Page 1 Sebring Convertible 2 0 1 0 OWNE R ’ S MANUAL...
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE ............3 INTRODUCTION .
Page 4 INTRODUCTION CONTENTS Introduction ......4 Vehicle Identification Number ....6 How To Use This Manual .
Page 5: Introduction
4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized Congratulations on selecting your new Chrysler Group dealer knows your vehicle best, has factory-trained tech- LLC vehicle. Be assured that it represents precision nicians and genuine MOPAR parts, and cares about workmanship, distinctive styling, and high quality - all your satisfaction.
Page 6 INTRODUCTION 5...
Page 7: Vehicle Identification Number
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in an accident or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 8: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS ▫ To Arm The System ....18 A Word About Your Keys ....12 ▫...
Page 11 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Remote Open Window Feature — If ▫ Wind Buffeting ..... . . 35 Equipped .
Page 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 ▫ BeltAlert Programming ....50 Engine Break-In Recommendations ..76 ▫...
Page 13: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The authorized dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your authorized dealer.
Page 14: Ignition Key Removal
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Ignition Key Removal NOTE: • If you try to remove the key before you place the shift Place the shift lever in PARK. Turn the ignition switch to the ACC position, push the key slightly inward, rotate the lever into PARK, the key may become trapped tempo- key to the LOCK position, and remove the key.
Page 15: Key-In-Ignition Reminder
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE switches, radio, hands–free system (if equipped), and CAUTION! power outlets will remain active for up to 10 minutes after the ignition switch is turned to the LOCK posi- An unlocked car is an invitation to thieves. Always tion.
Page 16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 The system uses ignition keys, which have an embedded If the Vehicle Security Light turns on during normal electronic chip (transponder), to prevent unauthorized vehicle operation (vehicle running for longer than 10 sec- vehicle operation.
Page 17: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Replacement Keys Customer Key Programming You can program new keys to the system if you have two NOTE: Only keys that have been programmed to the valid Sentry Keys by performing the following proce- vehicle electronics can be used to start the vehicle.
Page 18: General Information
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 4. Insert a blank Sentry Key into the ignition switch. your vehicle. The remaining keys must then be repro- Turn the ignition switch to the ON position within grammed. All vehicle keys must be taken to an autho- 60 seconds.
Page 19: Rearming The System
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If something triggers the alarm, the Vehicle Security NOTE: The Vehicle Security Alarm will not arm if you Alarm will signal for about 18 minutes. For the first three lock the doors with the manual door lock plungers. minutes, the horn will sound intermittently and the 3.
Page 20: To Disarm The System
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 To Disarm The System of the previously described arming sequences has oc- Either press the UNLOCK button on the RKE transmitter curred, the Vehicle Security Alarm will arm regardless of or insert a valid Sentry Key into the ignition lock whether you are in the vehicle or not.
Page 21: Illuminated Entry - If Equipped
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ILLUMINATED ENTRY — IF EQUIPPED REMOTE KEYLESS ENTRY (RKE) The courtesy/reading lights will turn on when you use This system allows you to lock or unlock the doors, open the Remote Keyless Entry (RKE) transmitter or open the trunk, open the convertible top (if equipped), lower either door.
Page 22: To Unlock The Doors
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 Remote Key Unlock, Driver Door/All Doors First Press This feature lets you program the system to unlock either the driver’s door or both doors on the first press of the UNLOCK button on the RKE transmitter. To change the current setting, proceed as follows: •...
Page 23 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Release both buttons at the same time. Flash Lights with Lock The feature will cause the turn signal lights to flash when 3. Test the feature while outside of the vehicle, by the doors are locked or unlocked with the RKE transmit- pressing the LOCK/UNLOCK buttons on the RKE trans- ter.
Page 24: To Lock The Doors
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 3. Test the feature while outside of the vehicle, by (EVIC)/Personal Settings (Customer-Programmable Fea- pressing the LOCK/UNLOCK buttons on the RKE trans- tures)” in “Understanding Your Instrument Panel” for mitter with the ignition in the LOCK position, and the further information.
Page 25: Convertible Top Operation Button - If Equipped
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles not equipped with the EVIC, perform the Alarm activated will cause the alarm to sound. Press the following steps: UNLOCK button to deactivate the Vehicle Security Alarm System. 1. Press the LOCK button on a programmed RKE trans- mitter for at least four seconds, but not longer than Convertible Top Operation Button —...
Page 26: Using The Panic Alarm
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 2. Press the UNLOCK button a second time and hold the Programming Additional Transmitters button until the windows lower completely or the win- Refer to Sentry Key “Customer Key Programming.” dows drop to the desired level, then release the button. If you do not have a programmed RKE transmitter, Using the Panic Alarm contact your authorized dealer for details.
Page 27: General Information
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. With the RKE transmitter buttons facing down, use a 2. Remove and replace the battery. Avoid touching the flat blade tool to pry the two halves of the RKE transmit- new battery with your fingers. Skin oils may cause ter apart.
Page 28: Remote Starting System - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 If your RKE transmitter fails to operate from a normal How To Use Remote Start distance, check for these two conditions: All of the following conditions must be met before the engine will remote start: 1.
Page 29 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: WARNING! • For security, power window operation is disabled • Do not start or run an engine in a closed garage or when the vehicle is in the Remote Start mode. confined area.
Page 30: Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 To Exit Remote Start Mode and Drive the Vehicle Before the end of the 15 minute cycle, press and release the UNLOCK button on the RKE transmitter to unlock the doors and disarm the Vehicle Security Alarm (if equipped).
Page 31: Power Door Locks
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks WARNING! A door lock switch is located on the driver and passenger • For personal security and safety in the event of an door trim panel. Press this switch to lock or unlock the doors.
Page 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 Auto Door Locks 6. The vehicle speed is 0 mph (0 km/h). When enabled, your door locks will lock automatically Auto Unlock Door on Exit Programming when the vehicle’s speed exceeds 15 mph (24 km/h). The The Automatic Unlock Doors on Exit feature can be Automatic Door Locks feature can be enabled or disabled enabled or disabled as follows:...
Page 33: Windows
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Press the power door UNLOCK switch to unlock the doors. 4. A single chime will indicate the completion of the programming. NOTE: This feature will not be functional until the vehicle has been driven and the shift lever returned to the PARK position.
Page 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 NOTE: to its full up position after closing the door. This action • If a fluttering noise is heard from the rear seat belts allows the door to open without resistance and prevents while driving with the windows down, safely bring window and top seal damage.
Page 35 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE will remain active for 45 seconds after the ignition switch 2. Press and hold the Power Top Switch in the Close is turned to the LOCK position. Opening either door will direction. Once the Power Top becomes fully closed, all cancel this feature.
Page 36: Wind Buffeting
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 If the buffeting occurs with one window open, then open both windows together to minimize the buffeting. TRUNK LOCK AND RELEASE To unlatch the trunk lid from inside the vehicle, press and release the TRUNK RELEASE Button located on the instrument panel to the left of the steering wheel.
Page 37: Trunk Safety Warning
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE enabled when the vehicle is unlocked by the RKE or if the On vehicles equipped with the Electronic Vehicle Infor- key is inserted into the ignition and turned to ON or mation Center (EVIC), the words “Trunk Ajar” will START.
Page 38: Trunk Internal Emergency Release
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 Trunk Internal Emergency Release OCCUPANT RESTRAINTS As a security measure, a Trunk Internal Emergency Release Some of the most important safety features in your lever is built into the trunk latching mechanism. In the vehicle are the restraint systems.
Page 39 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Front seat belts incorporate pretensioners to enhance Please pay close attention to the information in this occupant protection by managing occupant energy section. It tells you how to use your restraint system during an impact event —...
Page 40: Lap/Shoulder Belts
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 Research has shown that seat belts save lives, and they WARNING! can reduce the seriousness of injuries in a collision. Some • Be sure everyone in your vehicle is in a seat and of the worst injuries happen when people are thrown from the vehicle.
Page 41 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Two people should never be belted into a single seat belt. People belted together can crash into one another in an accident, hurting one another badly. Never use a lap/shoulder belt or a lap belt for more than one person, no matter what their size.
Page 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 3. When the belt is long enough to fit, insert the latch WARNING! plate into the buckle until you hear a “click.” • A belt that is buckled into the wrong buckle will not protect you properly.
Page 43 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • A shoulder belt placed behind you will not protect you from injury during a collision. You are more likely to hit your head in a collision if you do not wear your shoulder belt.
Page 44: Lap/Shoulder Belt Untwisting Procedure
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 WARNING! WARNING! • A lap belt worn too high can increase the risk of A frayed or torn belt could rip apart in a collision and internal injury in a collision. The belt forces won’t be leave you with no protection.
Page 45: Automatic Locking Retractors (Alr) Mode - If Equipped
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. At about 6 to 12 in (15 to 30 cm) above the latch plate, When To Use The Automatic Locking Mode grasp and twist the belt webbing 180° to create a fold that Use the Automatic Locking Mode anytime a child safety begins immediately above the latch plate.
Page 46: Seat Belt Pretensioners - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 Seat Belt Pretensioners — If Equipped Supplemental Rear Impact Active Head Restraints The seat belts for both front seating positions may be (AHR) equipped with pretensioning devices that are designed to These head restraints are passive, deployable compo- remove slack from the seat belt in the event of a collision.
Page 47 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE When AHR’s deploy during a rear impact, the head restraint front half extends forward to minimize the gap between the back of the head and the AHR. This system is designed to help prevent or reduce the extent of injuries the driver and front passenger in certain types of rear end impacts.
Page 48: Understanding The Features Of Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 1. Grasp the deployed AHR from the rear seat. CAUTION! All occupants, including the driver, should not oper- ate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of an accident.
Page 49 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Pull down then rearward towards the rear of the vehicle then down to engage the locking mechanism. 3 — Final Downward Movement To Engage Locking Mecha- nism 1 — Downward Movement 2 —...
Page 50: Enhanced Seat Belt Use Reminder System (Beltalert )
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 • For safety reasons, have the Active Head Restraints 4. The AHR front soft foam and trim half should lock into the back decorative plastic half. checked by a qualified specialist at an authorized dealer.
Page 51: Beltalert Programming
It may be necessary to retract the seat belt partially after unbuckling it. NOTE: Chrysler Group LLC does not recommend de- activating BeltAlert . 4. Turn the ignition switch to the LOCK position. A single chime will sound to signify that you have success- 1.
Page 52: Seat Belts And Pregnant Women
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 Seat Belts and Pregnant Women Seat Belt Extender We recommend that pregnant women use the seat belts If a seat belt is too short, even when fully extended, your throughout their pregnancy. Keeping the mother safe is authorized dealer can provide you with a seat belt the best way to keep the baby safe.
Page 53: Supplemental Restraint System (Srs) - Airbags
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Restraint System (SRS) - Airbags This vehicle has airbags for both the driver and front passenger as a supplement to the seat belt restraint systems. The driver’s front airbag is mounted in the center of the steering wheel.
Page 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 • Front and Side Impact Sensors The Advanced Front Airbags have a multistage inflator design. This allows the airbag to have different rates of • Steering Wheel and Column inflation that are based on the severity and type of •...
Page 55 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE low, medium, or high. If a low output is sufficient to meet WARNING! (Continued) the need, the remaining gas in the inflator is expended. • Do not drill, cut or tamper with the knee bolster in any way.
Page 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 WARNING! • Do not use accessory seat covers or place objects between you and the side airbags; the performance could be adversely affected and/or objects could be pushed into you, causing serious injury. Knee Impact Bolsters The Knee Impact Bolsters help protect the knees of the driver and the front passenger, and position everyone for...
Page 57 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Here are some simple steps you can take to minimize the ride properly buckled up in the rear seat. Never allow risk of harm from a deploying airbag: children to slide the shoulder belt behind them or under their arm.
Page 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 4. Do not lean against the door. If your vehicle has side WARNING! (Continued) airbags, and deployment occurs, the side airbags will • Being too close to the steering wheel or instrument inflate forcefully into the space between you and the panel during front airbag deployment could cause door.
Page 59: Airbag Deployment Sensors And Controls
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Deployment Sensors and Controls The Advanced Front Airbags will not deploy in all frontal collisions, including some that may produce substantial Occupant Restraint Controller (ORC) vehicle damage — for example, some pole collisions, The ORC is part of a Federally regulated safety system truck underrides, and angle offset collisions.
Page 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 The ORC monitors the readiness of the electronic parts of It also includes diagnostics that will illuminate the instru- the system whenever the ignition switch is in the START ment cluster Airbag Warning Light if a malfunction is or ON position.
Page 61 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the Advanced Front Airbags. Different airbag inflation The ORC determines if a side collision requires the side rates are possible, based on the collision type and sever- airbags to inflate based on the severity and type of ity.
Page 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 • Turn on the interior lights, which remain on as long as Front and Side Impact Sensors In front and side impacts, impact sensors aid the ORC in the battery has power or until the ignition key is determining appropriate response to impact events.
Page 63 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE floor. They are not caused by contact with chemicals. Do not drive your vehicle after the airbags have de- They are not permanent and normally heal quickly. ployed. If you are involved in another collision, the However, if you haven’t healed significantly within a airbags will not be in place to protect you.
Page 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Maintaining Your Airbag System WARNING! (Continued) • Do not attempt to modify any part of your ad- WARNING! vanced airbag system. The airbag may inflate • Modifications to any part of the airbag system accidentally or may not function properly if modi- could cause it to fail when you need it.
Page 65: Event Data Recorder (Edr)
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Warning Light located on the inside of the fuse block cover for the You will want to have the airbags ready to proper airbag fuses. See your authorized dealer if the inflate for your protection in a collision.
Page 66 Chrysler Group LLC, such investigations may be re- hicle, or crash, will be treated confidentially. Confidential quested by customers, insurance carriers, government data will not be disclosed by Chrysler Group LLC to any officials, and professional crash researchers, such as those third party except when: associated with universities, and with hospital and insur- ance organizations.
Page 67: Child Restraints
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Requested by police under a legal warrant. United States and all Canadian provinces require that small children ride in proper restraint systems. This is the 4. Otherwise required by law. law, and you can be prosecuted for ignoring it. Data parameters that are recorded: Children 12 years and younger should ride properly •...
Page 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 There are different sizes and types of restraints for infant carriers do, so they can be used rearward-facing children from newborn size to the child almost large by children who weigh more than 20 lbs (9 kg) but are enough for an adult safety belt.
Page 69 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Make sure that the child is upright in the seat. who weigh 20 to 40 lbs (9 to 18 kg) and who are older than one year. These child seats are also held in the •...
Page 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 bend over the front of the seat when their back is WARNING! against the seatback, should use the lap/shoulder belt • Improper installation can lead to failure of an in a rear seat. infant or child restraint.
Page 71 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • All passenger seating positions contain automatic for the installation of the child restraint without using the locking retractors. However, any seat belt system will vehicle’s seat belts. The two rear seating positions have loosen with time, so check the belt occasionally and lower anchorages that are capable of accommodating pull it tight if necessary.
