HP Compaq 6715b and 6715s
Notebook PC, HP Compaq 6710b and
6710s Notebook PC
Maintenance and Service Guide

Advertising

   Related Manuals for HP Compaq 6715b

   Summary of Contents for HP Compaq 6715b

  • Page 1

    HP Compaq 6715b and 6715s Notebook PC, HP Compaq 6710b and 6710s Notebook PC Maintenance and Service Guide...

  • Page 2

    SD Logo is a trademark of its proprietor. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.

  • Page 3

    Safety warning notice WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow.

  • Page 4

    Safety warning notice...

  • Page 5: Table Of Contents

    Table of contents 1 Product description ......................1 2 External component identification ................... 13 Top components ........................13 Buttons, switches, and fingerprint reader ..............13 Keys ........................15 Lights ........................16 TouchPad ....................... 17 Front components ........................18 Left-side components ....................... 19 Rear components ........................

  • Page 6: Table Of Contents

    Electrostatic discharge damage ..............47 Packaging and transporting guidelines ........48 Workstation guidelines .............. 48 Equipment guidelines ..............49 Unknown user password ..................50 Component replacement procedures ..................51 Serial number ......................51 Battery ........................52 SIM ........................53 Display inverter ....................... 54 Hard drive ......................

  • Page 7: Table Of Contents

    Diagnostics menu ....................104 System Configuration menu ..................105 6 Specifications ....................... 108 Computer specifications ......................108 15.4-inch, WSXGA display specifications ................109 15.4-inch, WXGA display specifications ................. 110 Hard drive specifications ...................... 111 Primary 6-cell, Li-ion battery specifications ................112 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive specifications ......

  • Page 8: Table Of Contents

    Backing up specific files or folders ............142 Backing up the entire hard drive .............. 142 Creating recovery points ................. 143 Scheduling backups ................143 Performing a recovery .................... 143 Performing a recovery from the recovery discs ........... 144 Performing a recovery from the hard drive ..........144 Initiating a recovery in Windows ..........

  • Page 9

    Index ..........................164...

  • Page 11: Product Description

    Product description Category Description HP Compaq HP Compaq HP Compaq 6715s 6715b 6715b Notebook PC Notebook PC Notebook PC without with WWAN WWAN √ √ √ Processors AMD Turion™ 64 Mobile Technology processors: ● TL-64 (dual-core) 2.2-GHz processor with 1 MB of L2 cache ●...

  • Page 12

    Category Description HP Compaq HP Compaq HP Compaq 6715s 6715b 6715b Notebook PC Notebook PC Notebook PC without with WWAN WWAN ● √ Panels 15.4-inch, WSXGA+ with WWAN and WLAN antenna transceivers and cables ● √ 15.4-inch, WXGA with WWAN and...

  • Page 13

    Category Description HP Compaq HP Compaq HP Compaq 6715s 6715b 6715b Notebook PC Notebook PC Notebook PC without with WWAN WWAN ● √ √ √ Hard drives Supports all 9.5-mm, 2.5-inch hard drives ● Serial ATA The following hard drives are available: ●...

  • Page 14

    Category Description HP Compaq HP Compaq HP Compaq 6715s 6715b 6715b Notebook PC Notebook PC Notebook PC without with WWAN WWAN ● √ √ √ S4/S5 wake on LAN (on AC power only) ● √ √ √ Network interface card (NIC) power...

  • Page 15

    Category Description HP Compaq HP Compaq HP Compaq 6715s 6715b 6715b Notebook PC Notebook PC Notebook PC without with WWAN WWAN ● √ √ √ RJ-45 Ethernet port ● √ √ S-Video-out connector ● √ √ √ Smart AC adapter connector ●...

  • Page 16

    HP Compaq 6715s 6715b 6715b Notebook PC Notebook PC Notebook PC without with WWAN WWAN ● √ √ HP 3D DriveGuard ● √ HP DriveGuard ● √ √ √ Security cable slot ● √ √ √ Smart card reader/bezel snap-in ●...

  • Page 17

    Category Description HP Compaq HP Compaq HP Compaq 6710s 6710b 6710b Notebook PC Notebook PC Notebook PC without with WWAN WWAN √ √ √ Processors Intel® Core™ Duo processors: ● T7700 2.4-GHz processor with 800- MHz Front Side Bus (FSB) and 4 MB of L2 cache ●...

  • Page 18

    Category Description HP Compaq HP Compaq HP Compaq 6710s 6710b 6710b Notebook PC Notebook PC Notebook PC without with WWAN WWAN ● √ √ √ Memory Two SODIMM slots, both customer accessible/upgradable (memory slot under the keyboard must be populated first) ●...

  • Page 19

    Category Description HP Compaq HP Compaq HP Compaq 6710s 6710b 6710b Notebook PC Notebook PC Notebook PC without with WWAN WWAN ● √ √ √ Optical drives 12.7-mm tray load ● Fixed, no modular requirements (1- screw removal) Supports all common optical formats including the following: ●...

  • Page 20

    Category Description HP Compaq HP Compaq HP Compaq 6710s 6710b 6710b Notebook PC Notebook PC Notebook PC without with WWAN WWAN ● √ √ √ Broadcom 802.11a/b/g ● √ √ √ Broadcom 802.11b/g ● √ √ Option for no WLAN...

  • Page 21

    Localized cable plug support ● 3-wire plug with ground pin ● Supports multipin AC connector ● √ √ Security Fingerprint reader ● √ √ HP 3D DriveGuard ● √ HP DriveGuard ● √ √ √ Security cable slot ● √ √ √...

  • Page 22

    Category Description HP Compaq HP Compaq HP Compaq 6710s 6710b 6710b Notebook PC Notebook PC Notebook PC without with WWAN WWAN Operating Preinstalled: system ● √ √ √ Windows Vista Home Basic ● √ √ √ Windows Vista Business 32/64 ●...

  • Page 23: External Component Identification, Top Components, Buttons, Switches, And Fingerprint Reader

    External component identification Top components Buttons, switches, and fingerprint reader Top components...

  • Page 24

    Item Component Function ● Power button When the computer is off, press the button to turn on the computer. ● When the computer is on, press the button to shut down the computer. ● When the computer is in the Sleep state (Windows Vista) or in Standby (Windows XP), press the button briefly to exit Sleep or Standby.

  • Page 25: Keys

    Keys Item Component Function Displays system information when pressed in combination with key. Executes frequently used system functions when pressed in combination with a function key or the key. Windows logo key Displays the Windows Start menu. Windows applications key Displays a shortcut menu for items beneath the pointer.

  • Page 26: Lights

    Lights Item Component Function ● Power lights (2) On: The computer is on. ● Blinking: The computer is in the Sleep state (Windows Vista) or in Standby (Windows XP). ● Blinking rapidly: An AC adapter with a higher power rating must be connected. ●...

