with the versatility. The seatbacks fold down easily by pulling rear seatbacks in the locked-up or folded down nylon tabs between the seatbacks and the bolsters.
Page 167: Console Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 Always place cargo evenly on the cargo floor. Put heavier accommodate large size cups and 20 oz. (.5 L) bottles. An objects as low and as far forward as possible. optional removable ashtray may be located in the one cupholder.
Page 168: Dual Storage Bins
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dual Storage Bins Lifting a latch at the front of the hinged armrest provides access to these storage areas. Storage Console Detail 1 — Release Top Compartment 2 — Release Bottom Compartment 3 — Top Compartment 4 —...
Page 169 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 The left latch opens to the top storage area. NOTE: A notch in the side of the console base under the The lower bin can be accessed directly, without first armrest will also allow use of cell phone while still exposing the upper bin, by operating the right latch with plugged into the power outlet and with the armrest the armrest down.
Page 170: Video Console - If Equipped
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Video Console — If Equipped The optional VES™ (Video Entertainment System) in- cludes the following components: The screen for a rear seat DVD player is stored under the armrest. Remote Control Audio/Video RCA Jacks Video Console Refer to, “Video Entertainment System —...
Page 171: Rear Window Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 REAR WINDOW FEATURES CAUTION! Rear Window Defroster — If Equipped To avoid damaging the electrical conductors of the The electric rear window defroster switch is lo- rear window defroster, do not use scrapers, sharp cated on the climate control.
Page 173: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....174 Personal Settings (Customer-Programmable Features) ......196 Instrument Cluster –...
Page 174 172 UNDERSTANDING YOUR INSTRUMENT PANEL List Button Notes On Playing MP3 Files ... . . 223 (Disc Mode For MP3/WMA Play) ..212 Operation Instructions - Auxiliary Mode .
Page 175 UNDERSTANDING YOUR INSTRUMENT PANEL 173 Electronic Serial Number/Sirius Right-Hand Switch Functions ... . 247 Identification Number (ESN/SID) ..239 Left-Hand Switch Functions For Radio Selecting Satellite Mode .
Page 176: Instrument Panel Features
174 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 - Air Outlet 6 - Radio 11 - Storage Compartment 7 - Upper Glove Compartment/Beverage 2 - Side Window Demister Outlet 12 - Climate Control Cooler – If Equipped 3 - Instrument Cluster 8 - Lower Glove Compartment 13 - Trunk Release Switch 4 - Ignition Switch...
Page 177: Instrument Cluster - Base
UNDERSTANDING YOUR INSTRUMENT PANEL 175 INSTRUMENT CLUSTER – BASE...
Page 178: Instrument Cluster - Premium
176 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER – PREMIUM...
Page 179: Instrument Cluster Descriptions
UNDERSTANDING YOUR INSTRUMENT PANEL 177 INSTRUMENT CLUSTER DESCRIPTIONS If the pointer rises to the H (red) mark, the instrument cluster will sound a chime. Pull over and stop the vehicle. 1. Fuel Gauge Idle the vehicle with the air conditioner turned off until When the ignition switch is in the ON position, the the pointer drops back into the normal range.
Page 180 178 UNDERSTANDING YOUR INSTRUMENT PANEL 5. Low Fuel Light 7. Airbag Warning Light When the fuel level drops to approximately 2.0 gal- The light comes on and remains on for six to lons (7.6 Liters), the fuel symbol will light and a eight seconds as a bulb check when the ignition single chime will sound.
Page 181 UNDERSTANDING YOUR INSTRUMENT PANEL 179 9. Seat Belt Reminder Light The light does not show the quantity of oil in the engine. When the ignition switch is first turned ON, this This can be determined using the procedure shown in light will come on for about six seconds.
Page 182 180 UNDERSTANDING YOUR INSTRUMENT PANEL 14. Odometer/Trip Odometer Vehicle Warning Messages The odometer shows the total distance the vehicle has When the appropriate conditions exist, “door,” “deck,” been driven. U.S. federal regulations require that upon “LoW TirE,” “CHAngE OIL,” “GASCAP” or “HOTOIL” transfer of vehicle ownership, the seller certify to the will display in the odometer.
Page 183 UNDERSTANDING YOUR INSTRUMENT PANEL 181 GASCAP means the engine oil change interval may fluctuate If the vehicle diagnostic system detects a leak or change dependent upon your personal driving style. in the evaporative system, or the fuel filler cap is loose, Unless reset, this message will continue to display each improperly installed, or damaged, the words “GASCAP”...
Page 184 182 UNDERSTANDING YOUR INSTRUMENT PANEL 4. For vehicles equipped with the Electronic Vehicle To reset the trip odometer, first set the display to Trip Information Center (EVIC), refer to “Electronic Vehicle Mode. Then push and hold the button (approximately Information Center (EVIC)” in this section of the 2 seconds) until the display resets to 0 miles.
Page 185 UNDERSTANDING YOUR INSTRUMENT PANEL 183 17. Electronic Throttle Control (ETC) Indicator Light 18. Electronic Stability Program (ESP) Indicator Light This light informs you of a problem with the / Traction Control System (TCS) Indicator Light — If Electronic Throttle Control (ETC) system. If a Equipped problem is detected, the light will come on If this indicator light flashes during accelera-...
Page 186 184 UNDERSTANDING YOUR INSTRUMENT PANEL The dual brake system provides a reserve braking capac- WARNING! ity in the event of a failure to a portion of the hydraulic system. Failure of either half of the dual brake system is Driving a vehicle with the brake light on is danger- indicated by the Brake Warning Light which will turn on ous.
Page 187 UNDERSTANDING YOUR INSTRUMENT PANEL 185 The light also will turn on when the parking brake is Warning Lamp” should turn off with the engine running. applied with the ignition switch in the ON position. If the “ESP/BAS Warning Lamp” comes on continuously with the engine running, a malfunction has been detected NOTE: This light shows only that the parking brake is in either the ESP or the BAS system.
Page 188 186 UNDERSTANDING YOUR INSTRUMENT PANEL If the ABS light is on, the brake system should be serviced As an added safety feature, your vehicle has been as soon as possible to restore the benefit of Anti-Lock equipped with a Tire Pressure Monitoring System Brakes.
Page 189 UNDERSTANDING YOUR INSTRUMENT PANEL 187 Your vehicle has also been equipped with a TPMS CAUTION! malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is The TPMS has been optimized for the original combined with the low tire pressure telltale. When the equipment tires and wheels.
Page 190 188 UNDERSTANDING YOUR INSTRUMENT PANEL 25. Malfunction Indicator Light (MIL) If the MIL flashes when the engine is running, serious The Malfunction Indicator Light (MIL) is part of conditions may exist that could lead to immediate loss of an onboard diagnostic system called OBD that power or severe catalytic converter damage.
Page 191: Electronic Vehicle Information Center (Evic) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 189 ELECTRONIC VEHICLE INFORMATION CENTER The EVIC consists of the following: (EVIC) – IF EQUIPPED System status The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display that is located in the Vehicle information warning message displays instrument cluster.
Page 192 190 UNDERSTANDING YOUR INSTRUMENT PANEL The system allows the driver to select information by Press and release the COMPASS button to pressing the following buttons on the instrument panel display the compass heading and the outside switch bank: temperature. COM- Press and release the MENU button to advance PASS the display to Trip Functions or Personal set-...
Page 193: Evic Displays
UNDERSTANDING YOUR INSTRUMENT PANEL 191 EVIC Displays Left/Right Door Ajar (one or more, with a single When the appropriate conditions exist, the Electronic chime if speed is above 1 mph / 1 km h) Vehicle Information Center (EVIC) displays the following Door(s) Ajar (with a single chime if vehicle is in messages.
Page 194: Trip Functions
192 UNDERSTANDING YOUR INSTRUMENT PANEL Unless reset, this message will continue to display each Trip Functions time you turn the ignition switch to the ON/RUN Press and release the MENU button until one of the position. To turn off the message temporarily, press and following Trip Functions displays in the EVIC: release the MENU button.
Page 195 UNDERSTANDING YOUR INSTRUMENT PANEL 193 Distance To Empty (DTE) Elapsed Time Shows the estimated distance that can be traveled with Shows the total elapsed time of travel since the last reset. the fuel remaining in the tank. This estimated distance is Elapsed time will increment when the ignition switch is determined by a weighted average of the instantaneous in the ON or START position.
Page 196: Compass Display
194 UNDERSTANDING YOUR INSTRUMENT PANEL Compass Display Manual Compass Calibration The compass heading indicates the direction If the compass appears erratic or inaccurate, and the the vehicle is facing. Press and release the variance has been properly set, you may wish to manu- compass button to display one of eight com- ally recalibrate the compass.
Page 197 UNDERSTANDING YOUR INSTRUMENT PANEL 195 Compass Variance Compass Variance is the difference between Magnetic North and Geographic North. To ensure compass accu- racy, the compass variance should be properly set accord- ing to the variance map for the zone where the vehicle will be driven.
Page 198: Personal Settings (Customer-Programmable Features)
196 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Press and release the STEP button until “Compass Press and release the MENU button until “Personal Variance” and the current Variance Value displays in the Settings” displays in the EVIC. EVIC. Press and release the STEP button to display the follow- 4.
Page 199 UNDERSTANDING YOUR INSTRUMENT PANEL 197 Remote Key Unlock Flash Lights with Lock When “Driver Door 1st Press” is selected, only the When ON is selected, the front and rear turn signals will driver’s door will unlock on the first press of the Remote flash when the doors are locked or unlocked with the Keyless Entry (RKE) transmitter UNLOCK button.
Page 200 198 UNDERSTANDING YOUR INSTRUMENT PANEL Headlights With Wipers (Available with Auto Opening a vehicle door will cancel this feature. To make Headlights Only) your selection, press and hold the RESET button until When ON is selected, and the headlight switch is in the Off, 45 sec., 5 min., or 10 min.
Page 201: Setting The Analog Clock
UNDERSTANDING YOUR INSTRUMENT PANEL 199 SETTING THE ANALOG CLOCK To set the analog clock, lo- cated at the top center of the instrument panel, press and hold the button in until the setting is correct. The clock will adjust slowly at first and then quicker the longer the button is held.
Page 202 200 UNDERSTANDING YOUR INSTRUMENT PANEL Power Switch/Volume Control (Rotary) SCAN Button Push the ON/VOLUME control knob to turn on the Pressing the SCAN button causes the tuner to search for radio. Press the ON/VOLUME control knob a second the next listenable station, in AM, FM or Satellite (if time to turn off the radio.
Page 203 UNDERSTANDING YOUR INSTRUMENT PANEL 201 Phone Button (UConnect Hands-Free Phone) — If 3. After adjusting the hours, press the right side TUNE/ Equipped SCROLL control knob to set the minutes. The minutes Press this button to operate the Hands-Free Phone will begin to blink.
