Optional Accessories

The Caplio 500Gwide can be used with the items (sold separately)
listed below.
Item
Wide Conversion Lens
AC Adapter
Rechargeable Battery
Battery Charger
Rechargeable Battery Set
Soft Case

Using a Wide Conversion Lens

A wide conversion lens (DW-5) enables shooting at a lens
magnification of 0.8 times (equivalent to a 35mm camera's 22 mm
zoom in wide-angle).
1
Attach the wide conversion
lens to the lens of this camera.
Caution -----------------------------------------------------------------------------------------
8
• When shooting with the lens attached, be sure to view the image on the LCD monitor
of the camera. (The viewfinder does not show the actual shooting range.)
• When the wide conversion lens is attached, set the zoom position to the wide-angle
end. If the shutter release button is pressed when the zoom position set to the
telephoto side, the camera may not be focused.
• When the wide conversion lens is attached, even if you use the internal or external
flash, the area around the subject is not illuminated sufficiently so the picture will be
partly underexposed.
Note ---------------------------------------------------------------------------------------------
For cleaning and storage, see the documentation that came with your wide conversion
lens.
174
Model Remarks
DW-5 Used for wider angle shooting.
AC-4d Used for power supply from a household outlet to the camera.
DB-43 Rechargeable battery for use with this camera.
BJ-2e Used to charge the rechargeable battery (DB-43).
BS-3e Includes the rechargeable battery (DB-43) and battery charger
(BJ-2e).
SC-500 Used to store your camera.
