- Page 1 EFT920 EFT920 19 inch Flat CRT Color Monitor User’s Manual by Envision Peripherals, Inc. www.ENVISIONmonitor.com Before operating your monitor, please read this manual thoroughly. EFT920 v1_031004...
-
Page 2: For Your Safety
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help. EFT920 For Your Safety Notice 1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. - Page 3 • Disconnect the power cord to stop the power supply to the monitor. EFT920 For Your Safety • The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin.
-
Page 4: General Notes
@75Hz • EPA ENERGY STAR Package Contents The box that your monitor was shipped in should have included the following items: 1. EFT920 Color Monitor 2. Power Cord 3. Quick Start Guide 4. Booklet (containing Warranty and Safety information) EFT920 ®... -
Page 5: Before You Operate The Monitor
Before You Operate the Monitor EFT920 Installing & Removing the Base EFT920 v1_031004... - Page 6 3. Plug the other end of the power cord into a grounded AC outlet or UL-approved power strip. EFT920 Caution: Make sure the power cord is the correct type that is required in your area. This monitor...
-
Page 7: Front Panel Buttons
Contrast: Press this button to adjust the picture’s contrast. If the OSD window is open, this button allows you to move within the window and select desired functions. EFT920 Operating Instructions Front Panel Buttons MENU: Press this button to open the OSD window or select a highlighted function. -
Page 8: Adjusting The Osd Settings
3. Press MENU to open the function’s window. 4. Press the < or > buttons to change the settings of the function. EFT920 Operating Instructions 5. To save and exit, press the EXIT icon or leave the monitor alone for 10 seconds. If you want to adjust any other function, repeat steps 2-4. -
Page 9: Plug & Play Ddc1/2B Feature
EDID information. The DDC2B is a bidirectional data channel based on the I²C protocol. The host can request EDID information over the DDC2B. EFT920 Operating Instructions Windows INF Driver File Most computers will automatically configure your monitor to work with your computer. -
Page 10: Technical Support (Faq)
Screen image is not centered or sized properly Picture has color defects (white does not look white) EFT920 Technical Support (FAQ) Possible Solution • Make sure the power button is ON. • Make sure the power cord is properly connected to a grounded power outlet and to the monitor. -
Page 11: Specifications
Preset Display area 13.7” (346 mm) X 10.3” (260 mm) Dot Clock 200 MHz Maximum Resolution 1600 x 1200 pixels Plug & Play VESA DDC1/2B TM EFT920 Appendix Input Video Separate Sync. H/V Sync. H-Frequency V-Frequency Input Video Signal... - Page 12 Specifications (continued) Environmental Operating Temp: Considerations 32° to 104°F (0° to 40°C) ambient Operating Humidity: 10% to 85% Signal Cable Attached Mini D-sub 15 Male Optimal Viewing Mode: 1280 x 1024 @ 85 Hz EFT920 Appendix EFT920 v1_031004...
-
Page 13: Factory Preset Timing Table
Factory Preset Timing Table Standard VESA / 85 VESA / 75 EFT920 Appendix Resolution Horizontal (in pixels) Frequency 720 × 400 31.5 kHz 640 × 480 31.5 kHz 640 × 480 43.3 kHz 800 × 600 53.7 kHz 1024 × 768 68.7 kHz... -
Page 14: Connector Pin Assignment
Connector Pin Assignment Pin Number EFT920 Appendix Description Pin Number Green Blue Ground Ground R-Ground G-Ground B-Ground EFT920 Description Ground Monitor Ground DDC-Serial Data H-Sync V-Sync DDC-Serial Clock v1_031004...
