Summary of Contents for Fujitsu Siemens Computers D1931
- Page 1 answers Technisches Handbuch / Technical Manual Mainboard D1931 Deutsch / English...
- Page 2 Are there ..any technical problems or other questions you need clarified? Please contact: ● your sales partner ● your sales outlet The latest information and updates (e.g. BIOS update) on our mainboards can be found on the Internet under: http://www.fujitsu-siemens.com/mainboards...
- Page 4 Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Fujitsu Siemens Computers GmbH Bestell-Nr./Order No.: A26361-D1931-Z120-1-7419 Ausgabe/Edition 1 Printed in the Federal Republic of Germany...
- Page 5 Deutsch English Mainboard D1931 Technisches Handbuch Technical Manual Ausgabe Mai 2004 May 2004 edition...
- Page 6 Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt. Copyright Fujitsu Siemens Computers GmbH 2004 Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
-
Page 7: Übersicht/Overview Mainboard D1931
Übersicht/Overview Mainboard D1931 Diskettenlaufwerk / Floppy disk drive Interne Anschlüsse und Steckplätze / Stromversorgungsüberwachung / Internal connectors and slots Power supply control Bedienfeld / Front panel Stromversorgung / Power supply IDE-Laufwerke 1/2 / IDE-drives 1/2 Serial ATA3 Serial ATA4 Serial ATA2 Serial ATA1 10 = LCD-Anzeige / LCD Display... -
Page 9: Table Of Contents
Contents Übersicht/Overview Mainboard D1931 Mainboard D1931..........................1 Notational conventions.......................1 Important notes ..........................2 Information about boards ......................2 List of features...........................3 Special features.........................5 Brief instructions on installing mainboard...................7 Prior to installation ........................7 Interfaces and connectors ......................9 External ports ............................9 LAN connector...........................9 Graphics port ...........................10 Internal ports and connectors ......................10 Hard disk connection .......................10 Audio front panel........................11... -
Page 11: Mainboard D1931
Mainboard D1931 Your mainboard is available in different configuration levels. Depending on the configuration chosen, some of the hardware components described may not be available on your mainboard. Additional information Information on the BIOS Setup and additional descriptions of the drivers are contained: ●... -
Page 12: Important Notes
Important notes Important notes With the mainboard installed you must open the system to access the mainboard. How to dismantle and reassemble the system is described in the operating manual accompanying the system. Connecting cables for peripherals must be adequately shielded to avoid interference. Observe the safety notes in the operating manual of your system. -
Page 13: List Of Features
(FAN3) Temperature monitoring CPU/ONB1/ONB2/OFFB ! / - / - / - SmartCard Reader Support (USB / serial) ! / - Fujitsu Siemens Computers Keyboard Power Button Support Special onboard features Silent Fan / Silent Fan LT - / ! System Guard / Silent Drives... - Page 14 List of features Internal ports (continued) D1931-A Front panel Audio (9-pin for headphone, microphone) 1 / - AC'97 / High Definition Audio (Azalia) FireWire * (9-Pin, Intel standard header) USB Ports* (2.0, ~480 MB/s) Serial Ports* (FIFO, 16550 compatible) Fan Connectors PSU** / CPU (FAN1) / AUX1 (FAN2) / - / 1 / 1 / - AUX2 (FAN3) SMBus Connector* (Case Temperature)
-
Page 15: Special Features
USB Security is a BIOS function that offers protection against unauthorised access regardless of the operating system used. If USB Security is activated, the system can only be started, if the MemoryBird of Fujitsu Siemens Computers is connected to one of the existing USB-ports. - Page 16 PC switches into the Standby mode. In case of an unexpected power failure, the content of the main memory is loaded during booting from the hard disk. Additional information is available on the Internet at www.fujitsu- siemens.com/manageability. 6 - English...
