Gefen EXT-DPKVM-441 User Manual

4 x 1 displayport kvm switcher
Hide thumbs Also See for EXT-DPKVM-441:
Table of Contents

Advertisement

Quick Links

Download this manual
4 1
DisplayPort KVM
x
Switcher
SOURCES
DISPLAY
EXT-DPKVM-441
User Manual
Version A3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXT-DPKVM-441 and is the answer not in the manual?

Questions and answers

Related Manuals for Gefen EXT-DPKVM-441

Summary of Contents for Gefen EXT-DPKVM-441

  • Page 1 DisplayPort KVM Switcher SOURCES DISPLAY EXT-DPKVM-441 User Manual Version A3...

  • Page 2: Important Safety Instructions

    4x1 DPKVM Switcher Important Safety Instructions GENERAL SAFETY INFORMATION Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this product near water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install or place this product near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. To reduce the risk of electric shock and/or damage to this product, never handle or touch this unit or power cord if your hands are wet or damp. Do not expose this product to rain or moisture. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

  • Page 3: Warranty Information

    This warranty is in lieu of all other warranties expressed or implied, including without limitation, any implied warranty or merchantability or fitness for any particular purpose, all of which are expressly disclaimed. Proof of sale may be required in order to claim warranty. Customers outside the US are responsible for shipping charges to and from Gefen. Copper cables are limited to a 30 day warranty and cables must be in their original condition. The information in this manual has been carefully checked and is believed to be accurate. However, Gefen assumes no responsibility for any inaccuracies that may be contained in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. The technical information contained herein regarding the features and specifications is subject to change without notice. For the latest warranty coverage information, refer to the Warranty and Return Policy under the Support section of the Gefen Web site at www.gefen.com. PRODUCT REGISTRATION Please register your product online by visiting the Register Product page under the Support section of the Gefen Web site.
  • Page 4 4x1 DPKVM Switcher Contacting Gefen Technical Support Gefen, LLC c/o Customer Service 20600 Nordhoff St. Chatsworth, CA 91311 Telephone: (818) 772-9100 (800) 545-6900 Fax: (818) 772-9120 Email: support@gefen.com Visit us on the Web: www.gefen.com Technical Support Hours: 8:00 AM to 5:00 PM Monday - Friday, Pacific Time 4x1 DPKVM Switcher is a trademark of Gefen, LLC. Important Notice Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice. © 2011 Gefen, LLC. All Rights Reserved. All trademarks are the property of their respective owners.

  • Page 5: Operating Notes

    3GSDI Audio Embedder 4x1 DPKVM Switcher Operating Notes • The 4x1 DPKVM Switcher supports pass-through EDID. The Switcher will use the EDID from the monitor connected to the output. • Dual Link resolutions up to 2560 x 1600 are supported. • HDCP content is not supported. • The 4x1 DPKVM Switcher does not support DHCP. • The default IR channel for both the Switcher and the IR Remote Control Unit is channel 0. See Setting the IR Channel for more information.

  • Page 6: Packing List

    • Supports resolutions up to 2560 x 1600 • Supports RGB and YCbCr color spaces • RS-232 control • IP control • IR remote control • Supports USB 2.0 with backward-compatibility for USB 1.1 • Jack for external IR Receiver (EXT-RMT-EXTIR) • Save space on your desktop • Rack-mountable Packing List The 4x1 DPKVM Switcher ships with the items listed below. If any of these items are not present in your box when you first open it, immediately contact your dealer or Gefen. • 4x1 DPKVM Switcher • 1 x 6 ft. DisplayPort cables • 1 x 6 ft. USB 2.0 cables (A - B) • 1 x 6 ft. 3.5 mm mini-stereo audio cables • 1 x IR remote control unit (EXT-RMT-4IR) • 1 x 5V / 4A DC locking power supply (EXT-PS54AULP) • 1 x Set rack ears • 1 x Quick-Start Guide...

