PART NAMES

INDOOR UNIT
OUTDOOR UNIT
1 Inlet (Air)
1
2
2 Open Panel
3
3 Air Filter
4 AUX Button
4
5 Receiver Window
6 Power Supply Cord
5
7 Vertical Airfl ow Louvre
8 Horizontal Airfl ow Louvre
6
9 Outlet (Air)
7
8
9
10 PLASMACLUSTER Lamp
10
(blue)
11
11 OPERATION Lamp (red
12
13 12 TIMER Lamp (orange
13 FULL POWER Lamp
(green
14
14 Inlet (Air)
15 Refrigerant Pipe and In-
15
terconnecting Cord
16
16 Drainage Hose
17 Outlet (Air)
17
NOTE:
Actual units might vary slightly
from those shown above.
GB-2
)
)
)