  • Page 27: Touchpad

    ● Drive light Blinking green: The hard drive or optical drive is being accessed. ● Amber: HP 3D DriveGuard has temporarily parked the internal hard drive. TouchPad Item Component Function TouchPad* Moves the pointer and selects or activates items on the screen.

  • Page 28: Front Components

    ● Drive light Blinking green: The hard drive or optical drive is being accessed. ● Amber (select models only): HP 3D DriveGuard has temporarily parked the hard drive. Speakers Produce sound. Display release latch Opens the computer.

  • Page 29: Left-side Components

    Left-side components Item Component Function PC Card slot Supports optional Type I or Type II 32–bit (CardBus) or 16–bit PC Cards. PC Card eject button Ejects a PC Card from the PC Card slot. Power connector Connects an AC adapter. Vent Enables airflow to cool internal components.

  • Page 30: Rear Components

    Rear components Item Component Function Security cable slot Attaches an optional security cable to the computer. NOTE: The security cable is designed to act as a deterrent, but it may not prevent the computer from being mishandled or stolen. RJ-45 (network) jack Connects a network cable.

  • Page 31: Right-side Components

    Right-side components Item Component Function Media Card Reader (select models only) Supports the following optional digital card formats: ● Secure Digital (SD) Memory Card ● MultiMediaCard (MMC) ● Memory Stick (MS) ● Memory Stick Pro (MSP) ● Memory Stick Duo Adapter ●...

  • Page 32: Bottom Components

    Bottom components Item Component Function Battery bay Holds the battery. Battery release latches (2) Release the battery from the battery bay. Accessory battery connector Connects an optional accessory battery. Vents (3) Enable airflow to cool internal components. NOTE: The computer fan starts up automatically to cool internal components and prevent overheating.

  • Page 33: Illustrated Parts Catalog, Serial Number Location

    Illustrated parts catalog Serial number location When ordering parts or requesting information, provide the computer serial number and model number located on the bottom of the computer. Serial number location...

  • Page 34: Computer Major Components

    Computer major components Chapter 3 Illustrated parts catalog...

  • Page 35

    15.4-inch, WSXGA+ display assembly for use with HP Compaq 6715b and 6710b 443814-001 computer models with WWAN capability 15.4-inch, WXGA display assembly for use with HP Compaq 6715b and 6710b computer 443817-001 models with WWAN capability 15.4-inch, WXGA, BrightView display assembly for use with HP Compaq 6715b and...

  • Page 36

    Item Description Spare part number For use with HP Compaq 6715b and 6710b computer models (includes LED board and 443911-001 cable) For use with HP Compaq 6715s and 6710s computer models (does not include LED board 443910-001 and cable) Keyboards...

  • Page 37

    Computer feet (4 large rubber feet, 4 small rubber feet, not illustrated) (10) Processors (include thermal material) Processors for use with HP Compaq 6715 computer models in all countries and regions except Japan and Asia/ Pacific: AMD Turion TL-64 (2.2-GHz, 1-MB L2 cache) 443913-001 AMD Turion MK-38 (2.2-GHz, 512-KB L2 cache)

  • Page 38

    430872-001 Mobile AMD Sempron 3400+ (1.8-GHz, 256-KB L2 cache) 430871-001 Processors for use with HP Compaq 6715 computer models in Japan and Asia/Pacific countries and regions AMD Turion TL-60 (2.0-GHz, 1-MB L2 cache) 443892-001 AMD Turion TL-56 (1.8-GHz, 1-MB L2 cache) 443891-001 AMD Turion TL-52 (1.6-GHz, 1-MB L2 cache)

  • Page 39

    For use with HP Compaq 6710b computer models without WWAN capability (does not 446904-001 include WWAN module slot) For use with HP Compaq 6710s computer models 446906-001 (15) SIM slot board––for use with HP Compaq 6715b and 6710b computer models with 443907-001 WWAN capability (16) Speaker assembly 443821-001...

  • Page 40

    Zimbabwe For use in Israel and Japan 441530-291 802.11a/b/g/n Intel WLAN module for use with HP Compaq 6710 computer models For use in Antigua and Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda, 441086-001 Brunei, Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican...

  • Page 41

    Yemen, Zaire, Zambia, and Zimbabwe For use in Israel and Japan 441075-291 802.11a/b/g Intel WLAN modules for use with HP Compaq 6710 computer models For use in Antigua and Barbuda, Argentina, Australia, the Bahamas, Barbados, Brunei, 407575-001 Canada, Chile, the Dominican Republic, Guam, Guatemala, Hong Kong, India, Indonesia,...

  • Page 42

    Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe For use in Japan 441060-291 802.11b/g WLAN module for use with HP Compaq 6710 computer models in Japan 409280-004 (24) Bluetooth modules (include Bluetooth module cable)

  • Page 43: Plastics Kit

    Item Description Spare part number DVD/CD-RW Combo Drive 443901-001 DVD-ROM drive 443902-001 Plastics Kit Item Description Spare part number Plastics Kit 443905-001 PC Card slot bezel Hard drive cover (includes 2 captive screws, secured by C-clips) Memory/WLAN module compartment cover (includes 1 captive screw, secured by a C-clip) Bluetooth module cover (includes 1 captive screw, secured by a C-clip) Computer feet (4 large and 4 small rubber feet) Plastics Kit...

  • Page 44: Cable Kit

    Cable Kit Item Description Spare part number Cable Kit 443887-001 Modem module cable (includes RJ-11 connector and cable) Microphone (includes receiver and cable) Bluetooth module cable Chapter 3 Illustrated parts catalog...

  • Page 45: Mass Storage Devices

    Mass storage devices Item Description Spare part number Hard drives (include frame and connector) 160-GB, 5400-rpm 443920-001 120-GB, 5400-rpm 443919-001 80-GB, 7200-rpm 445939-001 80-GB, 5400-rpm 443918-001 Optical drives (include bezel and optical drive bracket) DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 443903-001 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive 443904-001...

  • Page 46: Miscellaneous Parts

    Miscellaneous parts Description Spare part number AC adapters 90-watt AC adapter for use in North America 391173-001 90-watt AC adapter for use in Africa, Europe, and the Middle East 416421-021 Power cords: Australia 246959-011 Brazil 246959-201 Denmark 246959-081 Europe, the Middle East, and Africa 246959-021 Israel 246959-BB1...

  • Page 47: Sequential Part Number Listing

    EVDO WWAN module 407575-001 802.11a/b/g Intel WLAN module for use with HP Compaq 6710 computer models in Antigua and Barbuda, Argentina, Australia, the Bahamas, Barbados, Brunei, Canada, Chile, the Dominican Republic, Guam, Guatemala, Hong Kong, India, Indonesia, Malaysia, Mexico, New Zealand, Panama, Paraguay, Saudi...

