APOLLO 1U ICE
J7A – Parallel port (LPT1)
DB25 female
PC99 Color: Maroon
DB25
D-type socket
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
© 2007 Eurotech Ltd
Issue C
Signal name
STROBE
D0
D1
D2
D3
D4
D5
D6
D7
ACKNOWLEDGE
BUSY
PAPER EMPTY
SELECT
AUTOFEED
ERROR
INIT
SELECT IN
Ground
Ground
Ground
Ground
Ground
Ground
Ground
Ground
Connectors
113
25
14
1
18