Page 204 202 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Push the rotary TUNE/SCROLL control knob a third Pressing the RW (Rewind) or FF (Fast Forward) buttons time and TREBLE will display. Turn the TUNE/SCROLL causes the tuner to search for the next frequency in the control knob to the right or left to increase or decrease the direction of the arrows.
Page 205 UNDERSTANDING YOUR INSTRUMENT PANEL 203 MUSIC TYPE Button 16-Digit Character Program Type Pressing this button once will turn on the Music Type Display mode for five seconds. Pressing the MUSIC TYPE button Foreign Language Language or turning the TUNE/SCROLL control knob within five Information Inform seconds will allow the program format type to be se-...
Page 206 204 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Turn the TUNE/SCROLL control knob to scroll 16-Digit Character Program Type through the entries. Push the AUDIO/SELECT button to Display select an entry and make changes. Sports Sports Talk Talk DVD Enter - When the disc is in DVD Menu mode, selecting DVD Enter will allow you to play the current Top 40 Top 40...
Page 207 UNDERSTANDING YOUR INSTRUMENT PANEL 205 Audio Stream – Repeatedly pressing SELECT will VES™ CH1/CH2 - Allows the user to change the switch to different audio languages (if supported on mode of either the IR1 or IR2, wireless headphones by the disc) (if equipped). pressing the AUDIO/SELECT button (if equipped).
Page 208 206 UNDERSTANDING YOUR INSTRUMENT PANEL Menu Language — If Equipped the disc). You can select a language not listed by scrolling Selecting this item will allow the user to choose the down and selecting other. Enter the country code using default startup DVD menu language (effective only if the TUNE/SCROLL control knob to scroll up and down language supported by disc).
Page 209 UNDERSTANDING YOUR INSTRUMENT PANEL 207 AutoPlay — If Equipped and press and release that button. If a button is not When this is set to On and a DVD video is inserted, it will selected within five seconds after pressing the SET but- bypass the DVD menu screen and automatically play the ton, the station will continue to play but will not be movie.
Page 210: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)
208 UNDERSTANDING YOUR INSTRUMENT PANEL Buttons 1 - 6 CAUTION! These buttons tune the radio to the stations that you commit to pushbutton memory {12 AM, 12 FM, and 12 The radio may shut down during extremely hot Satellite (if equipped) stations}. conditions.
Page 211 UNDERSTANDING YOUR INSTRUMENT PANEL 209 Radio display will show LOADING DISC when the disc The disc can be ejected with the radio and ignition OFF. is loading and “READING DISC” when the radio is SEEK Button (CD MODE) reading the disc. Press the right SEEK button for the next selection on the CD.
Page 212: Notes On Playing Mp3/Wma Files
210 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF (CD MODE) Supported Medium Formats (File Systems) Press and hold FF (Fast Forward) and the CD player will The medium formats supported by the radio are ISO 9660 begin to fast forward until FF is released, or RW or Level 1 and Level 2 and includes the Joliet extension.
Page 213 UNDERSTANDING YOUR INSTRUMENT PANEL 211 Multisession disc formats are supported by the radio. frequencies in the following table are supported. In Multisession discs may contain combinations of normal addition, variable bit rates (VBR) are also supported. The CD audio tracks and computer files (including MP3/ majority of MP3/WMA files use a 44.1 kHz sampling rate WMA files).
Page 214: List Button (Disc Mode For Mp3/Wma Play)
212 UNDERSTANDING YOUR INSTRUMENT PANEL ID3 Tag information for artist, song title, and album title Number of files and folders - Loading times will are supported for ID3 version 1 tags. ID3 version 2 is not increase with more files and folders supported by the radios.
Page 215: Info Button (Disc Mode For Mp3/Wma Play)
UNDERSTANDING YOUR INSTRUMENT PANEL 213 INFO Button (DISC Mode for MP3/WMA Play) Pressing the AUX button will change the mode to auxil- Pressing the INFO button repeatedly will scroll through iary device if the AUX jack is connected. the following TAG information: Song Title, Artist, File NOTE: The AUX device must be turned on and the Name, and Folder Name (if available).
Page 216 214 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (Auxiliary Mode) Operating Instructions - Hands-Free Phone Press the TIME button to change the display from (UConnect ) (If Equipped) elapsed playing time to time of day. The time of day will Refer to “Hands-Free Communication (UConnect )” in display for five seconds.
Page 217: Am/Fm/Cd/Dvd Multimedia System Radio (Rer/Ren) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 215 Macrovision The REN and RER Multimedia systems contain a radio, This product incorporates copyright protection technol- CD/DVD player, USB port, and a 30-gigabyte hard drive ogy that is protected by U.S. patents and other intellec- (HDD).
Page 218: Clock Setting Procedure
216 UNDERSTANDING YOUR INSTRUMENT PANEL Clock Setting Procedure 4. To move the hour forward, touch the screen where the word “Hour” with the arrow pointing upward is dis- Global Positioning System (GPS) — RER only played. To move the hour backward, touch the screen The GPS receiver used in this system is synchronized to where the word “Hour”...
Page 219 UNDERSTANDING YOUR INSTRUMENT PANEL 217 2. Touch the screen where the time is displayed. The Touch the screen where the words “Show Time if Radio is clock setting menu will appear on the screen. Off” are displayed to change the current setting. 3.
Page 220: Sales Code Res - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
218 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RES — AM/FM STEREO RADIO Operating Instructions — Radio Mode WITH CD PLAYER (MP3 AUX JACK) NOTE: The ignition switch must be in the ON or ACC NOTE: The radio sales code is located on the lower right position to operate the radio.
Page 221 UNDERSTANDING YOUR INSTRUMENT PANEL 219 to seek up and the left switch to seek down. The radio 4. Adjust the minutes using the right side Tune/Scroll will remain tuned to the new station until you make control knob. Press the Tune/Scroll control knob to save another selection.
Page 222 220 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary Tune/Scroll control knob a second time AM/FM Button and MID will display. Turn the Tune/Scroll control knob Press the buttons to select either AM or FM mode. to the right or left to increase or decrease the mid-range SET/RND Button —...
Page 223: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 221 and 12 FM stations to be stored into pushbutton memory. This radio is capable of playing compact discs (CD), The stations stored in SET 2 memory can be selected by recordable compact discs (CD-R), rewritable compact pressing the pushbutton twice.
Page 224 222 UNDERSTANDING YOUR INSTRUMENT PANEL If you have ejected a disc and have not removed it within CAUTION! 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it. This CD player will accept 4-3/4 in (12 cm) discs only.
Page 225: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 223 RW/FF Press the RND button a second time to stop Random Press the RW button to stop the CD at the beginning of Play. the current CD track/title. Notes on Playing MP3 Files Press and hold the FF (Fast Forward) button and the CD The radio can play MP3 files;...
Page 226 224 UNDERSTANDING YOUR INSTRUMENT PANEL The radio uses the following limits for file systems: Level 2: 31 (including a separator . and a three- character extension) Maximum number of folder levels: 8 Multisession disc formats are supported by the radio. Maximum number of files: 255 Multisession discs may contain combinations of normal Maximum number of folders.
Page 227 UNDERSTANDING YOUR INSTRUMENT PANEL 225 When using the MP3 encoder to compress audio data to ID3 Tag information for artist, song title, and album title an MP3 file, the bit rate and sampling frequencies in the are supported for version 1 ID3 tags. ID3 version 2 is not following table are supported.
Page 228: Operation Instructions - Auxiliary Mode
226 UNDERSTANDING YOUR INSTRUMENT PANEL Number of files and folders - Loading times will Pressing the DISC/AUX button will change the mode to increase with more files and folders auxiliary device if the AUX jack is connected. To increase the speed of disc loading, it is recommended NOTE: The AUX device must be turned on and the to use CD-R media and single-session discs.
Page 229: Sales Code Res/Rsc - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Sirius Radio
UNDERSTANDING YOUR INSTRUMENT PANEL 227 SALES CODE RES/RSC — AM/FM STEREO Operating Instructions — Radio Mode RADIO WITH CD PLAYER (MP3 AUX JACK) AND NOTE: The ignition switch must be in the ON or ACC SIRIUS RADIO position to operate the radio. NOTE: The radio sales code is located on the lower right Power Switch/Volume Control (Rotary) side of the radio faceplate.
Page 230 228 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons Phone Button (UConnect Hands-Free Phone) — If Press and release the SEEK buttons to search for the next Equipped listenable station in AM/FM mode. Press the right switch Press this button to operate the Hands-Free Phone to seek up and the left switch to seek down.
Page 231 UNDERSTANDING YOUR INSTRUMENT PANEL 229 3. After adjusting the hours, press the right side Tune/ INFO Button Scroll control knob to set the minutes. The minutes will Press the INFO button for an RDS station (one with call begin to blink. letters displayed).
Page 232 230 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary Tune/Scroll control knob a second time MUSIC TYPE Button and MID will display. Turn the Tune/Scroll control knob Pressing this button once will turn on the Music Type to the right or left to increase or decrease the mid-range mode for five seconds.
Page 233 UNDERSTANDING YOUR INSTRUMENT PANEL 231 16-Digit Character 16-Digit Character Program Type Program Type Display Display Foreign Language Language Sports Sports Information Inform Talk Talk Jazz Jazz Top 40 Top 40 News News Weather Weather Nostalgia Nostalga By pressing the SEEK button when the Music Type icon Oldies Oldies is displayed, the radio will be tuned to the next frequency...
Page 234 232 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button You may add a second station to each pushbutton by Pressing the SETUP button allows you to select between repeating the above procedure with this exception: Press the following items: the SET/RND button twice and SET 2 will show in the display window.
Page 235: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 233 Operation Instructions — CD MODE for CD and If you insert a disc with the ignition ON and the radio MP3 Audio Play ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will NOTE: show the disc number, the track number, and index time The ignition switch must be in the ON or ACC...
Page 236 234 UNDERSTANDING YOUR INSTRUMENT PANEL EJECT Button - Ejecting a CD the current selection. Pressing and holding the SEEK Press the EJECT button to eject the CD. button will allow faster scrolling through the tracks in CD, MP3 modes. TIME Button Press this button to change the display from a large CD If you have ejected a disc and have not removed it within playing time display to a small CD playing time display.
Page 237: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 235 SET/RND Button (Random Play Button) Supported Medium Formats (File Systems) Press this button while the CD is playing to activate The medium formats supported by the radio are ISO 9660 Random Play. This feature plays the selections on the Level 1 and Level 2 and includes the Joliet extension.
Page 238 236 UNDERSTANDING YOUR INSTRUMENT PANEL Maximum number of characters in file/folder names: extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will Level 1: 12 (including a separator . and a three- not play the file.
Page 239: List Button (Cd Mode For Mp3 Play)
UNDERSTANDING YOUR INSTRUMENT PANEL 237 ID3 Tag information for artist, song title, and album title Number of files and folders - Loading times will are supported for version 1 ID3 tags. ID3 version 2 is not increase with more files and folders supported by the radios.