  • Page 48

    Mobile AMD Sempron 3500+ 1.8-GHz processor for use with HP Compaq 6715 computer models in all countries and regions except Japan and Asia/Pacific (512-KB L2 cache) 430874-001 AMD Turion TL-52 1.6-GHz processor for use with HP Compaq 6715 computer models in all countries and regions except Japan and Asia/Pacific (1-MB L2 cache) 430875-001 AMD Turion TL-56 1.8-GHz processor for use with HP Compaq 6715 computer models in all countries and...

  • Page 49

    802.11a/b/g Broadcom WLAN module for use with all computer models only in Israel and Japan 441082-001 802.11a/b/g Intel WLAN module for use with HP Compaq 6710 computer models in Antigua & Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda, Brunei, Canada, the Cayman Islands, Chile, Colombia,...

  • Page 50

    802.11a/b/g/n Broadcom WLAN module for use with all computer models only in Israel and Japan 443808-001 Base enclosure for use with HP Compaq 6715b and 6710s computer models (includes 8 rubber feet) 443809-001 Base enclosure for use with HP Compaq 6715s and 6710s computer models (includes 8 rubber feet)

  • Page 51

    443812-001 15.4-inch WXGA, BrightView display assembly for use with HP Compaq 6715s and 6710s computer models 443813-001 15.4-inch WSXGA+ display assembly for use with HP Compaq 6715b and 6710b computer models without WWAN capability 443814-001 15.4-inch WSXGA+ display assembly for use with HP Compaq 6715b and 6710b computer models with...

  • Page 52

    LED board or LED board cable) 443911-001 Switch cover for use with HP Compaq 6715b and 6710b computer models (includes power button board and power button board cable and LED board and LED board cable)

  • Page 53

    Thermal Material Kit for use in Japan and Asia/Pacific countries and regions 445939-001 80-GB, 7200-rpm hard drive 446045-001 AMD Turion MK-38 2.2-GHz processor for use with HP Compaq 6715 computer models in all countries and regions except Japan and Asia/Pacific (512-KB L2 cache) 446870-001 Display inverter (includes 2-sided tape)

  • Page 54

    449137-001 RTC battery 449139-001 Modem module for use with HP Compaq 6710 computer models in Japan and Asia/Pacific countries and regions (includes modem module cable) 450066-001 Bluetooth module for use with all computer models in all countries and regions except Japan and Asia/Pacific...

  • Page 55: Removal And Replacement Procedures, Preliminary Replacement Requirements, Tools Required, Service Considerations, Plastic Parts

    Removal and replacement procedures Preliminary replacement requirements Tools required You will need the following tools to complete the removal and replacement procedures: ● Flat-bladed screwdriver ● Hex 5.0-mm nutdriver ● Magnetic screwdriver ● Phillips P0 and P1 screwdrivers ● Torx T8 screwdriver Service considerations The following sections include some of the considerations that you must keep in mind during disassembly and assembly procedures.

  • Page 56: Cables And Connectors, Drive Handling

    Cables and connectors CAUTION: When servicing the computer, be sure that cables are placed in their proper locations during the reassembly process. Improper cable placement can damage the computer. Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion.

  • Page 57: Grounding Guidelines, Electrostatic Discharge Damage

    Grounding guidelines Electrostatic discharge damage Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions.

  • Page 58: Packaging And Transporting Guidelines, Workstation Guidelines

    Packaging and transporting guidelines Follow these grounding guidelines when packaging and transporting equipment: ● To avoid hand contact, transport products in static-safe tubes, bags, or boxes. ● Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging. ● Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.

  • Page 59: Equipment Guidelines

    Equipment guidelines Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation. ● When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap snugly against the skin at all times.

  • Page 60: Unknown User Password

    Unknown user password If the computer you are servicing has an unknown user password, follow these steps to clear the password: NOTE: These steps also clear CMOS. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 61: Serial Number, Component Replacement Procedures

    Make special note of each screw and screw lock size and location during removal and replacement. Serial number Report the computer serial number to HP when requesting information or ordering spare parts. The serial number is located on the bottom of the computer. Component replacement procedures...

  • Page 62: Battery

    Battery Description Spare part number 6-cell, 2.55-Ah, 55-Wh, Li-ion battery 443885-001 6-cell, 2.20-Ah, 47-Wh, Li-ion battery 443884-001 Before disassembling the computer, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 63

    NOTE: This section applies only to computer models with WWAN capability. NOTE: If there is a SIM inserted in the SIM slot, remove it before disassembling the computer. Be sure the SIM is reinserted in the SIM slot after reassembling the computer. Before removing the SIM, follow these steps: Shut down the computer.

  • Page 64: Display Inverter

    Display inverter NOTE: If it has been determined that the display inverter is the component that must be replaced to complete the computer repair, the display assembly does not have to be removed. Follow the procedures in this section to replace the display inverter. For information on replacing the display assembly and display hinges, see Display assembly on page Description...

  • Page 65

    Release the bottom edge of the display bezel (3) from the display assembly. Release the inverter (1) from the display enclosure as far as the display panel cable and backlight cable allow. Disconnect the display panel cable (2) and the backlight cable (3) from the display inverter. Remove the display inverter.

  • Page 66: Hard Drive

    Hard drive Description Spare part number 160-GB, 5400-rpm hard drive 443920-001 120-GB, 5400-rpm hard drive 443919-001 80-GB, 7200-rpm hard drive 445939-001 80-GB, 5400-rpm hard drive 443918-001 Before disassembling the computer, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 67

    Grasp the Mylar tab (2) on the hard drive and slide the hard drive (3) to the right to disconnect it from the system board. Remove the hard drive (4) from the hard drive bay. If it is necessary to replace the hard drive bracket, remove the two Phillips PM3.0×3.0 hard drive bracket screws (1) from each side of the hard drive.

  • Page 68: Computer Feet, Bluetooth Module

    Computer feet The computer feet are adhesive-backed rubber pads. The feet are included in the Plastics Kit, spare part number 443905-001. There are 8 rubber feet in 2 different sizes. The feet attach to the base enclosure in the locations illustrated below. Bluetooth module Description Spare part number...

  • Page 69

    Lift the rear edge of the cover (2), swing it toward you, and remove the cover. NOTE: The Bluetooth module cover is included in the Plastics Kit, spare part number 443905-001. Remove the Bluetooth module (1) from the computer. Disconnect the Bluetooth module cable (2) from the module. Remove the Bluetooth module.

  • Page 70: Expansion Memory Module

    Expansion memory module Description Spare part number 2048-MB, PC2-5300, 1-DIMM, memory module 417506-001 1024-MB, PC2-5300, 1-DIMM, memory module 414046-001 512-MB, PC2-5300, 1-DIMM, memory module 414045-001 Before removing the expansion memory module, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 71

    Remove the memory module (2) by pulling the module away from the slot at an angle. NOTE: Memory modules are designed with a notch (3) to prevent incorrect installation into the memory module slot. Reverse this procedure to install the expansion memory module. Component replacement procedures...

