  • Page 2: Table Of Contents

    ABLE OF ONTENTS ABOUT THIS GUIDE............3 1. INTRODUCTION ..............4 ............5 EATURES AND ENEFITS ............7 NPACKING THE ACKAGE .............8 YSTEM EQUIREMENT ............9 HYSICAL ESCRIPTION 2. HARDWARE INSTALLATION .........11 ..........11 TTACHING THE ETAL ........12 ONNECTING THE THERNET CABLE ..........12 TTACHING THE OWER UPPLY 3.
  • Page 3 ..........19 ONFIGURATION TILITY ............21 YSTEM DMINISTRATION ..............46 IEWING IDEO 6. IPVIEW SE ................50 .................50 NSTALLATION ..............55 ETTING TARTED ............57 OW TO DD A AMERA .............62 OW TO HANGE AMERA ........63 ONNECT ISCONNECT THE MAGE ...........66 OW TO ELETE A AMERA ..............67 XTRA NFORMATION...

  • Page 4: About This Guide

    BOUT UIDE This manual provides instructions and illustrations on how to use your Pan/Tilt Internet Camera, includes: Chapter 1, Introduction, provides the general information on the camera. Chapter 2, Hardware Installation, describes the hardware installation procedure for the camera. Chapter 3, Security, explains the security feature of the camera.

  • Page 5: Introduction

    NTRODUCTION Thank you for purchasing the Pan/Tilt Internet Camera, a standalone system that can be connected directly to an Ethernet or Fast Ethernet. Compared to the conventional PC camera, the Pan/Tilt Internet Camera features a built-in CPU and web-based solutions that can provide a cost-effective solution to transmit the real-time high-quality video images for monitoring.

  • Page 6: Features And Benefits

    Features and Benefits Simple To Use The Pan/Tilt Internet Camera is a standalone system with built-in CPU, no special hardware (such as a PC frame capture card) or software required. The camera supports DirectX 9.0; therefore, the only requirement you need is the web browser software such as Internet Explorer 5.0 or above.
  • Page 7 Remote Utility The powerful IPView SE application assigns the administrator with a pre-defined user ID and password, allowing the administrator to modify the camera settings from the remote site via Intranet or Internet. When new firmware is available, you can also upgrade remotely over the network for added convenience.

  • Page 8: Unpacking The Package

    Unpacking the Package Unpack the package and check all the items carefully. In addition to this User’s Guide, be certain that you have: One Pan/Tilt Internet Camera One External Power Adapter (5V DC, 2A) One RJ-45 Ethernet Cable One Metal Clip One Multi-Language Quick Installation Guide One Installation CD-ROM If any item contained is damaged or missing, please contact your...

  • Page 9: System Requirement

    System Requirement Networking Local Area Network: 10Base-T Ethernet or 100Base-TX Fast Ethernet Accessing the Camera For Web Browser Users Operating System: Microsoft® Windows® 98SE/ME/ 2000/XP CPU: Intel Pentium II, 266 MHz or above Memory Size: 128MB (256MB recommended) Resolution: 800x600 or above Microsoft®...

  • Page 10: Physical Description

    Physical Description This section describes the externally components’ features of your camera. Front Panel There are two LED indicators on the front panel of the camera: Power LED and Link LED. 1. Power LED The Power LED is positioned on the right side of the two LEDs. A steady BLUE light confirms that the camera is powered on.

  • Page 11: Rear Panel

    Rear Panel DC Power Connector Network Cable Connector Reset Button 1. DC Power Connector The DC power input connector is located on the camera’s rear panel, and is labeled DC5V 2.5A with a single jack socket to supply power to the camera. Power will be generated when the power supply is connected to a wall outlet.

  • Page 12: Hardware Installation

    ARDWARE NSTALLATION Attaching the Metal Clip Wall screw Screw Ceiling screw Screw Wall screw Ceiling screw Base of the camera To attach the metal clip, remove the two rubber pads under the base of the camera firstly. Place the metal clip onto the camera base, and align the two holes of metal clip with two screw holes on the base.

  • Page 13: Connecting The Ethernet Cable

    Connecting the Ethernet cable Connect an Ethernet cable to the network cable connector located on the camera’s rear panel, and then attach it to the network. Attaching the Power Supply Attach the external power supply to the DC power input connector located on camera’s rear panel, and then connect it to your local power supply.

  • Page 14: Security

    ECURITY To ensure the highest security and prevent unauthorized usage of the camera the Administrator has the exclusive privilege to access the System Administration for settings and control requirements to allow users the level of entry and authorize the privileges for all users.

