Table 3. Part Function on Control Panel (continued)
Item Label
7 STORAGE CLUSTER 1
CHANNEL A-R
ENABLE
8 STORAGE CLUSTER 2
CHANNEL A-R
ENABLE
The HP SureStore E Disk Array XP512 Hardware
Indicator Description
LED Serial Channel/Fibre Channel:
(Green)
(1) On: Indicates some of the logical paths are
established.
(2) Fast blinking: Indicates that the corresponding
channel route is executing the channel command.
(Only Serial Channel)
(3) Slow blinking: Indicates none of the logical paths
are established.
(4) Off: Indicates that the corresponding channel route
is not enabled.
LED Serial Channel/Fibre Channel:
(Green)
(1) On: Indicates some of the logical paths are
established.
(2) Fast blinking: Indicates that the corresponding
channel route is executing the channel command. (Only
Serial Channel)
(3) Slow blinking: Indicates none of the logical paths
are established.
(4) Off: Indicates that the corresponding channel route
is not enabled.
(continued)
