MICRO COMPONENT SYSTEM
MODEL
XL-DK227NH
XL-DK257NH
OPERATION MANUAL
iPod is a trademark of Apple Inc., registered in
the U.S. and other countries.
XL-DK227NH Micro component system consisting of XL-DK227NH
(main unit) and CP-DK227NH (speaker system).
XL-DK257NH Micro component system consisting of XL-DK257NH
(main unit) and CP-DK257NH (speaker system).
The illustration printed in this operation manual are for the model
XL-DK227NH.
XL-DK227NH
XL-DK257NH
