PC Card/audio board assembly

Description
For use with HP Compaq 6715b and 6710b computer models
For use with HP Compaq 6715s and 6710s computer models
Before removing the PC Card/audio board assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the following components:
a. Hard drive (see
b. Memory/WLAN module compartment cover (see
c. Optical drive (see
d. Keyboard (see
e. Switch cover (see
f. Fan (see
g. Heat sink (see
h. Display assembly (see
i. Top cover (see
j. System board (see
WWAN module on page
Processor on page 74)
Modem module on page
SIM slot board on page
Battery on page
Hard drive on page
Optical drive on page
Keyboard on page
Switch cover on page
Fan on page 71)
Heat sink on page
Display assembly on page
Top cover on page
System board on page
68)
PC Card/audio board assembly on page
92)
94)
48).
52)
Expansion memory module on page
62)
64)
70)
72)
76)
81)
88)
Component replacement procedures
91)
Spare part number
443889-001
443888-001
56)
91
