- Page 1 SWITCHERS MANUAL PART NUMBER: 400-0063-003 PRODUCT REVISION: 1 DA1917SX 2-IN, 2-OUT VGA AUTOSWITCHER/ DISTRIBUTION AMPLIFIER USER’S GUIDE...
-
Page 2: Table Of Contents
We appreciate your selection of our products and are confident that you will join the ranks of our many satisfied customers throughout the world. This manual covers: DA1917SX – 2-in, 2-out VGA Auto Switcher / Distribution Amplifier SWITCHERS TABLE OF CONTENTS PRECAUTIONS / SAFETY WARNINGS ...2... -
Page 3: Precautions / Safety Warnings
Do not pull the power cord or any cable that is attached to the DA1917SX Switcher. If the DA1917SX Switcher is not to be used for an extended period of time, disconnect the Power AC Adapter from the power outlet. -
Page 4: About Your Switcher
The DA1917SX can be controlled manually by connecting a latching contact closure control to its 2.5mm mini-coaxial remote control jack. The DA1917SX comes with a small switch and a 6 foot cable (part # RC5203CC) which performs this control function, or the contact closure may be made from a control system. -
Page 5: Description Of Da1917Sx
Minimum Video Bandwidth Horizontal Vertical Cross-talk Coupling Power External Power Adapter 9V 500mA (included) Power Consumption Table 3. DA1917SX Electrical DESCRIPTION OF DA1917SX 380 MHz 350 @ -3 dB 15-200 kHz 20-190 Hz -40dB @10 MHz 3 watts max. SWITCHERS... -
Page 6: Auto-Switch Mode
The DA1916SX can be controlled manually by connecting a contact closure control switch to the Channel Select port of the DA1917SX. This port uses a 2.5mm mini-coaxial remote control jack and is located next to the Input 2. (Note that... -
Page 7: Installing Your Switcher
Step 6. If control system is used to control the DA1917SX, connect Channel Select port of the DA1917SX to the relays port of a control system. Step 7. Verify that the picture quality on the display is good. If you are not receiving... -
Page 8: Frequently Asked Questions
TROUBLESHOOTING GUIDE We have carefully tested and have found no problems in the supplied DA1917SX unit; however, we would like to offer these suggestions Please make sure that you have the correct setting of the Sync Source Switch. If you pass RGBS signal formats, the switch must be in the SYNC position. -
Page 9: Altinex Policy
11.2 RETURN POLICY It is very important to Altinex that you receive the products that you have ordered and that this product fulfills your need. In the unlikely event that an Altinex product needs to be returned...