  • Page 8: Table Of Contents

    3GSDI Audio Embedder 4x1 DPKVM Switcher Table of Contents Getting Started Panel Layout ......................2 Front Panel ....................2 Back Panel ....................3 IR Remote Control Unit ..................4 Front ......................4 Back ......................5 Installing the Battery ..................6 Setting the IR Channel .................. 6 Installation ......................7 Connecting the 4x1 DPKVM Switcher ............7 Sample Wiring Diagram ................7 Operating the 4x1 DPKVM Switcher Switching Sources .

  • Page 11: 01 Getting Started

    DisplayPort KVM Switcher SOURCES DISPLAY 01 Getting Started Panel Layout ......................2 Front Panel ....................2 Back Panel ....................3 IR Remote Control Unit ..................4 Front ......................4 Back ......................5 Installing the Battery ..................6 Setting the IR Channel .................. 6 Installation ......................7 Connecting the 4x1 DPKVM Switcher ............7 Sample Wiring Diagram ................7...

  • Page 12: Panel Layout

    Getting Started Panel Layout Front Panel Name Description Input indicators Each of these LED indicators glows bright blue according to the input selection. Receives IR signals from the included IR remote control unit. Input buttons Press these buttons to select the desired input. Power This LED indicator will glow bright red when the unit is powered. page | 2...

  • Page 13: Back Panel

    Getting Started Panel Layout Back Panel Name Description 5V DC Connect the included 5V DC locking power supply to this receptacle. Audio In (1 - 4) Connects up to 4 audio sources using 3.5mm mini-stereo cable. DP In (1 - 4) Connects up to 4 DisplayPort sources. Audio Out Connects an audio output device using a 3.5mm mini-stereo cable. DP Out Connects to a DisplayPort output (display). Ext. IR Connect an IR extender (Gefen part no. EXT-RMT-EXTIR) to this jack. USB In (1 - 4) Connects up to 4 USB host devices. USB Out (1 - 2) Connect up to 2 USB devices to these ports. RS-232 Connect an RS-232 cable from this port to an RS-232 control device. This port provides remote control of the product from a remote location. Ethernet Connect an Ethernet cable from this jack to a network in order to control the unit using the Telnet feature. page | 3...

  • Page 14: Ir Remote Control Unit

    Getting Started IR Remote Control Unit Front Name Description Activity indicator This LED glows bright orange when a key is pressed on the remote. Source selection buttons Used to control features in the On-Screen (1, 2, 3, 4) Display (see page 4). page | 4...

  • Page 15: Back

    Getting Started IR Remote Control Unit Back (shown with cover removed) Name Description DIP switch bank Use these DIP switches to set the IR channel of the remote (see page 5). Primary battery slot Holds the battery for operating the remote. (shown without battery) Use only 3V CR2032-type batteries. Make sure that the positive (+) side of the battery is facing up. Alternate battery slot Allows for the installation of secondary (backup) battery. page | 5...

  • Page 16: Installing The Battery

    Getting Started IR Remote Control Unit Installing the Battery The IR remote control unit ships with two batteries. Only one battery is required for operation. The second battery is a spare. WARNING: Use only 3V CR2032-type batteries. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Remove the back cover the IR Remote Control unit. Insert the included battery into the primary battery slot. The positive (+) side of the battery should be facing up. Replace the back cover. NOTE: An Activity Indicator that flashes quickly while holding down any one of the buttons indicates a low battery. Replace the battery as soon as possible. Setting the IR Channel In order for the included IR remote control to communicate with the 4x1 DPKVM Switcher, the IR remote control must be set to the same channel as the switcher. Use the #irrmtadd command to set the IR channel of the switcher. IR Channel DIP settings (default) DIP switches page | 6...