  • Page 72: Wlan Module

    Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe For use in Israel and Japan 441530-291 802.11a/b/g/n Intel WLAN modules for use with HP Compaq 6710 computer models For use in Antigua and Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda, Brunei, 441086-001...

  • Page 73

    Zambia, and Zimbabwe For use in Israel and Japan 441075-291 802.11a/b/g Intel WLAN modules for use with HP Compaq 6710 computer models For use in Antigua & Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda, Brunei, 441082-001 Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador, El...

  • Page 74

    Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe For use in Japan 441060-291 802.11b/g Intel WLAN module for use with HP Compaq 6710 computer models in Thailand 409280-004 Before removing the WLAN module, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 75

    Remove the WLAN module: Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module. NOTE: The black WLAN antenna cable is connected to the WLAN module “Main” terminal. The white WLAN antenna cable is connected to the WLAN module “Aux” terminal. If the computer is equipped with an 802.11a/b/g/n WLAN module, the yellow WLAN antenna cable (2) is connected to the middle terminal on the WLAN module.

  • Page 76: Optical Drive

    Optical drive NOTE: All optical drive spare part kits include an optical drive bezel and optical drive bracket. Description Spare part number DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 443903-001 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive 443904-001 DVD/CD-RW Combo Drive 443901-001...

  • Page 77

    Remove the optical drive (3) from the computer. If it is necessary to replace the optical drive bracket, remove the two Phillips PM2.0×3.0 screws (1) that secure the bracket to the optical drive. Remove the optical drive bracket (2). Reverse this procedure to reassemble and install the optical drive. Component replacement procedures...

  • Page 78: Keyboard

    Keyboard For use in Spare part number For use in Spare part number Belgium 443811-181 Latin America 443811-161 Brazil 443811-201 Norway 443811-091 The Czech Republic 443811-221 Portugal 443811-131 Denmark 443811-081 Russia 443811-251 France 443811-051 Saudi Arabia 443811-171 French Canada 443811-121 Slovakia 443811-231 Germany...

  • Page 79

    Loosen the three Phillips PM2.5×8.0 screws that secure the keyboard to the computer. Turn the computer display-side up, with the front toward you. Open the computer as far as possible. Slide the four keyboard retention tabs (1) toward you. The tabs are located between the keys, between the keys, between the keys, and between the...

  • Page 80: Internal Memory Module

    Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached and disconnect the keyboard cable (2) from the system board. Remove the keyboard. Reverse this procedure to install the keyboard. Internal memory module Description Spare part number 2048-MB, PC2-5300, 1-DIMM, memory module 417506-001 1024-MB, PC2-5300, 1-DIMM, memory module...

  • Page 81: Rtc Battery

    Remove the internal memory module: Spread the retaining tabs (1) on each side of the memory module slot to release the memory module. (The edge of the module opposite the slot rises away from the computer.) Remove the memory module (2) by pulling the module away from the slot at an angle. NOTE: Memory modules are designed with a notch (3) to prevent incorrect installation into the memory module slot.

  • Page 82: Wwan Module

    Remove the RTC battery: ▲ Use a non-conductive, flat-bladed tool to pry the RTC battery out of the slot. Reverse this procedure to install the RTC battery. Be sure the RTC battery is installed with the “+” sign facing up. WWAN module CAUTION: The WWAN module and WLAN module are not interchangeable.

  • Page 83

    Remove the WWAN module: Disconnect the WWAN antenna cables (1) from the terminals on the WWAN module. NOTE: The red WWAN antenna cable is connected to the WWAN module “Main” terminal. The blue WWAN antenna cable is connected to the WWAN module “Aux” terminal. If the computer is equipped with an HSPDA WWAN module, the red WWAN antenna cable is connected to the only terminal on the module.

  • Page 84: Switch Cover

    Switch cover Description Spare part number Switch cover for use with HP Compaq 6715b and 6710b computer models (includes power button 443911-001 board and cable and LED board and cable) Switch cover for use with HP Compaq 6715s and 6710s computer models (includes power button...

  • Page 85

    NOTE: The illustration below shows the fan removal steps for the HP Compaq 6715 computer model. The fan cable on the HP Compaq 6710 computer model is in a different location, but the disconnection steps are the same. Loosen the Phillips PM2.5×8.0 captive screw (2) that secures the fan to the computer.

  • Page 86: Heat Sink

    NOTE: All heat sink spare part kits include thermal material. Description Spare part number For use with HP Compaq 6715 computer models 443912-001 For use with HP Compaq 6710 computer models 446920-001 Thermal Material Kit for use in all countries and regions except Japan and Asia/Pacific...

  • Page 87

    NOTE: Step 1 applies to HP Compaq 6715 computer models. The heat sink on HP Compaq 6710 computer models is secured to the computer by captive screws which must be loosened rather than removed. Remove the four Phillips PM2.0×6.0 screws (1) that secure the heat sink to the system board.

  • Page 88: Processor

    All processor spare part kits include thermal material. Description Spare part number Processors for use with HP Compaq 6715 computer models in all countries and regions except Japan and Asia/Pacific: AMD Turion TL-64, 2.2-GHz processor (1-MB L2 cache) 443913-001 AMD Turion MK-38, 2.2-GHz processor (512-KB L2 cache) 446045-001 AMD Turion TL-60, 2.0-GHz processor (1-MB L2 cache)

  • Page 89

    The illustration below shows the processor removal steps for the HP Compaq 6715 computer model. NOTE: The illustration below shows the processor removal steps for the HP Compaq 6710 computer model. Reverse this procedure to install the processor.

  • Page 90: Display Assembly

    15.4-inch, WSXGA+ display assembly for use with HP Compaq 6715b and 6710b computer 443814-001 models with WWAN capability 15.4-inch, WXGA display assembly for use with HP Compaq 6715b and 6710b computer models 443817-001 with WWAN capability 15.4-inch, WXGA, BrightView display assembly for use with HP Compaq 6715b and 6710b...

  • Page 91

    Remove the wireless antenna cables (2) from the routing channels and clips built into the top cover. Remove the two Torx T8M2.5×9.0 screws (1) that secure the display assembly to the computer. NOTE: The screw removed from the left hinge secures a ground loop (2) for the display panel cable.

  • Page 92

    Lift the display assembly straight up and remove it (2). CAUTION: When installing the display assembly, be sure that the 4 wireless antenna cables routed out of the display right hinge are routed and arranged properly. Each antenna cable has an exposed section of cable (1) and a metallic grounding sleeve (2).