Page 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 to the top tether anchorage, have been available for some Because the lower anchorages are to be introduced to time. In fact, many child restraint manufacturers will passenger carrying vehicles over a period of years, child provide add-on tether strap kits for some of their older restraint systems having attachments for those anchor- products.
Page 73 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Remind all children in the vehicle that the seat belts are In addition, there are tether strap anchorages not toys and should not be played with, and never leave behind each rear seating position. Access ports your child unattended in the vehicle.
Page 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 seat cover material. Then rotate the tether anchorage restraint installation, instead of tucking the seat belt cover directly behind the seat where you are placing the behind the child restraint, route the seat belt through the child restraint, push the tether strap and hook through child restraint belt path and then buckle it.
Page 75 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing Child Restraints Using the Vehicle Seat In the rear seat, you may have trouble tightening the Belts lap/shoulder belt on the child restraint because the The passenger seat belts are equipped with Automatic buckle or latch plate is too close to the belt path opening Locking Retractors (ALRs), which are designed to keep on the restraint.
Page 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 2. Open the access port cover (A) behind the seat where NOTE: Route the tether strap to provide the most direct you are placing the child restraint. path from the child seat to the anchor. 4.
Page 77: Engine Break-In Recommendations
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. Remove slack in the tether strap according to the child ENGINE BREAK-IN RECOMMENDATIONS restraint manufacturer’s instructions. A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. WARNING! Drive moderately during the first 300 miles (500 km).
Page 78: Safety Tips
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 “Maintenance Procedures” in “Maintaining Your Ve- WARNING! hicle”. NON-DETERGENT OR STRAIGHT MINERAL • It is extremely dangerous to ride in a cargo area, OILS MUST NEVER BE USED. inside or outside of a vehicle. In a collision, people A new engine may consume some oil during its first few riding in these areas are more likely to be seri- thousand miles (kilometers) of operation.
Page 79: Exhaust Gas
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Exhaust Gas Whenever a change is noticed in the sound of the exhaust system, when exhaust fumes can be detected inside the WARNING! vehicle, or when the underside or rear of the vehicle is damaged, have a competent mechanic inspect the com- Exhaust gases can injure or kill.
Page 80: Periodic Safety Checks You Should Make Outside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 Front seat belt assemblies must be replaced after a Periodic Safety Checks You Should Make Outside collision. Rear seat belt assemblies must be replaced after the Vehicle a collision if they have been damaged (i.e., bent retractor, Tires torn webbing, etc.).
Page 81 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Fluid Leaks Check area under vehicle after overnight parking for fuel, engine coolant, oil, or other fluid leaks. Also, if gasoline fumes are detected or if fuel, power steering fluid, or brake fluid leaks are suspected, the cause should be located and corrected immediately.
Page 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ Emergency Bypass Mode (To Raise The Top Convertible Top Operation ....85 Only) ......106 ▫...
Page 83 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Automatic Headlights — If Equipped ..123 Voice Command — If Equipped ... 110 ▫ Headlights With Wipers (Available With Seats .
Page 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83 ▫ To Accelerate For Passing ....136 Windshield Wipers And Washers ..128 ▫...
Page 85 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Console Features ..... . 148 Rear Window Features ....150 ▫...
Page 86: Convertible Top Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85 CONVERTIBLE TOP OPERATION WARNING! CAUTION! The convertible top does not provide the structural protection that a reinforced metal roof does and the Failure to follow these cautions may cause interior fabric top cannot be expected to prevent the ejection water damage, stains or mildew on the top material: of the occupants of a vehicle in a collision.
Page 87: Power Convertible Top Usage Precautions
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The top does take up some space in the trunk when To complete either operation, the trunk lid returns to its retracted. However, the trunk will still hold a significant normal position and then latches. amount of cargo.
Page 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 • The Power Top Control Module (PTCM) monitors and CAUTION! controls lowering and raising of the top. A series of • Correctly position the cargo shield in the trunk micro-switches verify that operations are complete before allowing the next stage of lowering or raising before stowing the top.
Page 89 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! CAUTION! (Continued) • To prevent striking a low ceiling or automatic door Before operating the power top: opener with the top, it is strongly recommended • Always check the tonneau cover area to be sure that you do not operate the power top inside a that it is clear of debris or other items.
Page 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 CAUTION! (Continued) CAUTION! (Continued) • Do not allow the top to remain in the suspended • Do not leave the top lowered for several weeks at position. After approximately 10 minutes in the a time.
Page 91: Cargo Shield
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) WARNING! (Continued) • Never place any extremities (hands, feet, etc.) near • When using the power top switch on the instru- the convertible top components, the upper wind- ment panel, if potential danger exists while raising shield area, the shelf area behind the rear seats, or the top, release the switch immediately to inter- the convertible top stowage area while raising or...
Page 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 Positioning the Cargo Shield for Top Operation Pull the cargo shield toward you to begin unfolding the panels. Grasp the handle in the center of the outermost (top) panel and raise the cargo shield. Then, align and seat the tabs at each end of the cargo shield in the V slots in the trunk liner as shown in the illustration.
Page 93: Power Convertible Top Controls
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To stow the cargo shield, grasp the handle of the upright NOTE: The convertible top will NOT operate with the panel of the cargo shield, lifting the pins out of the V slots cargo shield in the stowed position.
Page 94: Lowering The Power Convertible Top
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 There is also a power top button on the Remote Keyless Lowering the Power Convertible Top Entry (RKE) transmitter for remotely lowering the power Using the Power Top Switch convertible top. NOTE: The power top switch will operate when the ignition switch is turned to the ON or ACC position and when in the power accessory delay.
Page 95: Raising The Power Convertible Top
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The driver has to press and hold the convertible top Raising the Power Convertible Top switch during the entire opening cycle, if there is an Using the Power Top Switch obstruction and the driver is alerted, the convertible top operation can be stopped by releasing the switch.
Page 96: Wind Stop - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 Manually Wind Stop — If Equipped Closing the power convertible top manually is a compli- The Wind Stop installs in the backseat area of the vehicle. cated and physically demanding procedure, and it re- The Wind Stop will not interfere with power top opera- quires a special tool to do so.
Page 97 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The frames must lie flat on each other in order to 4. Pivot the small frame (1) away from the large frame (2) snap them together. until the pivot lock (3) engages to lock the two frames in an L shape.
Page 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 5. Unfold both stems at the rear of the large frame. 6. Align and insert the stems into the slot in each trim panel.
Page 99 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 7. Align the pins at the front of the large frame with the Disengage the pivot lock (1) to fold the small frame flat hole in each trim panel. Slide the pins outward until fully onto the large frame.
Page 100: Power Convertible Top Operation And Warning Messages
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 Power Convertible Top Operation and Warning Messages When the appropriate conditions exist, the PTCM displays various power convertible top operation and warning messages in the Electronic Vehicle Information Center (EVIC) – if equipped, or in the Odometer for vehicles not equipped with the EVIC.
Page 101 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE EVIC Mes- EVIC Odometer Odometer Odometer Odometer Chime Condition Operator sage Message Message Message Message Message Action Display (< 5 mph Display (> 5 mph Display Required Time [8 km/ Time [8 km/ Time CONVERT- 9 sec.
Page 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 EVIC Mes- EVIC Odometer Odometer Odometer Odometer Chime Condition Operator sage Message Message Message Message Message Action Display (< 5 mph Display (> 5 mph Display Required Time [8 km/ Time [8 km/ Time CONVERT- Until Op-...
Page 103 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE EVIC Mes- EVIC Odometer Odometer Odometer Odometer Chime Condition Operator sage Message Message Message Message Message Action Display (< 5 mph Display (> 5 mph Display Required Time [8 km/ Time [8 km/ Time SPEED 9 sec.
Page 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 EVIC Mes- EVIC Odometer Odometer Odometer Odometer Chime Condition Operator sage Message Message Message Message Message Action Display (< 5 mph Display (> 5 mph Display Required Time [8 km/ Time [8 km/ Time TRUNK Continu-...
Page 105 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE EVIC Mes- EVIC Odometer Odometer Odometer Odometer Chime Condition Operator sage Message Message Message Message Message Action Display (< 5 mph Display (> 5 mph Display Required Time [8 km/ Time [8 km/ Time CONVERT- Until Fault...
Page 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 • If you are trying to lower the top and ambient temperature is 0°F (-18°C) or lower, wait until the temperature rises and the top is thawed and dry before operating the power top. A soft top should not be lowered at tem- peratures below 32°F (0°C).
Page 107: Emergency Bypass Mode (To Raise The Top Only)
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Emergency Bypass Mode (To Raise the Top Only) CAUTION! (Continued) This procedure is only to be used to raise the top when • Using the Emergency Bypass Mode could poten- the top cannot be returned to the UP (raised) position by tially damage the convertible top and should only pressing the POWER TOP switch or is in a position in be used to raise the power top to the UP (raised)
Page 108: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 MIRRORS Automatic Dimming Mirror This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light will illuminate to indicate when the dimming feature is activated.
Page 109: Outside Mirrors
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! WARNING! To avoid damage to the mirror during cleaning, never Vehicles and other objects seen in the passenger side spray any cleaning solution directly onto the mirror. convex mirror will look smaller and farther away Apply the solution onto a clean cloth and wipe the than they really are.
Page 110: Heated Mirrors - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 Mirror Directions Power Mirror Adjust Switch After selecting a mirror, move the knob in the same Heated Mirrors — If Equipped direction you want the mirror to move. When finished, These mirrors are heated to melt frost or ice. This return the knob to the center “O”...
Page 111: Vanity Mirror - If Equipped
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Vanity Mirror — If Equipped Uconnect™ Phone — IF EQUIPPED A vanity mirror is attached to the inside face of the sun Refer to “Uconnect™ Phone” in the Uconnect™ User visor. To use the mirror, rotate the sun visor downward Manual located on the DVD for further details.
Page 112: Power Seats
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 WARNING! • DO NOT allow people to ride in any area of your vehicle that is not equipped with seats and seat belts. In a collision, people riding in these areas are more likely to be seriously injured or killed. •...
Page 113: Heated Seats - If Equipped
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! CAUTION! • Adjusting a seat while the vehicle is moving is Do not place any article under any seat as it may dangerous. The sudden movement of the seat cause damage to the seat controls. could cause you to lose control.
Page 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Press the switch once to select High-level heat- WARNING! (Continued) ing. Press the switch a second time to select • Do not place anything on the seat that insulates Low-level heating. Press the switch a third time against heat, such as a blanket or cushion.
Page 115: Recliner Adjustment
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Recliner Adjustment The recliner control is on the outboard side of the seat. To recline the seat, lean forward slightly and lift the lever. Then lean back to the position desired and release the lever.
Page 116: Lumbar Support - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked.
Page 117: Easy Entry System
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Easy Entry System Pull the lever upward to move the seat and seatback The Easy Entry lever is located on upper seat belt anchor forward. cover. When returning the seat to its normal position, the memory feature restores the seat position and seatback recline position to their current settings.
Page 118: Adjusting Active Head Restraints
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 Adjusting Active Head Restraints To raise the head restraint, pull upward on the head Active Head Restraints can reduce the risk of injury in restraint (on some models, you may need to press the the event of a rear impact.
Page 119 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For comfort the Active Head Restraints can be tilted forward and backward. To tilt the head restraint closer to the back of your head, pull outward on the bottom of the head restraint. Push rearward on the bottom of the head restraint to move the head restraint away from your head.
Page 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 • In the event of deployment of an Active Head Re- WARNING! (Continued) straint, refer to “Occupant Restraints/Resetting Active • Do not place items over the top of the Active Head Head Restraints (AHR)” in “Things to Know Before Restraint, such as coats, seat covers or portable Starting Your Vehicle”...
Page 121: To Open And Close The Hood
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TO OPEN AND CLOSE THE HOOD 2. Move to the outside of the vehicle and lift the second- Two latches must be released to open the hood. ary latch underneath the center front edge of the hood and raise the hood.
Page 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Use the hood prop rod to secure the hood in the open CAUTION! position. Place the upper end of the prop rod in the hole on the underside of the hood. To prevent possible damage, do not slam the hood to close it.
Page 123: Lights
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Headlights And Parking Lights Turn the end of the multifunction lever to the first detent Multifunction Lever for parking light operation. Turn the end of the lever to The multifunction lever on the left side of the steering the second detent for headlight operation.
Page 124: Lights-On Reminder
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Lights-On Reminder Headlights with Wipers (Available with Automatic If the headlights or parking lights are on after the ignition Headlights Only) is turned to the LOCK position, a chime will sound to When this feature is active, the headlights will turn on alert the driver when the driver’s door is opened.
Page 125: Instrument Panel Dimmer
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To activate the delay, turn the ignition switch to the Instrument Panel Dimmer LOCK position while the headlights are still on. Then, Rotate the center portion of the lever to the extreme turn off the headlights within 45 seconds. The delay bottom position to fully dim the instrument panel lights interval begins when you turn off the headlights.
Page 126: Fog Lights - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 Dimmer Control Front Fog Light Control Fog Lights — If Equipped NOTE: The front fog lights will only operate with the To activate the front fog lights, turn on the parking headlights on low beam. Selecting high beam headlights lights or the low beam headlights and pull out on will turn off the front fog lights.
Page 127: Daytime Running Lights - If Equipped
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Daytime Running Lights — If Equipped The high beam headlights will turn on as Daytime Running Lights (DRL) and operate at lower intensity whenever the ignition is ON, the engine is running, the headlight switch is off, the parking brake is released and the shift lever is in any position except PARK.
Page 128: High/Low Beam Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 High/Low Beam Switch control in the multifunction lever. These lights are also Push the multifunction lever away from you to switch controlled automatically by the Illuminated Entry System. the headlights to high beam. Pull the multifunction lever toward you, to switch the headlights back to low beam.
Page 129: Battery Saver Feature
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE dimmer control in the multifunction lever. This light is also controlled automatically by the Illuminated Entry System. Battery Saver Feature To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition switch is moved to the LOCK position.
Page 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 CAUTION! • Turn the windshield wipers off when driving through an automatic car wash. Damage to the windshield wipers may result if the wiper control is left in any position other than off. •...
Page 131: Intermittent Wiper System
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Intermittent Wiper System Use the intermittent wiper system when weather condi- tions make a single wiping cycle with a variable pause between cycles desirable. Rotate the end of the wind- shield wiper/washer control lever to the first detent, and then turn the end of the lever to select the desired delay interval.
Page 132: Mist Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 WARNING! Sudden loss of visibility through the windshield could lead to an accident. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with defroster before and during wind- shield washer use.
Page 133: Windshield Washers
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE column) is placed in the AUTO position. In addition, the If you activate the washer while the wiper control is in headlights will turn off when the wipers are turned off if the off position, the wipers will operate for two wipe they were turned on by this feature.
Page 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 WARNING! Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle. Be sure the steering column is locked before driving your ve- hicle.