  • Page 15: Application Of The Camera

    PPLICATION AMERA The camera can be applied in wide variety of applications. With the built-in CPU, it can work as a standalone system that provides a web-based solution transmitting high quality video images and sounds for monitoring purposes. It can be managed remotely, accessed and controlled from any PC desktop over the Intranet or Internet via a web browser.

  • Page 16: Applications

    Applications Monitoring of local and remote places and objects such as construction sites, hospitals, amusement parks, schools and day-care centers through the use of a web browser. Capture single frame images from the IPView SE application. Configure the camera to upload image or send-mail messages with a single frame image.

  • Page 17: Application Diagrams Of The Camera

    Application Diagrams of the Camera Home Applications...
  • Page 18 SOHO Applications...
  • Page 19 Enterprise Applications...

  • Page 20: Using The Camera

    SING THE AMERA You can access and manage the camera through: 1) a web browser, and 2) the enclosed software IPView SE. This chapter describes the Web Configuration Utility, and provides the instructions on using the camera with a web browser. Web Configuration Utility The camera must be configured through its built-in Web-based Configuration.
  • Page 21 Default IP address Pre-view area Welcome Screen of the Configuration Utility After the default IP address is entered from the browser, the camera Welcome screen will appear with a still image. There will be three options to choose from to set-up and view your camera, including: View Video –...