-
Page 17: Brief Instructions On Installing Mainboard
Brief instructions on installing mainboard If you have purchased a separate mainboard, you can install the mainboard in your system in accordance with the following brief instructions. The activities described here assume a basic knowledge of PCs and cannot be carried out by a layperson. -
Page 18: Driver Installation
Brief instructions on installing mainboard ► Should no suitable connection field be provided in the case, then you must install the connection field (1) provided. Ensure the plate is aligned properly so that the connections are suitable for the mainboard later. ►... -
Page 19: Interfaces And Connectors
Interfaces and connectors The positions of the interfaces and connectors are shown on page "Cover". The components and connectors marked are not necessarily present on the mainboard. External ports The positions of the external ports are shown on page "Cover". PS/2 keyboard port, purple Audio input (Line in), light blue Serial interface, turquoise... -
Page 20: Graphics Port
Internal ports and connectors Graphics port Technical data Function: 2D/3D graphics controller, Dynamic Video memory Technology, 400 Mhz integrated 24-bit RAMDAC Features: Display Data Channel (DDC), 2 DVO channels (up to 165 megapixels per channel), dual-view support for ADD2 boards Screen resolution Depending on the operating system used, the screen resolutions in the following table refer to the mainboard screen controller. -
Page 21: Audio Front Panel
Internal ports and connectors Audio front panel If you want to use the internal connection for the audio front panel for the front side of the system, then proceed as follows: ► Remove all plug-in jumpers from the audio front panel connection. ►... -
Page 22: Pin Assignment Of Internal Ports
Pin assignment of internal ports Pin assignment of internal ports The pin assignment of some internal connections is shown in English in the following. Some of the following connectors may be optional! Front panel Power On/Off Message LED Power On LED 2) HD-LED Watch the poling of the LEDs. -
Page 23: Serial Ata
Pin assignment of internal ports Signal Signal Speaker - "Stand by" LED + "Power On" LED + Speaker + "Power On" LED + Reserved "Power On" LED - Reserved "Stand by" LED - (GND) "Message" LED + "Message" LED - Password Skip "SCSI"... - Page 24 Pin assignment of internal ports ATA interface Signal Signal Reset drive (low asserted) Data 7 (high asserted) Data 8 (high asserted) Data 6 (high asserted) Data 9 (high asserted) Data 5 (high asserted) Data 10 (high asserted) Data 4 (high asserted) Data 11 (high asserted) Data 3 (high asserted) Data 12 (high asserted)
-
Page 25: Audio Input
Pin assignment of internal ports Audio Input Signal Left audio input Audio GND Audio GND Right audio input Power control (system monitoring) Signal Power Guard Control PS FAN Control PS FAN Sense Audio port front Signal Signal Micro input Analogue GND Micro bias Analogue VCC Right line output... - Page 26 Pin assignment of internal ports USB - dual channel (Chipcard reader ready) Signal Signal Chipcard reader on or not connected VCC 1 or 3 VCC 2 or 4 Data negative 1 or 3 Data negative 2 or 4 Data positive 1 or 3 Data positive 2 or 4 not connected Fan 1, 2 and 3...
- Page 27 Pin assignment of internal ports Power supply BTX (ATX compatible) Signal Signal +3,3 V (P3V3P) +3,3 V (P3V3P) +3,3 V (P3V3P) -12 V (P12VN) +5V (VCC) PS on (low asserted) +5V (VCC) Powergood (high asserted) -5 V (P5VN) +5 V Auxiliary (VCC Aux) +5 V (VCC) +12 V (P12VP) +5 V (VCC)
-
Page 28: Jumper Settings
Pin assignment of internal ports Jumper settings Your mainboard is equipped with jumpers. The positions of the jumpers are shown on page "Cover". Setting via control-panel plug connector Pin pair A inserted = Skipping system and BIOS Setup password Pin pair B inserted = System BIOS recovery Pin pair C inserted = factory setting... -
Page 29: Add-On Modules / Upgrading
Celeron with 800 MHz Front Side Bus in the LGA775 design ● A current list of the processors supported by this mainboard is available on the Internet at: www.fujitsu-siemens.com/mainboards . Installing processor with heat sink Never touch the underside of the processor. Even minor soiling such as grease from the skin can impair the processor's operation or destroy the processor. - Page 30 Replacing processor ► Remove the old processor (2) from the socket. ► Insert the new processor in the socket so that the marking of the processor is aligned with the marking on the socket (a). ► Fold down the frame (1). ►...
- Page 31 Replacing processor Mounting heat sink Be sure to use heat conducting material between the processor and the heat sink. If a heat conducting pad (rubber-like foil) is already applied to the heat sink, then use it. Otherwise you must apply a very thin layer of heat conducting paste. Heat conducting pads can only be used once.
-
Page 32: Upgrading Main Memory
128, 256, 512 or 1024 Mbyte for one socket ● A current list of the memory modules recommended for this mainboard is available on the Internet at: www.fujitsu-siemens.com/mainboards. At least one memory module must be installed. Memory modules with different memory capacities can be combined. - Page 33 Upgrading main memory Installing a memory module ► Push the holders on each side of the memory slot outwards. ► Insert the memory module into the location (1). ► At the same time flip the lateral holders upwards until the memory module snaps in place (2). Removing a memory module ►...
-
Page 34: Adding Pci Express Cards
Adding PCI Express cards Adding PCI Express cards The PCI Express x16 slot is intended for graphics cards, and the PCI Express x1 slot for PCI Express x1 cards. Adding PCI cards Technical data: 32 bit / 33 MHz PCI slots 5 V and 3.3 V supply voltage 3.3 V auxiliary voltage PCI bus interrupts - Selecting correct PCI slot... - Page 35 Adding PCI cards Multifunctional expansion cards or expansion cards with integrated PCI-PCI bridge: These expansion cards require up to four PCI interrupts: INT A, INT B, INT C, INT D. How many and which of these interrupts are used is specified in the documentation provided with the card. The assignment of the PCI interrupts to the IRQ Lines is shown in the following table: Controller or slot INT Mechanical slot...
