Connectors - Eurotech APOLLO 1U ICE Technical Manual

APOLLO 1U ICE

Connectors

The connectors on the APOLLO let you connect external devices such as keyboards,
mouse devices, printers etc.
Connector
J1
J2
J3
J4A
J4B, J4C
J5A
J5B
J6A
J6B
J6C
J7A
J7B, J7C
The connectors are illustrated in the following diagram.
Further details about these connectors are provided in the following sections.
© 2007 Eurotech Ltd Issue C
Function
Audio Line Out.
Audio Line In.
Audio Mic In.
IEEE1394 port 0.
USB ports 1 to 2.
Primary LAN.
Secondary LAN.
VGA connector.
Keyboard.
Mouse.
Parallel port (LPT1).
Serial ports 1 to 2.
J7A
J7B
J7C
See ...
Page 13.
Page 13.
Page 14.
Page 14.
Page 14.
Page 15.
Page 15.
Page 16.
Page 16.
Page 17.
Page 18.
Page 19.
J6A
J5A
J6B J5B
J6C J4C
Connectors
J4A J1
J3
J4B J2