  • Page 93

    If it is necessary to replace the display hinges, remove the following: (1) Four rubber screw covers from the display bezel top edge (2) Four Torx T8M2.5×6.0 screws from the display bezel top edge (3) Two rubber screw covers from the display bezel bottom edge (4) Two Torx T8M2.5×7.0 screws from the display bezel top edge Flex the inside edges of the left and right sides (1) and the top and bottom sides (2) of the display bezel until the bezel disengages from the display enclosure.

  • Page 94

    Remove the display panel (2). Remove the four Phillips PM2.0×3.0 screws (1) that secure each display hinge to the display panel. Remove the display hinges (2). NOTE: The left and right display hinges are available using spare part number 446882-001. Reverse this procedure to reassemble and install the display assembly.

  • Page 95: Top Cover

    Top cover Description Spare part number Top cover for use with HP Compaq 6715b and 6710b computer models (includes TouchPad and 443822-001 cable and fingerprint reader) Top cover for use with HP Compaq 6715s and 6710s computer models (includes TouchPad and...

  • Page 96

    Disconnect the TouchPad cable (1) from the system board. NOTE: Step 6 applies only to HP Compaq 6715b and 6710b computer models. Disconnect the fingerprint reader board cable (2) from the system board. Remove the microphone (3) from the clip built into the top cover and remove the microphone cable from the clips built into the top cover.

  • Page 97

    Remove the three Torx T8M2.5×9.0 screws that secure the top cover to the computer. Lift the rear edge of the top cover (1) until it disengages from the base enclosure. Swing the rear edge of the top cover (2) toward you until it rests at an angle. Lift the top cover (3) straight up and remove it.

  • Page 98

    If it is necessary to replace the Bluetooth module cable, disconnect the cable (2) from the system board and remove the cable from the opening (3) in the base enclosure. NOTE: The Bluetooth module cable is included with the Bluetooth module, spare part numbers 398393-002 (for use with all computer models in all countries and regions except Japan and Asia/Pacific) and 450066-001 (for use with all computer models in all countries and regions except Japan and Asia/Pacific), and is also available in the Cable Kit, spare part number...

  • Page 99: Speaker Assembly

    Speaker assembly Description Spare part number Speaker assembly 443821-001 Before removing the speaker assembly, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.

  • Page 100: Usb/media Card Reader Board

    Remove the speaker assembly (3). Reverse this procedure to install the speaker assembly. USB/Media Card Reader board NOTE: This section applies only to HP Compaq 6715b and 6710b computer models. Description Spare part number USB/Media Card Reader board (includes USB/Media Card Reader board cable)

  • Page 101

    Display assembly (see Display assembly on page Top cover (see Top cover on page Remove the USB/Media Card Reader board: Disconnect the USB/Media Card Reader board cable (1) from the system board. Remove the three Phillips PM2.5×5.0 screws (2) that secure the USB/Media Card Reader board to the computer.

  • Page 102: System Board

    System board Description Spare part number System board for use with HP Compaq 6715b computer models with WWAN capability (includes 443896-001 WWAN module slot) System board for use with HP Compaq 6715b computer models without WWAN capability (does 443898-001 not include WWAN module slot)

  • Page 103

    Remove the system board: Press the PC Card eject button (1) twice. The first press releases the PC Card eject button from the PC Card slot. The second press releases the PC Card slot bezel from the PC Card slot. (The PC Card slot bezel is partially ejected from the PC Card slot.) NOTE: The PC Card slot bezel is included in the Plastics Kit, spare part number 443905-001.

  • Page 104

    Remove the following screws: (1) Two Phillips PM2.5×5.0 screws that secure the system board and PC Card/audio board assembly (2) One Phillips PM2.5×5.0 screw that secures the system board (3) Two Phillips PM2.5×5.0 screws that secure the optical drive connector board (4) Two Phillips PM2.5×3.0 screws that secure the system board NOTE: If the computer is equipped with a WWAN module, another Phillips PM2.5×5.0 screw...

  • Page 105: Pc Card/audio Board Assembly

    Reverse the preceding procedure to install the system board. PC Card/audio board assembly Description Spare part number For use with HP Compaq 6715b and 6710b computer models 443889-001 For use with HP Compaq 6715s and 6710s computer models 443888-001 Component replacement procedures...

  • Page 106

    Before removing the PC Card/audio board assembly, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.

  • Page 107: Modem Module

    All modem module spare part kits include a modem module cable. Description Spare part number For use with HP Compaq 6715 computer models and with HP Compaq 6710 computer models in 441074-001 all countries and regions except Japan and Asia/Pacific...

  • Page 108

    Switch cover (see Switch cover on page Fan (see Fan on page Heat sink (see Heat sink on page Display assembly (see Display assembly on page Top cover (see Top cover on page System board (see System board on page PC Card/audio board assembly (see PC Card/audio board assembly on page Remove the modem module:...

  • Page 109: Sim Slot Board

    SIM slot board NOTE: This section applies only to HP Compaq 6715b and 6710b computer models with WWAN capability. Description Spare part number SIM slot board 443907-001 Before removing the SIM slot board, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 110

    Lift the SIM slot board (1) straight up and remove it, making note of the location of the pins (2) on the SIM slot board and their alignment with the system board. Reverse this procedure to install the SIM slot board. Chapter 4 Removal and replacement procedures...

  • Page 111: Computer Setup, Starting Computer Setup

    Computer Setup Starting Computer Setup Computer Setup is a preinstalled, ROM-based utility that can be used even when the operating system is not working or will not load. NOTE: Some of the Computer Setup menu items listed in this guide may not be supported by your computer.

  • Page 112: Navigating And Selecting In Computer Setup, Restoring Factory Settings In Computer Setup, Using Computer Setup

    Using Computer Setup Navigating and selecting in Computer Setup The information and settings in Computer Setup are accessed from the File, Security, Diagnostics, and System Configuration menus. Open Computer Setup by turning on or restarting the computer, and then pressing while the "F10 = ROM Based Setup"...

  • Page 113: File Menu, Computer Setup Menus

    Computer Setup menus The menu tables in this section provide an overview of Computer Setup options. NOTE: Some of the Computer Setup menu items listed in this chapter may not be supported by your computer. File menu Select To do this ●...

  • Page 114: Security Menu, Diagnostics Menu

    Security menu Select To do this Setup password Enter, change, or delete a setup password. Power-On password Enter, change, or delete a power-on password. ● Password options Enable/disable stringent security. ● Enable/disable password requirement on computer restart. ● DriveLock passwords Enable/disable DriveLock on any computer hard drive and on optional MultiBay hard drives.

  • Page 115: System Configuration Menu

    System Configuration menu NOTE: Some of the listed System Configuration options may not be supported by your computer. Select To do this Language (or press f2) Change the Computer Setup language. ● Boot options Set f9, f10, and delay when starting up. ●...

  • Page 116

    LAN when not in use. ● Enable/disable SATA Native Mode. ● Enable/disable Dual Core CPU. ● Enable/disable Secondary Battery Fast Charge. ● Choose Bit-shift or LBA assisted HDD Translation Mode. ● Enable/disable Windows direct application launcher. ● Enable/disable HP Lockout. Chapter 5 Computer Setup...

