Figure 15 Menu Tree - Emerson Liebert Remote Monitoring Panel User Manual

The summary menu tree is shown in Figure 15. Refer to Table 12 for a detailed description of each
menu item.

Figure 15 Menu tree

Mains (input)
L-N voltage (V)
L-N current (A)
Frequency (Hz)
L-L voltage (V)
Power factor
Load
Sout (kVA)
Pout (kW)
Qout (kVAR)
Loadlevel %
Crest factor
Language
(Choices for
display)
Visible from the RMP,
but the control is
available at UPS only.
TX Input * Bypass
L-N voltage (V) L-N voltage (V)
L-L voltage (V) Frequency (Hz)
L-L voltage (V)
System
Sout (kVA)
Pout (kW)
Qout (kVAR)
Single unit, no
parallel data
Settings
Display contrast
Date format set
Date & time
Comm1 baud rate
Comm2 baud rate
Comm3 baud rate
Communication address
Communication mode
Callback times
Phone No.1
Phone No.2
Phone No.3
Command password
Output
L-N voltage (V)
L-N current (A)
Frequency (Hz)
L-L voltage (V)
Power factor
Battery
Battery voltage (V)
Battery current (A)
Battery temperature (°C)
Remain Time Min.
Battery capacity (%)
Battery boost charging
Battery float charging
Battery disconnected
Command
Battery maintenance test
Battery capacity test
System test
Stop testing
Freshening Charge
Stop Freshening Charge
Modem Auto-answer enable
Visible from the RMP,
but the control is avail-
able at UPS only.
* When configured, input transformer voltages are
displayed on the front LCD. When not activated, the
values are hidden.
** When configured, output transformer voltages are
displayed on the front LCD. When not activated, the
values are hidden.
13
Operation
TX Output **
L-N voltage (V)
L-L voltage (V)
Records
(history log)
Version
UPS version
UPS model
