- Page 1 Component Video with Digital Audio to HDMI Converter CPNTA2HDMI...
- Page 2 Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Instruction Manual Instruction Manual Table of Contents Introduction ................... 1 Features ..................1 Package contents ................1 System Requirements ..............1 Operating Controls and Functions ..........2 Front Panel ..................2 Rear Panel ...................2 Connection and Installation ............3 Specifications ................4... -
Page 4: Introduction
Instruction Manual Introduction Convert analog component video (YPbPr and YCbCr) and audio (digital or analog) to HDMI! Supporting resolutions of up to 1080p, and 5.1 channel audio, the Converge AV Component with Audio to HDMI Format Converter is extremely simple to install and configure to get the input signal you want from your source equipment. -
Page 5: Operating Controls And Functions
Instruction Manual Operating Controls and Functions Front Panel Rear Panel HDMI output connector : Connect to the HDMI input of your display TV using HDMI cable DC power supply 5V(1A) Power LED light Toslink Digital Audio Input: Connects to the Toslink output of your DVD or Set-Top-Box Analog YPbPr/YCbCr Input Connector: Connects to the YPbPr or... -
Page 6: Connection And Installation
Instruction Manual Connection and Installation CPNTA2HDMI HDMI Cable HDMI Capable Display 3 RCA to 3 RCA cable Video Source (PbPr Component OUT) -
Page 7: Specifications
Instruction Manual Specifications HD Input Analog YCbCr/YPbPr through 3 RCA Connectors 1 Vp-p 75 W, Cb/Cr or Pb/ Input Signal Pr:0.7Vp-p, 75 W Audio Input Digital Toslink Input/Output Resolutions HD: 480i, 480p, 720p, 1080i, 1080p@60Hz, 576i, 576p, 720p, 1080i, 1080p@50Hz 1080p @30Hz 1080p @25Hz 1080p @24Hz... -
Page 8: Warranty Information
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 9 Visit www.startech.com today for complete information about all our products and to access exclusive interactive tools such as the Cable Finder, Parts Finder and the KVM Reference Guide. StarTech.com makes it easy to complete almost any IT or A/V solution. Find out for yourself why our...
