Freecom MediaPlayer
TV Video
EN
Input Mode
Normal Video
6
S-Video
Component 480i
Component
480p
720p
1080i
DVI
480p
720p
1080i
1080p
640x480
800x600
1024x768
1280x1024
1600x1200
D-Sub
480p
720p
1080i
1080p
NTSC / PAL : Standard TV Output. Select the correct one for use in your
country.
66
Player Video
Output Mode
"TV Output"= Composite Mode
"Composite Mode" = C/S-Video
"TV Output" = Composite Mode
"Composite Mode" = C/YPbPr
"TV Output" = Component Mode
"Component Mode" = Select one
among 480p, 720p, and 1080i same
as TV input mode
"TV Output" = HD-DVI Mode
"HD-DVI Mode" = Select one
among 480p, 720p, 1080i,1080p,
640x480, 800x600, 1024x768,
and 1280x1024, 1600x1200 same
as TV input mode.
"TV Output" = HD-DVI RGB Mode
"HD-DVI RGB" = Select one among
480p, 720p, 1080i , and 1080psame as
TV input mode
Connection Jack
of TV, Player
CVBS or Composite Jack
(Generally Yellow Jack)
S-Video Jack
Component 3 Jack
* Y(Green), Pb(Blue),
Pr(Red)
DVI Jack
DVI jack of Player to D-
Sub jack of TV(Monitor)
Video Cable
Type
Yellow RCA Cable
(Supplied)
S -V ide o Cab le *
Black rounded
Component Cable
* Y(Green),
Pb(Blue), Pr(Red)
DVI Cable
DVI to D-Sub gen-
der
