OPERATING INSTRUCTIONS AND OWNER'S MANUAL
MR. HEATER
1000ID,
2000ID
3000ID
INDIRECT FIRED
PORTABLE HEATER
If the information in this manual is not followed exactly, afire or explosion
WARNING:
may result causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
— Service must be performed by a qualified service agency.
This is a vented portable heater. It uses air (oxygen) from the area in which it is used. Adequate
combustion air and ventilation must be provided. Refer to page 5.
READ INSTRUCTIONS CAREFULLY: Read
and follow all instructions. Place instructions in
a safe place for future reference. Do not allow
anyone who has not read these instructions to
assemble, light, adjust or operate the heater.
ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 800-251-0001
HEATSTAR
BY ENERCO
1000ID,
2000ID
3000ID,
4000ID
06/11 #50120 Rev.A
Advertisement
Table of Contents
Related Manuals for Enerco 1000ID
Summary of Contents for Enerco 1000ID
- Page 1 This is a vented portable heater. It uses air (oxygen) from the area in which it is used. Adequate combustion air and ventilation must be provided. Refer to page 5. ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 800-251-0001 06/11 #50120 Rev.A...
-
Page 2: Table Of Contents
• THE POWER SUPPLY CABLE MUST BE REPLACED ONLY BY QUALIFIED PERSONNEL. • ONLY USE AN ORIGINAL H07RN-F POWER CABLE WITH WATERPROOF PLUG. • DO NOT TOUCH THE EXHAUST GAS OUTLET. DANGER OF BURNS! ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual... -
Page 3: Specifications
Compulsory flue draft [in WC] 0.05 0.05 0.05 0.05 Tank capacity [gal] 10.8 17.2 27.7 35.7 Dimensions, l x W x H [in] 49.3x20.0x30.5 56.5x23.2x37.60 68.5x27.6x37.7 66.3x27.6x45.6 Net Weight [lb] eNeRCo GRoUP, INC. |Indirect Fired Portable Heater operating Instructions and owner’s Manual... -
Page 4: Warnings
• Floors and ceilings must be made of fireproof materials in moving the heater wait till it has totally cooled off and make sure the room where the heater is operated. oil tank cap is securely fixed. eNeRCo GRoUP, INC. |Indirect Fired Portable Heater operating Instructions and owner’s Manual... -
Page 5: Maintenance
Chimney ending H shape “GAP oF eleCTRoDeS”. n.B. above recommendation indicative only. Have your Flue connections diagram installation checked by local authority. VentilatiOn 6 “ eNeRCo GRoUP, INC. |Indirect Fired Portable Heater operating Instructions and owner’s Manual... -
Page 6: Troubleshooting
S • i t c • l i o If heater s t i l l not working properly, please revert to nearest authorized dealer. ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual... -
Page 7: Wiring Diagrams
PRESSOSTATS AIR PHOTOCELL HEATED FILTER Optional only for metal tank PHOTORESISTANCE FILTRE GASOIL RECHAUFFE CONDENSER CONDENSATEUR FAN MOTOR MOTEUR DU VENTILATOR ELECTRIC PILOT LAMP LAMPE TEMOIN D’ALIMENTATION CONTROL COMMUTATEUR ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual... -
Page 8: Wiring Diagram
FILTRE GASOIL RECHAUFF CONDENSER AIR PRESSURE SWITCH CONDENSATEUR PRESSOSTATS AIR FAN MOTOR FUA FUSE 6,3 A MOTEUR DU VENTILATOR FUSIBLE 6,3 A ELECTRIC PILOT LAMP LAMPE TEMOIN D’ALIMENTATION ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual... - Page 9 PHOTOCELL HEATED FILTER Optional PHOTORESISTANCE FILTRE GASOIL RECHAUFF CONDENSER AIR PRESSURE SWITCH CONDENSATEUR PRESSOSTATS AIR FAN MOTOR MOTEUR DU VENTILATOR ELECTRIC PILOT LAMP LAMPE TEMOIN D’ALIMENTATION CONTROL COMMUTATEUR ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual...
-
Page 19: Parts Ordering Information
This Warranty gives you speci c legal rights, and you may have other rights which vary from state to state. Enerco Group, Inc. reserves the right to make changes at any time, without notice or obligation, in colors, speci cations, accessories, materials and models.
