3.8

Prompt (Popup) Windows

The prompt window is displayed during the operation of the system to alert the user to certain condi-
tions and / or to require user confirmation of a command.
NOTE
The items in Table 14 are visible form the RMP, but the controls for them are available only at
the UPS.
Table 14 Prompt windows, meanings controlled at UPS only
Prompt
Transfer with interrupt, please confirm or cancel
The load is too high to be transferred with interrupt
This Operation Leads to Output Shutdown, Confirm or
Cancel
This operation leads to inverter overload, confirm or
cancel
Turn on more UPS to carry current load
Battery will be depleted, confirm
System self test finished - everything is ok.
System self test finished - Please check the current
warnings.
Enter control password
Battery Self Test aborted, condition not met
Battery Refresh Charge aborted, condition not met
Table 15 Prompt windows, meanings controlled at RMP
Prompt
Communication with UPS failed
Loading data from UPS
Remote Monitoring Panel silence
Remote Monitoring Panel silence off
Remote Monitoring Panel firmware updating
Firmware is not compatible with UPS
3.9

Dynamic Energy Flow Chart and UPS Help Screen

This screen displays a mimic diagram of the UPS that includes energy flow and status of isolation and
transfer switches. Press the "Help" key to activate this screen. Press "Help" again to toggle between
this screen and the main screen.
Meaning
Inverter and Bypass supplies are not synchronized and
any load transfer between the supplies will cause a brief
load interruption.
The total load must be less than the capacity of one unit
to allow a parallel system to perform an interrupted
transfer from bypass to inverter.
No alternative supply is available and any Inverter Off
operation will cause the load to be de-energized.
The turn-off this inverter will lead to the overload of
remaining inverter(s) in a parallel system.
The number of paralleled inverters already turned on is
insufficient to carry the existing load.
Battery Capacity test discharges the battery 100%
No action required
Check "Current Records" window
Required for Battery or UPS test (default = 12345)
Battery self-test condition is not enough. User should
check whether battery state is boost charging and
whether load level is greater than 20 percent.
Boost charging condition is not enough, such as (No
battery, charger has failed, etc.).
Meaning
The communication between RMP and UPS failed.
The RMP are loading data from UPS
The RMP unit has been muted.
The RMP silence is off
The RMP are updating firmware from ParameSet tool.
T
he RMP firmware is not compatible with UPS
20
Operation
