Enerco HeatStar MH35LPTS Parts List

35,000 BTU HeatStar Infrared Propane Heater

Model Numbers

MH35LPTS
Key Part
No. No.

Description

1 00333 CONT M-N SS PORT 3/8MPXI/4MP
2 02455 BURNR/LTFR PORTABLES/D1096
3 05455 ORIFICE/BURNER #55 DRILL
4 09352 THERMOCOUPLE ASSY/18"
5 09357 TIP-OVER SWITCH 6" LEAD(PORT)
6 09371 JUNCTION BLK ADPTR KIT/TIPSW
7 11663 REG L/P 27.5" W.C. OUT
8 CR705 IGNITOR, MODEL#35
9 CR735 PIEZO, MODEL#35
10 70724 WHEEL, MODEL#35
11 70720 HANDLE
12 70721 HANDLE LOCKING KNOBS (2)
13 70723 LOWER MAIN FRAME ASSEMBLY
35,000 BTU HeatStar Forced Air Propane Heater
Model Numbers
MH35FA
Key Part
No. No. Description
1 10720 Heater Body Kit
2 2100 Control Box Assy
3 8079 Valve w/Thermocouple
* 1007 Hose & Regulator Assembly
* 2130 Wire Assembly
7 8080 Electrode
8 6168 High Limit Switch 240oF (116oC)
10 8091 Nut Hex M8 x 1 Fine Thd Thermocouple (qty. 2)
11 8076 Motor 0.74 A
12 2101 Grille Assembly
13 8077 Fan Blade, 6.75 x .75 Pitch
14 2113 Power Cord Assembly
15 8136 Bushing Strain Relief
16 8116 Nut Hex 5-28 TE Valve (qty. 2)
17 7161 Nut, Piezo
18 6473 Piezo Ignitor
19 7094 Clip Handle (qty. 2)
20 7095 Handle
* M8494 Label, Model Warnings
* 70036 Label, Operating Instructions
* 8649 Manual, Operating Instructions/Parts List
* M8497 Label, Model
* 8204 Label, Hang Tag, LP
* Not shown on exploded view
