Lightolier Lytecaster 2005 Specification

Page 1 of 2
5 1/2"
2005/2002P1
Standard Incandescent
2005/2003R
0
NON-IC
™
Remodeler Ring
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim
2005 Matte Black
2005WH Matte White
2005NM Matte Black
w/Natural Metal
2005BNM
Natural Metal™ Baffle
w/Natural Metal™ Flange
* 60W A19 with 2003R
Features
1. Reflector: Hydroformed aluminum, .040" thick (18 ga.); matte white or
Natural Metal™ trim flange.
2. Step Baffle: Aluminum with stepped conical surface for low brightness.
3. Frame-In Kit: (2002P1 standard frame shown.) Other frames shown on the
right. See Frame-In Kit specification sheet for more detail.
Options & Accessories
Lytegems :
®
Retaining Clips:
Extra Thick Ceiling
Mounting Ring:
Labels
UL (Suitable for Damp Locations), I.B.E.W.
Lightolier is a Philips group brand
5 1/2"
Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Line Voltage
Frame-In Kit Install Type
2000P1 Non-IC
2002P1
Standard Non-IC 75W R20, PAR16
Flange
™
2003R Std. Non-IC Rem. 50W PAR20
2000IC IC
2000AIC
AirSeal ®
See 1300 Series Specification sheets.
1955 - For Installing in Existing Ceiling
1967C - Up to 2" thick ceiling
Lytecaster
Lamping Height Frame-In Kit Installation Type
40W A19** 2000LV
5 1/2"
2000LVR
5 1/2"
2000LVRE1 Remodeler Elec Low Voltage Non-IC
2000LVE1
2000LVE2
50W R20 PAR20 5 1/4"
45W PAR16 5 1/4"
2004ICV/N Lytening AirSeal
2000LVNT Low Voltage Remote Transformer
2000AICV
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • J0811
Recessed Downlighting
®
3 3/4" Aperture Step Baffle Reflector Trim
7 1/4"
2005/2004ICV/N
0
AirSeal
™
5 3/8"
2005/2000LVR
Remodeler Low Voltage
5 3/8"
2005/2000LVNT
Low Voltage Remote Transformer
Low Voltage
Standard Non-IC
Remodeler Non-IC
Electronic Low Voltage Non-IC 120V
Electronic Low Voltage Non-IC 277V
IC
®
Lytening AirSeal IC
®
Type:
2005
Insulated Ceiling
®
Lamping Height
5 3/8"
5 3/8"
5 3/8"
20W-50W MR16 5 3/8"
5 3/8"
5 3/8"
20W-42W MR16 5 3/8"
20W-35W MR16 7 5/16"
