2.4
System memory
2.4.1
Overview
The motherboard comes with four Double Data Rate 2 (DDR2) Dual Inline Memory
Modules (DIMM) sockets.
The figure illustrates the location of the DDR2 DIMM sockets:
®
P5K SE/EPU 240-pin DDR2 DIMM sockets
Channel
Channel A
Channel B
ASUS P5K SE/EPU
Sockets
DIMM_A1 and DIMM_B1
DIMM_A2 and DIMM_B2
2-13