  • Page 22: System Administration

    System Administration Under the Welcome screen of the Configuration Utility, click System Administration to enter the administration window that contains the settings required for the camera in the top menu bar, including Management, Configuration, Tools, Help, and Home. TIP: Once you have changed the settings in each option, click Save to store the settings, or Cancel to abandon, or Refresh to reload the status.
  • Page 23 System Click the System item in the left column to display the device status of your camera (as shown above). - Device Status: The information about the camera, including the Camera Name, Location, Model, Firmware Version, MAC Address and IP Address, can be found in this field.
  • Page 24 Video Click the Video item in the left column to display the video configuration of your camera. - Video Status: The video configuration about the camera, including the Video Resolution, Compression Rate, Frame Rate, Frame Size and IP Address, can be found in this field.
  • Page 25 - Network Status: The items in this field display the information of the LAN, such as the IP Address, Subnet Mask, Default Gateway, Primary/Secondary DNS Address, Dynamic DNS, Secondary HTTP Port, UPnP, as well as the FTP/E-mail upload status.
  • Page 26 User Click the User item in the left column to display the user(s) information. - Active Users: The items in this field display the user(s) information, including the user(s) IP address, Name, and DateTime.
  • Page 27 System Administration Configuration The Configuration window contains commands for settings that are required to input key details to setup the camera for operation. Click Configuration in the top menu bar and the Configuration window will appear as below: System Click the System item in the left column to setup the basic configuration of your camera (as shown above).
  • Page 28 the last six digit of the MAC Address. maximum length is 32 (printable ASCII). Location: This field is used to enter a descriptive name for the location used by the camera (optional). Admin: This field is used to enter the administrator name along with the password to access the System Administration settings.
  • Page 29 The default setting for the LED control is at Normal. When you have configured the LED control, the correct illumination will be set after 1 minute. Video Click the Video item in the left column to setup the image configuration of your camera. - Video Setting: In this field, you can configure the basic information of your camera.
  • Page 30 to Very High. Higher video compression rate will generate more compact file size with less video quality and vise-versa. The default setting is Medium. Frame Rate: Select the frame rate desired with default setting at Auto for optimal frame rate. Brightness Control: Adjust the brightness level with default setting at 64.
  • Page 31 Network Click the Network item in the left column to setup the LAN configuration of your camera. - TCP/IP: The items in this field display the information of the local area network. IP Address Mode: This field provides your with three options to select the IP Address Mode:...
  • Page 32 You can select this option and enter the IP address directly. The default settings are: Fixed IP IP Address – 192.168.0.20 Subnet Mask – 255.255.255.0 Default Gateway – 0.0.0.0 If your network uses the DHCP server, select this option. According to this setting, Dynamic the camera will be assigned an IP address Address...
  • Page 33 UPnP: UPnP is the architecture for pervasive peer- to-peer network connectivity of intelligent appliances, and PCs of all form factors. Check the Enable option to enable the function of your camera. User Click the User item in the left column to add, edit and delete users for your camera.
  • Page 34 - Define Users: Use this field to add or delete users for your camera. Add User: Enter the user name in this box, and enter the user’s password assigned by the administrator. The maximum password length is 8 (printable ASCII). The administrator has the authority to give permission for the privilege to control the Upload/E- mail Video control to the users by selecting Yes or No to activate the Upload/E-mail Video.
  • Page 35 DateTime Click the DateTime item in the left column to setup time and date for your camera, providing correct information for the remote users who might be thousands of miles away from the camera’s location. - Date & Time: You can set up time and date manually or automatically by selecting the Synchronized with Time Server option.
  • Page 36 Enter the IP Address of the Time Server in Address this box. Two options of NTP or Time are available Protocol for your selection to link with the Time Server. The default setting is NTP. Select the time zone for the region from the TimeZone pull-down menu.
  • Page 37 Passive Mode: This function depends on your FTP server. Please check with your IT manager if the FTP server uses passive mode. The default setting is...
  • Page 38 - Time Schedule: Select the Enable upload video to FTP server option and enter the relevant information, such as the schedule, video frequency and base file name. Schedule: You can 1.) Choose Always to always upload the video to FTP server, or 2.) Set the Schedule to manage the uploading task.
  • Page 39 E-mail Click the E-mail item in the left column to setup configuration for E-mail account, time schedule and manual operation settings.
  • Page 40 - E-mail Account: This field contains the following six basic settings for your FTP server. SMTP Server Address: SMTP (Simple Mail Transfer Protocol) is a protocol for sending e-mail messages between servers you need to input the mail server address in this field. Sender e-mail Address: Enter the e-mail address of the user who will send the e-mail.
  • Page 41 System Administration Tools The Tools window contains commands for restarting the camera. Click Tools in the top menu bar and the Tools window will appear as below: FTP Server Test Click the FTP Server Test item in the left column to test your FTP server (as shown above).
  • Page 42 E-mail Test Click the E-mail Test item in the left column to test your e-mail account. - Test E-mail Account: Click the Test button to test the e- mail account you provided. Reset Do you really want to reset this device? Click the Yes button from this option, and you can restart the camera just like turning the device off and on and saved settings are retained.
  • Page 43 Factory Reset Do you really want to factory reset this device? Click the Yes button from this option, and you can resume all factory default settings for the camera. If you do not want to restore the factory settings, exit this window without clicking Yes. Please NOTE that you have to configure the network settings again after a Factory Reset.
  • Page 44 Firmware Upgrade When new firmware is available, you can upgrade it through this window. Click the Browse… button to point to the firmware file, and then click Update to start upgrading. Backup Click the Backup item in the left column to backup the current configuration.
  • Page 45 - Backup Device Configuration to File: Do you really want to backup the configuration to file? Click the Backup button from this option, and you can save the current configuration to file. - Restore Device Configuration from File: You can resume the device configuration from saved file in the computer.
  • Page 46 System Administration Help The Help window provides the basic information of the camera. Click Help in the top menu bar and the Help window will appear as below: About Displays the camera’s model name and version. Once the configuration is completed, click Home to return to the Welcome screen and select the desired View Video option either through ActiveX Mode or Java Mode as described in the next section.

  • Page 47: Viewing Video

    desire image quality. Please refer to Appendix F for detailed instruction. Viewing Video To view video images from the browser, click View Video – ActiveX Mode or Java Mode from the Welcome screen to access the video images from your browser. Camera Name and Date/Time Camera Name and...
  • Page 48 Camera Name & Date/time: The Camera name and the current date/time will be displayed when the related information are entered under Configuration of Web Configuration Utility. Uploading/E-mailing Video In the View Video – ActiveX Mode or Java Mode, you are allowed to use the Upload Video and E-mail Video options.

  • Page 49: Controlling The Camera

    Controlling the Camera You can control the camera’s viewing angel through the control buttons on the left side of the viewing window. Control buttons Adjusting the Viewing Angle To adjust the camera’s viewing angel, simply click the Up/Down/ Left/Right button. Then, you can easily move the camera’s lens to focus on the object that you want.
  • Page 50 Storing the Position You can store the position(s) that you want to monitor, so that you can quickly move the camera’s lens to focus on the object that you want. You can store up to 24 positions in the camera (the number “0”...

