Freecom MediaPlayer
Chapter 1: Use as External USB HDD
EN

1.1 Insert the Hard Disk (only Drive-In Kit)

1
• Only use a 3.5" IDE Hard Disk.
• Hard Disk should be jumpered as "Master". However, if the Hard Disk supports "Single
mode", you need to try to set "Single mode".
1
1. Unscrew the 4 screws and open the cover by slid-
ing it in the direction of the arrow.
2. Connect Power and IDE 40-pin connector to Hard
Disk.
3. Close the cover by sliding it in the direction of the
arrow.