Page 240: Info Button (Cd Mode For Mp3 Play)
238 UNDERSTANDING YOUR INSTRUMENT PANEL INFO Button (CD Mode for MP3 Play) Pressing the AUX button will change the mode to auxil- Pressing the INFO button repeatedly will scroll through iary device if the AUX jack is connected. the following TAG information: Song Title, Artist, File NOTE: The AUX device must be turned on and the Name, and Folder Name (if available).
Page 241: Satellite Radio - If Equipped (Ren/Req/Rer/Res/Reu Radios Only)
UNDERSTANDING YOUR INSTRUMENT PANEL 239 SATELLITE RADIO — IF EQUIPPED how to setup your on-line listening account at no addi- (REN/REQ/RER/RES/REU RADIOS ONLY) tional charge. For further information, call the toll-free Satellite radio uses direct satellite-to-receiver broadcast- number 888-539-7474, or visit the Sirius web site at ing technology to provide clear digital sound, coast to www.sirius.com, or at www.siriuscanada.ca for Cana- coast.
Page 242: Selecting Satellite Mode
240 UNDERSTANDING YOUR INSTRUMENT PANEL To access the ESN/SID, refer to the following steps: Next, turn the knob surrounding the joystick in the center of the radio to scroll to Subscription, and then press and ESN/SID Access With REQ/RES Radios release the joystick.
Page 243: Reception Quality
UNDERSTANDING YOUR INSTRUMENT PANEL 241 Reception Quality SEEK Buttons Satellite reception may be interrupted due to one of the Press and release the SEEK buttons to search for the next following reasons: channel in Satellite mode. Press the right switch to seek up and the left switch to seek down.
Page 244 242 UNDERSTANDING YOUR INSTRUMENT PANEL INFO Button — Except REU Radio MUSIC TYPE Button — Except REU Radio Pressing the INFO button will cycle the display informa- Pressing this button once will turn on the Music Type tion between Artist, Song Title, and Composer (if avail- mode for five seconds.
Page 245 UNDERSTANDING YOUR INSTRUMENT PANEL 243 MUSIC TYPE Button — REU Radio SET Button – To Set the Pushbutton Memory Pressing this button provides a MUSIC TYPES list from When you are receiving a channel that you wish to which you can make a selection. Once a selection is commit to pushbutton memory, press the SET button.
Page 246: Operating Instructions - Hands-Free Phone (If Equipped)
244 UNDERSTANDING YOUR INSTRUMENT PANEL Buttons 1 - 6 A diagonal 7 in (17.8 cm) Liquid Crystal Display (LCD) These buttons tune the radio to the channels that you screen integrated into the center console armrest. The commit to pushbutton memory (12 Satellite stations). screen features brightness control for optimum day- time and nighttime viewing.
Page 247 UNDERSTANDING YOUR INSTRUMENT PANEL 245 The LCD screen swings up from the rear of the armrest The touch screen radio and DVD player controls allow to allow the rear seat passenger(s) to view the display. front seat operation for easy setup in the case of younger rear seat passengers.
Page 248: Remote Sound System Controls - If Equipped
246 UNDERSTANDING YOUR INSTRUMENT PANEL Two wireless infrared headsets allow rear seat passen- REMOTE SOUND SYSTEM CONTROLS — IF gers to listen to the same or individual audio sources. EQUIPPED The remote sound system controls are located on the rear Audio/Video RCA Jacks (AUX Jacks) surface of the steering wheel.
Page 249: Right-Hand Switch Functions
UNDERSTANDING YOUR INSTRUMENT PANEL 247 Right-Hand Switch Functions Left-Hand Switch Functions for Media (i.e., CD) Operation Press the top of the switch to increase the volume. Press the top of the switch once to listen to the next Press the bottom of the switch to decrease the volume. track.
Page 250: Cd/Dvd Maintenance
248 UNDERSTANDING YOUR INSTRUMENT PANEL CD/DVD MAINTENANCE NOTE: If you experience difficulty in playing a particu- To keep a CD/DVD in good condition, take the following lar disc, it may be damaged (i.e. scratched, reflective precautions: coating removed, a hair, moisture or dew on the disc) oversized, or have theft protection encoding.
Page 251: Climate Controls
UNDERSTANDING YOUR INSTRUMENT PANEL 249 CLIMATE CONTROLS Blower Control The Air Conditioning and Heating System is designed to Rotate this control to regulate the make you comfortable in all types of weather. amount of air forced through the ven- tilation system in any mode. The Manual Heating Ventilation and Air Conditioning blower speed increases as you move (HVAC)
Page 252 250 UNDERSTANDING YOUR INSTRUMENT PANEL Temperature Control Mode Control (Air Direction) Rotate this control to regulate the tem- Rotate this control to choose from sev- perature of the air inside the passenger eral patterns of air distribution. You compartment. Rotating the dial left can select either a primary mode as into the blue area of the scale indicates identified by the symbols on the con-...
Page 253 UNDERSTANDING YOUR INSTRUMENT PANEL 251 NOTE: For all settings except full cold or full hot, there Defrost is a difference in temperature between the upper and Air is directed through the windshield and side lower outlets. The warmer air flows to the floor outlets. window demist outlets.
Page 254 252 UNDERSTANDING YOUR INSTRUMENT PANEL Recirculation Control The A/C will engage automatically to prevent fogging Pressing the Recirculation Control button will when the recirculation button is pressed and the mode temporarily put the system in recirculation control is set to panel or panel / floor. mode (ten minutes).
Page 255: Automatic Temperature Control (Atc) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 253 NOTE: The air conditioning compressor will not engage Automatic Temperature Control (ATC) — If until the engine has been running for about 10 seconds. Equipped MAX A/C For maximum cooling use the A/C and recirculation buttons at the same time.
Page 256 254 UNDERSTANDING YOUR INSTRUMENT PANEL The controls on the climate control provide the system 2. Dial in the temperature you would with operator input. Other sensors take account of ve- like the system to maintain by rotating hicle speed, A/C pressure, outside temperature, and the Temperature Control knob.
Page 257 UNDERSTANDING YOUR INSTRUMENT PANEL 255 NOTE: Blower Control The temperature setting can be adjusted at anytime For full automatic operation or for without affecting automatic operation. automatic blower operation turn the knob to AUTO position. In manual Pressing the Air Conditioning Control button while in mode there are six blower speeds that AUTO mode will cause the LED in the control button can be individual selected.
Page 258 256 UNDERSTANDING YOUR INSTRUMENT PANEL...
Page 259 UNDERSTANDING YOUR INSTRUMENT PANEL 257 The operator can override the AUTO mode setting to Floor change airflow distribution by rotating the Mode Control Air is directed through the floor outlets with a knob (on the right) to one of the following positions. small amount flowing through the defrost and side window demist outlets.
Page 260 258 UNDERSTANDING YOUR INSTRUMENT PANEL Air Conditioner Control NOTE: Press this button to turn on the air conditioning When the ignition switch is turned to the LOCK during manual operation only. When the air con- position, the recirculation feature will be cancelled. ditioning is turned on, cool dehumidified air will In cold weather, use of the Recirculation mode may flow through the outlets selected with the Mode control...
Page 261: Operating Tips
UNDERSTANDING YOUR INSTRUMENT PANEL 259 Most of the time, when in Automatic Operation, you Summer Operation can temporarily put the system into Recirculation The engine cooling system in air-conditioned vehicles Mode by pressing the Recirculation Button. However, must be protected with a high-quality antifreeze coolant to provide proper corrosion protection and to protect under certain conditions, while in Automatic Mode, against engine overheating.
Page 262 260 UNDERSTANDING YOUR INSTRUMENT PANEL Window Fogging Outside Air Intake Interior fogging on the windshield can be quickly re- Make sure the air intake, located directly in front of the moved by turning the mode selector to Defrost. The windshield, is free of obstructions such as leaves. Leaves Defrost/Floor mode can be used to maintain a clear collected in the air intake may reduce airflow, and if they windshield and provide sufficient heating.
Page 263 UNDERSTANDING YOUR INSTRUMENT PANEL 261 Control Setting Suggestions for Various Weather Conditions...
Page 265: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ....267 Brake/Transaxle Interlock System ..271 Normal Starting .
Page 266 264 STARTING AND OPERATING Traction ......278 Brake Assist System (BAS) ....292 Driving Through Water .
Page 267 STARTING AND OPERATING 265 Tread Wear Indicators ....311 Reformulated Gasoline ....326 Life Of Tire .
Page 268 266 STARTING AND OPERATING Starting ......332 Trailer Towing ......338 Cruising Range .
Page 269: Starting Procedures
STARTING AND OPERATING 267 STARTING PROCEDURES WARNING! (Continued) Before starting your vehicle, adjust your seat, adjust both Be sure to turn off the engine and remove the key inside and outside mirrors, and fasten your seat belt. from the ignition switch if you want to rest or Make sure all occupants have securely fastened their seat sleep in your car.
Page 270: Tip Start Feature
268 STARTING AND OPERATING Tip Start Feature If Engine Fails to Start Do not press the accelerator. Turn the ignition key briefly WARNING! to START position, and release it. The starter motor will continue to run, and it will disengage automatically Never pour fuel or other flammable liquid into the when the engine is running.
Page 271: After Starting
STARTING AND OPERATING 269 If the engine fails to start after you have followed the ENGINE BLOCK HEATER — IF EQUIPPED “Normal Starting” or “Extreme Cold Weather” proce- The engine block heater warms the engine, and permits dures, it may be flooded. To clear any excess fuel, push quicker starts in cold weather.
Page 272: Automatic Transaxle
270 STARTING AND OPERATING AUTOMATIC TRANSAXLE NOTE: You MUST press and hold the brake pedal down while shifting the shift lever out of PARK. CAUTION! WARNING! Damage to the transaxle may occur if the following precautions are not observed: It is dangerous to move the shift lever out of or if the engine speed is higher than idle speed.
Page 273: Brake/Transaxle Interlock System
STARTING AND OPERATING 271 NOTE: If a malfunction occurs, the transaxle will not WARNING! (Continued) shift out of PARK. Battery power is required to release the Unintended movement of a vehicle could injure Brake/Transaxle Interlock system. However, an override those in and near the vehicle. As with all vehicles, system allows you to shift out of PARK in case of loss of you should never exit a vehicle while the engine is power.
Page 274: Automatic Transaxle Ignition Interlock System
272 STARTING AND OPERATING NOTE: If this occurs, even if the override is successful, 4 Speed/6 Speed Automatic Transaxle it is recommended that you visit a dealer at your earliest The electronically controlled transaxle provides a precise possible convenience. Your dealer has diagnostic equip- shift schedule.
Page 275 STARTING AND OPERATING 273 Gear Ranges WARNING! PARK Never use PARK as a substitute for the parking Supplements the parking brake by locking the transaxle. brake. Always apply parking brake fully when The engine can be started in this range. Never attempt to parked to guard against vehicle movement and pos- use PARK while vehicle is in motion.
