Lightolier Lytecaster 1082 Specification

Page 1 of 2
1082/1002P1 Series
Standard Incandescent
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim - Eyeball
1082 Perma White Finish
Features
1. Housing: Aluminum, .040" (18 ga.); Perma White trim flange.
2. Eyeball: Die-formed, one piece, aluminum, .040" (18 ga.); provides 358°
horizontal rotation and 0° to 45° vertical adjustment; non-yellowing,
scratch resistant Perma White finish.
3. Frame-In Kit: (1002P1 standard frame shown). Other frames listed above
and shown on the right. See Frame-In Kit specification sheets for more
details.
Options & Accessories
Retaining Clips: 1955 - For installing in existing ceiling
Labels
UL (Suitable for Damp Locations), I.B.E.W.
Lytecaster
1082/1000IC Series
Insulated Ceiling
Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Frame-In Kit Installation Type
1002P1 Non-IC
1003R Non-IC Remodeler
1000IC
IC
1000AICM AirSeal® IC
1004IC/N AirSeal® IC
1004ICR IC Remodeler
1004ICX/N AirSeal® IC
1004IC/N Non-IC
1004ICR Non-IC Remodeler
® Recessed Downlighting
5" Aperture Basic Eyeball Reflector Trim
7 1/2"
6 7/8"
Incandescent
Lamping Height
50W PAR20 6 7/8"
75W R20 6 7/8"
50W PAR20 7 5/16"
75W R20 7 5/16"
7 1/2"
7 1/2"
7 1/4"
50W PAR20 7 1/2"
75W R20 7 1/2"
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • C0906
1082/1004IC 0
Convertible
IC/Non-IC
0 1082/1003R
™
Non-IC Remodeler
Type:
www.lightolier.com
1082
45˚
™