  • Page 17: Installation

    Connecting the 4x1 DPKVM Switcher Connect up to four DisplayPort source devices to the DisplayPort inputs on the back panel of the Switcher using DisplayPort cables. Connect a DisplayPort-supported display to the DisplayPort output on the back panel of the Switcher. Connect up to four USB host devices (computers, etc) to the USB In ports. Connect up to two USB devices (mouse, keyboard, camera, etc.) to the USB Out ports. Connect the included 5V locking power supply to the power receptacle on the 4x1 DPKVM Switcher. Connect the AC power cord to an available electrical outlet. To use the RS-232 communication feature, connect an RS-232 cable between the Switcher and RS-232 host controller. To communicate with the Switcher using Telnet, connect an Ethernet cable from the Ethernet jack on the back of the Switcher to the network. See IP Configuration for more information on using the Telnet feature. To extend the range of the IR control, connect an IR Extender (Gefen part no. EXT-RMT-EXTIR) to the back of the Switcher. Sample Wiring Diagram MINI STEREO AUDIO CABLE DISPLAYPORT CABLE RS-232 CABLE Computer USB CABLE Computer ETHERNET Computer IR Extender Computer Router DisplayPort...

  • Page 19: Operating The 4X1 Dpkvm Switcher

    DisplayPort KVM Switcher SOURCES DISPLAY 02 Operating the 4x1 DPKVM Switcher Switching Sources ....................10 Switching sources using the Front Panel Buttons ........10 Switching sources using the IR Remote Control ......... 11...

  • Page 20: Switching Sources

    Operating the 4x1 DPKVM Switcher Switching Sources Switching sources using the Front Panel Buttons The front panel of the 4x1 DPKVM Switcher has a set of four (4) LED indicators, displaying which input (source) is being displayed. Each of these LED indicators corresponds to one of the push-buttons on the front panel. For our first example, we will switch to Input 3 using the buttons on the front panel. Press button 3 on the front panel of the 4x1 DPKVM Switcher. The LED indicator for input 3 will glow bright blue on the front panel. Press button 3 LED indicates that Input 3 is the active input. page | 10...

  • Page 21: Switching Sources Using The Ir Remote Control

    Operating the 4x1 DPKVM Switcher Switching Sources Switching sources using the IR Remote Control In this example, we will switch to Input 1, using the IR remote control unit. Point the IR remote control unit at the IR sensor on the front panel of the 4x1 DPKVM Switcher. If an IR Extender (Gefen part no. EXT-RMT-EXTIR) is being used, then point the IR remote control unit at the sensor of the IR Extender. Prress button 1 on the IR Remote Control Unit. The Activity Indicator on the IR Remote Control Unit will glow yellow, indicating that a button was pressed. The LED indicator, on the front panel, for Input 1 will glow bright blue. LED indicates a button was pressed Press button 1 on the IR remote control unit. IR sensor LED indicates that Input 1 is the active input. page | 11...

  • Page 23: 03 Advanced Operation

    DisplayPort KVM Switcher SOURCES DISPLAY 03 Advanced Operation RS-232 and IP Configuration ................14 RS-232 Interface ..................14 RS-232 Settings ..................14 IP Configuration ..................15 RS-232 / IP Commands ..................16 page | 13...

  • Page 24: Rs-232 Interface

    Advanced Operation RS-232 and IP Configuration RS-232 Interface DE-9 DA-15 RS-232 Controller Switcher TXD TXD DB-25 DC-37 Only TXD, RXD, and GND are used. RS-232 Settings Description Setting DD-50 19200 Baud rate Data bits None Parity Stop bits None Hardware flow control IMPORTANT: When sending RS-232 commands, a carriage return must be included at the end of the command. A space must be included between the command and each parameter. page | 14...