Page 276 274 STARTING AND OPERATING NEUTRAL conditions, reducing shifting by selecting the appropriate Engine may be started in this range. gear in AutoStick will improve the performance and extend transmission life by reducing excessive shifting WARNING! and heat build-up. DRIVE – 4 Speed Transaxle Do not coast in NEUTRAL and never turn off the This range should be used for most city and highway ignition to coast down a hill.
Page 277 STARTING AND OPERATING 275 DRIVE 3 — 4 Speed Transaxle CAUTION! This range eliminates shifts into fourth gear. The trans- axle will operate normally in first and second gear. Shifts If the transaxle operating temperature exceeds ac- into third gear may be delayed to provide second gear ceptable limits, the vehicle computer will override operation at higher speeds.
Page 278: Autostick - If Equipped
276 STARTING AND OPERATING In the event of a momentary problem, the transaxle can AUTOSTICK — IF EQUIPPED be reset to regain all forward gears by performing the AutoStick is a driver-interactive transaxle that offers six following steps: manual ratio changes to provide you with more control. AutoStick allows you to maximize engine braking, 1.
Page 279: General Information
STARTING AND OPERATING 277 NOTE: In Autostick mode, the transaxle will only shift Avoid using speed control when Autostick is en- up or down when the driver moves the shift lever to the gaged. right (+) or left (-). The transaxle will automatically shift up when maxi- AutoStick is deactivated when the shift lever is moved mum engine speed is reached while Autostick from the AutoStick (+/-) position into the DRIVE...
Page 280: Driving On Slippery Surfaces
278 STARTING AND OPERATING DRIVING ON SLIPPERY SURFACES Traction When driving on wet or slushy roads, it is possible for a Acceleration wedge of water to build up between the tire and road Rapid acceleration on snow covered, wet, or other slip- surface.
Page 281: Driving Through Water
STARTING AND OPERATING 279 DRIVING THROUGH WATER Shallow Standing Water Driving through water more than a few inches/ Although your vehicle is capable of driving through centimeters deep will require extra caution to ensure shallow standing water, consider the following Caution safety and prevent damage to your vehicle.
Page 282 280 STARTING AND OPERATING CAUTION! (Continued) WARNING! Driving through standing water may cause dam- Driving through standing water limits your vehi- age to your vehicle’s drivetrain components. Al- cle’s traction capabilities. Do not exceed 5 mph ways inspect your vehicle’s fluids (i.e., engine oil, (8 km/h) when driving through standing water.
Page 283: Power Steering
STARTING AND OPERATING 281 POWER STEERING WARNING! The standard power steering system will give you good vehicle response and increased ease of maneuverability Continued operation with reduced power steering in tight spaces. The system will provide mechanical assist could pose a safety risk to yourself and others. steering capability if power assist is lost.
Page 284: Power Steering Fluid Check
282 STARTING AND OPERATING Power Steering Fluid Check If necessary, add fluid to restore to the proper indicated Checking the power steering fluid level at a defined level. With a clean cloth, wipe any spilled fluid from all service interval is not required. The fluid should only be surfaces.
Page 285 STARTING AND OPERATING 283 When parking on a flat surface, place the shift lever in the PARK position first, and then apply the parking brake. When parking on a hill, it is important to apply the parking brake before placing the shift lever in PARK, otherwise the load on the transaxle locking mechanism may make it difficult to move the shift lever out of PARK.
Page 286 284 STARTING AND OPERATING If the parking brake is applied while the vehicle is WARNING! moving, a chime will sound to alert the driver. The chime will sound up to 10 times or until the vehicle Never leave children alone in a vehicle. Leaving has returned to a stop.
Page 287: Brake System
STARTING AND OPERATING 285 BRAKE SYSTEM WARNING! Your vehicle is equipped with dual hydraulic brake systems. If either of the two hydraulic Riding the brakes can lead to brake failure and systems loses normal capability, the remaining possibly an accident. Driving with your foot rest- system will still function.
Page 288: Anti-Lock Brake System - If Equipped
286 STARTING AND OPERATING The ABS motor running (it may continue to run for a Anti-Lock Brake System — If Equipped The Anti-Lock Brake System (ABS) provides increased short time after the stop), vehicle stability and brake performance under most The clicking sound of solenoid valves, braking conditions.
Page 289 STARTING AND OPERATING 287 WARNING! (Continued) WARNING! (Continued) Pumping of the Anti-Lock Brakes will diminish The capabilities of an ABS equipped vehicle must their effectiveness and may lead to an accident. never be exploited in a reckless or dangerous Pumping makes the stopping distance longer. Just manner, which could jeopardize the user’s safety press firmly on your brake pedal when you need or the safety of others.
Page 290: Anti-Lock Brake System (Abs)
288 STARTING AND OPERATING If the Anti-Lock Brake Light remains on or comes on ANTI—LOCK BRAKE SYSTEM (ABS) while driving, it indicates that the Anti-Lock portion of The Anti-Lock Brake System (ABS) provides increased the brake system is not functioning and that service is vehicle stability and brake performance under most required.
Page 291 STARTING AND OPERATING 289 The ABS light monitors the Anti-Lock Brake WARNING! (Continued) System. The light will come on when the The ABS cannot prevent the natural laws of phys- ignition switch is turned to the ON position ics from acting on the vehicle, nor can it increase and may stay on for as long as four seconds.
Page 292 290 STARTING AND OPERATING If both the Brake Warning Light and the ABS Light The ABS motor running (it may continue to run for a remain on, the Anti-Lock brakes (ABS) and Electronic short time after the stop), Brake Force Distribution (EBD) systems are not function- the clicking sound of solenoid valves, ing.
Page 293: Electronic Brake Control System
STARTING AND OPERATING 291 All vehicle wheels and tires must be the same size and Traction Control System (TCS) type and tires must be properly inflated to produce This system monitors the amount of wheel spin accurate signals for the computer. of each of the driven wheels.
Page 294: Brake Assist System (Bas)
292 STARTING AND OPERATING Brake Assist System (BAS) WARNING! The BAS is designed to optimize the vehicle’s braking capability during emergency braking maneuvers. The BAS cannot prevent the natural laws of physics system detects an emergency braking situation by sens- from acting on the vehicle, nor can it increase ing the rate and amount of brake application and then braking efficiency beyond that afforded by the...
Page 295: Electronic Stability Program (Esp)
STARTING AND OPERATING 293 Electronic Stability Program (ESP) ESP/TCS Indicator Light The “ESP/TCS Indicator Light, located in the instrument This system enhances directional control and stability of cluster, starts to flash as soon as the tires lose traction and the vehicle under various driving conditions. ESP cor- the ESP system becomes active.
Page 296 294 STARTING AND OPERATING This mode should be used for almost all driving situa- WARNING! (Continued) tions. ESP should only be turned to Partial Off for specific ESP cannot prevent accidents, including those reasons as noted below. resulting from excessive speed in turns, driving on Partial ESP Mode very slippery surfaces, or hydroplaning.
Page 297 STARTING AND OPERATING 295 ESP/BAS Warning Light and ESP/TCS Indicator WARNING! Light The malfunction indicator for the ESP is com- In the Partial ESP mode, the engine torque reduction bined with the BAS indicator. The yellow ESP/ and stability features are desensitized. Therefore, the BAS Warning Light and the yellow ESP/TCS enhanced vehicle stability offered by ESP is unavail- Indicator Light in the instrument cluster both...
Page 298: Tire Safety Information
296 STARTING AND OPERATING NOTE: TIRE SAFETY INFORMATION The ESP Indicator Light and the ESP/BAS Warning Tire Markings Light come on momentarily each time the ignition switch is turned ON. Each time the ignition is turned ON, the ESP System will be ON even if it was turned off previously.
Page 299 STARTING AND OPERATING 297 NOTE: Temporary spare tires are high-pressure compact P (Passenger) - Metric tire sizing is based on U.S. spares designed for temporary emergency use only. design standards. P-Metric tires have the letter “P” Tires designed to this standard have the letter “T” molded into the sidewall preceding the size designa- molded into the sidewall preceding the size designa- tion.
Page 300 298 STARTING AND OPERATING Tire Sizing Chart EXAMPLE: Size Designation: P = Passenger car tire size based on U.S. design standards ..blank..= Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 301 STARTING AND OPERATING 299 EXAMPLE: Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 302: Tire Identification Number (Tin)
300 STARTING AND OPERATING Look for the TIN on the outboard side of black sidewall Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on the outboard side, then you will find it on the inboard however, the date code may only be on one side.
Page 303: Tire Loading And Tire Pressure
STARTING AND OPERATING 301 Tire Loading and Tire Pressure This placard tells you important information about the: Tire Placard Location 1) number of people that can be carried in the vehicle NOTE: The proper cold tire inflation pressure is listed 2) total weight your vehicle can carry on the driver’s side B-Pillar.
Page 304 302 STARTING AND OPERATING NOTE: Under a maximum loaded vehicle condition, 2. Determine the combined weight of the driver and gross axle weight ratings (GAWRs) for the front and rear passengers that will be riding in your vehicle. axles must not be exceeded. For further information on 3.
Page 305 STARTING AND OPERATING 303 6. If your vehicle will be towing a trailer, load from your and number and size of occupants. This table is for trailer will be transferred to your vehicle. Consult this illustration purposes only and may not be accurate for manual to determine how this reduces the available the seating and load carry capacity of your vehicle.
Page 306 304 STARTING AND OPERATING...
Page 307: Tires - General Information
STARTING AND OPERATING 305 Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause accidents. recommended load capacity for your vehicle. Never Under inflation increases tire flexing and can result overload them.
Page 308: Tire Inflation Pressures
306 STARTING AND OPERATING Tire Inflation Pressures WARNING! (Continued) The proper cold tire inflation pressure is listed on the Unequal tire pressures from one side of the vehicle driver’s side “B” Pillar. to the other can cause the vehicle to drift to the right Some vehicles may have Supplemental Tire Pressure or left.
Page 309 STARTING AND OPERATING 307 Tire pressures change by approximately 1 psi (7 kPa) per CAUTION! 12° F (7° C) of air temperature change. Keep this in mind when checking tire pressure inside a garage, especially in After inspecting or adjusting the tire pressure, al- the winter.
Page 310: Radial-Ply Tires
308 STARTING AND OPERATING Tire Pressures for High Speed Operation Radial-Ply Tires The manufacturer advocates driving at safe speeds WARNING! within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high Combining radial ply tires with other types of tires speeds, maintaining correct tire inflation pressure is very on your vehicle will cause your vehicle to handle...
Page 311: Compact Spare Tire - If Equipped
STARTING AND OPERATING 309 Compact Spare Tire — If Equipped CAUTION! The compact spare is for temporary emergency use with radial tires. It is engineered to be used on your style Prolonged use of limited use spare, or an incorrect vehicle only.
