10. Connect the power cord to the power outlet (Figure E.1).
NOTE: If you have difficulty removing the cable cover, please push the
lower opening upward to remove it, as show in Figure E.2.
NOTE: Please refer to Caution section of this manual for proper selection
of AC power cord.
11. Turn on the monitor with the front power button and the computer
(Figure E.1).
12. No-touch Auto Adjust automatically adjusts the monitor to optimal settings upon initial setup for most timings.
For further adjustments, use the following OSD controls:
• Auto Adjust Contrast
• Auto Adjust
Refer to the Controls section of this User's Manual for a full description of these OSD controls.
NOTE: If you have any problem, please refer to the Troubleshooting section of this User's Manual.

Raise and Lower Monitor Screen

The monitor may be raised or lowered. To raise or lower
screen, place hands on each side of the monitor and lift or
lower to the desired height (Figure RL.1).
NOTE: Handle with care when raising or lowering the
monitor screen.
Screen Pivot
Before rotating, the screen must be raised to the highest level
to avoid accidentally damaging the screen and to avoid
pinching fingers. With one hand, grip the top of the display by
the handle using the other hand to grip the bottom. Lift up to
the highest position (Figure RL.1).
To rotate the screen, place hands on each side of the monitor
screen and turn clockwise from Landscape to Portrait or
counter-clockwise from Portrait to Landscape (Figure R.1).
NOTE: Disconnect cables before rotating the screen.
Re-connect cables when screen is in desired position.
Tilt and Swivel
Grasp both sides of the monitor screen with your hands and adjust the tilt and swivel
as desired (Figure TS.1).
NOTE: Handle with care when tilting and swivelling the monitor screen.
Figure E.2
English-5
Power Button
Figure E.1
Figure RL.1
Figure R.1
Figure TS.1
