Torx T8M2.5×9.0 screw
Color
Black
Where used:
(1) One screw that secures the optical drive to the computer
(2) Four screws that secure the display assembly to the computer
Where used: 2 screws that secure the display assembly to the computer
Quantity
Length
23
9.0 mm
Thread
Head diameter
2.5 mm
5.0 mm
Torx T8M2.5×9.0 screw 121