Page 312: Limited Use Spare - If Equipped
310 STARTING AND OPERATING Limited Use Spare — If Equipped WARNING! The limited use spare tire is for temporary emergency use on your vehicle. This tire is identified by a limited use The limited use spare tires are for emergency use spare tire warning label located on the limited use spare only.
Page 313: Tire Spinning
STARTING AND OPERATING 311 Tire Spinning Tread Wear Indicators When stuck in mud, sand, snow, or ice conditions, do not Tread wear indicators are in the original equipment tires spin your vehicle’s wheels faster than 30 mph (48 km/h) to help you in determining when your tires should be or for longer than 30 seconds continuously without replaced.
Page 314: Life Of Tire
312 STARTING AND OPERATING These indicators are molded into the bottom of the tread WARNING! grooves. They will appear as bands when the tread depth becomes approximately 1/16 in (2 mm). When the tread Tires and spare tire should be replaced after six years, is worn to the tread wear indicators, the tire should be regardless of the remaining tread.
Page 315 STARTING AND OPERATING 313 Information” placard for the size designation of your tire. WARNING! The service description and load identification will be found on the original equipment tire. Failure to use Do not use a tire, wheel size or rating other than equivalent replacement tires may adversely affect the that specified for your vehicle.
Page 316: Tire Chains
314 STARTING AND OPERATING WARNING! (Continued) CAUTION! Failure to equip your vehicle with tires having Damage to the vehicle may result if tire chains are adequate speed capability can result in sudden tire used. failure and loss of vehicle control. SNOW TIRES CAUTION! Snow tires should be of the same size and type construc-...
Page 317: Tire Rotation Recommendations
STARTING AND OPERATING 315 TIRE ROTATION RECOMMENDATIONS Tires on the front and rear axles of vehicles operate at different loads and perform different steering, driving, and braking functions. For these reasons, they wear at unequal rates and tend to develop irregular wear pat- terns.
Page 318: Tire Pressure Monitor System (Tpms)
316 STARTING AND OPERATING TIRE PRESSURE MONITOR SYSTEM (TPMS) pressure will also increase as the vehicle is driven - this is normal and there should be no adjustment for this The Tire Pressure Monitor System (TPMS) will warn increased pressure. the driver of a low tire pressure based on the vehicle recommended cold placard pressure.
Page 319 STARTING AND OPERATING 317 once the system receives the updated tire pressures. CAUTION! The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) in order for the TPMS to The TPMS has been optimized for the original receive this information.
Page 320: Base System
318 STARTING AND OPERATING NOTE: Seasonal temperature changes will affect tire pressure, The TPMS is not intended to replace normal tire care and the TPMS will monitor the actual tire pressure in and maintenance, or to provide warning of a tire the tire.
Page 321 STARTING AND OPERATING 319 Tire Pressure Monitoring Low Pressure Warnings repeat, providing the system fault still exists. The Tire The Tire Pressure Monitoring Telltale Light will Pressure Monitoring Telltale Light will turn off when the illuminate in the instrument cluster and a chime fault condition no longer exists.
Page 322: Premium System - If Equipped
320 STARTING AND OPERATING NOTE: Light will turn OFF, as long no tire pressure is below the 1. The compact spare tire (if so equipped) does not have low-pressure warning limit in any of the four active road a tire pressure monitoring sensor. Therefore, the TPMS tires.
Page 323 STARTING AND OPERATING 321 Three Trigger Modules (mounted in three of the four wheel-wells) Various Tire Pressure Monitoring System Messages, which display in the Electronic Vehicle Information Center (EVIC) Tire Pressure Monitoring Telltale Light Tire Pressure Monitoring Low Pressure Warnings The Tire Pressure Monitoring Telltale Light will illuminate in the instrument cluster and a chime will sound when tire pressure is low in one or...
Page 324 322 STARTING AND OPERATING Should this occur, you should stop as soon as possible, (- -) in place of the pressure value to indicate which and inflate all tires with low pressure (those flashing in sensor is not being received. the EVIC graphic) to the vehicle’s recommended cold placard pressure value.
Page 325 STARTING AND OPERATING 323 If the ignition key is cycled, this sequence will repeat, NOTE: providing the system fault still exists. If the system fault 1. The compact spare tire (if so equipped) does not have no longer exists, the Tire Pressure Monitoring Telltale a tire pressure monitoring sensor.
Page 326: General Information
324 STARTING AND OPERATING 4. For each subsequent ignition key cycle, a chime will General Information sound, the TPM Telltale Light will flash on and off for This device complies with part 15 of the FCC rules and 75 seconds and then remain on solid, and the EVIC will RSS 210 of Industry Canada.
Page 327: Fuel Requirements
STARTING AND OPERATING 325 FUEL REQUIREMENTS using high-quality unleaded gasoline having an octane range of 89. The manufacturer recommends the use of 2.4L and 2.7L Engine 89 octane for optimum performance. The use of premium The 2.4L and 2.7L engines are designed to gasoline is not recommended.
Page 328: Reformulated Gasoline
326 STARTING AND OPERATING Over 40 automobile manufacturers around the world Gasoline/Oxygenate Blends have issued and endorsed consistent gasoline specifica- Some fuel suppliers blend unleaded gasoline with oxy- tions (the World Wide Fuel Charter, WWFC) which genates such as 10% ethanol, MTBE, and ETBE. Oxygen- define fuel properties necessary to deliver enhanced ates are required in some areas of the country during the emissions, engine performance, and durability for your...
Page 329: E-85 Usage In Non-Flex Fuel Vehicles
STARTING AND OPERATING 327 Problems that result from using methanol/gasoline or To fix a Non-FFV vehicle inadvertently fueled once with E85 Ethanol blends are not the responsibility of the E-85 perform the following: manufacturer. While MTBE is an oxygenate made from drain the fuel tank (see your authorized dealer) Methanol, it does not have the negative effects of Methanol.
Page 330: Materials Added To Fuel
328 STARTING AND OPERATING of gasoline may not be indicated on the gasoline pump, Fuel System Cautions therefore, you should ask your gasoline retailer whether CAUTION! or not his/her gasoline contains MMT. It is even more important to look for gasolines without Follow these guidelines to maintain your vehicle’s MMT in Canada, because MMT can be used at levels performance:...
Page 331: Carbon Monoxide Warnings
STARTING AND OPERATING 329 The use of fuel additives, which are now being sold as Do not inhale exhaust gases. They contain carbon octane enhancers, is not recommended. Most of these monoxide, a colorless and odorless gas, which can kill. products contain high concentrations of methanol.
Page 332: Flexible Fuel- 2.7L Only (Except California Emission States)
330 STARTING AND OPERATING FLEXIBLE FUEL— 2.7L ONLY (EXCEPT CALIFORNIA EMISSION STATES) E-85 General Information The information in this section is for Flexible Fuel ve- hicles only. This section only covers those subjects that are unique to these vehicles. Please refer to the other sections of this manual for information on features that are common between Flexible Fuel and gasoline only powered vehicles.
Page 333: Ethanol Fuel (E-85)
STARTING AND OPERATING 331 Along with the special E-85 fuel filler cap, your vehicle WARNING! may display a badge, which also indicates it can operate on E-85. Ethanol vapors are extremely flammable and could cause serious personal injury. Never have any smok- ing materials lit in or near the vehicle when remov- ing the fuel filler tube cap (gas cap) or filling the tank.
Page 334: Selection Of Engine Oil For Flexible Fuel Vehicles (E-85) And Gasoline Vehicles
When you do switch fuel types it is recommended that: in MOPAR engine oils, and in equivalent oils meeting Chrysler Specification MS-6395. The manufacturer only you do not add less than 5 gal (19 L) when refueling recommends engine oils that are API Certified and meet you drive the vehicle immediately after refueling for at the requirements of Material Standard MS-6395.
Page 335: Cruising Range
STARTING AND OPERATING 333 Cruising Range Maintenance Because E-85 fuel contains less energy per gallon than CAUTION! gasoline, you will experience an increase in fuel con- sumption. You can expect your fuel economy and driving Do not use ethanol mixture greater than 85% in your range to decrease by about 30% compared to gasoline vehicle.
Page 336 334 STARTING AND OPERATING The gas cap is behind the fuel filler door, on the left rear After removing the gas cap, place the gas cap tether cable quarter panel of the vehicle. If the gas cap is lost or over a hook on the inside of the fuel door.
Page 337 STARTING AND OPERATING 335 CAUTION! WARNING! Damage to the fuel system or emission control Never have any smoking materials lit in or near system could result from using an improper fuel the vehicle when the gas cap is removed or the tank filler tube cap (gas cap).
Page 338: Loose Filler Cap Message
336 STARTING AND OPERATING NOTE: indicate a damaged cap. If the problem is detected twice Tighten the gas cap until you hear a “clicking” sound. in a row, the system will turn on the Malfunction This is an indication that the gas cap is tightened Indicator Light (MIL).
Page 339: Gross Vehicle Weight Rating (Gvwr)
STARTING AND OPERATING 337 Type of Vehicle WARNING! Month Day and Hour of Manufacture (MDH) Because the front wheels steer the vehicle, it is The bar code allows a computer scanner to read the important that you do not exceed the maximum front Vehicle Identification Number (VIN).
Page 340: Loading
338 STARTING AND OPERATING Figure out the weight on the front and rear of the vehicle TRAILER TOWING separately. It is important that you distribute the load In this section, you will find safety tips and information evenly over the front and rear axles. on limits to the type of towing you can reasonably do with your vehicle.
Page 341 STARTING AND OPERATING 339 Gross Vehicle Weight Rating (GVWR) Gross Axle Weight Rating (GAWR) The GVWR is the total allowable weight of your vehicle. The GAWR is the maximum capacity of the front and rear This includes driver, passengers, cargo, and tongue axles.
Page 342: Trailer Hitch Classification
340 STARTING AND OPERATING Frontal Area Trailer Hitch Classification The frontal area is the maximum height and maximum Max. GTW Class width of the front of a trailer and its cargo. (Gross Trailer Wt.) Class I - Light Duty 2,000 lbs (907 kg) Weight-Carrying Hitch A weight-carrying hitch supports the trailer tongue Refer to the “Trailer Towing Weights (Maximum...
Page 343: Trailer Towing Weights (Maximum Trailer Weight Ratings)
Tire cylinder and 2.7L engines with automatic transaxle. and Loading Information placard. Refer to “Tire Safety Please refer to the following website, http://www- Information” in Section 5 of this manual. 5.chrysler.com/searchapp/ui.jsp or your authorized dealer for additional information.
Page 344: Trailer And Tongue Weight
342 STARTING AND OPERATING CAUTION! Towing a trailer with a larger than recommended frontal area could cause the engine to overheat or cause severe engine damage under extreme condi- tions. Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer.
Page 345: Towing Requirements
STARTING AND OPERATING 343 NOTE: Remember that everything put into or on the Towing Requirements trailer adds to the load on your vehicle. Also, additional To promote proper break-in of your new vehicle driv- factory-installed options, or authorized dealer-installed etrain components the following guidelines are recom- options, must be considered as part of the total load on mended: your vehicle.