  • Page 51: Ipview Se

    This chapter describes the IPView SE, which is a powerful software application designed with a user-friendly interface for ease of control and navigation requirements. Installation Insert the CD-ROM into the CD-ROM drive to initiate the auto- run program. Once completed, a menu screen will appear as below:...
  • Page 52 To install the IPView SE application, click the IPView SE item to activate the installation procedure for the application program. Click Next in the welcome screen of InstallShield Wizard. Read and accept the software’s License Agreement; then, click Yes.
  • Page 53 Choose the destination location. If no specific requirement, leave the default setting and click Next. The InstallShield Wizard starts to install the software, and the progress bar indicates the installation is proceeding.
  • Page 54 Windows® XP Windows® 2000 If you use Windows® 2000/XP, it will appear a Digital Signature warning screen. Click Continue Anyway (Windows® XP) or Yes (Windows® 2000). Click Finish to complete the installation.
  • Page 55 After successfully installing the IPView SE, the application program for the camera is automatically installed to \Programs\ Files directory. To start running IPView SE, click Start > Programs > IPView SE > IPView SE. Once login, the IPView SE application is executed and the interface of IPView SE will appear in the default List View format as bellow:...

  • Page 56: Getting Started

    Getting Started IPView SE is responsible for the management of preview, configuration, and searching of each camera. It is designed with a user-friendly interface for ease of control and navigation requirements as illustrated below. IPView SE Control Panel Minimize Exit Play Scan About...
  • Page 57 Minimize To minimize the control panel. Exit To close IPView SE. Play To play back the recorded file. Scan To display for each camera one by one. Combine To combine all display windows in one. About To display the information of IPView SE.

  • Page 58: How To Add A Camera

    How to Add a Camera Add Camera Add Camera To add a new camera, click the Add Camera button (1~4). An Add Camera dialog box will appear as illustrated below.
  • Page 59 You must select the camera and click the Add button to add a new camera. You can select the Input IP button, an Input IP dialog box will appear as illustrated below. Enter the IP Address of the camera in the specified field and click the Add button to add a new camera.
  • Page 60 4. If you forget the IP Address that you want to add, a dialog box will appear to notify you of the error. If you are unsure of the IP Address of the camera, you can click the ReSearch button, it will start searching the available camera(s) again, and display the result in the dialog box.
  • Page 61 You must select the camera and click the Add button to add a new camera. If the Login Camera dialog box appears, make sure to enter the correct User Name and Password and click the OK button. Then, the camera will be added into IPView SE in list format. If the User Name and Password is entered incorrectly, the camera will not be added into IPView SE.
  • Page 62 Make sure to save any changes you have made to keep the information updated. Note : You are allowed to add only one camera at a time. When the user adds the camera, the additional control/ configuration buttons will appear, including: Assign IP to Camera, Connect/Disconnect, Erase, Extra Information, etc.

  • Page 63: How To Change Camera

    How to Change Camera Assign IP of New Camera To change camera, click the Assign IP of Camera button on the Control Panel. An Assign IP of Camera dialog box will appear as illustrated below. You must select the camera and click the Add button to add a new camera.

  • Page 64: Connect/Disconnect The Image

    Connect/Disconnect the Image Connect the Image Click the Connect/Disconnect button and the preview screen will appear with the video image. NOTE: When a new camera is added, it is connected. You can see the image right away. If you click the “Connect/ Disconnect”...
  • Page 65 Close Click to close the display screen of the camera. Always on top Click to have the display screen always appear on the top of the window. Wake up control panel Click to open the control panel again when it is closed. Color setting Click to adjust color of the image.

  • Page 66: Disconnect The Image

    Disconnect the Image Click the Connect/Disconnect button, and the camera will be disconnected.

  • Page 67: How To Delete A Camera

    How to Delete a Camera Liberate Camera To delete a camera, you must select the camera to delete from the IPView SE control panel. Then, click the Liberate Camera button. After deleting the camera, the IPView SE control panel will appear as below.

  • Page 68: Extra Information

    Extra Information Extra Information The screen displays the camera’s information.

  • Page 69: How To Adjust The Property Setting

    How to Adjust the Property Setting System Configure From the control panel, select the button and the dialog box will appear as shown below. Log Storage: 1. Single HDD Reserve Space This option permits reserved HDD space from 500 MB to 1000 MB.
  • Page 70 3. Storage List This option is used to define the path to save image files. The software will create a camera name folder as the “Storage List” which is allowed to create up to 16 File Path. Recycle: When you enabled this function, it will recycle the HDD space once the disk space is less than the size defined.

  • Page 71: Camera Configure

    Camera Configure Click the Camera Config button and it will active the Camera Setting, Motion Setting and Update Firmware buttons. Camera Setting Motion Setting Update Firmware Camera Setting Please refer to the “Web Configuration” section.