Page 135: Electronic Speed Control
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRONIC SPEED CONTROL NOTE: In order to ensure proper operation, the Elec- When engaged, the Electronic Speed Control takes over tronic Speed Control System has been designed to shut the accelerator operation at speeds greater than 25 mph down if multiple Speed Control functions are operated (40 km/h).
Page 136: To Set A Desired Speed
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 To Deactivate WARNING! A soft tap on the brake pedal, or pulling the Electronic Speed Control lever toward you (CANCEL), or normal Leaving the Electronic Speed Control on when not in brake pressure while slowing the vehicle will deactivate use is dangerous.
Page 137: To Accelerate For Passing
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ACCEL lever. If the lever is continually held in the WARNING! RESUME ACCEL position, the set speed will continue to increase until the lever is released, then the new set speed Electronic Speed Control can be dangerous where the will be established.
Page 138: Garage Door Opener - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 On steep hills, a greater speed loss or gain may occur so The HomeLink buttons that are located in the headliner it may be preferable to drive without Electronic Speed or sun visor designate the three different HomeLink Control.
Page 139: Programming Homelink
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming HomeLink WARNING! Before You Begin • Your motorized door or gate will open and close If you have not trained any of the HomeLink buttons, while you are training the universal transceiver. erase all channels before you begin training.
Page 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 • After training a HomeLink channel, if the garage Place the handheld transmitter 1 to 3 in (3 to 8 cm) away from the HomeLink button you wish to program while door does not operate with HomeLink and the ga- keeping the indicator light in view.
Page 141 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE This can usually be found where the hanging antenna 6. Firmly press and release the LEARN or TRAINING wire is attached to the garage door opener motor. It is button. The name and color of the button may vary by NOT the button normally used to open and close the manufacturer.
Page 142: Gate Operator/Canadian Programming
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 Using HomeLink Gate Operator/Canadian Programming To operate, press and release the programmed Canadian radio frequency laws require transmitter sig- HomeLink button. Activation will now occur for the nals to time-out (or quit) after several seconds of trans- trained device (i.e., garage door opener, gate operator, mission –...
Page 143: Security
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE successfully accepted the frequency signal. The indica- Troubleshooting Tips tor light will flash slowly and then rapidly when fully If you are having trouble programming HomeLink , here are some of the most common solutions: trained.
Page 144: Electrical Power Outlets
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 2. This device must accept any interference that may be ELECTRICAL POWER OUTLETS received including interference that may cause undesired There are two 12 Volt (13 Amp) electrical power outlets operation. on this vehicle. Both of the power outlets are protected by a fuse.
Page 145 144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: If desired, the instrument panel power outlet The center console power outlet is powered directly from can be converted by your authorized dealer to provide the battery (power available at all times). Items plugged power with the ignition switch while in the LOCK into this power outlet may discharge the battery and/or position.
Page 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 WARNING! CAUTION! • Many accessories that can be plugged in draw To avoid serious injury or death: • Only devices designed for use in this type of power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.).
Page 147: Cigar Lighter And Ash Receiver - If Equipped
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CIGAR LIGHTER AND ASH RECEIVER — IF CAUTION! EQUIPPED An optional ash receiver is available from your autho- For vehicles equipped with the heated and cooled rized dealer and will fit in the center console front cupholder, locate the cup holder ash receiver in the cupholder.
Page 148: Rear Seat Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 Rear Seat Cup Holder Front Cupholders Rear Seat Cupholders WARNING! Cupholders for the rear seat occupants are located in the armrests. Each cupholder is capable of holding up to a If containers of hot liquid are place in the cupholder, 20 oz.
Page 149 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONSOLE FEATURES Storage The center console contains a cubby bin with flip-down cover located below the climate controls. This compart- ment also contains a 12 Volt electrical outlet. WARNING! Do not place ashes inside the cubby bin located on the center console.
Page 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 The top compartment holds small items, such as a pen and note pad, while the larger bottom compartment will hold CDs and alike. The bottom compartment also con- tains a 12 Volt power outlet and a molded-in coin holder (designed to hold various size coins).
Page 151 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sliding Armrest — If Equipped REAR WINDOW FEATURES On some models the center console armrest slides for- Rear Window Defroster ward and rearward for added user comfort. The rear window defroster button is located on the climate control (Mode) knob.
Page 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 CAUTION! Failure to follow these cautions can cause damage to the heating elements: • Use care when washing the inside of the rear window. Do not use abrasive window cleaners on the interior surface of the window. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements.
Page 154 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS ▫ Personal Settings (Customer-Programmable Instrument Panel Features ....156 Features) ......179 Instrument Cluster .
Page 155 154 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ List Button (Disc Mode For ▫ Operating Instructions — Radio Mode ..202 MP3/WMA Play) ....195 ▫...
Page 156 UNDERSTANDING YOUR INSTRUMENT PANEL 155 Uconnect™ Multimedia (Satellite Radio) — If Remote Sound System Controls — Equipped (REN/REQ/RER/RBZ/RES Radios If Equipped ......228 Only).
Page 157: Instrument Panel Features
156 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Outlet 6 — Radio 11 — Hazard Switch 2 — Side Window Demister Outlet 7 — Passenger Airbag 12 — Storage Compartment 3 — Instrument Cluster 8 — Glove Compartment 13 —...
Page 158: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 157 INSTRUMENT CLUSTER...
Page 159: Instrument Cluster Descriptions
158 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS removes this heat. You can also turn the Temperature control to maximum heat, the Mode control to Floor and 1. Temperature Gauge the Fan control to High. This allows the heater core to act The temperature gauge shows engine coolant tempera- as a supplement to the radiator and aids in removing heat ture.
Page 160 UNDERSTANDING YOUR INSTRUMENT PANEL 159 5. Low Fuel Light If jump starting is required, refer to “Jump Starting When the fuel level drops to approximately 2.0 gal- Procedures” in “What To Do In Emergencies”. lons (7.6 Liters), the fuel symbol will light and a 7.
Page 161 160 UNDERSTANDING YOUR INSTRUMENT PANEL you do not buckle up, the light will remain on. Refer to 10. Engine Temperature Warning Light “Occupant Restraints” in “Things To Know Before Start- This light warns of an overheated engine condi- ing Your Vehicle” for further information. tion.
Page 162 UNDERSTANDING YOUR INSTRUMENT PANEL 161 The light will remain on until the cause is corrected. In the event of an EBD failure, the Brake Warning Light will turn on along with the ABS Light. Immediate repair NOTE: The light may flash momentarily during sharp to the ABS system is required.
Page 163 162 UNDERSTANDING YOUR INSTRUMENT PANEL 12. Tachometer the same as it was before the repair or service. If s/he The silver area of the scale shows the permissible engine cannot do so, then the odometer must be set at zero, and revolutions-per-minute (RPM x 1000) for each gear range.
Page 164 UNDERSTANDING YOUR INSTRUMENT PANEL 163 Vehicle Odometer Messages LoW TirE When the appropriate conditions exist, the odometer will When the appropriate condition exists, the odometer display the following messages: display will toggle between LoW and TirE for three cycles. door ......Door Ajar HOTOIL deck .
Page 165 164 UNDERSTANDING YOUR INSTRUMENT PANEL tighten the fuel filler cap properly and press the odom- To turn off the message temporarily, press and release the eter reset button to turn off the “gASCAP” message. Trip Odometer button on the instrument cluster. To reset (Refer to “Onboard Diagnostic System —...
Page 166 UNDERSTANDING YOUR INSTRUMENT PANEL 165 15. Cruise Indicator — If Equipped Dual Trip Odometer — If Equipped This indicator shows that the Electronic Speed Press and release this button to change the display from Control System is ON. odometer to “Trip A.” Press and release it a second time to change the display to “Trip B.”...
Page 167 166 UNDERSTANDING YOUR INSTRUMENT PANEL If the light is flashing when the engine is running you 20. Turn Signal Indicators may experience power loss, an elevated/rough idle, and The arrows will flash in unison with the exterior increased brake pedal effort, and your vehicle may turn signal, when using the turn signal lever.
Page 168 UNDERSTANDING YOUR INSTRUMENT PANEL 167 If the ABS light remains on or comes on during driving, it with the engine running. If the “ESC Indicator Light” indicates that the Anti-Lock portion of the brake system is comes on continuously with the engine running, a mal- not functioning and that service is required, however, the function has been detected in the ESC system.
Page 169 168 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: As an added safety feature, your vehicle has been • The “ESC Indicator Light” come on momentarily each equipped with a Tire Pressure Monitoring System time the ignition switch is turned ON. (TPMS) that illuminates a low tire pressure telltale when one or more of your tires is significantly under-inflated.
Page 170 UNDERSTANDING YOUR INSTRUMENT PANEL 169 Your vehicle has also been equipped with a TPMS CAUTION! malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is The TPMS has been optimized for the original combined with the low tire pressure telltale. When the equipment tires and wheels.
Page 171 170 UNDERSTANDING YOUR INSTRUMENT PANEL does not come on when turning the key from LOCK to WARNING! ON, have the condition checked promptly. A malfunctioning catalytic converter, as referenced Certain conditions such as a loose or missing gas cap, above, can reach higher temperatures than in normal poor fuel quality, etc., may illuminate the light after operating conditions.
Page 172 UNDERSTANDING YOUR INSTRUMENT PANEL 171 requested speed. If the high speed is maintained, the 28. High Beam Indicator overheating will reoccur as before in a cyclic fashion. This light indicates that the headlights are on high beam. Pull the turn signal lever toward the steer- CAUTION! ing wheel to switch the headlights to low beam.
Page 173: Electronic Vehicle Information Center (Evic) - If Equipped
172 UNDERSTANDING YOUR INSTRUMENT PANEL ELECTRONIC VEHICLE INFORMATION CENTER The EVIC consists of the following: (EVIC) – IF EQUIPPED • System Status The Electronic Vehicle Information Center (EVIC) fea- • Vehicle information warning message displays tures a driver-interactive display that is located in the instrument cluster.
Page 174 UNDERSTANDING YOUR INSTRUMENT PANEL 173 The system allows the driver to select information by Press and release the COMPASS button to pressing the following buttons on the instrument panel display the compass heading and the outside switch bank located below the climate controls: temperature.
Page 175: Electronic Vehicle Information Center (Evic) Displays
174 UNDERSTANDING YOUR INSTRUMENT PANEL • Left/Right Door Ajar (one or more, with a single Electronic Vehicle Information Center (EVIC) Displays chime if speed is above 1 mph) When the appropriate conditions exist, the EVIC displays • Door(s) Ajar (with a single chime if vehicle is in the following messages: motion) •...
Page 176: Oil Change Required - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 175 Oil Change Required — If Equipped 2. Fully depress the accelerator pedal slowly three times Your vehicle is equipped with an engine oil change within 10 seconds. indicator system. The “Oil Change Required” message 3. Turn the ignition switch to the LOCK position. will flash in the EVIC display for approximately five seconds after a single chime has sounded to indicate the NOTE: If the indicator message illuminates when you...
Page 177 176 UNDERSTANDING YOUR INSTRUMENT PANEL The Trip Functions mode displays the following informa- When the DTE value is less than 30 miles (48 km) tion: estimated driving distance, the DTE display will change to a text display of LOW FUEL. This display will con- •...
Page 178: Compass Display
UNDERSTANDING YOUR INSTRUMENT PANEL 177 To reset all resettable functions, press and release the Automatic Compass Calibration RESET button a second time within three seconds of This compass is self-calibrating, which eliminates the resetting the currently displayed function (Reset ALL will need to calibrate the compass manually.
Page 179 178 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Press and release the MENU Button until “Personal NOTE: Keep magnetic materials away from the top of Settings” displays in the EVIC. the instrument panel, such as iPod’s, Cell Phones, Lap- tops and Radar Detectors. This is where the compass 3.
Page 180: Personal Settings (Customer-Programmable Features)
UNDERSTANDING YOUR INSTRUMENT PANEL 179 1. Turn the ignition switch to the ON position. Leave the Personal Settings (Customer-Programmable shift lever in PARK. Features) Personal Settings allows the driver to set and recall 2. Press and release the MENU button until “Personal features when the automatic transaxle is in PARK.
Page 181 180 UNDERSTANDING YOUR INSTRUMENT PANEL Auto Unlock On Exit Sound Horn with LOCK When ON is selected and the transaxle is in the PARK or When ON is selected, a short horn sound will occur when NEUTRAL position, all doors will unlock when the the RKE transmitter LOCK button is pressed.
Page 182: Starting And Operating
UNDERSTANDING YOUR INSTRUMENT PANEL 181 Headlights With Wipers (Available with Auto Opening a vehicle door will cancel this feature. To make Headlights Only) your selection, press and hold the RESET button until When ON is selected, and the headlight switch is in the OFF, 45 sec, 5 min, or 10 min appears.
Page 183: Setting The Analog Clock
182 UNDERSTANDING YOUR INSTRUMENT PANEL Display Units In MEDIA CENTER 230 (REQ) — AM/FM STEREO The EVIC and odometer can be changed between English RADIO AND 6–DISC CD/DVD CHANGER and Metric units of measure. To make your selection, (MP3/WMA AUX JACK) press and release the RESET button until “ENGLISH”...
Page 184: Operating Instructions - Radio Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 183 Operating Instructions - Radio Mode to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make NOTE: The ignition switch must be in the ON or ACC another selection.
Page 185 184 UNDERSTANDING YOUR INSTRUMENT PANEL If your vehicle is not equipped with or this feature is not 2. Adjust the hours by turning the right side TUNE/ available on your vehicle, a “Not Equipped With SCROLL control knob. Uconnect” message will display on the radio screen. 3.
Page 186 UNDERSTANDING YOUR INSTRUMENT PANEL 185 RW/FF Push the rotary TUNE/SCROLL control knob a third Pressing the RW (Rewind) or FF (Fast Forward) buttons time and TREBLE will display. Turn the TUNE/SCROLL causes the tuner to search for the next frequency in the control knob to the right or left to increase or decrease the direction of the arrows.
Page 187 186 UNDERSTANDING YOUR INSTRUMENT PANEL or turning the TUNE/SCROLL control knob within five 16-Digit Character Program Type seconds will allow the program format type to be se- Display lected. Many radio stations do not currently broadcast Jazz Jazz Music Type information. News News Toggle the MUSIC TYPE button to select the following...
Page 188 UNDERSTANDING YOUR INSTRUMENT PANEL 187 NOTE: Turn the TUNE/SCROLL control knob to scroll 16-Digit Character Program Type through the entries. Push the AUDIO/SELECT button to Display select an entry and make changes. Top 40 Top 40 • DVD Enter - When the disc is in DVD Menu mode, Weather Weather selecting DVD Enter will allow you to play the current...
Page 189 188 UNDERSTANDING YOUR INSTRUMENT PANEL • Audio Stream – Repeatedly pressing SELECT will • VES™ CH1/CH2 - Allows the user to change the switch to different audio languages (if supported on mode of either the IR1 or IR2 wireless headphones by the disc) (if equipped).