  • Page 117

    Select To do this ● Built-In Device Options Enable/disable embedded WWAN Device Radio. ● Enable/disable embedded WLAN Device Radio. ● Enable/disable embedded Bluetooth® Device Radio. ● Enable/disable LAN/WLAN Switching. When enabled, switches to a WLAN when a LAN is either unavailable or disconnected. ●...

  • Page 118: Computer Specifications, Specifications

    Specifications Computer specifications Metric U.S. Dimensions Height (front to back) 3.49 to 4.05 cm 1.37 to 1.59 in Width 35.7 cm 14.05 in Depth 26.5 cm 10.43 in Weight (with optical drive, hard drive, and battery) 2.75 kg 6.06 lbs Input power Operating voltage 19.0 V dc @ 4.74 A –...

  • Page 119: Inch, Wsxga Display Specifications

    Metric U.S. Operating 0.75 g zero-to-peak, 10 Hz to 500 Hz, 0.25 oct/min sweep rate Nonoperating 1.50 g zero-to-peak, 10 Hz to 500 Hz, 0.5 oct/min sweep rate NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The computer operates well within this range of temperatures.

  • Page 120: Inch, Wxga Display Specifications

    15.4-inch, WXGA display specifications Metric U.S. Dimensions Height 20.7 cm 8.15 in Width 33.1 cm 13.03 in Diagonal 39.1 cm 15.39 in Number of colors Up to 16.8 million Contrast ratio 200:1 (typical) Brightness 180 nits (typical) Pixel resolution Pitch 0.259 ×...

  • Page 121: Hard Drive Specifications

    Hard drive specifications 160-GB* 120-GB* 80-GB* Dimensions Height 9.5 mm 9.5 mm 9.5 mm Width 70 mm 70 mm 70 mm Weight 101 g 101 g 101 g Interface type SATA SATA SATA Transfer rate 100 MB/sec 100 MB/sec 100 MB/sec Security ATA security ATA security...

  • Page 122: Primary 6-cell, Li-ion Battery Specifications

    Primary 6-cell, Li-ion battery specifications Metric U.S. Dimensions Height 2.0 cm 0.79 in Width 20.3 cm 7.99 in Depth 5.3 cm 2.09 in Weight 0.34 kg 0.75 lb Energy Voltage 14.4 V Amp-hour capacity 2.2 Ah and 2.55 Ah Watt-hour capacity 47 Wh and 55Wh Temperature Operating...

  • Page 123: Dvd±rw And Cd-rw Super Multi Double-layer Combo Drive Specifications

    DVD±RW and CD-RW Super Multi Double-Layer Combo Drive specifications Applicable disc Read: Write: CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-R and CD-RW CD-ROM, CD-ROM XA, MIXED MODE DVD+R, DVD+RW, DVD-R, DVD-RW, CD, CD-I, CD-I Bridge (Photo-CD, Video DVD-RAM CD), Multisession CD (Photo-CD, CD- EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,...

  • Page 124

    Startup time < 15 seconds Stop time < 6 seconds Chapter 6 Specifications...

  • Page 125: Dvd/cd-rw Combo Drive Specifications

    DVD/CD-RW Combo Drive specifications Applicable disc Read: Write: CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-R and CD-RW CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD- EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-RAM Center hole diameter...

  • Page 126: Dvd-rom Drive

    DVD-ROM drive Applicable disc DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18, CD-ROM (Mode 1 and 2), CD Digital Audio, CD-XA ready (Mode 2, Form 1 and Form 2), CD-I (Mode 2, Form 1 and Form 2), CD-R, CD-RW, Photo CD (single and multisession), CD-Bridge Center hole diameter 1.5 cm (0.59 in) Disc diameter...

  • Page 127: System Dma Specifications

    System DMA specifications Hardware DMA System function DMA0 Not applicable DMA1* Not applicable DMA2* Not applicable DMA3 Not applicable DMA4 Direct memory access controller DMA5* Available for PC Card DMA6 Not assigned DMA7 Not assigned *PC Card controller can use DMA 1, 2, or 5. System DMA specifications...

  • Page 128: System Interrupt Specifications

    System interrupt specifications Hardware IRQ System function IRQ0 System timer IRQ1 Standard 101-/102-Key or Microsoft® Natural Keyboard IRQ2 Cascaded IRQ3 Intel 82801DB/DBM USB2 Enhanced Host Controller—24CD IRQ4 COM1 IRQ5* Conexant AC—Link Audio Intel 82801DB/DBM SMBus Controller—24C3 Data Fax Modem with SmartCP IRQ6 Diskette drive IRQ7*...

  • Page 129: System I/o Address Specifications

    System I/O address specifications I/O address (hex) System function (shipping configuration) 000 - 00F DMA controller no. 1 010 - 01F Unused 020 - 021 Interrupt controller no. 1 022 - 024 Opti chipset configuration registers 025 - 03F Unused 02E - 02F 87334 “Super I/O”...

  • Page 130

    I/O address (hex) System function (shipping configuration) 1F8 - 200 Unused JoyStick (decoded in ESS1688) 202 - 21F Unused 220 - 22F Entertainment audio 230 - 26D Unused 26E - 26 Unused 278 - 27F Unused 280 - 2AB Unused 2A0 - 2A7 Unused 2A8 - 2E7...

  • Page 131: System Memory Map Specifications

    System memory map specifications Size Memory address System function 640 KB 00000000-0009FFFF Base memory 128 KB 000A0000-000BFFFF Video memory 48 KB 000C0000-000CBFFF Video BIOS 160 KB 000C8000-000E7FFF Unused 64 KB 000E8000-000FFFFF System BIOS 15 MB 00100000-00FFFFFF Extended memory 58 MB 04800000-07FFFFFF Super extended memory 58 MB...

  • Page 132: Torx T8m2.5×7.0 Screw, Screw Listing

    Screw listing This section provides specification and reference information for the screws and screw locks used in the computer. All screws and screw locks listed in this section are available in the Screw Kit, spare part number 443906-001. Torx T8M2.5×7.0 screw Color Quantity Length...

  • Page 133: Phillips Pm2.0×5.0 Captive Screw

    Phillips PM2.0×5.0 captive screw Color Quantity Length Thread Head diameter Black 5.0 mm 2.0mm 5.0 mm Where used: (1) Two screws that secure the hard drive cover to the computer (screws are captured on the cover by C-clips) (2) One screw that secures the Bluetooth module cover to the computer (screw is captured on the cover by a C-clip) (3) One screw that secures the memory/WLAN module compartment cover to the computer (screw is captured on the cover by a C-clip)

  • Page 134: Phillips Pm2.5×13.0 Captive Screw

    Phillips PM2.5×13.0 captive screw Color Quantity Length Thread Head diameter Black 13.0 mm 2.5 mm 6.0 mm Where used: One screw that secures the hard drive to the computer Chapter 7 Screw listing...