  • Page 72: Motion Setting

    Motion Setting You can adjust the sensitivity level and choose the Invoke Alarm options to work with motion detection function. Besides the Alarm Beep, Send Email can be enabled when motion detected. The user can define the time interval to Send E-mail.
  • Page 73 Mail Server: Mail Server IP or name. Mail From: E-Mail Address of sender. Mail To: E-Mail Address of receiver. Subject: Can be any information to high light the message. User Name: Enter the user name in this field. Password: Enter the user password in this field to login receiver’s mail server Interval Time: The time interval to send next E-Mail the unit is by second.

  • Page 74: Update Firmware

    Update Firmware Enter the File Path and click the Update button, the firmware will be updated automatically. If you are unsure of the File path, you can click the Browse button, the Browse dialog box will appear, allowing you to find the file. Warning During firmware update process, please make sure no interruptions will occur as it might possibly cause serious damage to the Internet...

  • Page 75: Adjust The Recording Setting

    Adjust the Recording Setting There are three ways to start recording image - Motion Record, Schedule Record & Manual Record. Motion Record This option allows the camera to trigger recording by motion detected. You can adjust the sensitivity level and choose the warning options when motion is detected from motion setting.

  • Page 76: Appendix

    PPENDIX A. Frequently Asked Questions Internet Camera Features Q: What is an Internet Camera? A: The camera is a standalone system connecting directly to an Ethernet or Fast Ethernet network. It is different from the conventional PC camera, the camera is an all-in-one system with built-in CPU and web-based solutions providing a low cost solution that can transmit high quality video images for monitoring.
  • Page 77 Q: What algorithm is used to compress the digital image? A: The camera utilizes the JPEG image compression technology providing high quality images for users. JPEG is adopted since it is a standard for image compression and can be applied to various web browser and application software without the need to install extra software.

  • Page 78: Ping Your Ip Address

    B. PING Your IP Address The PING (Packet Internet Groper) command can determine whether a specific IP address is accessible by sending a packet to the specific address and waiting for a reply. It can also provide a very useful tool to confirm if the IP address conflicts with the camera over the network.

  • Page 79: Trouble Shooting

    C. Trouble Shooting Q: I cannot access the camera from a web browser. A1: The possible cause might be the IP Address for the camera is already being used by another device. To correct the possible problem, you need to first disconnect the camera from the network.
  • Page 80 the product by connecting a local computer to the unit, utilizing a standard Crossover (hub to hub) Cable. If the problem is not solved the camera might be faulty. Q: Why does the Power LED not light up constantly? A: The power supply used might be at fault. Confirm that you are using the provided power supply DC 5V for the camera and verify that the power supply is well connected.
  • Page 81 a more shaded area immediately as this will damage the CMOS sensor. Q: There is bad focus on the camera, what should be done? A1: The focus might not be correctly adjusted for the line of sight. You need to adjust the camera focus manually as described in Adjust Internet Camera Focus.
  • Page 82 brightness, contrast, hue and light frequency. Please refer to the Web Configuration section for detail information. Q: There are no images available through the web browser? A: The ActiveX might be disabled. If you are viewing the images from Internet Explorer make sure ActiveX has been enabled in the Internet Options menu.

  • Page 83: Time Zone Table

    D. Time Zone Table...

  • Page 85: Xplug Control Installation

    E. Xplug Control Installation Installation To Web Server Important Information It is highly recommended to install the Xplug Control application to the Web Server for IE 5.0. It must be installed to a Public Domain with Fixed IP address. 1. Installation: Copy the “xplug.ocx”...
  • Page 86 Installation To Local PC Insert the CD-ROM into the CD-ROM drive to initiate the auto- run program. Once completed, a menu screen will appear as below: To install Xplug Control, click the Xplug Control item to activate the installation procedure for the plug-in program. Once executed, a prompt will appear requesting the input of the desired language selection.
  • Page 87 Click the Next button to The Welcome screen will appear. proceed with the installation. The License Agreement prompt will appear as below. Read the details carefully and click the Yes button to continue with the installation procedure.
  • Page 88 Click the Finish button to complete Setup of the Xplug Control Utility program for the camera.

  • Page 89: Adjust Internet Camera Focus

    F. Adjust Internet Camera Focus To adjust the focus of the lens, you need to turn the lens slowly in either clockwise or anti-clockwise direction until the desired image appears. DO NOT over turn the lens in either of the directions, as it will be out of focus.