Page 190 UNDERSTANDING YOUR INSTRUMENT PANEL 189 Enter the four-digit country code using the TUNE/ Subtitles — If Equipped SCROLL control knob to scroll up and down to select the Selecting this item allows you to choose between subtitle number and then push to select. Off or On.
Page 191 190 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The user will have to set these defaults before You may add a second station to each pushbutton by loading a disc. If changes are made to these settings after repeating the above procedure with this exception: Press a disc is loaded, changes will not be effective.
Page 192: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)
UNDERSTANDING YOUR INSTRUMENT PANEL 191 Operation Instructions - (DISC MODE for CD and NOTE: The ignition switch must be in the ON or ACC MP3/WMA Audio Play, DVD-VIDEO) position to operate the radio. The radio DVD player and many DVD discs are coded by LOAD Button —...
Page 193 192 UNDERSTANDING YOUR INSTRUMENT PANEL Eject Button — Ejecting Compact Disc(s) SCAN Button (CD MODE) Press the EJECT button and the pushbutton Press the SCAN button to scan through each track on the with the corresponding number (1-6) where the CD currently playing.
Page 194: Notes On Playing Mp3/Wma Files
UNDERSTANDING YOUR INSTRUMENT PANEL 193 Notes On Playing MP3/WMA Files The radio uses the following limits for file systems: The radio can play MP3/WMA files; however, acceptable • Maximum number of directory levels: 8 MP3/WMA file recording media and formats are limited. •...
Page 195 194 UNDERSTANDING YOUR INSTRUMENT PANEL If a disc contains multi-formats, such as CD audio and MPEG Sampling Bit Rate (kbps) MP3/WMA tracks, the radio will only play the MP3/ Specification Frequency (kHz) WMA tracks on that disc. 320, 256, 224, MPEG-1 Audio 192, 160, 128, Supported MP3/WMA File Formats...
Page 196: List Button (Disc Mode For Mp3/Wma Play)
UNDERSTANDING YOUR INSTRUMENT PANEL 195 Playback of MP3/WMA Files LIST Button (DISC Mode for MP3/WMA Play) When a medium containing MP3/WMA data is loaded, Pressing the LIST button will bring up a list of all folders the radio checks all files on the medium. If the medium on the disc.
Page 197 196 UNDERSTANDING YOUR INSTRUMENT PANEL Press and hold the INFO button again for three seconds SCAN Button (Auxiliary Mode) to return to elapsed time display. No function. Operation Instructions - Auxiliary Mode EJECT Button (Auxiliary Mode) The auxiliary (AUX) jack is an audio input jack which No function.
Page 198 UNDERSTANDING YOUR INSTRUMENT PANEL 197 Operating Instructions — Voice Command System Operating Instructions - Video Entertainment (If Equipped) System (VES)™ (If Equipped) For the radio, Refer to “Voice Command” in the Refer to “Video Entertainment System (VES)™” in the Uconnect™ User Manual located on the DVD for further Uconnect™...
Page 199: Media Center 730N/430 (Rer/Ren/Rbz) - Am/Fm Stereo Radio And Cd/Dvd/Hdd/ Nav - If Equipped
198 UNDERSTANDING YOUR INSTRUMENT PANEL DTS™ Operating Instructions — Voice Command DTS™ and DTS™ 2.0 are trademarks of Digital The- System — If Equipped ater Systems, Inc. Refer to “Voice Command” in the Uconnect™ User Manual located on the DVD for further details. MEDIA CENTER 730N/430 (RER/REN/RBZ) —...
Page 200 UNDERSTANDING YOUR INSTRUMENT PANEL 199 3. To move the hour forward, touch the screen where the 2. Touch the screen where the time is displayed. The word “Hour” with the arrow pointing upward is dis- clock setting menu will appear on the screen. played.
Page 201: Clock Setting Procedure - Rer/Ren Radio
200 UNDERSTANDING YOUR INSTRUMENT PANEL Changing the Time Zone satellite clock is Greenwich Mean Time (GMT). This is the worldwide standard for time. This makes the system’s 1. Turn on the radio. clock very accurate once the appropriate time zone and 2.
Page 202 UNDERSTANDING YOUR INSTRUMENT PANEL 201 displayed. To move the minute backward, touch the Show Time if Radio is Off screen where the word “Min” with the arrow pointing When selected, this feature will display the time of day downward is displayed. on the touch screen when the radio is turned off.
Page 203: Media Center 130 (Res) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
202 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Touch the screen where “User Clock” is displayed, the clock setting menu will appear on the screen. 4. Touch the screen where the words “Set Time Zone” are displayed. The time zone selection menu will appear on the screen.
Page 204 UNDERSTANDING YOUR INSTRUMENT PANEL 203 Power Switch/Volume Control (Rotary) TIME Button Push the ON/VOLUME control knob to turn on the Press the TIME button to alternate display of the time radio. Push the ON/VOLUME control knob a second and radio frequency. time to turn off the radio.
Page 205 204 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Push the rotary TUNE/SCROLL control knob a third Pressing the RW (Rewind) or FF (Fast Forward) buttons time and TREBLE will display. Turn the TUNE/SCROLL causes the tuner to search for the next frequency in the control knob to the right or left to increase or decrease the direction of the arrows.
Page 206: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 205 SET/RND Button — To Set the Pushbutton Every time a preset button is used, a corresponding Memory button number will display. When you are receiving a station that you wish to Buttons 1 - 6 commit to pushbutton memory, press the SET/RND These buttons tune the radio to the stations that you button.
Page 207 206 UNDERSTANDING YOUR INSTRUMENT PANEL discs (CD-RW), compact discs with MP3 tracks and CAUTION! multisession compact discs with CD and MP3 tracks. • This CD player will accept 4-3/4 in (12 cm) discs Inserting Compact Disc(s) only. The use of other sized discs may damage the Gently insert one CD into the CD player with the CD CD player mechanism.
Page 208 UNDERSTANDING YOUR INSTRUMENT PANEL 207 If you have ejected a disc and have not removed it within RW/FF 10 seconds, it will be reloaded. If the CD is not removed, Press and hold the FF (Fast Forward) button and the CD the radio will reinsert the CD but will not play it.
Page 209: Notes On Playing Mp3 Files
208 UNDERSTANDING YOUR INSTRUMENT PANEL • Maximum number of files: 255 Notes on Playing MP3 Files The radio can play MP3 files; however, acceptable MP3 • Maximum number of folders. (The radio display of file file recording media and formats are limited. When names and folder names is limited.
Page 210 UNDERSTANDING YOUR INSTRUMENT PANEL 209 Discs created with an option such as keep disc open after MPEG Sampling Bit Rate (kbps) writing are most likely multisession discs. The use of Specification Frequency (kHz) multisession for CD audio or MP3 playback may result in 320, 256, 224, longer disc loading times.
Page 211: Operation Instructions - Auxiliary Mode
210 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files Operation Instructions - Auxiliary Mode When a medium containing MP3 data is loaded, the The auxiliary (AUX) jack is an audio input jack, which radio checks all files on the medium. If the medium allows the user to plug in a portable device, such as an contains a lot of folders or files, the radio will take more MP3 player, or cassette player, and utilize the vehicle’s...
Page 212: Media Center 130 (Res/Rsc) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Sirius Radio
UNDERSTANDING YOUR INSTRUMENT PANEL 211 MEDIA CENTER 130 (RES/RSC) — AM/FM Operating Instructions — Radio Mode STEREO RADIO WITH CD PLAYER (MP3 AUX NOTE: The ignition switch must be in the ON or ACC JACK) AND SIRIUS RADIO position to operate the radio. NOTE: The radio sales code is located on the lower right Power Switch/Volume Control (Rotary) side of the radio faceplate.
Page 213 212 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons If your vehicle is not equipped with or this feature is not Press and release the SEEK buttons to search for the next available on your vehicle, a “Not Equipped With listenable station in AM/FM mode. Press the right switch Uconnect”...
Page 214 UNDERSTANDING YOUR INSTRUMENT PANEL 213 2. Adjust the hours by turning the right side TUNE/ INFO Button SCROLL control knob. Press the INFO button for an RDS station (one with call letters displayed). The radio will return a Radio Text 3.
Page 215 214 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a second Push the rotary TUNE/SCROLL control knob again to time and MID will display. Turn the TUNE/SCROLL exit setting tone, balance, and fade. control knob to the right or left to increase or decrease the MUSIC TYPE Button mid-range tones.
Page 216 UNDERSTANDING YOUR INSTRUMENT PANEL 215 16-Digit Character Dis- 16-Digit Character Dis- Program Type Program Type play play Classic Rock Cls Rock Soft Soft College College Soft Rock Soft Rck Country Country Soft Rhythm and Blues Soft R&B Foreign Language Language Sports Sports Information...
Page 217 216 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button window. Select the button (1–6) you wish to lock onto this Pressing the SETUP button allows you to select between station and press and release that button. If a button is the following items: not selected within five seconds after pressing the SET/ RND button, the station will continue to play but will not •...
Page 218: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 217 Buttons 1 - 6 Inserting Compact Disc(s) These buttons tune the radio to the stations that you Gently insert one CD into the CD player with the CD commit to pushbutton memory (12 AM and 12 FM label facing up.
Page 219 218 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Ejecting with the ignition OFF is not allowed on CAUTION! (Continued) convertible or soft-top models (if equipped). • Do not use adhesive labels. These labels can peel SEEK Button away and jam the player mechanism. Press the right SEEK button for the next selection on the •...
Page 220: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 219 AM/FM Button Supported Media (Disc Types) Press the button to select either AM or FM mode. The MP3 file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3, and CDDA+MP3. SET/RND Button (Random Play Button) Press this button while the CD is playing to activate Supported Medium Formats (File Systems) Random Play.
Page 221 220 UNDERSTANDING YOUR INSTRUMENT PANEL a number instead. With a maximum number of files, Supported MP3 File Formats exceeding 20 folders will result in this display. With The radio will recognize only files with the *.MP3 exten- 200 files, exceeding 50 folders will result in this sion as MP3 files.
Page 222 UNDERSTANDING YOUR INSTRUMENT PANEL 221 Playback of MP3 Files MPEG Sampling Bit Rate (kbps) When a medium containing MP3 data is loaded, the Specification Frequency (kHz) radio checks all files on the medium. If the medium 320, 256, 224, contains a lot of folders or files, the radio will take more MPEG-1 Audio 192, 160, 128, 48, 44.1, 32...
Page 223: List Button (Cd Mode For Mp3 Play)
222 UNDERSTANDING YOUR INSTRUMENT PANEL LIST Button (CD Mode for MP3 Play) Press and hold the INFO button again for three seconds Pressing the LIST button will bring up a list of all folders to return to elapsed time display. on the disc.
Page 224: Uconnect™ Multimedia (Satellite Radio) - If
UNDERSTANDING YOUR INSTRUMENT PANEL 223 TIME Button (Auxiliary Mode) coast. The subscription service provider is Sirius Satellite Press this button to change the display to time of day. The Radio. This service offers over 130 channels of music, time of day will display for five seconds (when the sports, news, entertainment, and programming for chil- ignition is OFF).
Page 225: Electronic Serial Number/Sirius Identification Number (Esn/Sid)
224 UNDERSTANDING YOUR INSTRUMENT PANEL Electronic Serial Number/Sirius Identification ESN/SID Access With REN/RER/RBZ Radios Number (ESN/SID) While in SAT mode, press the MENU button on the radio Please have the following information available when faceplate. calling: Next, touch the SUBSCRIPTION tab on the touch screen. 1.
Page 226: Reception Quality
UNDERSTANDING YOUR INSTRUMENT PANEL 225 Reception Quality SEEK Buttons Satellite reception may be interrupted due to one of the Press and release the SEEK buttons to search for the next following reasons: channel in Satellite mode. Press the right switch to seek up and the left switch to seek down.
Page 227 226 UNDERSTANDING YOUR INSTRUMENT PANEL additional three seconds will make the radio display the Toggle the MUSIC TYPE button again to select the music Song Title all of the time (press and hold again to return type. to normal display). By pressing the SEEK button when the Music Type RW/FF function is active, the radio will be tuned to the next...
Page 228: Operating Instructions - Uconnect™ Phone (If Equipped)
UNDERSTANDING YOUR INSTRUMENT PANEL 227 SET Button – To Set the Pushbutton Memory pushbutton memory. The channels stored in SET 2 When you are receiving a channel that you wish to memory can be selected by pressing the pushbutton commit to pushbutton memory, press the SET button. twice.
Page 229: Remote Sound System Controls - If Equipped
228 UNDERSTANDING YOUR INSTRUMENT PANEL REMOTE SOUND SYSTEM CONTROLS — IF EQUIPPED The remote sound system controls are located on the rear surface of the steering wheel. The left and right controls are rocker-type switches with a pushbutton in the center of each switch.
Page 230: Left-Hand Switch Functions For Radio Operation
UNDERSTANDING YOUR INSTRUMENT PANEL 229 • Press the button in the center of the switch to change beginning of the previous track if it is within one modes (i.e., AM, FM, etc.). second after the current track begins to play. •...
Page 231: Radio Operation And Cellular Phones
230 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Do not use solvents such as benzene, thinner, cleaners, RADIO OPERATION AND CELLULAR PHONES or anti-static sprays. Under certain conditions, the cellular phone being on in your vehicle can cause erratic or noisy performance from 5.
Page 232: Manual Heating And Air Conditioning
UNDERSTANDING YOUR INSTRUMENT PANEL 231 Manual Heating and Air Conditioning Blower Control Rotate this control to regulate the amount of air forced through the ven- tilation system in any mode. The blower speed increases as you move the control to the right from the “O” (OFF) position.
Page 233 232 UNDERSTANDING YOUR INSTRUMENT PANEL Temperature Control Mode Control (Air Direction) Rotate this control to regulate the tem- Rotate this control to choose from sev- perature of the air inside the passenger eral patterns of air distribution. You compartment. Rotating the dial left can select either a primary mode as into the blue area of the scale indicates identified by the symbols on the con-...
Page 234 UNDERSTANDING YOUR INSTRUMENT PANEL 233 NOTE: For all settings except full cold or full hot, there Defrost is a difference in temperature between the upper and Air is directed through the windshield and side lower outlets. The warmer air flows to the floor outlets. window demist outlets.
Page 235 234 UNDERSTANDING YOUR INSTRUMENT PANEL will cause the LED in the control button to illuminate. several times then go out. Recirculation will be dis- After ten minutes, the system will return to normal mode abled automatically is these modes are selected. function and the LED will turn off.
Page 236: Automatic Temperature Control (Atc) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 235 • MAX A/C Automatic Temperature Control (ATC) — If For maximum cooling use the A/C and recirculation Equipped buttons at the same time. • ECONOMY MODE If economy mode is desired, press the A/C button to turn OFF the indicator light and the A/C compressor.
