Lightolier 4SB115 Specification

Decorative, Pendalux Suspension, Basic Canopy
45º
3
5
Complete Luminaire consists of Body and Suspension. Order each separately.
Short (Close to Ceiling) Single Stem Suspension, with Swivel, Basic Canopy.
Catalog No. Suggested Use w/Luminaire dia. Nominal Overall Length (A)*
4SB115PB 23" or 28"
4SB115SB 23" or 28"
4SB115SN 23" or 28"
23" or 28"
4SB115WH
4SB118PB 35"
4SB118SB 35"
4SB118SN 35"
4SB118WH 35"
4SB121PB 42"
4SB121SB 42"
4SB121SN 42"
4SB121WH 42"
*Add this length (A) to Body length (C) from Body Spec Sheet(s) to get Total Luminaire Nominal OAL.
4
8 ⅞"
8 ⅞"
8 ⅞"
8 ⅞"
10
15
10
15
10
15
10
15
11 ⅝"
11 ⅝"
11 ⅝"
11 ⅝"
4SB115
A
Body Diagram
⁄ "
16
⁄ "
16
⁄ "
16
⁄ "
16
Job Information
Job Name:
Cat. No.:
Notes:
(18) (21)
Nominal OAL
C
Suspension (Stem) and Canopy Finish
Polished Brass
Satin Brass
Satin Nickel
White
Polished Brass
Satin Brass
Satin Nickel
White
Polished Brass
Satin Brass
Satin Nickel
White
Type:
Page 1 of 2
