DeVilbiss FUNCY JGX-3C-343 Operation Manual

Important：Read and follow all instructions and SAFETY PRECAUTIONS
MODELS
FUNCY - Air Cap № - Fluid Tip size – Type of feed（Ｇ：Gravity，Ｓ：Suction）
(例)： FUNCY–343-1.3 -G ←
SPECIFICATIONS
Maximum Working Air Pressure： 9 bar
Chart．1
Air Cap №
Tip size（mm）
Part
1.0 1.3
Number
○ ○
JGX-3C-343
○
PARTS LIST
Chart. 2
Ref. № Part Number
1 FUNCY-6
2 JGX-61C-K5
3 See Ｃhart.1
4 See Ｃhart.3
5 FUNCY-7
6 FUNCY-8-K5
7 JGX-2C-G
8 FUNCY-BODY-G
FUNCY-BODY-S
9 FUNCY-44
10 FUNCY-443
11 FUNCY-43
12 FUNCY-25-K5
13 FUNCY-12
14 See Chart. 3
15 FUNCY-14-K5
16 FUNCY-13
17 JGX-463C
18 JGX-11C-K3
19 JGX-46C-K10
20 JGX-45C
21 FUNCY-108
22 FUNCY-42
23 JGX-30C
24 FUN-34 (option)
25 LUNA-34
FUNCY
GUN
before using this equipment
（ №343 Air Cap - Size1.3ｍｍ - Gravity ）
, Maximum Working Fluid Pressure： 14 bar
Feed
1.5 1.8
○ ○
G
○ ○
S
Description
Retaining Ring Assy.
Seat Kit of 5
Air Cap
Fluid Tip
Baffle with Gasket
Baffle Gasket Kit of 5
Fluid Inlet
Gun Body (not for sale)
Pattern Valve
Valve Seal Kit (3 pieces)
Air Valve
Valve Spring Kit of 5
Air Valve Bushing
Needle Assy.
Needle Spring Kit of 5
Adjusting Screw
Needle Packing
Packing Gland Kit of 3
E-ring Kit of 10
Bearing Stud
Trigger
Cheater Valve
Air connector
Valve Seal Inserting Tool
Spanner
Operation Manual
Air consumption Pattern
Gun inlet width
pressure (mm)
225L/min
250
0.2MPa
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Note) Ref. No. 24 (FUN-34) is needed for Ref. 10 (FUNCY-
1
443) installation.
1
When removing it, be careful not to damage the surface of seat
1
where inserted. A damaged seat can lead air leakage.
1
1
Description
1
Size （mm）
1
1
1.0
1
1.3
1
1.5
1
1.8
1
Application
Mid-high Volume, fine
atomization, auto-refinishing,
Wood, plastic & metal finishing
Fluid Tip
FUNCY-4-1.0
FUNCY-4-1.3
FUNCY-4-1.5
FUNCY-4-1.8
SB-E-FUNCY-A
Fluid Air Weight
inlet inlet (g)
G1/4 G1/4 320
Chart.3
Needle
FUNCY-41-1.0
FUNCY-41-1.3
FUNCY-41-1.5
FUNCY-41-1.8