  • Page 135: Phillips Pm3.0×3.0 Screw

    Phillips PM3.0×3.0 screw Color Quantity Length Thread Head diameter Silver 3.0 mm 3.0 mm 5.0 mm Where used: 4 screws that secure the hard drive bracket to the hard drive Phillips PM3.0×3.0 screw...

  • Page 136: Phillips Pm2.5×3.0 Screw

    Phillips PM2.5×3.0 screw Color Quantity Length Thread Head diameter Black 3.0 mm 2.5 mm 5.0 mm Where used: 2 screws that secure the WLAN module to the computer Where used: 2 screws that secure the WWAN module to the computer Chapter 7 Screw listing...

  • Page 137

    Where used: 2 screws that secure the modem module to the PC Card/audio board assembly Phillips PM2.5×3.0 screw...

  • Page 138: Torx T8m2.5×9.0 Screw

    Torx T8M2.5×9.0 screw Color Quantity Length Thread Head diameter Black 9.0 mm 2.5 mm 5.0 mm Where used: (1) One screw that secures the optical drive to the computer (2) Four screws that secure the display assembly to the computer Where used: 2 screws that secure the display assembly to the computer Chapter 7 Screw listing...

  • Page 139

    Where used: 13 screws that secure the top cover to the computer Where used: 3 screws that secure the top cover to the computer Torx T8M2.5×9.0 screw...

  • Page 140: Phillips Pm2.0×3.0 Screw

    Phillips PM2.0×3.0 screw Color Quantity Length Thread Head diameter Black 3.0 mm 2.0 mm 4.5 mm Where used: 2 screws that secure the optical drive bracket to the optical drive Where used: 8 screws that secure the display hinges to the display panel Chapter 7 Screw listing...

  • Page 141: Black Phillips Pm2.5×8.0 Captive Screw

    Black Phillips PM2.5×8.0 captive screw Color Quantity Length Thread Head diameter Black 8.0 mm 2.5 mm 5.0 mm Where used: 3 screws that secure the keyboard to the computer Black Phillips PM2.5×8.0 captive screw...

  • Page 142: Silver Phillips Pm2.5×8.0 Captive Screw

    Silver Phillips PM2.5×8.0 captive screw Color Quantity Length Thread Head diameter Silver 8.0 mm 2.5 mm 5.0 mm Where used: One captive screw that secures the fan to the computer Chapter 7 Screw listing...

  • Page 143: Phillips Pm2.5×8.0 Screw

    Phillips PM2.5×8.0 screw Color Quantity Length Thread Head diameter Black 8.0 mm 2.5 mm 5.0 mm Where used: One screw that secures the fan to the system board Phillips PM2.5×8.0 screw...

  • Page 144: Phillips Pm2.0×6.0 Screw

    Phillips PM2.0×6.0 screw Color Quantity Length Thread Heat width Silver 6.0 mm 2.0 mm 4.5 mm Where used: 4 screws that secure the heat sink to the computer Chapter 7 Screw listing...

  • Page 145: Torx T8m2.5×6.0 Screw

    Torx T8M2.5×6.0 screw Color Quantity Length Thread Head diameter Black 6.0 mm 2.5 mm 5.0 mm Where used: 4 screws that secure the top edge of the display bezel to the display enclosure Where used: 4 screws that secure the top edge of the display panel to the display enclosure Torx T8M2.5×6.0 screw...

  • Page 146: Hex Hm5.0×9.0 Screw Lock

    Hex HM5.0×9.0 screw lock Color Quantity Length Thread Head diameter Silver 9.0 mm 3.0 mm 5.0 mm Where used: 2 screw locks that secure the top cover to the computer Chapter 7 Screw listing...

  • Page 147: Phillips Pm2.5×5.0 Screw

    Phillips PM2.5×5.0 screw Color Quantity Length Thread Head diameter Black 5.0 mm 2.5 mm 5.0 mm Where used: (1) Two screws that secure the speaker assembly to the base enclosure (2) Three screws that secure the USB/Media Card Reader board to the base enclosure Phillips PM2.5×5.0 screw...

  • Page 148

    Where used: (1) Two screws that secure the system board and PC Card/audio board assembly to the base enclosure (2) One screw that secures the system board to the base enclosure (3) Two screws that secure the optical drive connector board to the system board (4) One screw that secures the SIM slot board to the base enclosure (5) One screw that secures the PC Card/audio board assembly to the system board Chapter 7 Screw listing...

  • Page 149: Phillips Pm2.5×3.0 Broad-head Screw

    Phillips PM2.5×3.0 broad-head screw Color Quantity Length Thread Head diameter Silver 3.0 mm 2.5 mm 7.0 mm Where used: 2 screws that secure the system board to the base enclosure Phillips PM2.5×3.0 broad-head screw...

  • Page 150: Backup And Recovery In Windows Vista, Creating Recovery Discs, Backing Up Your Information

    You can only recover files that you have previously backed up. HP recommends that you use HP Backup & Recovery Manager to create an entire drive backup as soon as you set up your computer. Chapter 8 Backup and recovery...

  • Page 151: Backup Suggestions

    Before you can perform backup and recovery procedures, the computer must be connected to external power. NOTE: Drivers, utilities, and applications installed by HP can be copied to a CD or to a DVD using HP Backup & Recovery Manager. Backup and recovery in Windows Vista...

  • Page 152: Backing Up Specific Files Or Folders, Backing Up The Entire Hard Drive

    This process will take several minutes, depending on the file size and the speed of the computer. To back up specific files or folders: Select Start > All Programs > HP Backup & Recovery > Backup & Recovery Manager. Click Next.

  • Page 153: Creating Recovery Points, Scheduling Backups, Performing A Recovery

    You can only recover files that you have previously backed up. HP recommends that you use HP Backup & Recovery Manager to create an entire drive backup as soon as you set up your computer. Backup and recovery in Windows Vista...

  • Page 154: Performing A Recovery From The Recovery Discs, Performing A Recovery From The Hard Drive

    HP Backup & Recovery Manager helps you with the following tasks for safeguarding your information and restoring it in case of a system failure: ● Recovering important files—This feature helps you reinstall important files without performing a full system recovery.

  • Page 155: Initiating A Recovery In Windows, Initiating A Recovery From The Hard Drive Recovery Partition

    Initiating a recovery in Windows To initiate a recovery in Windows, follow these steps: Back up all personal files. Select Start > All Programs > HP Backup & Recovery > Backup & Recovery Manager. Click Next. Click Perform a recovery, and then click Next.

