NOTE
Priorities are enforced only when there is congestion on the network. If there is no congestion, all
traffic is handled at the same priority.
Following are some examples of setting QoS priority levels on VE_Port 12:
•
•
•
•
For more information on using Fabric OS commands, optional arguments, and command output
refer to the Fabric OS Command Reference Manual.

QoS, DSCP, and VLANs

Quality of Service (QoS) refers to policies for handling differences in data traffic. These policies are
based on data characteristics and delivery requirements. For example, ordinary data traffic is
tolerant of delays and dropped packets, but real-time voice and video data are not. QoS policies
provide a framework for accommodating these differences in data as it passes through a network.
QoS for Fibre Channel traffic is provided through internal QoS priorities. Those priorities can be
mapped to TCP/IP network priorities using zone name prefixes and VCs. The different priority TCP
sessions can be marked upon egress. The TCP marking is done at the IP layer using Layer 3
Differentiated Services Code Point (DSCP) or at the Ethernet layer within the 802.1Q tag header
using 802.1P. There are two options for TCP/IP network-based QoS:
•
•
QoS, DSCP & VLANs are configured at the FCIP circuit level and not at the tunnel level

DSCP Quality of Service

Layer 3 Class of Service Differentiated Services Code Point (DSCP) refers to a specific
implementation for establishing QoS policies as defined by RFC 2475. DSCP uses six bits of the
Type of Service (TOS) field in the IP header to establish up to 64 different values to associate with
data traffic priority.
Fabric OS FCIP Administrator's Guide
53-1002748-01
QoS priority settings must be the same on each end of the tunnel.
The following command sets the QoS high priority to 60 percent.
portcfg fciptunnel 1/12 create --qos-high 60
The following command sets the QoS medium priority to 30 percent.
portcfg fciptunnel 1/12 create --qos-medium 30
The following command sets the QoS low priority to 10 percent.
portcfg fciptunnel 1/12 create --qos-low 10
The following command displays details of the FCIP tunnel configuration, including set QoS
percentages.
portshow fciptunnel 1/12