Page 346 344 STARTING AND OPERATING Safety chains must always be used between your WARNING! vehicle and trailer. Always connect the chains to the frame or hook retainers of the vehicle hitch. Cross the Improper towing can lead to an injury accident. chains under the trailer tongue and allow enough Follow these guidelines to make your trailer tow- slack for turning corners.
Page 347 STARTING AND OPERATING 345 4. Trailer tongue weight rating for the trailer hitch When replacing tires, refer to “Tires — General Infor- utilized (This requirement may limit the ability to mation” in this section for information on replacement always achieve 10% of trailer tongue weight as a tires and for proper tire replacement procedures.
Page 348: Towing Tips
346 STARTING AND OPERATING CAUTION! WARNING! (Continued) Towing any trailer will increase your stopping If the trailer weighs more than 1,000 lbs (450 kg) distance. When towing, you should allow for ad- loaded, it should have its own brakes with adequate ditional space between your vehicle and the ve- braking capacity.
Page 349 STARTING AND OPERATING 347 Automatic Transaxle NOTE: Check the four-speed automatic transaxle fluid The DRIVE range can be selected when towing. How- level before towing. AutoStick six—speed transmission ever, if frequent shifting occurs while in this range, third is sealed and the fluid level cannot be checked. See your gear for a four-speed automatic and the fifth gear for a authorized dealership service center for assistance.
Page 350: Recreational Towing (Behind Motorhome, Etc.)
348 STARTING AND OPERATING Cooling System RECREATIONAL TOWING (BEHIND To reduce potential for engine and transaxle overheating, MOTORHOME, ETC.) take the following actions: Towing This Vehicle Behind Another Vehicle (Flat City Driving towing with all four wheels on the ground) When stopped for short periods of time, put transaxle in CAUTION! neutral and increase engine idle speed.
Page 351: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....350 Jump-Starting Procedure ....360 If Your Engine Overheats .
Page 352: Hazard Warning Flasher
350 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER NOTE: With extended use, the Hazard Warning flasher The Hazard Warning flasher switch is located on the may wear down your battery. instrument panel, below the radio. IF YOUR ENGINE OVERHEATS Press the switch to turn on the Hazard In any of the following situations, you can reduce the Warning flashers.
Page 353 WHAT TO DO IN EMERGENCIES 351 NOTE: There are steps that you can take to slow down CAUTION! an impending overheat condition. If your air conditioner is on, turn it off. The air conditioning system adds heat to Driving with a hot cooling system could damage the engine cooling system and turning off the A/C your vehicle.
Page 354: Engine Oil Overheating (2.4L Engine Only) - If Equipped
352 WHAT TO DO IN EMERGENCIES NOTE: The vehicle speed is reduced to a maximum of WARNING! 53 mph (85 km/h). You may of course, reduce your vehicle speed further if needed. A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling JACKING AND TIRE CHANGING coolant.
Page 355: Jack Location
WHAT TO DO IN EMERGENCIES 353 Spare Tire Removal WARNING! (Continued) Lift up the load floor cover and remove the hold down. The jack is designed to use as a tool for changing tires only. The jack should not be used to lift the vehicle for service purposes.
Page 356: Preparations For Jacking
354 WHAT TO DO IN EMERGENCIES Preparations For Jacking 4. Turn OFF the ignition. 1. Park the vehicle on a firm level surface. Avoid ice or 5. Turn on the Hazard Warning Flasher. slippery areas. 6. Block both the front and rear of the wheel diagonally opposite the jacking WARNING! position.
Page 357: Jacking Instructions
WHAT TO DO IN EMERGENCIES 355 Jacking Instructions WARNING! (Continued) Do not get under the vehicle when it is on a jack. WARNING! Only use the jack in the positions indicated and Carefully follow these tire changing warnings to help for lifting this vehicle during a tire change.
Page 358 356 WHAT TO DO IN EMERGENCIES 1. Remove the scissors jack and lug wrench from the spare wheel as an assembly. Turn the jack screw to the left to loosen the lug wrench, and remove the wrench from the jack assembly. NOTE: The jack handle attaches to the side of the jack with two attachment points.
Page 359 WHAT TO DO IN EMERGENCIES 357 Jacking Locations...
Page 360 358 WHAT TO DO IN EMERGENCIES CAUTION! WARNING! Do not attempt to raise the vehicle by jacking on Raising the vehicle higher than necessary can make locations other than those indicated in step 3. the vehicle less stable. It could slip off the jack and hurt someone near it.
Page 361 WHAT TO DO IN EMERGENCIES 359 WARNING! WARNING! To avoid possible personal injury, handle the wheel A loose tire or jack thrown forward in a collision or covers with care to avoid contact with any sharp hard stop could endanger the occupants of the ve- edges.
Page 362: Jump-Starting Procedure
360 WHAT TO DO IN EMERGENCIES JUMP-STARTING PROCEDURE WARNING! (Continued) The battery is stored between the left front headlight Do not attempt to push or tow your vehicle to get assembly and the left front wheel splash shield. Access is it started.
Page 363 WHAT TO DO IN EMERGENCIES 361 2. When boosting from a battery in another vehicle, park 5. Connect the other cable, first to the negative terminal that vehicle within booster cable reach, but without of the booster battery and then to the engine ground (-) allowing the vehicles to touch.
Page 364 362 WHAT TO DO IN EMERGENCIES 6. If the vehicle is equipped with Sentry Key Immobi- WARNING! lizer, turn the ignition switch to the ON position for three seconds before moving the ignition switch to the START During cold weather when temperatures are below position.
Page 365: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES 363 NOTE: WARNING! If your vehicle is equipped with Traction Con- Any procedure other than above could result in: trol, turn the system to Partial OFF before Personal injury caused by electrolyte squirting out attempting to “rock” the vehicle. Refer to “Par- the battery vent;...
Page 366: Towing A Disabled Vehicle
364 WHAT TO DO IN EMERGENCIES than 15 miles (25 km), the vehicle must be transported CAUTION! either with a flat bed truck or with the front wheels off the ground. Racing the engine or spinning the wheels too fast may lead to transaxle overheating and failure.
Page 367: Towing Without The Ignition Key
WHAT TO DO IN EMERGENCIES 365 Towing Without The Ignition Key Towing This Vehicle Behind Another Vehicle With Special care must be taken when the vehicle is towed A Tow Dolly with the ignition in the LOCK position. Flatbed towing is Rear towing is not recommended with the front wheels the preferred towing method.
Page 368 366 WHAT TO DO IN EMERGENCIES Battery power is required to release the brake/transaxle Insert a key, screwdriver, or similar object into the interlock system. There is an override system that allows front hole then push and hold the manual override you to shift out of PARK in case of loss of power.
Page 369: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 2.4L ... . . 369 Maintenance Procedures ....375 Engine Compartment —...
Page 370 368 MAINTAINING YOUR VEHICLE Adding Washer Fluid ....385 Bulb Replacement ..... 411 Exhaust System .
Page 371: Engine Compartment - 2.4L
MAINTAINING YOUR VEHICLE 369 ENGINE COMPARTMENT — 2.4L 1 — Engine Coolant Reservoir 7 — Air Cleaner Filter 2 — Power Steering Fluid Reservoir 8 — Engine Oil Fill 3 — Automatic Transaxle Dipstick 9 — Coolant Pressure Cap 4 — Brake Fluid Reservoir 10 —...
Page 372: Engine Compartment - 2.7L
370 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 2.7L 1 — Engine Coolant Reservoir 7 — Power Distribution Center 2 — Coolant Pressure Cap 8 — Air Cleaner Filter 3 — Power Steering Fluid Reservoir 9 — Engine Oil Dipstick 4 — Automatic Transaxle Dipstick 10 —...
Page 373: Engine Compartment - 3.5L
MAINTAINING YOUR VEHICLE 371 ENGINE COMPARTMENT — 3.5L 1 — Engine Coolant Reservoir 6 — Air Cleaner Filter 2 — Coolant Pressure Cap 7 — Engine Oil Dipstick 3 — Power Steering Fluid Reservoir 8 — Engine Oil Fill 4 — Brake Fluid Reservoir 9 —...
Page 374: Onboard Diagnostic System - Obd Ii
372 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated Onboard Diagnostic system called OBD II. This system monitors Prolonged driving with the “Malfunction Indica- the performance of the emissions, engine, and automatic tor Light”...
Page 375: Emissions Inspection And Maintenance Programs
MAINTAINING YOUR VEHICLE 373 the gas cap is properly tightened. Press the trip odometer Normally, the OBD II system will be ready. The OBD II “Reset” button to turn off the message. If the problem system may not be ready if your vehicle was recently persists, the message will appear the next time the serviced, recently had a dead battery or a battery replace- vehicle is started.
Page 376: Replacement Parts
374 MAINTAINING YOUR VEHICLE 5. Approximately 15 seconds later, one of two things will Regardless of whether your vehicle’s OBD II system is happen: ready or not, if the MIL is illuminated during normal vehicle operation you should have your vehicle serviced a.
Page 377: Dealer Service
MAINTAINING YOUR VEHICLE 375 DEALER SERVICE MAINTENANCE PROCEDURES Your authorized dealer has the qualified service person- The pages that follow contain the required maintenance nel, special tools, and equipment to perform all service services determined by the engineers who designed your operations in an expert manner.
Page 378 376 MAINTAINING YOUR VEHICLE The best time to check the engine oil level is about CAUTION! 5 minutes after a fully warmed engine is shut off. Do not check oil level before starting the engine after it has sat Do not overfill the engine. Overfilling the engine overnight.
Page 379 API Certified and meet the temperatures. This engine oil improves low temperature requirements of Chrysler Material Standard MS-6395. starting and vehicle fuel economy. Your engine oil filler cap also shows the recommended engine oil viscosity for American Petroleum Institute (API) Engine Oil your vehicle.
Page 380 378 MAINTAINING YOUR VEHICLE Engine Oil Viscosity (SAE Grade) — 3.5L Engine Synthetic Engine Oils SAE 10W-30 engine oil is preferred for all operating You may use synthetic engine oils provided the recom- temperatures. The engine oil filler cap also shows the mended oil quality requirements are met, and the recom- recommended engine oil viscosity for your vehicle.
Page 381: Engine Oil Filter
MAINTAINING YOUR VEHICLE 379 station, or governmental agency for advice on how and Engine Air Cleaner Filter where used oil and oil filters can be safely discarded in WARNING! your area. Engine Oil Filter The air induction system (air cleaner, hoses, etc.) can The engine oil filter should be replaced at every engine provide a measure of protection in the case of engine oil change.
Page 382: Maintenance-Free Battery
380 MAINTAINING YOUR VEHICLE Engine Air Cleaner Filter Selection WARNING! The quality of replacement engine air cleaner filters varies considerably. Only high quality filters should be Battery fluid is a corrosive acid solution and can used to assure most efficient service. MOPAR engine air burn or even blind you.
