Note: If the cooktop is installed into a 36"
Step
base cabinet, the pressure regulator MUST BE
installed to the bottom of the cooktop before
the cooktop is placed into the cabinet.
Install
• Remove packaging from the cooktop.
Cooktop
• To insure a good fit, position the cooktop
• Carefully, lift and remove the cooktop.
3/8"
• Cut a 3/16" gasket strip in half. Peel off the
• Apply the other gasket strip to the underside
• Remove remaining adhesive backing.
• Position the cooktop over the opening,
• Lower the cooktop into the cutout, pressing
6
over the cutout opening and carefully lower
into place. Check edges all the way around
to be sure all cutout edges are concealed
and there are no gaps.
1/16"
backing and apply to the underside of the
glass cooktop edge.
– on each side at least 3/8" from the back
and as close to the edge as possible without
protruding.
of the glass at the front of the cooktop.
making sure that the power cord is dropped
into the cabinet.
gently and evenly to seat.

Installation

G a s Updraf t Cooktop
Countertop
Note: If the cooktop is installed in a 36" base
cabinet, the mounting brackets cannot be
used because of interference with the cabinet
sides. In this case, the cooktop can be secured
to the cabinet with angle brackets (not
supplied).
–Remove one screw at the bottom of the
cooktop body on both sides and secure the
bracket with those screws. Then, secure the
brackets to the cabinet sides.
• Insert hold-down bracket into highest slots
on the right and left sides of the cooktop:
–Cooktop has three slots, the highest
available will depend on the thickness of
the countertop.
• Secure the brackets to the underside of the
countertop with screws provided.
Gasket