Page 237 236 UNDERSTANDING YOUR INSTRUMENT PANEL Operation of the system is quite simple. the “O” (OFF) position on the blower control stops the system completely and closes the outside air intake. 1. Turn the Mode Control knob (on the right) and the Blower Control knob (on the left) to AUTO.
Page 238 UNDERSTANDING YOUR INSTRUMENT PANEL 237 the radiator and through the condenser. Fabric front Manual Operation fascia protectors may reduce airflow to the condenser, This system offers a full complement of manual override reducing air conditioning performance. features, which consist of Blower Preferred Automatic, Mode Preferred Automatic, or Blower and Mode Pre- •...
Page 239 238 UNDERSTANDING YOUR INSTRUMENT PANEL...
Page 240 UNDERSTANDING YOUR INSTRUMENT PANEL 239 • Floor The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control Air is directed through the floor outlets with a knob (on the right) to one of the following positions. small amount flowing through the defrost and side window demist outlets.
Page 241 240 UNDERSTANDING YOUR INSTRUMENT PANEL • Air Conditioner Control NOTE: • When the ignition switch is turned to the LOCK Press this button to turn on the air conditioning during manual operation position, the recirculation feature will be cancelled. only. When the air conditioning is •...
Page 242: Operating Tips
UNDERSTANDING YOUR INSTRUMENT PANEL 241 • Most of the time, when in Automatic Operation, you Summer Operation can temporarily put the system into Recirculation The engine cooling system in air-conditioned vehicles Mode by pressing the Recirculation button. However, must be protected with a high-quality antifreeze coolant under certain conditions, while in Automatic Mode, to provide proper corrosion protection and to protect the system is blowing air out the defrost vents.
Page 243 242 UNDERSTANDING YOUR INSTRUMENT PANEL adequate system lubrication to minimize the possibility FLOOR, MIX, or DEFROST mode. The air is directed at of compressor damage when the system is started again. the area of the windows through which you view the outside mirrors.
Page 244 UNDERSTANDING YOUR INSTRUMENT PANEL 243 Control Setting Suggestions for Various Weather Conditions...
Page 246 STARTING AND OPERATING CONTENTS ▫ Brake/Transaxle Interlock System ..254 Starting Procedures ....249 ▫...
Page 247 246 STARTING AND OPERATING ▫ Traction ......262 Tire Safety Information ....279 ▫...
Page 248 STARTING AND OPERATING 247 ▫ Materials Added To Fuel ....311 Tire Chains ......297 ▫...
Page 249 248 STARTING AND OPERATING ▫ Trailer Hitch Classification ....323 Adding Fuel ......317 ▫...
Page 250: Starting Procedures
STARTING AND OPERATING 249 STARTING PROCEDURES Automatic Transaxle Before starting your vehicle, adjust your seat, adjust the The shift lever must be in the PARK or NEUTRAL inside and outside mirrors, fasten your seat belt, and if position before you can start the engine. Apply the brakes present, instruct all other occupants to buckle their seat before shifting to any driving gear.
Page 251: Extreme Cold Weather (Below 20°F Or 29°C)
250 STARTING AND OPERATING For vehicles equipped with Tip Start (Six-Speed Trans- If Engine Fails To Start axle), turn the ignition switch to the START position and WARNING! release it as soon as the starter engages. The starter motor will continue to run, and it will disengage automatically •...
Page 252: What To Do In Emergencies
STARTING AND OPERATING 251 the way to the floor and hold it there while cranking the WARNING! (Continued) engine. This should clear any excess fuel in case the • Do not attempt to push or tow your vehicle to get engine is flooded.
Page 253: After Starting
252 STARTING AND OPERATING With Tip Start ENGINE BLOCK HEATER — IF EQUIPPED If the engine fails to start after you have followed the The engine block heater warms the engine, and permits “Normal Starting” or “Extreme Cold Weather” proce- quicker starts in cold weather.
Page 254: Automatic Transaxle
STARTING AND OPERATING 253 AUTOMATIC TRANSAXLE NOTE: You MUST press and hold the brake pedal down while shifting the shift lever out of PARK. CAUTION! WARNING! Damage to the transaxle may occur if the following • It is dangerous to move the shift lever out of PARK precautions are not observed: •...
Page 255: Key Ignition Park Interlock
254 STARTING AND OPERATING can only be removed from the ignition when the ignition WARNING! (Continued) is in the LOCK position and once removed the shift lever • Unintended movement of a vehicle could injure is locked in PARK. those in and near the vehicle. As with all vehicles, Brake/Transaxle Interlock System you should never exit a vehicle while the engine is This vehicle is equipped with a Brake Transmission Shift...
Page 256: Automatic Transaxle Ignition Interlock System
STARTING AND OPERATING 255 • Insert the ignition key into the ignition switch and Automatic Transaxle Ignition Interlock System rotate it to the ON position. This system prevents the key from being removed unless the shift lever is in PARK. It also prevents shifting out of •...
Page 257: Four-Speed/Six-Speed Automatic Transaxle
256 STARTING AND OPERATING Four-Speed/Six-Speed Automatic Transaxle The electronically controlled transaxle provides a precise shift schedule. The transaxle electronics are self- calibrating; therefore, the first few shifts on a new vehicle may be somewhat abrupt. This is a normal condition, and precision shifts will develop within a few hundred miles/kilometers.
Page 258 STARTING AND OPERATING 257 When parking on a flat surface, place the shift lever into CAUTION! the PARK position first, and then apply the parking brake. DO NOT race the engine when shifting from PARK or NEUTRAL positions into another gear range as When parking on a hill, it is important to set the parking this can damage the drivetrain.
Page 259 258 STARTING AND OPERATING gear in AutoStick will improve the performance and WARNING! extend transmission life by reducing excessive shifting and heat build-up. Do not coast in NEUTRAL and never turn off the ignition switch to coast down a hill. These are unsafe DRIVE –...
Page 260 STARTING AND OPERATING 259 gear in AutoStick will improve the performance and occur only to prevent engine overspeed while downshifts extend transmission life by reducing excessive shifting occur earlier than other gear range selections. and heat build-up. CAUTION! DRIVE 3 — Four-Speed Transaxle This range eliminates shifts into fourth gear.
Page 261: Autostick - If Equipped
260 STARTING AND OPERATING will continue to operate. The Reset feature allows the If the transaxle cannot be reset, dealer service is required. vehicle to be driven to a dealer for service without AUTOSTICK — IF EQUIPPED damaging the transaxle. AutoStick is a driver-interactive transaxle that offers six In the event of a momentary problem, the transaxle can manual ratio changes to provide you with more control...
Page 262: General Information
STARTING AND OPERATING 261 • The transaxle will automatically shift up when maxi- NOTE: In AutoStick mode, the transaxle will only shift up or down when the driver moves the shift lever to the mum engine speed is reached while AutoStick is right (+) or left (-).
Page 263: Driving On Slippery Surfaces
262 STARTING AND OPERATING DRIVING ON SLIPPERY SURFACES Traction When driving on wet or slushy roads, it is possible for a Acceleration wedge of water to build up between the tire and road Rapid acceleration on snow covered, wet, or other slip- surface.
Page 264: Driving Through Water
STARTING AND OPERATING 263 DRIVING THROUGH WATER Shallow Standing Water Driving through water more than a few inches/ Although your vehicle is capable of driving through centimeters deep will require extra caution to ensure shallow standing water, consider the following Caution safety and prevent damage to your vehicle.
Page 265 264 STARTING AND OPERATING CAUTION! (Continued) WARNING! • Driving through standing water may cause dam- • Driving through standing water limits your vehi- age to your vehicle’s drivetrain components. Al- cle’s traction capabilities. Do not exceed 5 mph ways inspect your vehicle’s fluids (i.e., engine oil, (8 km/h) when driving through standing water.
Page 266: Power Steering
STARTING AND OPERATING 265 POWER STEERING system. This noise should be considered normal, and it The standard power steering system will give you good does not in any way damage the steering system. vehicle response and increased ease of maneuverability WARNING! in tight spaces.
Page 267: Parking Brake
266 STARTING AND OPERATING checked if a leak is suspected, abnormal noises are If necessary, add fluid to restore to the proper indicated apparent, and/or the system is not functioning as antici- level. With a clean cloth, wipe any spilled fluid from all pated.
Page 268 STARTING AND OPERATING 267 NOTE: • When the parking brake is applied and the transaxle is placed in gear, the “Brake Warning Light” will flash. If vehicle speed is detected, a chime will sound to alert the driver. Fully release the parking brake before attempting to move the vehicle.
Page 269 268 STARTING AND OPERATING WARNING! WARNING! (Continued) • Always fully apply the parking brake when leav- • Never use the PARK position as a substitute for ing your vehicle or it may roll and cause damage or the parking brake. Always apply the parking injury.
Page 270: Anti-Lock Brake System (Abs)
STARTING AND OPERATING 269 ANTI-LOCK BRAKE SYSTEM (ABS) WARNING! (Continued) The Anti-Lock Brake System (ABS) provides increased • The ABS cannot prevent the natural laws of phys- vehicle stability and brake performance under most ics from acting on the vehicle, nor can it increase braking conditions.
Page 271 270 STARTING AND OPERATING The “Anti-Lock Brake Warning Light” moni- If both the “Brake Warning Light” and the “Anti-Lock tors the Anti-Lock Brake System. The light will Brake Warning Light” remain on, the Anti-Lock Brake come on when the ignition switch is turned to (ABS) and Electronic Brake Force Distribution (EBD) the ON position and may stay on for as long as Systems are not functioning.
Page 272 STARTING AND OPERATING 271 You also may experience the following when the brake WARNING! system goes into anti-lock: The Anti-Lock Brake System contains sophisticated • The ABS motor running (it may continue to run for a electronic equipment that may be susceptible to short time after the stop), interference caused by improperly installed or high •...
Page 273: Electronic Brake Control System
272 STARTING AND OPERATING ELECTRONIC BRAKE CONTROL SYSTEM Traction Control System (TCS) Your vehicle may be equipped with an optional ad- This system monitors the amount of wheel spin of each of vanced electronic brake control system that includes the driven wheels. If wheel spin is detected, brake Anti-Lock Brake System (ABS), Traction Control System pressure is applied to the slipping wheel(s) and engine (TCS), Brake Assist System (BAS), Hill Start Assist (HSA),...
Page 274: Hill Start Assist (Hsa) - If Equipped
STARTING AND OPERATING 273 applies optimum pressure to the brakes. This can help WARNING! (Continued) reduce braking distances. The BAS complements the • The BAS cannot prevent accidents, including Anti-Lock Brake System (ABS). Applying the brakes very those resulting from excessive speed in turns, quickly results in the best BAS assistance.
Page 275 274 STARTING AND OPERATING and the vehicle will roll down the incline. The system will WARNING! release brake pressure in proportion to the amount of throttle applied. There may be situations on minor hills (i.e., less than 7%), with a loaded vehicle or while pulling a trailer During operation, HSA will activate the brake control where the system will not activate and slight rolling system and a clicking noise may occur.
Page 276 STARTING AND OPERATING 275 HSA Off 7. Press the “ESC Off” switch four times within 20 sec- onds. The “ESC Off Indicator Light” should turn on and Non-EVIC Equipped Vehicles turn off two times. If you wish to turn off the HSA system, follow this procedure: 8.
Page 277: Electronic Stability Control (Esc)
276 STARTING AND OPERATING Electronic Stability Control (ESC) ESC Off Indicator Light The “ESC Off Indicator Light” (located in the This system enhances directional control and stability of instrument cluster) starts to flash as soon as the the vehicle under various driving conditions. ESC cor- tires lose traction and the ESC system becomes rects for over/under steering of the vehicle by applying active.
Page 278 STARTING AND OPERATING 277 several ignition cycles, and the vehicle has been driven WARNING! (Continued) several miles (kilometers) at speeds greater than 30 mph • ESC cannot prevent accidents, including those (48 km/h), see your authorized dealer as soon as possible resulting from excessive speed in turns, driving on to have the problem diagnosed and corrected.
Page 279 278 STARTING AND OPERATING ESC Operating Modes other stability features of ESC function normally, with the All ESC equipped vehicles can choose the following ESC exception of engine power reduction. This mode is operating modes: intended to be used if the vehicle is in deep snow, sand, or gravel conditions and more wheel spin than ESC ESC On would normally allow is required to gain traction.
Page 280: Tire Safety Information
STARTING AND OPERATING 279 NOTE: To improve the vehicle’s traction when driving TIRE SAFETY INFORMATION with snow chains, or starting off in deep snow, sand or Tire Markings gravel, it may be desirable to switch to the “Partial Off” mode by pressing the “ESC Off” switch. Once the situa- tion requiring ESC to be switched to the “Partial Off”...
Page 281 280 STARTING AND OPERATING • Temporary spare tires are high-pressure compact NOTE: • P (Passenger) - Metric tire sizing is based on U.S. spares designed for temporary emergency use only. design standards. P-Metric tires have the letter “P” Tires designed to this standard have the letter “T” molded into the sidewall preceding the size designa- molded into the sidewall preceding the size designa- tion.
Page 282 STARTING AND OPERATING 281 Tire Sizing Chart EXAMPLE: Size Designation: P = Passenger car tire size based on U.S. design standards ..blank..= Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 283 282 STARTING AND OPERATING EXAMPLE: Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 284: Tire Identification Number (Tin)
STARTING AND OPERATING 283 Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side.
Page 285: Tire Terminology And Definitions
284 STARTING AND OPERATING Tire Terminology and Definitions Term Definition B-Pillar The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof. Cold Tire Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 286: Tire Loading And Tire Pressure
STARTING AND OPERATING 285 Tire Loading and Tire Pressure Tire and Loading Information Placard Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry 3) tire size designed for your vehicle...
Page 287 286 STARTING AND OPERATING Loading occupants and cargo should never exceed XXX lbs or The vehicle maximum load on the tire must not exceed XXX kg” on the Tire and Loading Information placard. the load carrying capacity of the tire on your vehicle. You The combined weight of occupants, cargo/luggage and will not exceed the tire’s load carrying capacity if you trailer tongue weight (if applicable) should never exceed...
Page 288 STARTING AND OPERATING 287 4. The resulting figure equals the available amount of NOTE: • The following table shows examples on how to calcu- cargo and luggage load capacity. For example, if “XXX” amount equals 1,400 lbs (635 kg) and there will be five late total load, cargo/luggage, and towing capacities 150 lb (68 kg) passengers in your vehicle, the amount of of your vehicle with varying seating configurations...
Page 289 288 STARTING AND OPERATING...
Page 290: Tires - General Information
STARTING AND OPERATING 289 Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause accidents. recommended load capacity for your vehicle.
Page 291: Tire Inflation Pressures
290 STARTING AND OPERATING Tire Inflation Pressures WARNING! (Continued) The proper cold tire inflation pressure is listed on the • Unequal tire pressures from one side of the ve- driver’s side B-Pillar. hicle to the other can cause the vehicle to drift to Some vehicles may have Supplemental Tire Pressure the right or left.
