Portrait Width
•
Portrait Height
Note: The smallest supported Universal size is 76 x 127 mm (3
x 5 in.); the largest size is 216 x 356 mm (8.5 x 14 in.).
1
From the home screen, navigate to:
> Paper Menu > Universal Setup > Units of Measure > select
a unit of measure
2
Touch Portrait Width or Portrait Height > select the width or
height > Submit.
Loading the standard or optional
550‑sheet tray
The printer has one standard 550‑sheet tray (Tray 1) and may have up
to four optional 550‑sheet trays including the special media tray. For
narrow paper sizes such as A6 and envelopes, use the special media
tray. For more information, see "Loading the optional 550‑sheet special
media tray" on page 7.
CAUTION—POTENTIAL INJURY: To reduce the risk of
equipment instability, load each paper drawer or tray
separately. Keep all other trays closed until needed.
1
Pull the tray completely out.
Note: Do not remove trays while a job prints or while Busy
appears on the display. Doing so may cause a jam.
6
2
Squeeze and slide the width guide to the correct position for the
paper size you are loading.
Note: Use the paper size indicators at the bottom of the tray to
help position the length and width guides.
3 Squeeze and slide the length guide to the correct position for the
paper size you are loading.
