National Instruments NI PXI-1006 User Manual

NI PXI-1006 Power Supply Shuttle
User Guide
Unpacking

What You Need to Get Started

National Instruments™, NI™, and ni.com™ are trademarks of National Instruments Corporation. Product and company
names mentioned herein are trademarks or trade names of their respective companies. For patents covering
National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file
on your CD, or ni.com/patents.
ni.com
© 2003 National Instruments Corp. All rights reserved.
The NI PXI-1006 power supply shuttle is a replacement part for the
PXI-1006 chassis.
To minimize downtime caused by a power supply failure, the PXI-1006
chassis has a modular power supply shuttle. This power supply shuttle
includes the chassis power supply, cooling fans, and fan-control circuitry.
Key features of the power supply shuttle include the following:
• Universal AC input with automatic voltage and frequency ranging
• Over-current protection through push-reset circuit breaker
• Remote power monitoring and inhibit through a rear-panel connector
• Selectable fan speed
Carefully inspect the shipping container and the power supply shuttle for
damage. Check for visible damage to the metal work. Check to make sure
all handles, hardware, and switches are undamaged. Visually inspect the
inside of the shuttle for any possible damage, debris, or detached
components. If damage appears to have been caused during shipment,
file a claim with the carrier. Retain the packing material for possible
inspection and/or reshipment.
❑
NI PXI-1006 chassis (the unit being repaired)
❑
NI PXI-1006 power supply shuttle
❑
Read Me First: Safety and Radio-Frequency Interference
April 2003
323569A-01