  • Page 25: Rs-232 And Ip Configuration

    Advanced Operation RS-232 and IP Configuration IP Configuration The 4x1 DPKVM Switcher supports also IP-based control using Telnet. To set up IP control, the network settings for the 4x1 DPKVM Switcher must be configured via RS-232. The default network settings for the switcher are as follows: Description IP Address / Port Description IP Address / Port 192.168.1.72 IP Address Telnet Port 255.255.255.0 Subnet 192.168.1.254 Gateway HTTP Port Connect an RS-232 cable from the PC to the 4x1 DPKVM Switcher. Also make sure that an Ethernet cable is connected between the switcher and the network. Launch a terminal emulation program (e.g. HyperTerminal) and use the RS-232 settings listed on the previous page. NOTE: Depending upon the network, all related IP / Telnet settings will need to be assigned. Consult your network administrator to obtain the proper settings. Set the IP address for the switcher using the #sipadd command. Set the subnet mask using the #snetmask command. Set the gateway (router) IP address using the #sgateway command. Set the Telnet listening port using the #set_telnet_port command. Set the HTTP listening port using the #set_http_port command.

  • Page 26: Rs-232 / Ip Commands

    Advanced Operation RS-232 / IP Commands Command Description #activebolo Activates the boot loader #display_telnet_welcome Enables / disables the Telnet welcome message #fadefault Resets the routing state to factory-default settings #get_indev_name Retrieves the specified input device name #get_outdev_name Retrieves the output device name #help Displays the list of RS-232 / Telnet commands #ipconfig Displays all TCP/IP settings #irrmtadd Sets the IR channel for the switcher #resetip Sets IP configuration to default settings #set_http_port Sets the Web server listening port #set_indev_name Sets the name of the specified input device #set_outdev_name Set the name of the output device #set_pass Sets the Telnet password #set_telnet_port Sets the Telnet listening port #set_user_name Sets the Telnet user name #sgateway Specifies the new gateway #show_pass Displays the current Telnet password #show_user_name...
  • Page 27 Advanced Operation RS-232 / IP Commands #activebolo The #activebolo command activates the boot loader. This command is use when upgrading the firmware. See the Firmware Upgrade Procedure for instructions on upgrading the firmware. Syntax: #activebolo Parameters: None #display_telnet_welcome The #display_telnet_welcome command enables or disables the Telnet welcome message. Syntax: #display_telnet_welcome param1 Parameters: Value [0 ... 1] param1 Value Description Disable welcome message Enable welcome message page | 17...