Page 292 STARTING AND OPERATING 291 Tire pressures change by approximately 1 psi (7 kPa) per CAUTION! 12°F (7°C) of air temperature change. Keep this in mind when checking tire pressure inside a garage, especially in After inspecting or adjusting the tire pressure, al- the winter.
Page 293: Radial-Ply Tires
292 STARTING AND OPERATING Tire Pressures for High Speed Operation Radial-Ply Tires The manufacturer advocates driving at safe speeds WARNING! within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high Combining radial ply tires with other types of tires speeds, maintaining correct tire inflation pressure is very on your vehicle will cause your vehicle to handle...
Page 294: Tire Spinning
STARTING AND OPERATING 293 Do not install a wheel cover or attempt to mount a WARNING! conventional tire on the compact spare wheel since the wheel is designed specifically for the compact spare. Temporary use spare tires are for emergency use only. With these tires, do not drive more than 50 mph Do not install more than one compact spare tire/wheel (80 km/h).
Page 295: Tread Wear Indicators
294 STARTING AND OPERATING Refer to “Freeing A Stuck Vehicle” in “What To Do In Emergencies” for further information. WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one.
Page 296: Life Of Tire
STARTING AND OPERATING 295 Life of Tire Replacement Tires The service life of a tire is dependent upon varying The tires on your new vehicle provide a balance of many factors including but not limited to: characteristics. They should be inspected regularly for wear and correct cold tire inflation pressure.
Page 297 296 STARTING AND OPERATING WARNING! WARNING! (Continued) • Failure to equip your vehicle with tires having • Do not use a tire, wheel size or rating other than adequate speed capability can result in sudden tire that specified for your vehicle. Some combinations failure and loss of vehicle control.
Page 298: Tire Chains
STARTING AND OPERATING 297 TIRE CHAINS Snow tires generally have lower speed ratings than what Due to limited clearance, tire chains are not recom- was originally equipped with your vehicle and should mended. not be operated at sustained speeds over 75 mph (120 km/h).
Page 299: Tire Pressure Monitor System (Tpms)
298 STARTING AND OPERATING Refer to “Maintenance Schedule” for the proper mainte- TIRE PRESSURE MONITOR SYSTEM (TPMS) nance intervals. More frequent rotation is permissible if The Tire Pressure Monitor System (TPMS) will warn the desired. The reasons for any rapid or unusual wear driver of a low tire pressure based on the vehicle recom- should be corrected prior to rotation being performed.
Page 300 STARTING AND OPERATING 299 The TPM System will warn the driver of a low tire For example, your vehicle may have a recommended pressure if the tire pressure falls below the low-pressure cold (parked for more than three hours) placard pressure warning limit for any reason, including low temperature of 30 psi (207 kPa).
Page 301 300 STARTING AND OPERATING NOTE: CAUTION! • The TPMS is not intended to replace normal tire care • The TPMS has been optimized for the original and maintenance, or to provide warning of a tire failure or condition. equipment tires and wheels. TPMS pressures and warning have been established for the tire size •...
Page 302: Base System
STARTING AND OPERATING 301 • Seasonal temperature changes will affect tire pressure, Tire Pressure Monitoring Low Pressure Warnings and the TPMS will monitor the actual tire pressure in The “Tire Pressure Monitoring Telltale Light” will the tire. illuminate in the instrument cluster and a chime will sound when tire pressure is low in one or Base System more of the four active road tires.
Page 303 302 STARTING AND OPERATING will repeat, providing the system fault still exists. The NOTE: “Tire Pressure Monitoring Telltale Light” will turn off 1. The compact spare tire (if so equipped) does not have when the fault condition no longer exists. A system fault a tire pressure monitoring sensor.
Page 304: Premium System - If Equipped
STARTING AND OPERATING 303 5. Once you repair or replace the original road tire, and NOTE: It is particularly important for you to check the reinstall it on the vehicle in place of the compact spare, tire pressure in all of the tires on your vehicle monthly the TPMS will update automatically and the “TPM and to maintain the proper pressure.
Page 305 304 STARTING AND OPERATING Tire Pressure Monitoring Low Pressure Warnings The “Tire Pressure Monitoring Telltale Light” will illuminate in the instrument cluster and a chime will sound when tire pressure is low in one or more of the four active road tires. In addition, the Electronic Vehicle Information Center (EVIC) will display a graphic showing the pressure values of each tire with the low tire pressure values flashing.
Page 306 STARTING AND OPERATING 305 will turn off. The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information. Check TPMS Warning When a system fault is detected, a chime will sound and the “Tire Pressure Monitoring Telltale Light”...
Page 307 306 STARTING AND OPERATING If the ignition key is cycled, this sequence will repeat, NOTE: providing the system fault still exists. If the system fault 1. The compact spare tire (if so equipped) does not have no longer exists, the “Tire Pressure Monitoring Telltale a tire pressure monitoring sensor.
Page 308: General Information
STARTING AND OPERATING 307 75 seconds and then remain on solid, and the EVIC will General Information display a CHECK TPM SYSTEM message for three This device complies with part 15 of the FCC rules and seconds and then display dashes (- -) in place of the RSS 210 of Industry Canada.
Page 309: Fuel Requirements
308 STARTING AND OPERATING FUEL REQUIREMENTS for optimum performance. The use of premium gasoline is not recommended, as it will not provide any benefit 2.4L and 2.7L Engine over regular gasoline in these engines. All engines are designed to meet all emis- sion regulations and provide excellent fuel Light spark knock at low engine speeds is not harmful to economy and performance when using...
Page 310: Reformulated Gasoline
STARTING AND OPERATING 309 vehicle. The manufacturer recommends the use of gaso- winter months to reduce carbon monoxide emissions. lines that meet the WWFC specifications if they are Fuels blended with these oxygenates may be used in available. your vehicle. Reformulated Gasoline CAUTION! Many areas of the country require the use of cleaner...
Page 311: E-85 Usage In Non-Flex Fuel Vehicles
310 STARTING AND OPERATING manufacturer. While MTBE is an oxygenate made from To fix a Non-FFV vehicle inadvertently fueled once with Methanol, it does not have the negative effects of E-85 perform the following: Methanol. • drain the fuel tank (see your authorized dealer) E-85 Usage In Non-Flex Fuel Vehicles •...
Page 312: Materials Added To Fuel
STARTING AND OPERATING 311 of gasoline may not be indicated on the gasoline pump, Fuel System Cautions therefore, you should ask your gasoline retailer whether CAUTION! or not his/her gasoline contains MMT. It is even more important to look for gasolines without Follow these guidelines to maintain your vehicle’s MMT in Canada, because MMT can be used at levels performance:...
Page 313: Carbon Monoxide Warnings
312 STARTING AND OPERATING Carbon Monoxide Warnings CAUTION! (Continued) • The use of fuel additives, which are now being WARNING! sold as octane enhancers, is not recommended. Carbon monoxide (CO) in exhaust gases is deadly. Most of these products contain high concentra- Follow the precautions below to prevent carbon tions of methanol.
Page 314: Flexible Fuel (2.7L Only) - If Equipped
STARTING AND OPERATING 313 the other sections of this manual for information on WARNING! (Continued) features that are common between Flexible Fuel and • Guard against carbon monoxide with proper gasoline-only powered vehicles. maintenance. Have the exhaust system inspected NOTE: The 2.7L engine is now rated for E85 Ethanol every time the vehicle is raised.
Page 315: Ethanol Fuel (E85)
314 STARTING AND OPERATING Ethanol Fuel (E85) CAUTION! E85 is a mixture of approximately 85% fuel ethanol and 15% unleaded gasoline. Only vehicles with the E85 fuel filler door label can operate on E85. WARNING! Ethanol vapors are extremely flammable and could cause serious personal injury.
Page 316: Selection Of Engine Oil For Flexible Fuel Vehicles (E85) And Gasoline Vehicles
MOPAR engine oils, and in equivalent oils meeting during warm up. Chrysler Specification MS-6395. The manufacturer only NOTE: recommends engine oils that are API Certified and meet • Use seasonally adjusted E85 fuel (ASTM D5798). With the requirements of Material Standard MS-6395.
Page 317: Starting
316 STARTING AND OPERATING Starting Replacement Parts The characteristics of E85 fuel make it unsuitable for use Many components in your Flexible Fuel Vehicle (FFV) are when ambient temperatures fall below 0°F (-18°C). In the designed to be compatible with ethanol. Always be sure range of 0°F (-18°C) to 32°F (0°C), you may experience an that your vehicle is serviced with correct ethanol com- increase in the time it takes for your engine to start, and...
Page 318: Adding Fuel
STARTING AND OPERATING 317 ADDING FUEL After removing the gas cap, place the gas cap tether cable over a hook on the inside of the fuel door. This keeps the Fuel Filler Cap (Gas Cap) gas cap suspended away from and protects the vehicle’s The gas cap is behind the fuel filler door, on the left rear surface.
Page 319 318 STARTING AND OPERATING CAUTION! WARNING! (Continued) • Never add fuel when the engine is running. This is • Damage to the fuel system or emission control in violation of most state and federal fire regula- system could result from using an improper fuel tions and doing so will cause the MIL to turn on.
Page 320: Loose Filler Cap Message
STARTING AND OPERATING 319 • Month and year of manufacture Loose Filler Cap Message If the vehicles diagnostic system determines that the fuel • Gross Vehicle Weight Rating (GVWR) filler cap in loose, improperly installed, or damaged, a • Gross Axle Weight Rating (GAWR) front “gASCAP”...
Page 321: Gross Axle Weight Rating (Gawr)
320 STARTING AND OPERATING Gross Axle Weight Rating (GAWR) The best way to figure out the total weight of your The GAWR is the maximum capacity of the front and rear vehicle is to weigh it when it is fully loaded and ready for axles.
Page 322: Trailer Towing
STARTING AND OPERATING 321 the specified GVWR, you must redistribute the weight. Common Towing Definitions Improper weight distribution can have an adverse effect The following trailer towing related definitions will assist on the way your vehicle steers and handles and the way you in understanding the following information: the brakes operate.
Page 323 322 STARTING AND OPERATING Gross Combination Weight Rating (GCWR) Trailer Tongue Weight (TW) The GCWR is the total permissible weight of your vehicle The tongue weight is the downward force exerted on the and trailer when weighed in combination. hitch ball by the trailer. In most cases it should not be less than or more than 10% of the trailer load.
Page 324: Trailer Hitch Classification
STARTING AND OPERATING 323 Trailer Hitch Classification Trailer Hitch Classification Definitions The following chart provides the industry standard for Class Max. Trailer Hitch Industry the maximum trailer weight a given trailer hitch class can Standards tow and should be used to assist you in selecting the Class I - Light Duty 2,000 lbs (907 kg) correct trailer hitch for your intended towing condition.
Page 325: Trailer Towing Weights (Maximum Trailer Weight Ratings)
324 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Maximum Trailer Weight Ratings Engine/Transaxle Max. Frontal Area Max. GTW (Gross Trailer Wt.) Max. Trailer Tongue Wt. 2.4L/Auto See Note Not Recommended...
Page 326: Trailer And Tongue Weight
STARTING AND OPERATING 325 Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle. Loads balanced over the wheels or heavier in the rear can cause the trailer to sway severely side to side which will cause loss of control of vehicle and trailer.
Page 327: Towing Requirements
326 STARTING AND OPERATING NOTE: Remember that everything put into or on the Towing Requirements trailer adds to the load on your vehicle. Also, additional To promote proper break-in of your new vehicle drive- factory-installed options, or authorized dealer-installed train components the following guidelines are recom- options, must be considered as part of the total load on mended: your vehicle.
Page 328 STARTING AND OPERATING 327 WARNING! WARNING! (Continued) • Safety chains must always be used between your Improper towing can lead to an injury accident. vehicle and trailer. Always connect the chains to Follow these guidelines to make your trailer towing the frame or hook retainers of the vehicle hitch.
Page 329 328 STARTING AND OPERATING • Check for signs of tire wear or visible tire damage WARNING! (Continued) before towing a trailer. Refer to “Tires – General 3. GAWR Information” in “Starting and Operating” for informa- 4. Trailer tongue weight rating for the trailer hitch tion on tread wear indicators and for proper inspection utilized (This requirement may limit the ability to procedure.
Page 330 STARTING AND OPERATING 329 • An electronically actuated trailer brake controller is WARNING! required when towing a trailer with electronically • Do not connect trailer brakes to your vehicle’s actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic hydraulic brake lines.
Page 331: Towing Tips
330 STARTING AND OPERATING Towing Tips If you REGULARLY TOW a trailer for more than 45 min- Before setting out on a trip, practice turning, stopping, utes of continuous operation, then change the automatic and backing the trailer in an area located away from transaxle fluid and filter according to the interval speci- heavy traffic.
Page 332: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING 331 Cooling System RECREATIONAL TOWING (BEHIND To reduce potential for engine and transaxle overheating, MOTORHOME, ETC.) take the following actions: Towing This Vehicle Behind Another Vehicle (Flat • City Driving towing with all four wheels on the ground) When stopped for short periods of time, shift the trans- CAUTION! axle into NEUTRAL and increase engine idle speed.
Page 334 WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....334 Jump-Starting ......343 ▫...
Page 335: Hazard Warning Flasher
334 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located on the In any of the following situations, you can reduce the instrument panel, below the radio. potential for overheating by taking the appropriate action. •...
Page 336: Engine Oil Overheating - 2.4L Engine Only (If Equipped)
WHAT TO DO IN EMERGENCIES 335 NOTE: There are steps that you can take to slow down Engine Oil Overheating — 2.4L Engine Only (If an impending overheat condition: Equipped) During sustained high-speed driving or trailer tow up • If your air conditioner (A/C) is on, turn it off. The A/C long grades on hot day, the engine oil temperature may system adds heat to the engine cooling system and become too hot.
Page 337: Jacking And Tire Changing
336 WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING WARNING! (Continued) • The jack is designed to use as a tool for changing WARNING! tires only. The jack should not be used to lift the • Do not attempt to change a tire on the side of the vehicle for service purposes.
Page 338: Jack Location
WHAT TO DO IN EMERGENCIES 337 6. Block both the front and rear of the wheel diagonally opposite the jacking position. For example, if changing the right front tire, block the left rear wheel. NOTE: Passengers should not remain in the vehicle when the vehicle is being jacked.
Page 339: Jacking Instructions
338 WHAT TO DO IN EMERGENCIES Jacking Instructions WARNING! (Continued) • Do not let anyone sit in the vehicle when it is on a WARNING! jack. Carefully follow these tire changing warnings to • Do not get under the vehicle when it is on a jack. help prevent personal injury or damage to your •...
Page 340 WHAT TO DO IN EMERGENCIES 339 Jack Warning Label 1. Remove the scissors jack and lug wrench from the spare wheel as an assembly. Turn the jack screw to the left to loosen the lug wrench, and remove the wrench from the jack assembly.