Page 383: Air Conditioner Maintenance
MAINTAINING YOUR VEHICLE 381 at the start of each warm season. This service should CAUTION! include cleaning of the condenser fins and a performance test. It is essential when replacing the cables on the battery that the positive cable is attached to the WARNING! positive post and the negative cable is attached to the negative post.
Page 384: A/C Air Filter - If Equipped
382 MAINTAINING YOUR VEHICLE Refrigerant Recovery and Recycling The A/C Air Filter is located in the fresh air inlet behind R-134a air conditioning refrigerant is a hydrofluoro- the glove box. Perform the following procedure to re- carbon (HFC) that is endorsed by the Environmental place the filter: Protection Agency and is an ozone-saving product.
Page 385 MAINTAINING YOUR VEHICLE 383 4. Pivot the glove box downward. 6. Remove the A/C Air Filter by pulling it straight out of the housing. 5. Disengage the two retaining tabs that secure the filter cover to the HVAC housing and remove the cover. 7.
Page 386: Body Lubrication
384 MAINTAINING YOUR VEHICLE Body Lubrication Windshield Wiper Blades Locks and all body pivot points, including such items as Clean the rubber edges of the wiper blades and the seat tracks, door hinge pivot points and rollers, liftgate, windshield periodically with a sponge or soft cloth and a tailgate, sliding doors and hood hinges, should be lubri- mild non-abrasive cleaner or use the washer solvent.
Page 387: Adding Washer Fluid
MAINTAINING YOUR VEHICLE 385 NOTE: Always refer to the wiper blade packaging for Exhaust System specific installation instructions. Many wiper blade re- The best protection against carbon monoxide entry into placements fit multiple vehicles. the vehicle body is a properly maintained engine exhaust system.
Page 388 386 MAINTAINING YOUR VEHICLE WARNING! CAUTION! Exhaust gases can injure or kill. They contain carbon Damage to the catalytic converter can result if your monoxide (CO) which is colorless and odorless. vehicle is not kept in proper operating condition. In Breathing it can make you unconscious and can the event of engine malfunction, particularly involv- eventually poison you.
Page 389 MAINTAINING YOUR VEHICLE 387 To minimize the possibility of catalyst damage: WARNING! Do not shut off the engine or interrupt the ignition A hot exhaust system can start a fire if you park over when the transaxle is in gear and the vehicle is in materials that can burn.
Page 390: Cooling System
388 MAINTAINING YOUR VEHICLE rusty in appearance, the system should be drained, Cooling System flushed, and refilled with fresh engine coolant (anti- WARNING! freeze). Check the front of the A/C condenser for any accumulation of bugs, leaves, etc. If dirty, clean by gently When working near the radiator cooling fan, dis- spraying water from a garden hose vertically down the connect the fan motor lead or turn the ignition...
Page 391 MAINTAINING YOUR VEHICLE 389 Selection Of Coolant CAUTION! (Continued) Use only the manufacturer’s recommended coolant. Re- Do not use water alone or alcohol-based engine fer to “Fluids, Lubricants, and Genuine Parts” in this coolant (antifreeze) products. Do not use addi- section for the correct fluid type.
Page 392 390 MAINTAINING YOUR VEHICLE Adding Coolant Mix a minimum solution of 50% HOAT engine coolant Your vehicle has been built with an improved engine (antifreeze) and distilled water. Use higher concentra- coolant (antifreeze) that allows extended maintenance tions (not to exceed 70%) if temperatures below 34 F intervals.
Page 393 MAINTAINING YOUR VEHICLE 391 Cooling System Pressure Cap WARNING! The cap must be fully tightened to prevent loss of engine coolant (antifreeze), and to ensure that engine coolant The warning words “DO NOT OPEN HOT” on (antifreeze) will return to the radiator from the coolant the cooling system pressure cap are a safety pre- recovery bottle.
Page 394 392 MAINTAINING YOUR VEHICLE Disposal of Used Engine Coolant 6 Cylinder Engines — the level of the engine coolant Used ethylene glycol based engine coolant (antifreeze) is (antifreeze) in the pressurized coolant bottle should be a regulated substance requiring proper disposal. Check between the “COLD”...
Page 395 MAINTAINING YOUR VEHICLE 393 humidity accumulating on the radiator and being vapor- Maintain engine coolant (antifreeze) concentration at ized when the thermostat opens, allowing hot engine 50% HOAT engine coolant (antifreeze) (minimum) coolant (antifreeze) to enter the radiator. and distilled water for proper corrosion protection of your engine, which contains aluminum components.
Page 396: Brake System
394 MAINTAINING YOUR VEHICLE Brake System Check the fluid level in the master cylinder when per- In order to assure brake system performance, all brake forming underhood services. system components should be inspected periodically. Clean the top of the master cylinder area before removing Refer to the “Maintenance Schedule”...
Page 397: Automatic Transaxle
MAINTAINING YOUR VEHICLE 395 WARNING! CAUTION! Overfilling the brake fluid reservoir can result in Do not allow petroleum base fluid to contaminate the spilling brake fluid on hot engine parts and the brake fluid, all brake seal components could be brake fluid catching fire.
Page 398 396 MAINTAINING YOUR VEHICLE Fluid Level Check — Vehicles with 2.4L and 2.7L driven at least 15 miles (24 km). Hot fluid cannot be held Engines comfortably between the fingertips. Cold fluid is at a Use the following procedure to check the automatic temperature below 80°F (27°...
Page 399 MAINTAINING YOUR VEHICLE 397 Fluid Level Check — Vehicles with 3.5L Engine CAUTION! The automatic transaxle has no dipstick and is dealer serviced only. Using a transmission fluid other than the manu- facturer’s recommended fluid may cause deterio- Transmission Fluid and Filter Changes ration in transmission shift quality and/or torque Refer to the “Maintenance Schedule”...
Page 400: Appearance Care And Protection From Corrosion
398 MAINTAINING YOUR VEHICLE Appearance Care And Protection From Corrosion What Causes Corrosion? Corrosion is the result of deterioration or removal of Protection of Body and Paint from Corrosion paint and protective coatings from your vehicle. Vehicle body care requirements vary according to geo- graphic locations and usage.
Page 401 MAINTAINING YOUR VEHICLE 399 Washing CAUTION! Wash your vehicle regularly. Always wash your ve- Do not use abrasive or strong cleaning materials such hicle in the shade using MOPAR Car Wash or a mild as steel wool or scouring powder, which will scratch car wash soap, and rinse the panels completely with metal and painted surfaces.
Page 402 400 MAINTAINING YOUR VEHICLE If your vehicle is damaged due to an accident or heavy soil and/or excessive brake dust, use MOPAR similar cause which destroys the paint and protective Wheel Cleaner or equivalent or select a nonabrasive, coating, have your vehicle repaired as soon as pos- non-acidic cleaner.
Page 403 MAINTAINING YOUR VEHICLE 401 Do not use abrasive cleaning components, solvents, steel Cleaning Leather Upholstery wool or other aggressive material to clean the lenses. MOPAR Total Clean is specifically recommended for leather upholstery. Interior Care Your leather upholstery can be best preserved by regular Instrument Panel Cover cleaning with a damp soft cloth.
Page 404 402 MAINTAINING YOUR VEHICLE For grease stains, apply MOPAR Multi-Purpose WARNING! Cleaner to a clean, damp cloth and remove stain. Use a fresh, damp towel to remove soap residue. Do not use volatile solvents for cleaning purposes. Many are potentially flammable, and if used in Do not use any solvents or protectants on Yes Essen- closed areas they may cause respiratory harm.
Page 405: Cleaning Center Console Cupholders
MAINTAINING YOUR VEHICLE 403 Cleaning Plastic Instrument Cluster Lenses Replace the belts if they appear frayed or worn or if the The lenses in front of the instruments in this vehicle are buckles do not work properly. molded in clear plastic. When cleaning the lenses, care Dry with a soft tissue.
Page 406: Fuses
404 MAINTAINING YOUR VEHICLE Installation Align the liner in the cupholder and press down firmly. FUSES Totally Integrated Power Module (TIPM) The TIPM is located in the engine compartment near the air cleaner assembly. This center contains cartridge fuses and mini fuses. A label that identifies each component may be printed on the inside of the cover.
Page 407 MAINTAINING YOUR VEHICLE 405 Cartridge Cartridge Cavity Mini Fuse Description Cavity Mini Fuse Description Fuse Fuse 40 Amp Power Top Mod- Ignition Off — Green ule (If Equipped) Draw (IOD) — 10 Amp — Power Mirror 20 Amp — AWD Module Switch/Climate Yellow Controls...
Page 408 406 MAINTAINING YOUR VEHICLE Cartridge Cartridge Cavity Mini Fuse Description Cavity Mini Fuse Description Fuse Fuse Battery Feed — Battery Feed — 40 Amp 20 Amp Cabin Compart- — Radiator Fan Re- — Green Yellow ment Node (CCN) IGN Run/ACC 15 Amp Lt Selectable Power 15 Amp Lt.
Page 409 MAINTAINING YOUR VEHICLE 407 Cartridge Cartridge Cavity Mini Fuse Description Cavity Mini Fuse Description Fuse Fuse Ignition Off Battery Feed — 25 Amp 20 Amp Draw (IOD) — — PWR Sunroof — Clear Yellow Power Amp Feed Feed 2 - if equipped Ignition Run —...
Page 410 408 MAINTAINING YOUR VEHICLE Cartridge Cartridge Cavity Mini Fuse Description Cavity Mini Fuse Description Fuse Fuse Ignition Run — Battery Feed — Occupant Classi- Switch Bank/ 10 Amp fication Module Diagnostic Link — 10 Amp (OCM)/Occupant — Connector/ Restraint Control- Powertrain Con- ler (ORC) trol Module...
Page 411 MAINTAINING YOUR VEHICLE 409 Cartridge CAUTION! Cavity Mini Fuse Description Fuse When installing the Totally Integrated Power Battery Feed — Module cover, it is important to ensure the cover is Anti-Lock Brakes properly positioned and fully latched. Failure to (ABS) Module - If 40 Amp Equipped/ do so may allow water to get into the Totally...
Page 412: Vehicle Storage
410 MAINTAINING YOUR VEHICLE NOTE: For lighted switches, see your authorized dealer VEHICLE STORAGE If you will not be using your vehicle for more than for replacement. 21 days, you may want to take steps to preserve your battery. LIGHT BULBS — Exterior Bulb No.
Page 413: Bulb Replacement
MAINTAINING YOUR VEHICLE 411 BULB REPLACEMENT Headlight 1. Raise and prop open the hood. Locate the connector behind the headlight. NOTE: It may be necessary to remove the air cleaner filter housing and position the totally integrated power module aside prior to replacing the low beam headlight on the driver’s side of the vehicle.
