KitchenAid KECC507RBB02 Parts List page 2

30" electric ceran cooktop
Hide thumbs


Advertisement

For Models: KECC507RBL02, KECC507RWW02, KECC507RBB02, KECC507RSS02
Illus.
Part
No.
No.
DESCRIPTION
1
Literature Parts
Installation
Instructions
8286066 Cooktop
8304571 Undercounter Oven
8286447 Wiring Diagram
8286608 Use & Care Guide
Safer Cooking Tips
3191638 English
9759133 French
2
Cooktop, Glass
W10048540 Black
W10048550 White
W10048560 Biscuit
3
246119 Screw
4
8285935 Bracket, Switch
Mounting
5
8286535 Bracket, Bottom
6
9759094 Spring Locator (8)
COOKTOP PARTS
(Black)
(Pure White)
Illus.
Part
No.
No.
DESCRIPTION
7
Switch, Infinite
9763763 Single (2)
9763764 Dual
9763765 Triple
8
3183956 Seal, Switch Shaft
9
8286577 Wall, Inside
10
Knob, Control (4)
8286096BL Black
8286096WH White
8286096BT Biscuit
8286096CM Cashmere Metal
11
8286554 Box, Burner
12
4455917 Bracket, Mounting
13
8285240 Seal, Heat
14
3196537 Screw
15
4449868 Block ,Terminal
16
Seal, Switch
8285469 Black
17
311865 Screw
18
3196163 Screw
19
3400093 Screw
20
9763517 Rail, Element
2
(Pure Biscuit)
(Stainless)
Illus.
Part
No.
No.
21
8286344 Rail, Element
22
8286055 Lamp, Hot
23
8285709 Frame, Cooktop
24
8523698 1200W LR
8523697 1500W RF
8285937 2000/1000W RR
8286187 2500/1800/900W LF
25
8286573 Box, Control
26
8285426 Seal, Heat Shield
27
112432 Nut
28
8286599 Inside Wall,
29
8286607 Grommet, Flexible
30
3192439 Seal, Limiter
DESCRIPTION
Surface Indicator
(Stainless Only)
Element, Surface
Insulation
W10121456
