Install Pressure Regulator; Connect Electrical; Assemble Burners, Check Ignition - GE Monogram ZGU3650 Installation Instructions Manual

2
• Install the supplied pressure regulator and
Step
Install
Pressure
• Install a manual shut-off valve in the gas line
Regulator
Note: Instead of using solid piping to connect
to pressure regulator, an approved flexible
metal appliance connector may be used
between the pipe stub and the shut-off valve
and the pressure regulator, if local codes
permit.
– Appropriate flare nuts and adapters are
• Turn on the gas. Check for leaks using a
3
• Plug power cord into properly grounded
Step
Connect
electrical
4
• Assemble burner as shown. Check to be sure
Step
Assemble
burners,
check ignition
Make sure slot in burner head
is positioned over electrode
nipple in the gas line as close to the cooktop
inlet as possible. Allowances for ventilation
ducting may be necessary.
–Make sure the regulator is installed in the
right direction.
in an easily accessible location.
required at each end of the flexible
connector.
liquid leak detector at all joints in the system
(the pressure test nipple is adjacent to the
gas inlet pipe on the rear right hand side of
the cooktop bottom.
CAUTION Do not use a flame to check for
gas leaks.
CAUTION PRUDENCE
IL NE FAUT PAS UTILISER
DE FLAMME POUR VÉRIFIER S'IL Y A
DES FUITES.
receptacle.
that burner heads are securely seated and
caps are positioned as shown.
Installation
Gas Updraft Cooktop
IMPORTANT: Disconnect the cooktop and
the individual shut-off valve from the gas
supply piping system during any pressure
testing of that system at test pressures greater
than 1/2 psig. Isolate the cooktop from the
gas supply piping system by closing the
individual manual shut-off valve to the
cooktop during any pressure testing of the gas
supply piping system at test pressures equal to
or less than 1/2 psig.
Medium Head
And Cap
Burner Grate
Medium Head
And Cap
• Check for proper ignition:
Burner Cap
–Push in one control knob and turn 90 to
HIGH position.
Burner Head
–The igniter will spark and the burner will
light; the igniter will cease sparking when
Burner Bowl
the burner is lit.
–First test may require some time, while air is
flushed out of the gas line.
Electrode
–Turn knob to OFF.
–Repeat the procedure for each burner.
Regulator
Solid Piping
or Flexible
Connector
Shut-Off
Valve
Pipe Stub
Medium Head
And Cap
Small Head
And Cap
Large Head
And Cap
Front
7