  • Page 90: Specification

    G. Specification Image Sensor Sensor resolution : 640 x 480 pixel Sensor type : 1/4” Color CMOS Sensor Lens : f: 6.0 mm, F: 1.8 Video Image compression : JPEG Image Frame rate : 30fps @ QQVGA, 25fps @ QVGA, 10fps @ VGA Compression Rate selection : 5 levels: Very low/Low/...
  • Page 91 : RDC R2880 : 8MB Flash ROM : 2MB : RTOS Power Supply : DC 5V 2.5A, switching type Power consumption : 6.5 Watt (1300mA x 5V) LED Indicator : Power LED (Blue) Link LED (Orange) Pan/Tilt : Pan -156°~ +156° Tilt -45 ~ +70°...

  • Page 92: Glossary Of Terms

    H. Glossary of Terms NUMBERS 10BASE-T 10BASE-T is Ethernet over UTP Category III,IV, or V unshielded twisted-pair media. 100BASE-TX two-pair twisted-media implementation 100BASE-T is called 100BASE-TX. Applet Applets are small Java programs that can be embedded in an HTML page. The rule at the moment is that an applet can only make an Internet connection to the computer form that the applet was sent.
  • Page 93 Bootstrap Protocol is an Internet protocol that can BOOTP automatically configure a network device in a diskless workstation to give its own IP address. Communication Communication has four components: sender, receiver, message, and medium. In networks, devices and application tasks and processes communicate messages to each other over media.
  • Page 94 of manually assigning it a unique IP address. DHCP allows the specification for the service provided by a router, gateway, or other network device that automatically assigns an IP address to any device that requests one Domain Name System is an Internet service that translates domain names into IP addresses.
  • Page 95 Fast Ethernet, also called 100BASE-T, operates at 10 Fast Ethernet or 100Mbps per second over UTP, STP, or fiber-optic media. Firewall is considered the first line of defense in Firewall protecting private information. For better security, data can be encrypted. A system designed to prevent unauthorized access to or from a private network.
  • Page 96 for humans to read hexadecimal numbers than binary numbers. IEEE Institute of Electrical and Electronic Engineers. This is a private network, inside an organization or Intranet company, that uses the same software you will find on the public Internet. The only difference is that an Intranet is used for internal usage only.
  • Page 97 IP address IP address is a 32-binary digit number that identifies each sender or receiver of information that is sent in packets across the Internet. For example 80.80.80.69 is an IP address, it is the closet thing the Internet has to telephone numbers.
  • Page 98 Network Address Translator generally applied by a router, that makes many different IP addresses on an internal network appear to the Internet as a single address. For routing messages properly within your network, each device requires a unique IP address. But the addresses may not be valid outside your network.
  • Page 99 by sending a packet to the specified address and waits for a reply. It is primarily used to troubleshoot Internet connections. PPPoE Point-to-Point Protocol over Ethernet. PPPoE is a specification for connecting the users on an Ethernet to the Internet through a common broadband medium, such as DSL or cable modem.
  • Page 100 Reverse Address Resolution Protocol, a TCP/IP RARP protocol that allows a physical address, such as an Ethernet address, to be translated into an IP address. RJ-45 RJ-45 connector is used for Ethernet cable connections. Router A router is the network software or hardware entity charged with routing packets between networks.
  • Page 101 Transmission Control Protocol/Internet Protocol is a (TCP/IP) widely used transport protocol that connects diverse computers of various transmission methods. It was developed y the Department of Defense to connect different computer types and led to the development of the Internet. Transceiver A transceiver joins two network segments together.
  • Page 102 Unshielded twisted-pair. UTP is a form of cable used by all access methods. It consists of several pairs of wires enclosed in an unshielded sheath. Wide-Area Network. A wide-area network consists of groups of interconnected computers that are separated by a wide distance and communicate with each other via common carrier telecommunication techniques.
  • Page 103 Limited Warranty TRENDware warrants its products against defects in material and workmanship, under normal use and service, for the following lengths of time from the date of purchase. Internet Camera Server – 3 Years Warranty If a product does not operate as warranted above during the applicable warranty period, TRENDware shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or...
  • Page 104 marked on the outside of the package, and sent prepaid, insured and packaged appropriately for safe shipment. WARRANTIES EXCLUSIVE: IF THE TRENDWARE PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT TRENDWARE’S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW,...
  • Page 105 ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH DAMAGES, LIMITS LIABILITY REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE PRICE PAID, AT TRENDWARE’S OPTION. THIS DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