  • Page 156: Backup And Recovery In Windows Xp, Creating Recovery Discs, Backing Up Your Information

    NOTE: You can only recover files that you have previously backed up. HP recommends that you use HP Backup and Recovery Manager to create an entire drive backup as soon as you set up your computer. With HP Backup and Recovery Manager, you can perform the following tasks: ●...

  • Page 157

    Before you can perform Backup and Recovery procedures, the computer must be connected to external power. NOTE: Drivers, utilities, and applications installed by HP can be copied to a CD or to a DVD using HP Backup and Recovery Manager. Backing up specific files or folders You can back up specific files or folders to the recovery partition on the hard drive, to an optional external hard drive, or to optical discs (CDs or DVDs).

  • Page 158: Backing Up The Entire Hard Drive

    To back up specific files or folders: Select Start > All Programs > HP Backup and Recovery > HP Backup and Recovery Manager. Click Next. Click Back up to protect system settings and important data files, and then click Next.

  • Page 159: Scheduling Backups, Creating Recovery Points, Performing A Recovery

    NOTE: You can only recover files that you have previously backed up. HP recommends that you use HP Backup and Recovery Manager to create an entire drive backup as soon as you set up your computer. Backup and recovery in Windows XP...

  • Page 160: Performing A Recovery From The Hard Drive, Performing A Recovery From The Recovery Discs

    HP Backup and Recovery Manager helps you with the following tasks for safeguarding your information and restoring it in case of a system failure: ● Recovering important files—This feature helps you reinstall important files without performing a full system recovery.

  • Page 161: Initiating A Recovery From The Hard Drive Recovery Partition, Initiating A Recovery In Windows

    Initiating a recovery in Windows To initiate a recovery in Windows, follow these steps: Back up all personal files. Select Start > All Programs > HP Backup and Recovery > HP Backup and Recovery Manager. Click Next. Click Recover important files or the entire system, and then click Next.

  • Page 162: Audio-out (headphone), Audio-in (microphone), Connector Pin Assignments

    Connector pin assignments Audio-out (headphone) Signal Audio out, left channel Audio out, right channel Ground Audio-in (microphone) Signal Audio signal in Audio signal in Ground Chapter 9 Connector pin assignments...

  • Page 163: External Monitor

    External monitor Signal Red analog Green analog Blue analog Not connected Ground Ground analog Ground analog Ground analog +5 VDC Ground Monitor detect DDC 2B data Horizontal sync Vertical sync DDC 2B clock External monitor...

  • Page 164: Rj-11 (modem), Rj-45 (network)

    RJ-11 (modem) Signal Unused Ring Unused Unused Unused RJ-45 (network) Signal Transmit + Transmit - Receive + Unused Unused Receive - Unused Unused Chapter 9 Connector pin assignments...

  • Page 165: S-video-out, Universal Serial Bus

    S-Video-out Signal S-VHS color (C) signal Composite video signal S-VHS intensity (Y) signal S-VHS color ground TV-CD S-VHS intensity ground Composite video ground Universal Serial Bus Signal +5 VDC Data - Data + Ground S-Video-out...

  • Page 166: Requirements For All Countries And Regions, Power Cord Set Requirements

    10 Power cord set requirements The wide range input feature of the computer permits it to operate from any line voltage from 100 to 120 volts AC or from 220 to 240 volts AC. The 3-conductor power cord set included with the computer meets the requirements for use in the country or region where the equipment is purchased.

  • Page 167: Requirements For Specific Countries And Regions

    Requirements for specific countries and regions Country or region Accredited agency Applicable note number Australia EANSW Austria Belgium CEBC Canada Denmark DEMKO Finland FIMKO France Germany Italy Japan METI Korea The Netherlands KEMA Norway NEMKO The People's Republic of China Sweden SEMKO Switzerland...

  • Page 168: Display, Battery, Recycling

    NOTE: Materials Disposal. This HP product contains mercury in the backlight in the display assembly that might require special handling at end-of-life. Disposal of mercury may be regulated because of environmental considerations. For disposal or recycling information, contact your local authorities, or see the Electronic Industries Alliance (EIA) Web site at http://www.eiae.org.

  • Page 169

    Perform the following steps to disassemble the display assembly: Remove all screw covers (1) and screws (2) that secure the display bezel to the display assembly. Lift up and out on the left and right inside edges (1) and the top and bottom inside edges (2) of the display bezel until the bezel disengages from the display assembly.

  • Page 170

    Disconnect all display panel cables (1) from the display inverter and remove the inverter (2). Remove all screws (1) that secure the display panel assembly to the display enclosure. Remove the display panel assembly (2) from the display enclosure. Turn the display panel assembly upside down. Remove all screws that secure the display panel frame to the display panel.

  • Page 171

    Remove the display panel frame (2) from the display panel. Remove the screws (1) that secure the backlight cover to the display panel. Lift the top edge of the backlight cover (2) and swing it outward. Remove the backlight cover. Turn the display panel right-side up.

  • Page 172

    Remove the backlight cables (1) from the clip (2) in the display panel. Turn the display panel upside down. WARNING! The backlight contains mercury. Exercise caution when removing and handling the backlight to avoid damaging this component and causing exposure to the mercury. Remove the backlight frame from the display panel.

  • Page 173

    Remove the backlight from the backlight frame. Disconnect the display cable (1) from the LCD panel. Remove the screws (2) that secure the LCD panel to the display rear panel. Release the LCD panel (3) from the display rear panel. Release the tape (4) that secures the LCD panel to the display rear panel.

  • Page 174

    Index Symbols/Numerics Bluetooth module rear 20 1394 port 19 removal 58 right-side 21 spare part numbers 32, 37, switches 13 44, 58 top 13 AC adapter, spare part numbers Bluetooth module cable TouchPad 17 36, 37 illustrated 34 computer feet accessory battery connector 22 removal 88 illustrated 33...

  • Page 175

    removal 83 Execution Disable 106 spare part number 25, 43 external media cards, product I/O address specifications 119 display component recycling 158 description 4, 10 info button 14 display enclosure, spare part external monitor port interrupt specifications 118 numbers 25, 43, 44 location 20 inverter display hinge...

  • Page 176

    optical drive pointing devices, product mass storage devices, spare part location 21 description 5 numbers 35 precautions 46 ports Media Card Reader 21 product description 3, 9 1394 19 memory check 104 removal 66 external monitor 20 memory map specifications 121 spare part numbers 32, 35, monitor 20 memory module...

  • Page 177

    recovery discs speakers 18 transporting guidelines 48 creating 140, 146 specifications using 144, 150 battery 112 Universal Serial Bus (USB) port recovery partition 145, 151 computer 108 location 19, 21 recovery points 143, 149 display 109, 110 pin assignments 155 removal/replacement DVD-ROM drive 116 unknown password 50...

This manual also for:

Compaq 6715s, Compaq 6710b, Compaq 6710s

Comments to this Manuals

Symbols: 0
Latest comments:
