Quick Reference

Learning about the printer

Using the printer control panel

1
2
9
8
7
6
Use the
To
1
Menus button Open the menus.
Notes:
The menus are available only when the
printer is in the Ready state.
Pressing the button while navigating
within the menus returns the printer
control panel to the top‑level menu
screen.
2
Display
View printing options as well as status and error
messages.
Use the
3
Sleep button
4
Stop button
3
5
Right arrow
button
6
Select button
4
7
Left arrow
5
button
8
Back button
9
Indicator light Determine the status of the printer.
Understanding the colors of the indicator
and Sleep button lights
The colors of the indicator and Sleep button lights on the printer control
panel signify a certain printer status or condition.
To
Enable Sleep mode or Hibernate mode.
Notes:
Pressing any hard button will cause the
printer to wake from Sleep mode.
Pressing the Sleep button or the power
switch will cause the printer to wake
from Hibernate mode.
Exit the menus and return to the Ready
state.
Stop printer activities, such as printing or
downloading fonts.
Scroll through menus or to move between
screens and menu options.
Scroll through settings or text. For menus
with numeric values, press and hold an
arrow button to scroll through the settings.
Release the button when the value you
want appears.
Open a menu.
Display available values or settings for a
menu. The current default setting is
indicated by an asterisk (*).
Save the displayed value as the new user
default setting.
Scroll through menus or to move between
screens and menu options.
Scroll through settings or text. For menus
with numeric values, press and hold an
arrow button to scroll through the settings.
Release the button when the value you
want appears.
Return to the previous screen.
1
Indicator light color and its corresponding printer status
Indicator light
Printer status
Off
The printer is off or in Hibernate mode.
Blinking green
The printer is warming up, processing data,
or printing.
Solid green
The printer is on, but idle.
Blinking red
The printer requires user intervention.
Sleep button light color and its corresponding printer status
Sleep button light
Printer status
Off
The printer is off, idle or in Ready state.
Solid amber
The printer is in Sleep mode.
Blinking amber
The printer is entering or waking from
Hibernate mode.
Blinking amber for 0.1
The printer is in Hibernate mode.
second, then goes
completely off for 1.9
seconds in a slow, pulsing
pattern
Loading paper and specialty
media
Setting the paper size and type
1
From the printer control panel, navigate to:
> Paper Menu >
> Paper Size/Type >
2
Select Tray [x] Size or Tray [x] Type, and then press
3
Change the paper size or type setting, and then press
Notes:
The paper size setting for the standard 250‑sheet tray (Tray 1),
optional 250‑ or 550‑sheet tray (Tray 2), and the multipurpose
feeder must be set manually in the Paper Size menu.
.
.
