KitchenAid KECC507RBB02 Parts List page 3

30" electric ceran cooktop
Hide thumbs


Advertisement

For Models: KECC507RBL02, KECC507RWW02, KECC507RBB02, KECC507RSS02
W10121456
OPTIONAL PARTS
(Black)
(Pure White)
Illus.
Part
No.
No.
DESCRIPTION
Miscellaneous
OPTIONAL PARTS
3172515 Mounting,
Hardware Kit
3192408 Bracket
Support (2)
8286642 Tape, Foam
FOLLOWING PARTS
NOT ILLUSTRATED
SPLICING WIRES−−25FT.
LENGTH
4456028 Wire, Jumper
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
ACCESSORY PARTS
3191048 Cleaner, Glass
WIRING HARNESS PARTS
8286467 Wiring Harness
8286382 Clip, Harness
3400015 Screw
8286338 Conduit, Harness
8286238 Thermostat
3
(Pure Biscuit)
(Stainless)