Page 341 340 WHAT TO DO IN EMERGENCIES Jacking Locations...
Page 342 WHAT TO DO IN EMERGENCIES 341 head is properly engaged with the lift area closest to the CAUTION! wheel to be changed. Do not raise the vehicle until you are sure the jack is securely engaged. Do not attempt to raise the vehicle by jacking on locations other than those indicated in Step 3.
Page 343 342 WHAT TO DO IN EMERGENCIES toward the wheel. Lightly tighten the nuts. To avoid the torque is 100 ft. lbs (135 N. m). If you doubt that you have risk of forcing the vehicle off the jack, do not tighten the tightened the nuts correctly, have them checked with a nuts fully until the vehicle has been lowered.
Page 344: Jump-Starting
WHAT TO DO IN EMERGENCIES 343 11. Check the spare tire pressure as soon as possible. WARNING! Correct the tire pressure as required. When temperatures are below the freezing point, JUMP-STARTING electrolyte in a discharged battery may freeze. Do not If your vehicle has a discharged battery it can be jump- attempt jump-starting because the battery could rup- started using a set of jumper cables and a battery in...
Page 345 344 WHAT TO DO IN EMERGENCIES WARNING! • Take care to avoid the radiator cooling fan when- ever the hood is raised. It can start anytime the ignition switch is on. You can be injured by moving fan blades. • Remove any metal jewelry such as watch bands or bracelets that might make an inadvertent electrical contact.
Page 346: Jump-Starting Procedure
WHAT TO DO IN EMERGENCIES 345 3. Remove the protective cover over the remote positive WARNING! (+) battery post. To remove the cover, press the locking tab and pull upward on the cover. Do not allow vehicles to touch each other as this could establish a ground connection and personal injury could result.
Page 347 346 WHAT TO DO IN EMERGENCIES 1. Connect the positive (+) end of the jumper cable to the 5. Start the engine in the vehicle that has the booster remote positive (+) post of the discharged vehicle. battery, let the engine idle a few minutes, and then start the engine in the vehicle with the discharged battery.
Page 348: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES 347 10. Reinstall the protective cover over the remote posi- front wheels. Then shift back and forth between RE- tive (+) battery post of the discharged vehicle. VERSE and FIRST gear. Using minimal accelerator pedal pressure to maintain the rocking motion, without spin- If frequent jump-starting is required to start your vehicle ning the wheels, is most effective.
Page 349: Towing A Disabled Vehicle
348 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE CAUTION! (Continued) With The Ignition Key • Revving the engine or spinning the wheels too fast Your vehicle may be towed under the following condi- may lead to transmission overheating and failure. tions: It can also damage the tires.
Page 350: Without The Ignition Key
WHAT TO DO IN EMERGENCIES 349 If you must use the accessories (wipers, defrosters, etc.) CAUTION! (Continued) while being towed, the key must be in the ON position, • If the transaxle is not operative, or if the vehicle is not the ACC position.
Page 352 MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 2.4L ... . . 353 Maintenance Procedures ....359 ▫...
Page 353 352 MAINTAINING YOUR VEHICLE ▫ Adding Washer Fluid ....370 Replacement Bulbs ....398 ▫...
Page 354: Engine Compartment - 2.4L
MAINTAINING YOUR VEHICLE 353 ENGINE COMPARTMENT — 2.4L 1 — Engine Coolant Reservoir 7 — Air Cleaner Filter 2 — Power Steering Fluid Reservoir 8 — Engine Oil Fill 3 — Automatic Transaxle Dipstick 9 — Coolant Pressure Cap 4 — Brake Fluid Reservoir 10 —...
Page 355: Engine Compartment - 2.7L
354 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 2.7L 1 — Engine Coolant Reservoir 7 — Power Distribution Center 2 — Coolant Pressure Cap 8 — Air Cleaner Filter 3 — Power Steering Fluid Reservoir 9 — Engine Oil Dipstick 4 — Automatic Transaxle Dipstick (Four-Speed Only) 10 —...
Page 356: Engine Compartment - 3.5L
MAINTAINING YOUR VEHICLE 355 ENGINE COMPARTMENT — 3.5L 1 — Engine Coolant Reservoir 6 — Air Cleaner Filter 2 — Coolant Pressure Cap 7 — Engine Oil Dipstick 3 — Power Steering Fluid Reservoir 8 — Engine Oil Fill 4 — Brake Fluid Reservoir 9 —...
Page 357: Onboard Diagnostic System - Obd Ii
356 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated Onboard • Prolonged driving with the “Malfunction Indica- Diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic tor Light”...
Page 358: Emissions Inspection And Maintenance Programs
MAINTAINING YOUR VEHICLE 357 the gas cap is properly tightened. Press the trip odometer Normally, the OBD II system will be ready. The OBD II “Reset” button to turn off the message. If the problem system may not be ready if your vehicle was recently persists, the message will appear the next time the serviced, recently had a dead battery or a battery replace- vehicle is started.
Page 359: Replacement Parts
358 MAINTAINING YOUR VEHICLE 4. Approximately 15 seconds later, one of two things will Regardless of whether your vehicle’s OBD II system is happen: ready or not, if the MIL is illuminated during normal vehicle operation you should have your vehicle serviced a.
Page 360: Maintenance Procedures
Only do service work for which you mance. Immediately have potential malfunctions have the knowledge and the proper equipment. If examined by an authorized Chrysler Group LLC you have any doubt about your ability to perform a dealership or qualified repair center.
Page 361: Engine Oil
360 MAINTAINING YOUR VEHICLE fully warmed engine is shut off. Do not check oil level CAUTION! (Continued) before starting the engine after it has sat overnight. • Your vehicle has been built with improved fluids Checking engine oil level when the engine is cold will that protect the performance and durability of give you an incorrect reading.
Page 362 Do not overfill the engine. Overfilling the engine mends engine oils that are API Certified and meet the will cause oil aeration, which can lead to loss of oil requirements of Chrysler Material Standard MS-6395. pressure and an increase in oil temperature. This could damage your engine.
Page 363 362 MAINTAINING YOUR VEHICLE Lubricants which do not have both the engine oil certi- CAUTION! fication mark and the correct SAE viscosity grade num- ber should not be used. Do not use chemical flushes in your engine oil as the chemicals can damage your engine.
Page 364: Engine Oil Filter
MAINTAINING YOUR VEHICLE 363 Lubricants which do not have both the engine oil certi- environment. Contact your authorized dealer, service fication mark and the correct SAE viscosity grade num- station, or governmental agency for advice on how and ber should not be used. where used oil and oil filters can be safely discarded in your area.
Page 365: Engine Air Cleaner Filter
364 MAINTAINING YOUR VEHICLE Engine Air Cleaner Filter used to assure most efficient service. MOPAR engine air cleaner filters are high quality and are recommended. WARNING! Maintenance-Free Battery You will never have to add water, nor is periodic main- The air induction system (air cleaner, hoses, etc.) can tenance required.
Page 366 MAINTAINING YOUR VEHICLE 365 WARNING! CAUTION! • Battery fluid is a corrosive acid solution and can • It is essential when replacing the cables on the burn or even blind you. Do not allow battery fluid battery that the positive cable is attached to the to contact your eyes, skin, or clothing.
Page 367: Air Conditioner Maintenance
366 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance WARNING! For best possible performance, your air conditioner • Use only refrigerants and compressor lubricants should be checked and serviced by an authorized dealer at the start of each warm season. This service should approved by the manufacturer for your air condi- include cleaning of the condenser fins and a performance tioning system.
Page 368: A/C Air Filter - If Equipped
MAINTAINING YOUR VEHICLE 367 Refrigerant Recovery and Recycling The A/C Air Filter is located in the fresh air inlet behind R-134a air conditioning refrigerant is a hydrofluoro- the glove box. Perform the following procedure to re- carbon (HFC) that is endorsed by the Environmental place the filter: Protection Agency and is an ozone-saving product.
Page 369 368 MAINTAINING YOUR VEHICLE 5. Disengage the two retaining tabs that secure the filter 7. Install the A/C Air Filter with the arrow on the filter cover to the HVAC housing and remove the cover. pointing toward the floor. When installing the filter cover, make sure the retaining tabs fully engage the cover.
Page 370: Body Lubrication
MAINTAINING YOUR VEHICLE 369 Body Lubrication amount of a high quality lubricant such as MOPAR Locks and all body pivot points, including such items as Lock Cylinder Lubricant or equivalent directly into the seat tracks, door hinge pivot points and rollers, liftgate, lock cylinder.
Page 371: Adding Washer Fluid
370 MAINTAINING YOUR VEHICLE Keep the blade rubber out of contact with petroleum WARNING! products such as engine oil, gasoline, etc. Commercially available windshield washer solvents NOTE: Life expectancy of wiper blades varies depend- are flammable. They could ignite and burn you. Care ing on geographical area and frequency of use.
Page 372 MAINTAINING YOUR VEHICLE 371 exhaust system each time the vehicle is raised for an oil CAUTION! change or lubrication. Replace as required. The catalytic converter requires the use of unleaded WARNING! fuel only. Leaded gasoline will destroy the effective- ness of the catalyst as an emissions control device Exhaust gases can injure or kill.
Page 373 372 MAINTAINING YOUR VEHICLE CAUTION! WARNING! Damage to the catalytic converter can result if your A hot exhaust system can start a fire if you park over vehicle is not kept in proper operating condition. In materials that can burn. Such materials might be the event of engine malfunction, particularly involv- grass or leaves coming into contact with your exhaust ing engine misfire or other apparent loss of perfor-...
Page 374: Cooling System
MAINTAINING YOUR VEHICLE 373 To minimize the possibility of catalyst damage: WARNING! (Continued) • Do not shut off the engine or interrupt the ignition • You or others can be badly burned by hot engine when the transaxle is in gear and the vehicle is in coolant (antifreeze) or steam from your radiator.
Page 375 374 MAINTAINING YOUR VEHICLE Check the coolant recovery bottle tubing for brittle rub- CAUTION! ber, cracking, tears, cuts, and tightness of the connection • Mixing of engine coolant (antifreeze) other than at the bottle and radiator. Inspect the entire system for leaks.
Page 376 MAINTAINING YOUR VEHICLE 375 When adding engine coolant (antifreeze): CAUTION! (Continued) • The manufacturer recommends using MOPAR • This vehicle has not been designed for use with Antifreeze/Coolant 5 Year/100,000 Mile Formula Propylene Glycol based engine coolant (anti- HOAT (Hybrid Organic Additive Technology) or freeze).
Page 377 376 MAINTAINING YOUR VEHICLE Please note that it is the owner’s responsibility to main- WARNING! tain the proper level of protection against freezing ac- • The warning words “DO NOT OPEN HOT” on cording to the temperatures occurring in the area where the vehicle is operated.
Page 378 MAINTAINING YOUR VEHICLE 377 rules for your community. To prevent ingestion by ani- The radiator normally remains completely full, so there is mals or children, do not store ethylene glycol based no need to remove the radiator cap unless checking for engine coolant (antifreeze) in open containers or allow it engine coolant (antifreeze) freeze point or replacing cool- to remain in puddles on the ground.
Page 379: Brake System
378 MAINTAINING YOUR VEHICLE • Make sure that the radiator and coolant recovery If an examination of your engine compartment shows no evidence of radiator or hose leaks, the vehicle may be bottle overflow hoses are not kinked or obstructed. safely driven.
Page 380 MAINTAINING YOUR VEHICLE 379 Clean the top of the master cylinder area before removing WARNING! the cap. If necessary, add fluid to bring the fluid level up to the requirements described on the brake fluid reser- Riding the brakes can lead to brake failure and voir.
Page 381 380 MAINTAINING YOUR VEHICLE WARNING! WARNING! (Continued) • To avoid contamination from foreign matter or • Use only manufacturer’s recommended brake moisture, use only new brake fluid or fluid that fluid. Refer to “Fluids, Lubricants, and Genuine has been in a tightly closed container. Keep the Parts”...
Page 382: Automatic Transaxle
MAINTAINING YOUR VEHICLE 381 2. Run the engine at curb idle speed for a minimum of WARNING! (Continued) 60 seconds. • Do not allow petroleum based fluid to contami- 3. Apply the parking brake fully. nate the brake fluid. Brake seal components could be damaged, causing partial or complete brake 4.
Page 383 382 MAINTAINING YOUR VEHICLE 7. Wipe the dipstick clean and reinsert until seated. Then, CAUTION! remove dipstick and note the reading. • Using a transmission fluid other than the manu- a. If the fluid is hot, the reading should be in the facturer’s recommended fluid may cause deterio- crosshatched area marked “HOT”...
Page 384: Appearance Care And Protection From Corrosion
MAINTAINING YOUR VEHICLE 383 Fluid Level Check – 3.5L Engine CAUTION! The automatic transaxle has no dipstick and is dealer serviced only. Do not use chemical flushes in your transaxle as the chemicals can damage your transaxle components. Transmission Fluid and Filter Changes Such damage is not covered by the New Vehicle Refer to “Maintenance Schedule”...
Page 385 384 MAINTAINING YOUR VEHICLE The following maintenance recommendations will enable Washing you to obtain maximum benefit from the corrosion • Wash your vehicle regularly. Always wash your ve- resistance built into your vehicle. hicle in the shade using MOPAR Car Wash or equiva- What Causes Corrosion? lent, or a mild car wash soap, and rinse the panels Corrosion is the result of deterioration or removal of...
Page 386 MAINTAINING YOUR VEHICLE 385 • If your vehicle is damaged due to an accident or CAUTION! similar cause which destroys the paint and protective coating, have your vehicle repaired as soon as pos- Do not use abrasive or strong cleaning materials such sible.
Page 387 386 MAINTAINING YOUR VEHICLE heavy soil and/or excessive brake dust, use MOPAR Do not use abrasive cleaning components, solvents, steel Wheel Cleaner or equivalent or select a nonabrasive, wool or other aggressive material to clean the lenses. non-acidic cleaner. Do not use scouring pads, steel wool, Stain Repel Fabric Cleaning Procedure –...
Page 388 MAINTAINING YOUR VEHICLE 387 • Do not use any harsh solvents or any other form of Cleaning Leather Upholstery protectants on Stain Repel products. MOPAR Total Clean or equivalent is specifically recom- mended for leather upholstery. Interior Care Your leather upholstery can be best preserved by regular Instrument Panel Cover cleaning with a damp soft cloth.
Page 389 388 MAINTAINING YOUR VEHICLE Cleaning Plastic Instrument Cluster Lenses WARNING! The lenses in front of the instruments in this vehicle are molded in clear plastic. When cleaning the lenses, care Do not use volatile solvents for cleaning purposes. must be taken to avoid scratching the plastic. Many are potentially flammable, and if used in closed areas they may cause respiratory harm.