  • Page 28: Return To Factory Default

    Advanced Operation RS-232 / IP Commands #fadefault The #fadefault command resets the routing to factory-default settings. This command is similar to the #resetip command, except that TCP/IP settings are preserved. Syntax: #fadefault Parameters: None Example: #fadefault Return to factory default Route to input 1 #get_indev_name The #get_indev_name command retrieves the specified input name. Use the #set_indev_name command to assign a name to the input. Syntax: #get_indev_name Parameters: param1 Input [1 ... 4] Example: #get_indev_name 1 Device input name = Macbook page | 18...
  • Page 29 Advanced Operation RS-232 / IP Commands #get_outdev_name The #get_outdev_name command retrieves the output device name. Syntax: #get_outdev_name Parameters: None Example: #get_outdev_name Device output name = None #help The #help command displays the list of available RS-232 / IP commands. The #help command can also be used to provide help on a specific command. Syntax: #help [param1] Parameters: Command (optional) param1 Notes: When asking for help on a specific command, the “#” character must be included as part of the command. Example: #help #fadefault Cmd #fadefault: Return to factory default: Routing=1, Disable Lock power mode, IR RMT add=0 page | 19...
  • Page 30 Advanced Operation RS-232 / IP Commands #ipconfig The #ipconfig command displays the current TCP/IP settings. Syntax: #ipconfig Parameters: None Example: #ipconfig ------------- TCP/IP settings ------------- MAC addr = 00:1C:91:02:50:27 IP addr = 192.168.2.204 Net Mask = 255.255.255.0 Gateway = 192.168.2.1 Web Server Port = 80 Telnet Server Port = 23 Telnet password on login is set to OFF Telnet welcome at login is set to OFF page | 20...
  • Page 31 Advanced Operation RS-232 / IP Commands #irrmtadd The #irrmtadd command sets the IR channel of the switcher. In order for the included IR remote control unit to function correctly with the switcher, both the IR remote control unit and the switcher must share the same IR channel. After executing this command, the DIP switch settings for the included IR remote control unit are returned. See Setting the IR Channel for information on setting the IR channel on the IR remote control unit. Syntax: #irrmtadd param1 Parameters: IR channel [0 ... 3] param1 Example: #irrmtadd 2 Set IR RMT 2 #resetip The #resetip command resets the IP configuration to factory-default settings. The switcher must be rebooted after executing this command. Syntax: #resetip Parameters: None Example: #resetip TCP/IP configuration was cleared to default, reboot to take efect page | 21...
  • Page 32 Advanced Operation RS-232 / IP Commands #set_http_port The #set_http_port command specifies the Web server listening port. The switcher must be rebooted after executing this command. The default port setting is 80. Syntax: #set_http_port param1 Parameters: Port [1 ... 65535] param1 Example: #set_http_port 82 New HTTP port set to: 82 #set_indev_name The #set_indev_name command sets the name for the specified input. The name of the input cannot exceed 15 characters in length. Use the #get_indev_name command to retrieve the specified input name. Syntax: #set_indev_name param1 param2 Parameters: param1 Input [1 ... 4] param2 Name Example: #set_indev_name Macbook page | 22...
  • Page 33 Advanced Operation RS-232 / IP Commands #set_outdev_name The #set_outdev_name command sets the name for the input. The name of the output cannot exceed 15 characters in length. Use the #get_outdev_name command to retrieve the output name. Syntax: #set_outdev_name param1 Parameters: Name param1 Example: #set_indev_name Macbook #set_pass The #set_pass command sets the Telnet password. The default password is Admin. The switcher must be rebooted after executing this command. The password cannot exceed 20 characters in length. Use the #show_pass command to display the current Telnet password. Syntax: #set_pass param1 Parameters: param1 Password Example: #set_pass reindeer Telnet password updated to: reindeer page | 23...
  • Page 34 Advanced Operation RS-232 / IP Commands #set_telnet_port The #set_telnet_port command sets the TCP terminal server listening port. The default port setting is 23. The switcher must be rebooted after executing this command. Syntax: #set_telnet_port param1 Parameters: Port [1 ... 65535] param1 Example: #set_telnet_port 24 New Telnet port set to: 24 #set_user_name The #set_user_name command sets the Telnet user name. The user name cannot exceed 20 characters in length. The default user name is Admin. Use the #show_user_name command to display the current user name. Syntax: #set_user_name param1 Parameters: param1 User name Example: #set_user_name Doc_Holiday Telnet username set to: Doc_Holiday page | 24...
  • Page 35 Advanced Operation RS-232 / IP Commands #sgateway The #sgateway command sets the gateway address. The gateway must be typed using dot-decimal notation. The default gateway is 192.168.1.254. The switcher must be rebooted after executing this command. Syntax: #sgateway param1 Parameters: Gateway param1 Example: #sgateway 192.168.1.1 New IP Gateway set to: 192.168.1.1 #show_pass The #show_pass command displays the current Telnet password. Use the #set_pass command to set the Telnet password. Syntax: #show_pass Parameters: None Example: #show_pass Telnet password: reindeer page | 25...
  • Page 36 Advanced Operation RS-232 / IP Commands #show_user_name The #show_user_name command displays current user name. Use the #set_user_name command to set the user name. Syntax: #show_user_name Parameters: None Example: #show_user_name Telnet login: Admin #show_ver_data The #show_ver_data command displays the current hardware and firmware version. Syntax: #show_ver_data Parameters: None Example: #show_ver_data Hardware version 0 Firmware Release version 1.4.9 Release date: Apr 22 2012 Release time: 14:56:52 Boot loader version 1.6 page | 26...
  • Page 37 Advanced Operation RS-232 / IP Commands #sipadd The #sipadd command sets the IP address of the switcher. The IP address must be entered using dot-decimal notation. The switcher must be rebooted after executing this command. Syntax: #sipadd param1 Parameters: IP address param1 Example: #sipadd 192.168.1.127 New IP set to: 192.168.1.127 #snetmask The #snetmask command sets the subnet mask. The net mask must be entered using dot-decimal notation. The switcher must be rebooted after executing this command. The default net mask is 255.255.255.0 Syntax: #snetmask param1 Parameters: Gateway param1 Example: #snetmask 255.255.0.0 New IP mask set to: 255.255.0.0 page | 27...
  • Page 38 Advanced Operation RS-232 / IP Commands #stbymode The #stbymode command toggles the Standby Mode state. When Standby Mode is enabled, the LED of the currently active input will flash. Once the switcher is placed in Standby Mode, no video will be displayed. The power LED will continue to glow bright red. Placing the switcher in Standby Mode does not power-down the switcher. Syntax: #stbymode param1 Parameters: Value [0 ... 1] param1 Value Description Disable Standby mode (On) Enable Standby mode (Off) Examples: #stbymode 1 Video power is set to OFF #stbymode 0 Video power is set to ON page | 28...
  • Page 39 Advanced Operation RS-232 / IP Commands #use_telnet_pass The #use_telnet_pass command enables or disables the login credentials when starting a Telnet session. Syntax: #use_telnet_pass param1 Parameters: Value [0 ... 1] param1 Value Description Disable password Force password Example: #use_telnet_pass 1 Telnet password on login is set to ON page | 29...
  • Page 40 Advanced Operation RS-232 / IP Commands The r command switches to the specified input. Do not precede this command with the “#” symbol. Syntax: r param1 Parameters: Input [1 ... 4] param1 Example: Route to input 3 page | 30...