Page 414 412 MAINTAINING YOUR VEHICLE 3. Rotate bulb and connector one-quarter turn and pull 4. Pull the bulb out of the socket and replace the bulb. outward from assembly. 5. If the bulb comes in contact with any oily surface, clean the bulb with rubbing alcohol. CAUTION! 6.
Page 415: Front Turn Signal/Parking Light
MAINTAINING YOUR VEHICLE 413 Front Turn Signal/Parking Light 3. Remove the bulb from the connector socket and install the replacement bulb. 1. Raise and prop open the hood. 4. Install the bulb and connector assembly into the 2. Rotate the bulb’s electrical connector one-quarter turn headlight housing and rotate the connector one-quarter counterclockwise and remove it from the headlight hous- turn clockwise to lock it in place.
Page 416 414 MAINTAINING YOUR VEHICLE 1. Rotate the bulb’s electrical connector one-quarter turn 2. Remove the bulb from the connector socket and install counterclockwise and remove it from the fog light hous- the replacement bulb. ing. CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life.
Page 417: Tail/Stop, Rear Turn Signal And Backup Lights
MAINTAINING YOUR VEHICLE 415 Tail/Stop, Rear Turn Signal and Backup Lights Changing the Tail/Stop Light or Rear Turn Signal The taillights are a two piece design. The turn signal, Light brake and taillights are located in the rear corner body 1.
Page 418 416 MAINTAINING YOUR VEHICLE 2. Remove the two plastic wing nuts from the taillight 4. Rotate the applicable bulb’s electrical connector one- housing. quarter turn counterclockwise and remove it from the taillight housing. 3. Grasp the taillight housing and pull it firmly outward while pushing gently on the studs from inside to disen- 1 —...
Page 419 MAINTAINING YOUR VEHICLE 417 6. Install the bulb and connector assembly into the taillight housing and rotate the connector one-quarter turn clockwise to lock it in place. 7. Reinstall the taillight housing. Changing the Backup Light 1. Open the trunk. 2.
Page 420: License Plate Light
418 MAINTAINING YOUR VEHICLE License Plate Light Center High-Mounted Stop Light (CHMSL) 1. Remove two retaining screws holding the light lens in 1. Open the trunk lid. place. 2. Rotate the bulb’s electrical connector one-quarter turn counterclockwise and remove it from the CHMSL hous- ing.
Page 421: Fluids And Capacities
MAINTAINING YOUR VEHICLE 419 3. Remove the bulb from the connector socket and install 4. Install the bulb and connector assembly into the the replacement bulb. CHMSL housing and rotate the connector one-quarter turn clockwise to lock it in place. FLUIDS AND CAPACITIES U.S.
Page 422: Fluids, Lubricants, And Genuine Parts
Engine Coolant brid Organic Additive Technology) or equivalent Use API Certified engine oil. SAE 5W-20 is recommended. Refer to the Engine Oil (2.4L and 2.7L Engines) engine oil fill cap for the correct SAE grade meeting Chrysler Material Standard MS-6395.
Page 423 Fluid, Lubricant, or Genuine Part Use API Certified engine oil. SAE 10W-30 is recommended. Refer to the Engine Oil (3.5L Engine) engine oil viscosity chart for the correct SAE grade meeting Chrysler Material Standard MS-6395. Oil Filter (2.4L Engine ) MOPAR Oil Filter (P/N 04884900AB) or equivalent Oil Filter (2.7L and 3.5L Engine)
Page 424 422 MAINTAINING YOUR VEHICLE Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transaxle MOPAR ATF+4 Automatic Transmission Fluid MOPAR DOT 3 and SAE J1703 should be used. If DOT 3 brake fluid is not Brake Master Cylinder available, then DOT 4 is acceptable. Use only recommended brake fluids. Power Steering Reservoir MOPAR ATF+4 Automatic Transmission Fluid...
Page 425 MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..424 Required Maintenance Intervals ..426 Maintenance Schedule ....424...
Page 426 424 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE MAINTENANCE SCHEDULE The Scheduled Maintenance services listed in bold type The oil change indicator system will remind you that it is must be done at the times or mileages specified to ensure time to take your vehicle in for scheduled maintenance. the continued proper functioning of the emissions control On Electronic Vehicle Information Center (EVIC) system.
Page 427 MAINTENANCE SCHEDULES 425 NOTE: dealer the message can be reset by referring to the steps The oil change indicator message will not monitor the described under “Oil Change Required” in “Use Factory time since the last oil change. Change your vehicles oil Settings”...
Page 428 426 MAINTENANCE SCHEDULES Once a Month At Each Oil Change Check tire pressure and look for unusual wear or Change the engine oil filter. damage. Inspect the brake hoses and lines. Inspect the battery and clean and tighten the terminals CAUTION! as required.
Page 429 Inspect the exhaust system. Perform the first inspection at 12,000 miles (20 000 km) or 12 months. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 430 Inspect the exhaust system. Inspect the front suspension, tie rod ends and boot seals, and replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 431 Replace the air conditioning filter (if equipped). Odometer Reading Date Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 432: Service Schedule
Inspect the exhaust system. Inspect the front suspension, tie rod ends and boot seals, and replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 433 Change the automatic transaxle fluid & filter if using your vehicle for any of the following: police, taxi, fleet, or frequent trailer towing. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 434 Inspect the exhaust system. Inspect the front suspension, tie rod ends and boot seals, and replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 435 Inspect and replace the PCV valve, if necessary. necessary†. Replace the air conditioning filter (if equipped). Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 436 Inspect the front suspension, tie rod ends and boot seals, and replace if necessary. Inspect accessory drive belt, replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 437 Inspect the brake linings, and replace as necessary. Replace the air conditioning filter (if equipped). Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 438 Inspect the front suspension, tie rod ends and boot seals, and replace if necessary. Change the automatic transaxle fluid & filter. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 439 Inspect the brake linings, and replace as necessary. Replace the air conditioning filter (if equipped). Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 440 Inspect the exhaust system. Inspect the front suspension, tie rod ends and boot seals, and replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 441 MAINTENANCE SCHEDULES 439 † This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment.
Page 443 Reporting Safety Defects ....446 Chrysler LLC Customer Center ... 444 In The 50 United States And Washington, D.C.
Page 444 442 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....447 Traction Grades ..... . 449 Department Of Transportation Uniform Tire Temperature Grades .
Page 445: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 443 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...
Page 446: Chrysler Llc Customer Center
Phone: (800) 992-1997 If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- Chrysler Canada Inc. Customer Center ship. They want to know if you need assistance. P.O. Box 1621...
Page 447: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
IF YOU NEED CONSUMER ASSISTANCE 445 Customer Assistance For The Hearing Or Speech have any questions about the service contract, call the Impaired (TDD/TTY) manufacturer’s Service Contract National Customer Hot- To assist customers who have hearing difficulties, the line at 1-800-521-9922. manufacturer has installed special TDD (Telecommuni- The manufacturer will not stand behind any service cation Devices for the Deaf) equipment at its customer...
Page 448: Warranty Information (U.s. Vehicles Only)
WARRANTY INFORMATION (U.S. Vehicles Only) See the Warranty Information Booklet for the terms and If NHTSA receives similar complaints, it may open an provisions of Chrysler Motors LLC warranties applicable investigation, and if it finds that a safety defect exists in to this vehicle.
Page 449: In Canada
Recalls, 2780 Sheffield Road, Ottawa, Ontario K1B need in diagnosing/troubleshooting, problem solving, 3V9. maintaining, servicing, and repairing Chrysler LLC vehicles. A complete working knowledge of the ve- hicle, system, and/or components is written in straightforward language with illustrations, diagrams,...
Page 450: Department Of Transportation Uniform Tire
Chrysler LLC vehicles. your vehicle. Included are starting, operating, emergency and main-...
Page 451: Treadwear
IF YOU NEED CONSUMER ASSISTANCE 449 Treadwear Traction Grades The Treadwear grade is a comparative rating, based on The Traction grades, from highest to lowest, are AA, A, B, the wear rate of the tire when tested under controlled and C. These grades represent the tire’s ability to stop on conditions on a specified government test course.
Page 452 450 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat The temperature grade for this tire is established for and its ability to dissipate heat, when tested under a tire that is properly inflated and not overloaded.
Page 453 INDEX...
Page 454 452 INDEX About Your Brakes ....282,285 Airbag, Side ......56,61,62 ABS (Anti-Lock Brake System) .
Page 455 INDEX 453 Automatic Temperature Control (ATC) ..253 Body Mechanism Lubrication ....384 Automatic Transaxle ....13,270,395 B-Pillar Location .
Page 456 454 INDEX Caps, Filler Child Restraint ....69,70,75,78 Fuel ....... 333 Child Restraint Tether Anchors .
Page 457 INDEX 455 Contract, Service ......445 Customer Programmable Features ... . 196 Coolant Pressure Cap (Radiator Cap) .
Page 458 456 INDEX Door Opener, Garage ..... 148 Emission Control System Maintenance ..373,424 Driving Engine ......369,370,371 On Slippery Surfaces .
Page 459 INDEX 457 Temperature Gauge ....177 Hazard Warning ..... . . 350 Engine Oil Viscosity .
Page 460 458 INDEX Power Steering ..... 282,422 Octane Rating ..... . 325,420 Fluids .
Page 461 INDEX 459 Gearshift ......273 On With Wipers ..... . . 143 General Information .
Page 462 460 INDEX Infant Restraint ......69,70 Key, Replacement ......17 Information Center, Vehicle .
Page 463 INDEX 461 Anti-Lock ......287 Malfunction Indicator (Check Engine) ..188 Back-Up .
Page 464 462 INDEX Power Door ......33 Mirrors ....... . 87 Low Tire Pressure System .
Page 465 INDEX 463 Oil Change Indicator, Reset ....181,191 Operator Manual (Owner’s Manual) ... . 4 Oil, Engine ......375,420 Overdrive .
Page 466 464 INDEX Mirrors ......89 Rear Cupholder ......162 Outlet (Auxiliary Electrical Outlet) .
Page 467 INDEX 465 Replacement Keys ......17 Seat Belt Maintenance ....403 Replacement Parts .
Page 468 466 INDEX Heated ......130 Side Window Demisters (Defrosters) ..260 Lumbar Support .
Page 469 INDEX 467 Storage ......163,410 Tire Identification Number (TIN) ... . . 300 Storage, Vehicle .
Page 470 468 INDEX Radial ......308 Hitches ......340 Replacement .
Page 471 INDEX 469 Transmitter Programming Vanity Mirrors ......90 (Remote Keyless Entry) ....26 Variance, Compass .
Page 472 470 INDEX Washing Vehicle ......399 Windshield Defroster ....251,257 Water Windshield Washers .
Page 473 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 474 Chrysler LLC 81-026-0904 First Edition Printed in U.S.A.

This manual is also suitable for:

Sebring 2009

Chrysler Sebring Owner's Manual

Introduction 1

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Quick Links

Chapters

Related Manuals for Chrysler Sebring

Summary of Contents for Chrysler Sebring