Page 390: Cleaning Center Console Cupholders
MAINTAINING YOUR VEHICLE 389 Replace the belts if they appear frayed or worn or if the Installation buckles do not work properly. Align the liner in the cupholder and press down firmly. Dry with a soft tissue. Convertible Top Care Cleaning Center Console Cupholders CAUTION! Removal...
Page 391 390 MAINTAINING YOUR VEHICLE CAUTION! (Continued) CAUTION! • Use care when washing the vehicle, water pressure Avoid high-pressure car washes, as they can damage directed at the weather strip seals may cause water the top material. Also, increased water pressure may to leak into the vehicles interior.
Page 392 MAINTAINING YOUR VEHICLE 391 Additional Cleaning Procedure CAUTION! For additional cleaning assistance in removing stubborn stains, apply MOPAR Convertible Cloth Top Cleaner or Never use an abrasive type cleaner or bleaches. equivalent to the complete stain, extending 2 inches Cleaners should not contain silicones, organic sol- (50 mm) beyond the stain.
Page 393: Weather Strip Care - Soft And Hard Top
392 MAINTAINING YOUR VEHICLE CAUTION! Avoid getting Scotchguard on the surrounding weather strips, moldings, paint, or glass. Damage to these items might occur. Weather Strip Care – Soft and Hard Top Lubricate all top and door glass weather strips periodi- cally with MOPAR Weather Strip Lubricant or equiva- lent to keep them soft and pliable.
Page 394 MAINTAINING YOUR VEHICLE 393 Cartridge Cartridge Cavity Mini Fuse Description Cavity Mini Fuse Description Fuse Fuse Battery Feed – Ignition Off 30 Amp Center High — Draw (IOD) Green — 10 Amp Red Mounted Stop Sense 2 Light (CHMSL)/ Battery Feed – Brake Switch Power Seats –...
Page 395 394 MAINTAINING YOUR VEHICLE Cartridge Cartridge Cavity Mini Fuse Description Cavity Mini Fuse Description Fuse Fuse 20 Amp Yel- Ignition Off — — Draw (IOD) – Wireless Control Ignition Off — 10 Amp Red Module (WCM)/ Draw (IOD) – Clock/Steering Cabin Compart- —...
Page 396 MAINTAINING YOUR VEHICLE 395 Cartridge Cartridge Cavity Mini Fuse Description Cavity Mini Fuse Description Fuse Fuse — 10 Amp Red — Auto Shutdown 15 Amp Lt. — (ASD) Relay Ignition Run – Blue Feed 2 Climate — 10 Amp Red Controls/Hot Ignition Run –...
Page 397 396 MAINTAINING YOUR VEHICLE Cartridge Cartridge Cavity Mini Fuse Description Cavity Mini Fuse Description Fuse Fuse Hot Car (No Battery Feed – — — Fuse Required) Anti-Lock Brakes (ABS) Module – Ignition Run – 20 Amp Yel- 30 Amp If Equipped/ —...
Page 398: Vehicle Storage
MAINTAINING YOUR VEHICLE 397 Cartridge CAUTION! (Continued) Cavity Mini Fuse Description Fuse • When replacing a blown fuse, it is important to Battery Feed – use only a fuse having the correct amperage rating. Passenger Door 30 Amp The use of a fuse with a rating other than indicated —...
Page 399: Replacement Bulbs
398 MAINTAINING YOUR VEHICLE REPLACEMENT BULBS LIGHT BULBS – Exterior Bulb No. All the inside bulbs are brass or glass wedge base. Low Beam Headlamp..... 9006 Aluminum base bulbs are not approved and should not High Beam Headlamp .
Page 400: Bulb Replacement
MAINTAINING YOUR VEHICLE 399 BULB REPLACEMENT Headlamp 1. Raise and prop open the hood. Locate the connector behind the headlamp. NOTE: It may be necessary to remove the air cleaner filter housing and position the totally integrated power module aside prior to replacing the low beam headlamp on the driver’s side of the vehicle.
Page 401 400 MAINTAINING YOUR VEHICLE 5. If the bulb comes in contact with any oily surface, CAUTION! clean the bulb with rubbing alcohol. Do not touch the new bulb with your fingers. Oil 6. Reinsert the bulb and socket assembly and rotate contamination will severely shorten bulb life.
Page 402: Front Turn Signal/Parking Lamp
MAINTAINING YOUR VEHICLE 401 Front Turn Signal/Parking Lamp 3. Remove the bulb from the connector socket and install the replacement bulb. 1. Raise and prop open the hood. 4. Install the bulb and connector assembly into the 2. Rotate the bulb’s electrical connector one-quarter turn headlamp housing and rotate the connector one-quarter counterclockwise and remove it from the headlamp turn clockwise to lock it in place.
Page 403: Front Fog Lamp
402 MAINTAINING YOUR VEHICLE Front Fog Lamp NOTE: Access to the lamps through the lower fascia cutout is limited. We recommend you access the lamps by turning the steering wheel to allow access and remove the inner fender shield. 1. Rotate the bulb’s electrical connector one-quarter turn counterclockwise and remove it from the fog lamp hous- ing.
Page 404: Tail/Stop, Rear Turn Signal And Backup Lamps
MAINTAINING YOUR VEHICLE 403 CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with an oily surface, clean the bulb with rubbing alcohol. 3. Install the bulb and connector assembly into the fog lamp housing and rotate the connector one-quarter turn clockwise to lock it in place.
Page 405 404 MAINTAINING YOUR VEHICLE Changing the Tail/Stop Lamp or Rear Turn Signal 2. Remove the two plastic wing nuts from the taillamp Lamp housing. 1. Open the trunk and gently pull back the trunk liner behind the taillamp 3. Grasp the taillamp housing and pull it firmly outward while pushing gently on the studs from inside to disen- gage the housing from the vehicle.
Page 406 MAINTAINING YOUR VEHICLE 405 4. Rotate the applicable bulb’s electrical connector one- 5. Remove the bulb from the connector socket and install quarter turn counterclockwise and remove it from the the replacement bulb. taillamp housing. 6. Install the bulb and connector assembly into the taillamp housing and rotate the connector one-quarter turn clockwise to lock it in place.
Page 407: License Plate Lamp
406 MAINTAINING YOUR VEHICLE Changing the Backup Lamp 3. Remove the bulb from the connector socket and install the replacement bulb. 1. Open the trunk. 4. Install the bulb and connector assembly into the 2. Rotate the bulb’s electrical connector one-quarter turn housing and rotate the connector one-quarter turn clock- counterclockwise and remove it from the housing.
Page 408: Center High-Mounted Stop Lamp (Chmsl)
MAINTAINING YOUR VEHICLE 407 2. Rotate the bulb’s electrical connector one-quarter turn counterclockwise and remove it from the CHMSL housing. 2. Gently pry the lens loose. 3. Pull bulb from socket, replace and reattach the lamp 3. Remove the bulb from the connector socket and install lens with the two retaining screws.
Page 409: Fluid Capacities
408 MAINTAINING YOUR VEHICLE FLUID CAPACITIES U.S. Metric Fuel (Approximate) All Engines 16.9 Gallons 64 Liters Engine Oil with Filter 2.4L Engine (SAE 5W-20, API Certified) 4.5 Quarts 4.4 Liters 2.7L Engine (SAE 5W-20, API Certified) 5.5 Quarts 5.2 Liters 3.5L Engine (SAE 10W-30, API Certified) 5.5 Quarts 5.2 Liters...
Page 410: Fluids, Lubricants, And Genuine Parts
Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Engine Oil – 2.4L and 2.7L Engines Chrysler Material Standard MS-6395. Refer to your engine oil filler cap for correct SAE grade. Use API Certified SAE 10W-30 Engine Oil, meeting Chrysler Material Engine Oil –...
Page 411: Chassis
410 MAINTAINING YOUR VEHICLE Chassis Component Fluid, Lubricant, or Genuine Part MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed Automatic Transaxle ATF+4 product. MOPAR DOT 3 and SAE J1703 should be used. If DOT 3 brake fluid is Brake Master Cylinder not available, then DOT 4 is acceptable.
Page 412 MAINTENANCE SCHEDULES CONTENTS ▫ Required Maintenance Intervals ..414 Emissions Control System Maintenance ..412 Maintenance Schedule ....412...
Page 413 412 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE MAINTENANCE SCHEDULE The Scheduled Maintenance services listed in bold type The oil change indicator system will remind you that it is must be done at the times or mileages specified to ensure time to take your vehicle in for scheduled maintenance. the continued proper functioning of the emissions control On Electronic Vehicle Information Center (EVIC) system.
Page 414 MAINTENANCE SCHEDULES 413 if it has been 6 months since your last oil change even At Each Stop for Fuel if the oil change indicator message is NOT illumi- • Check the engine oil level about five minutes after a nated.
Page 415 414 MAINTENANCE SCHEDULES • Check all lights and other electrical items for correct Required Maintenance Intervals operation. Refer to the Maintenance Schedules on the following pages for the required maintenance intervals. At Each Oil Change • Change the engine oil filter. •...
Page 416 ❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 417: Service Schedule
❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 418 ❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for except PZEV*). damage, wear, improper looseness or end play; replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 419 ❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 420 ❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 421 ❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 422 ❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 423 ❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for necessary†. damage, wear, improper looseness or end play; replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 424 ❏ Inspect accessory drive belt, replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 425 ❏ Change the automatic transaxle fluid & filter. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 426 ❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 427 ❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Odometer Reading Date Odometer Reading Date Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer...
Page 428 • Failure to properly inspect and maintain your vehicle could result in a component malfunction and effect vehicle handling and performance. This Odometer Reading Date could cause an accident Repair Order # Dealer Code Signature Authorized Chrysler Dealer...
Page 430: If You Need Consumer Assistance
Reporting Safety Defects ....434 ▫ Chrysler Group LLC Customer Center ..432 ▫ In The 50 United States And Washington, D.C.
Page 431 430 IF YOU NEED CONSUMER ASSISTANCE ▫ Traction Grades ..... 437 Publication Order Forms ....435 ▫...
Page 432: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 431 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...
Page 433: Chrysler Group Llc Customer Center
• Vehicle delivery date and mileage This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- Chrysler Group LLC Customer Center solved with this process. P.O. Box 21–8004 • If for some reason you are still not satisfied, talk to the Auburn Hills, MI 48321–8004...
Page 434: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
IF YOU NEED CONSUMER ASSISTANCE 433 Customer Assistance For The Hearing Or Speech the manufacturer’s service contracts. If you purchased a Impaired (TDD/TTY) manufacturer’s service contract, you will receive Plan To assist customers who have hearing difficulties, the Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date.
Page 435: Warranty Information (U.s. Vehicles Only)
See the Warranty Information Booklet, located on the the ownership experience. You’ll be pleased with their DVD, for the terms and provisions of Chrysler Group sincere efforts to resolve any warranty issues or related LLC warranties applicable to this vehicle.
Page 436: In Canada
Customer Service Department imme- need in diagnosing/troubleshooting, problem solving, diately. Canadian customers who wish to report a safety maintaining, servicing, and repairing Chrysler Group defect to the Canadian government should write to: LLC vehicles. A complete working knowledge of the...
Page 437: Quality Grades
436 IF YOU NEED CONSUMER ASSISTANCE vehicle, system, and/or components is written in acquaint you with specific Chrysler Group LLC ve- straightforward language with illustrations, diagrams, hicles. Included are starting, operating, emergency and charts. and maintenance procedures as well as specifications, capabilities and safety tips.
Page 438: Traction Grades
IF YOU NEED CONSUMER ASSISTANCE 437 in each category is shown on the sidewall of the tires on wet pavement, as measured under controlled conditions your vehicle. on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction perfor- All passenger car tires must conform to Federal safety mance.
Page 439 438 IF YOU NEED CONSUMER ASSISTANCE grade C corresponds to a level of performance, which all passenger car tires must meet under the Federal Motor Vehicle Safety Standard No. 109. Grades B and A repre- sent higher levels of performance on the laboratory test wheel, than the minimum required by law.
Page 440 INDEX...
Page 441 440 INDEX About Your Brakes ..... . . 266 Airbag Maintenance ..... . . 63 ABS (Anti-Lock Brake System) .
Page 442 INDEX 441 Automatic Oil Change Indicator ..164,175,412 Belts, Seat ......39,78 Automatic Temperature Control (ATC) .
Page 443 442 INDEX Caps, Filler Child Restraint Tether Anchors ... . . 70,72 Fuel ....... 317 Cigar Lighter .
Page 444 INDEX 443 Coolant Pressure Cap (Radiator Cap) ..376 Daytime Running Lights ....126 Cooling System .
Page 445 444 INDEX Door Opener, Garage ..... 137 Towing ......348 Driver’s Seat Back Tilt .
Page 446 INDEX 445 Oil Filter Disposal ..... 363 Air Conditioning ....242,367 Oil Selection .
Page 447 446 INDEX Fluid Capacities ......408 Filler Door (Gas Cap) ....158 Fluid Leaks .
Page 448 INDEX 447 Gauges Head Restraints ......117 Coolant Temperature ....158 Headlights .
Page 449 448 INDEX Hitches Integrated Power Module (Fuses) ... . 392 Trailer Towing ......323 Interior Appearance Care .
Page 450 INDEX 449 Lane Change and Turn Signals ... 126,166 Center Mounted Stop ....407 Lane Change Assist .
Page 451 450 INDEX Lights On Reminder ....123 Tires ....... 285 Low Fuel .
Page 452 INDEX 451 Master Cylinder (Brakes) ....379 Occupant Restraints ....37,58,61 Memory Feature (Memory Seat) .
Page 453 452 INDEX Viscosity ......362,408 Phone, Cellular ......110 Oil Filter, Change .
Page 454 INDEX 453 Radial Ply Tires ......292 Remote Starting System ....27 Radiator Cap (Coolant Pressure Cap) .
Page 455 454 INDEX Safety Tips ......77 Heated ......112 Satellite Radio Antenna .
Page 456 INDEX 455 Shifting Starting Procedures ..... . 249 Automatic Transaxle ....253 Steering Shoulder Belts .
Page 457 456 INDEX Temperature Gauge, Engine Coolant ..158,334 Inflation Pressures ..... 290 Tether Anchor, Child Restraint ....70 Jacking .
Page 458 INDEX 457 Towing ....... 321 Operation ......253 Disabled Vehicle .
Page 459 458 INDEX Uconnect™ (Hands-Free Phone) ... . . 110 Warning Lights Understanding Your Instrument Panel ..156 (Instrument Cluster Description) ... . . 158 Uniform Tire Quality Grades .
Page 460 INDEX 459 Windshield Wiper Blades ....369 Wiper Blade Replacement ....369 Windshield Wipers .
Page 461 Chrysler Group LLC 10C27-126-AB Printed in U.S.A. 2nd Edition...

Chrysler 2010 Sebring Convertible Owner's Manual

Sebring Convertible

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Maintaining Your Vehicle

Quick Links

Chapters

Related Manuals for Chrysler 2010 Sebring Convertible

Summary of Contents for Chrysler 2010 Sebring Convertible