  • Page 43: 04 Appendix

    DisplayPort KVM Switcher SOURCES DISPLAY 04 Appendix Firmware Upgrade Procedure ................34 Mounting Plate Installation .................. 35 Specifications ...................... 36 page | 33...

  • Page 44: Firmware Upgrade Procedure

    Appendix Firmware Upgrade Procedure The following items are required to update firmware: • Gefen 4x1 DPKVM Switcher • Computer running Windows XP • Terminal-emulation program (e.g. HyperTerminal) • RS-232 cable (do not use a null-modem cable) • Firmware files (downloaded from Gefen Web site) To begin the update procedure use the #activebolo command. The following set of instructions will be using Hyperterminal. Power-on the switcher. Connect an RS-232 cable to the PC and open the terminal program. See RS-232 Settings for configuration information. Type the command #activebolo and press the ENTER key. Type and enter the #activebolo command a second time. The following will be displayed on the terminal screen: ============================== Download new program_____1 Cancel___________________0 ============================== Press the ‘1’ on the computer keyboard to select Download new program. The following will be displayed: Waiting for the file to be sent ... (press ‘a’ to abort) In Hyperterminal, click Transfer -->...

  • Page 45: Mounting Plate Installation

    Appendix Mounting Plate Installation Rack mount ears are provided for installation of this unit into a 1U rack mount space. Locate the side screws on the unit. Remove the front 2 screws that are located closest to the front of the unit. Using the removed screws, screw the rack mounting bracket into the unit. Repeat the procedure on the opposite side of the unit. Front of unit Rear of unit page | 35...

  • Page 46: Specifications

    Appendix Specifications Supported Formats Resolution (max.) • 2560 x 1600 Electrical Maximum Pixel Clock • 360 MHz Input indicators • 4 x LED, blue Power Indicator • 1 x LED, red Connectors Video Inputs • 4 x DisplayPort, female Video Output • 1 x DisplayPort, female Audio Inputs • 4 x 3.5mm mini-stereo Audio Output • 1 x 3.5 mini-stereo • 4 x Type B, female • 1 x Type A, female RS-232 • 1 x DB-9, male Ethernet • 1 x RJ-45 (100BaseT) IR Extender •...
  • Page 48 Stretch it, Switch it, Split it, Control it. Gefen’s got it. ® 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefen.com support@gefen.com This product uses UL or CE listed power supplies.
