Target (Reserved) LDEV list

The Target (Reserved) LDEV list contains IDs, emulation type, capacity, and other statistics of each
reserved LDEV in the selected parity group, external volume group, or Thin Provisioning group.
The reserved LDEV fields are summarized in the following table.
Item
LDEV identifier
Emulation
Capacity
Ave. (%)
Max (%)
CLPR
Pool ID
Pool Remainder
Pool Capacity

Manual Plan list

The Manual Plan list contains details of the Manual Migration plans, including information source
volumes and target volumes. This list displays all the manual plans created using the Manual
Migration window.
Item
Stat
DEL
%
Source LDEV
LDEV
Emulation
Type Description
field Indicates the LDEV ID of the volume in the following convention:
LDKC:CU:LDEV
field Indicates the emulation type of the volume (VLVI or LUN).
field Indicates the capacity of the volume.
field Indicates the average usage rate for the parity group. An exclamation mark (!)
preceding the percentage value indicates that the reported usage rate is likely to
be inaccurate. This can occur when volumes used in Auto LUN are also formatted
by Virtual LVI or Open Volume Management. A "+0" succeeding the percentage
value indicates that the usage rate is between 0 and 1 percent.
field Indicates the maximum usage rate for the parity group. An exclamation mark (!)
preceding the percentage value indicates that the reported usage rate is likely to
be inaccurate. This can occur when volumes used in Auto LUN are also formatted
by Virtual LVI or Open Volume Management. A "+0" succeeding the percentage
value indicates that the usage rate is between 0 and 1 percent.
field Indicates the number and name of the CLPR corresponding to the parity group. The
following convention is used:
CLPR-number:CLPR-name
field Indicates the ID of the Thin Provisioning pool.
field Indicates the remaining capacity of the Thin Provisioning pool.
field Indicates the capacity of the Thin Provisioning pool.
Type Description
field PSUE is displayed in this field if the execution of a migration plan created outside of
Remote Web Console fails. In this case, you must check the status of the application
software which created the migration plan.
field "D" is displayed in this field if you attempt to delete a migration plan that is waiting for
execution, or is already in progress. Migration plans indicated by "D" are actually
deleted when you click Apply.
field This field indicates the progress of the Manual Migration plan. The progress value is
updated at one-minute intervals.
An error code is displayed if clicking Apply generates an error. For the error details
and solution, see HP StorageWorks P9000 Remote Web Console Messages.
field Displays information about source volumes.
field
Indicates the volume ID of the source volume in this format: LDKC:CU:LDEV. A
to the left of the device ID indicates that the volume is being migrated or is registered
in a migration plan.
field Indicates the emulation type of the volume (VLVI or LUN).
Manual Migration window
icon
