TECHNICAL DATA SHEET
No wall space? No problem. The ceiling is a great place to mount
a flat panel when there is no wall available. Ceiling installation is
made simple with PC930s one-, two-, three- design. Simply at-
tach the ceiling plate, attach the mounting plate to the screen and
hook-on the TV on to the mount – Done. This VESA
LCD mount delivers the ultimate in positioning options with its
tilt and infinite swivel options for that ultimate flat panel viewing
experience.
Features:
• VESA 75 and 100 compliant
®
• Three adjustable extension lengths:
PC930A models - 9.8" - 13.9"
PC930B models - 13.78" - 21.89"
PC930C models - 20.24" - 34.02"
• Adjustable tilt of +20/-5° with optional lock in 5° increments
• Mountable adjustment for screen placement opportunities
• Internal cable management within extension channels for clean,
clutter-free appearance
• Safety catch designed into extension channels to ensure user
and equipment safety
• Supports up to 50 lb LCD flat panel TVs
Shipping Carton Dimensions
The Ceiling Mount shall be Peerless models
tilt. It shall be constructed of heavy gauge cold rolled steel and finished with scratch resistant Black, Silver or White Fused Epoxy. Assembly and
installation shall be done according to instructions provided by the manufacturer.
Peerless Industries, Inc.
3215 W. North Ave. Melrose Park, IL 60160
708-865-8870 800-865-2112 Fax 708-865-2941
www.peerlessmounts.com
Paramount™ LCD Ceiling Mount for
15" to 24" LCD Screens
Dimensions:
Product Weight
Shipping Weight
Maximum Load Capacity
A R C H I T E C T S S P E C I F I C A T I O N S
and shall be located where indicated on the plans. It shall feature adjustable +20°/-5°
MODELS: PC930A, PC930A-S, PC930A-W
PC930B, PC930B-S, PC930B-W
PC930C, PC930C-S, PC930C-W
compliant
®
PC930A
PC930A-S
PC930A-W
3.22 lb (1.46 kg)
4.84 lb (2.2 kg)
50 lb (22.7 kg)
L= 12.0625" (306 mm)
W= 9.3125" (237 mm)
H= 4.25" (108 mm)
All other brand and product names are trademarks or registered trademarks of their respective owners
Models
PC930B PC930C
PC930B-S PC930C-S
PC930B-W PC930C-W
3.9 lb (1.77 kg) 4.99 lb (2.26 kg)
5.44 lb (2.47 kg) 6.64 lb (3.01 kg)
50 lb (22.7 kg) 50 lb (22.7 kg)
12.0625" (306 mm) 19.375 (492 mm)
9.3125" (237 mm) 10 (254 mm)
4.25" (108 mm) 4.375 (111 mm)
ISSUED: 02-11-08 SHEET NO: 202-9577-2 05-27-09