-
Page 36: Replacing The Lithium Battery
Adding PCI cards Replacing the lithium battery In order to permanently save the system information, a lithium battery is installed to provide the CMOS-memory with a current. A corresponding error message notifies the user when the charge is too low or the battery is empty. The lithium battery must then be replaced. Incorrect replacement of the lithium battery may lead to a risk of explosion! The lithium battery may be replaced only with an identical battery or with a type recommended by the manufacturer. -
Page 37: Bios Update
BIOS update BIOS update When should a BIOS update be carried out? Fujitsu Siemens Computers makes new BIOS versions available to ensure compatibility to new operating systems, new software or new hardware. In addition, new BIOS functions can also be integrated. -
Page 38: Bios Recovery - Recovering System Bios
BIOS Recovery - Recovering System BIOS BIOS Recovery - Recovering System BIOS All BIOS settings are reset to the default values. ► Open the casing as described in the operating manual. ► Set the switch for "Restore system BIOS" to ON . ►... -
Page 39: Microcode Update
Safety for processor on Fujitsu Siemens Computers mainboards If the processor uses an old or incorrect microcode, error-free operation cannot be ensured. Fujitsu Siemens Computers has therefore implemented a function on its mainboards that interrupts the booting process if no suitable microcode is available for the installed processor. -
Page 40: Drivers
Drivers Drivers Only when no drivers are installed on your system, or you want to update these, proceed as follows: ► Insert the CD "Drivers & Utilities Collection" into the CD-ROM drive. ► If the CD does not start automatically, run the START.EXE programme in the main directory of the CD. -
Page 41: Annex
25 W of power. For high-end graphics cards that require a power supply of up to 75 W, a BTX power supply unit is required. If you do not have a PC from Fujitsu Siemens Computer, make sure that the power supply unit provides the required amperages. -
Page 42: Apm And Acpi System Status, Energy-Saving Modes
APM and ACPI system status, energy-saving modes The specifications apply to the onboard components and represent the least favourable case. In addition, at least 350 mA is required for PCI on 3.3 V, and 500 mA per connected device for USB on 5 V. -
Page 43: Mainboard Revision And Bios Version
The compatibility, e.g. with new processors, can be independent of the BIOS version or the revision status of the mainboard used. The CPU and BIOS compatibility lists are available on the Internet at www.fujitsu-siemens.de/mainboards . Mainboard Revision The revision status of the mainboard exactly identifies which mainboard you have. It is indicated on... -
Page 44: Error Messages
Available CPUs do not support the same bus frequency - System halted! Memory type mixing detected Non Fujitsu Siemens Memory Module detected - Warranty void There are more than 32 32 RDRAM devices in the system Check whether the system configuration has changed. If necessary, correct the settings. - Page 45 Error messages DMA test failed EISA CMOS not writable Extended RAM Failed at offset: nnnn Extended RAM Failed at address line: nnnn Failing Bits: nnnn Fail-Safe Timer NMI failed Multiple-bit ECC error occurred Memory decreased in size Memory size found by POST differed from EISA CMOS Single-bit ECC error occurred Software NMI failed System memory exceeds the CPU’s caching limit...
- Page 46 Error messages Missing or invalid NVRAM token Switch the device off and on again. If the message is still displayed, please contact your sales outlet or customer service centre. Monitor type does not match CMOS - RUN SETUP Correct the entry for the monitor type in the Main menu of the BIOS Setup . On Board PCI VGA not configured for Bus Master In the BIOS Setup , in the Advanced menu, submenu PCI Configuration , set the Shared PCI Master Assignment entry to VGA .
- Page 47 Error messages System battery is dead - Replace and run SETUP Replace the lithium battery on the mainboard and redo the settings in the BIOS Setup . System Cache Error - Cache disabled Switch the device off and on again. If the message is still displayed, please contact your sales outlet or customer service centre.
-
Page 48: Glossary
Glossary The technical terms and abbreviations given below represent only a selection of the full list of common technical terms and abbreviations. Not all technical terms and abbreviations listed here are valid for the described mainboard. IAPC Instantly Available Power Managed Desktop PC Design AC'97 Audio Codec '97... - Page 49 Glossary D ata) SMBus System Management Bus SVGA Super Video Graphic Adapter TEMP Temperature Video Graphic Adapter Universal Serial Bus Video Graphic Adapter Wake On LAN English - 39 A26361-D1931-Z120-1-7419, Edition 1...
