National Instruments NI PXI-1042 User Manual

NI PXI-1042 P
U G
SER UIDE
Introduction
Unpacking
National Instruments™, NI™, and ni.com™ are trademarks of National Instruments Corporation. Product and company
names mentioned herein are trademarks or trade names of their respective companies. For patents covering
National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file
on your CD, or ni.com/patents.
ni.com
© 2002 National Instruments Corp. All rights reserved.
S
OWER UPPLY
The NI PXI-1042 power supply shuttle is a replacement part for the
PXI-1042 chassis.
To minimize downtime caused by a power-supply failure, the PXI-1042
chassis has a modular power supply shuttle. This power supply shuttle
includes the chassis power supply, cooling fans, and fan-control circuitry.
Key features of the power supply shuttle include:
• Universal AC input with automatic voltage and frequency ranging
• Over-current protection via push-reset circuit breaker
• Remote power monitoring and inhibit via a rear-panel connector
• Temperature-sensing module that can adjust fan speed based on
air-intake temperature to minimize audible noise
• Circuitry to control a front-panel LED that indicates power supply
failure
Carefully inspect the shipping container and the power supply shuttle for
damage. Check for visible damage to the metal work. Check to make sure
all handles, hardware, and switches are undamaged. Visually inspect the
inside of the shuttle for any possible damage, debris, or detached
components. If damage appears to have been caused during shipment, file
a claim with the carrier. Retain the packing material for possible inspection
and/or reshipment.
S
HUTTLE
October 2002
323499A-01
